Electrolux Dito XBMF20AST5, Dito XBMF20AT35, Dito XBMF20AST6, Dito XBMF20AT36, Dito 601850 Specifications

Item
Model
ProjectName

Planetary mixers

601850

XBM20 Table Model
with Hub

Powerful motor that provides all the basic
mixer functions faultlessly: kneading of all
sort of pastes, mixing of semiliquid
products, emulsions and various
sauces.The best results, in particular for
the mixing of pastries, is one of the key
features of DITO mixers.The increasing
speed facilitates the preparation of
mousses and emulsions by significantly
reducing the operation time.The easy and
precise speed regulation, highly
appreciated by the chefs, makes it a
versatile appliance suitable for preparing
various recipies.

FEATURES

V With a 750 W rating, the

XBM20 can handle hard, low
hydration kneadings for speciality
breads. Used with the
recommended quantities, it can
also be used to produce pizza
dough.

V Body in non-corrosive material.
V 18/8 Stainless steel bowl - 3

tools: hook, paddle and whisk.

V Accessory drive hub for extra

functions: vegetable cutter, meat
mincer, puree strainer,
sharpening grindstone.

V Revolving and dismountable

safety guard fitted with a
removable feeding arm for
adding products while the
machine is operating.

Specifications

MODEL

XBMF20AST5

601850

XBMF20AT35

601851

XBMF20AST6

601852

XBMF20AT36

601853

Bowl Capacity lt 20 20 20 20
External dimensions - mm
width 521 521 521 521
depth 685 685 685 685
height 1010 1010 1010 1010
Working capacity - kg of flour
Choux pastry 3 3 3 3
Shortcrust pastry 5 5 5 5
Cold water paste 6 6 6 6
Sweet pastry 4 4 4 4
Croissant 5 5 5 5
Brioche 5 5 5 5
Meat kg 10 10 10 10
Puree - kg of potatoes 10 10 10 10
Power - kW
installed-electric 0.75 0.75 0.75 0.75
Net weight - kg. 76 76 76 76
Supply voltage 220...240 V, 1N, 50 200...240/380...415,

3, 50

200...240 V, 1N, 60 200...220/380...440
, 3, 60

V Touch button control panel

improves the ergonomics and the
reliability against the humidity or
water jets.

V Control panel equipped with 0-59

minute timer.

V XBM20 is constructed in

compliance with EN 454 European
regulation on Beater-mixers safety
and hygiene.

Included accessories

CODE DESCRIPTION

XBMF20AST5

601850

XBMF20AT35

601851

XBMF20AST6

601852

XBMF20AT36

601853

653426 BOWL FOR 20LT MIXER 1 1 1 1
653114 DOUGH HOOK FOR 20LT

MIXER

1 1 1 1

653116 PADDLE FOR 20LT MIXER 1 1 1 1
653109 WHISK FOR 20LT MIXER 1 1 1 1

Optional accessories

CODE DESCRIPTION

XBMF20AST5

601850

XBMF20AT35

601851

XBMF20AST6

601852

XBMF20AT36

601853

653064 10L

BOWL,HOOK,PADDLE,WHISK
FOR 20L MIXER

✓ ✓ ✓ ✓

653426 BOWL FOR 20LT MIXER ✓ ✓ ✓ ✓
653114 DOUGH HOOK FOR 20LT

MIXER

✓ ✓ ✓ ✓

653016 MEATMINCER 70MM-H

HUB-ENTERPR.CUT+3DISCS

✓ ✓ ✓ ✓

653116 PADDLE FOR 20LT MIXER ✓ ✓ ✓ ✓
653226 PLANETARY MIXER 10L-H

HUB-DISCONN.DRIVE

✓ ✓ ✓ ✓

653187 PUREE STRAINER FOR H HUB

WITH 3 GRIDS

✓ ✓ ✓ ✓

653254 REINFORCED WHISK FOR

20LT MIXER

✓ ✓ ✓ ✓

653435 S/S DISH SHELF FOR 20L/30L

PLANET. MIXER

✓ ✓ ✓ ✓

653434 S/S TABLE FOR 20LT

PLANETARY MIXER

✓ ✓ ✓ ✓

653062 SHARPENING GRINDSTONE

FOR H HUB

✓ ✓ ✓ ✓

653225 VEGETAB.CUTTER H

HUB+EJECTOR-DISCONNECT.

✓ ✓ ✓ ✓

653015 VEGETABLE CUTTER H HUB

WITH EJECTOR

✓ ✓ ✓ ✓

653109 WHISK FOR 20LT MIXER ✓ ✓ ✓ ✓

ADAC020

www.dito-electrolux.com

Planetary mixers

The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.

Installation drawings

XXX

I - Electrical connection 220...240 V, 1N, 50 200...240/380...415,

3, 50

200...240 V, 1N, 60 200...220/380...440 ,
3, 60

MODEL

XBMF20AST5

601850

XBMF20AT35

601851

XBMF20AST6

601852

XBMF20AT36

601853

601850, 601853, 601852, 601851

1008

685

I

521

190
