Page 1
Item
Model
ProjectName
Planetary mixers
601883
XBM40 with Hub
Universal 40 litre kitchen and
pastry making planetary mixer.
XBM40 is designed for restaurants,
pastry makers and catering
companies. It has a mechanical
range drive, with belt variator
system that protects against
overloading and makes the
machine extremely versatile.
FEATURES
V Powerful motor that provides all the
basic mixer functions faultlessly:
kneading of all sort of pastes, mixing of
semiliquid products, emulsions and
various sauces.
V With a 900 W rating, the XBM40 can
handle hard, low hydration kneadings
for speciality breads.
V The motor is sufficiently dimensioned
for all kitchen work.
V Body in non-corrosive material.
V 18/8 Stainless steel bowl - 3 tools:
flat hook, paddle and whisk.
V Splash proof planetary system to
avoid water from entering the
mechanism.
V Control panel equipped with 0-59
minute timer.
V Touch button control panel improves
the ergonomics and the reliability
against the humidity or water jets.
Page 2
Specifications
MODEL
XBMF40AS35
601883
XBMF40AS36
601886
Bowl Capacity lt 40 40
External dimensions - mm
width 670 670
depth 700 700
height 1380 1380
Working capacity - kg of flour
Choux pastry 6 6
Shortcrust pastry 10 10
Cold water paste 9 9
Sweet pastry 10 10
Croissant 8 8
Brioche 8 8
Meat kg 20 20
Puree - kg of potatoes 20 20
Power - kW
installed-electric 0.9 0.9
Net weight - kg. 113 113
Supply voltage 200...240/380...415,
3, 50
200...220/380...440
V, 3, 60
V Accessory drive hub for extra functions:
vegetable cutter, meat mincer, puree
strainer, sharpening grindstone.
V A kit of wheels is available as optional
accessory for easier movement.
V Adjustable feet for stability.
V Removable safety guard for easy
cleaning.
Page 3
Included accessories
CODE DESCRIPTION
XBMF40AS35
601883
XBMF40AS36
601886
653525 BOWL FOR 40LT MIXER 1 1
653523 DOUGH HOOK FOR 40LT MIXER 1 1
653524 PADDLE FOR 40LT MIXER 1 1
653522 WHISK FOR 40LT MIXER 1 1
Optional accessories
CODE DESCRIPTION
XBMF40AS35
601883
XBMF40AS36
601886
653534 20L BOWL,HOOK,PADDLE,WHISK FOR 40L
MIXER
✓ ✓
653525 BOWL FOR 40LT MIXER ✓ ✓
653585 BOWL TROLLEY-40/60/80LT PLANETARY
MIXERS
✓ ✓
653523 DOUGH HOOK FOR 40LT MIXER ✓ ✓
653431 ELECTRIC HEATING FOR 40L PLANETARY
MIXER
✓ ✓
653552 KIT WHEELS FOR (XB)20/30/40L PLAN.MIXERS ✓ ✓
653016 MEATMINCER 70MM-H
HUB-ENTERPR.CUT+3DISCS
✓ ✓
653524 PADDLE FOR 40LT MIXER ✓ ✓
653226 PLANETARY MIXER 10L-H
HUB-DISCONN.DRIVE
✓ ✓
653187 PUREE STRAINER FOR H HUB WITH 3 GRIDS ✓ ✓
653232 S/S MEATMINCER 82MM-H HUB-ENTERPR+1
DISC
✓ ✓
653062 SHARPENING GRINDSTONE FOR H HUB ✓ ✓
653225 VEGETAB.CUTTER H
HUB+EJECTOR-DISCONNECT.
✓ ✓
653015 VEGETABLE CUTTER H HUB WITH EJECTOR ✓ ✓
653522 WHISK FOR 40LT MIXER ✓ ✓
Page 4
ADAH020
www.dito-electrolux.com
Planetary mixers
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
Installation drawings
XXX
I - Electrical connection 200...240/380...415, 3,50200...220/380...440 V,
3, 60
MODEL
XBMF40AS35
601883
XBMF40AS36
601886
601883, 601886
1380
670
700
I
200
