Electrolux Dito 660071, Dito 660072, Dito LVA100, Dito LVA100D, Dito LVA100B Specifications
Page 1
Item
Model
ProjectName
Veg.washer/Spin dryer
660072
LVA100
This Dito washing and drying
machine presents all those
characteristics of efficiency,
functionality and hygiene which
makes it an essential component
on the modern kitchens. This
appliance is designed for the
efficient and safe treatment of
vegetables in the commercial
kitchen. It has been constructed on
the basis of rigorous technical
principles to guarantee
functionality, long term reliability
and efficient running costs.
FEATURES
V Bearing frame, external panelling, lid
and extractable basket all in 304 AISI
stainless steel and mounted on height
adjustable feets.
V Basket support in corrosion resistant
aluminium.
V Lid microswitch to prevent the
starting of the machine when the lid is
open.
V Electromagnectic device immediately
stops the machine when the lid is
opened during use.
V Very efficient and easy to clean
filtering system.
V Pressed well with rounded corners.
V 1 self cleaning cycle of the well.
V This model is endowed with a
cleansing container with detergent
liquid display and include sanitizing
doser kit.
Page 2
Specifications
MODEL
LVA100B
660072
LVA100D
660071
Well capacity - lt. 30 30
External dimensions - mm
width 700 700
depth 700 700
height 1000 1000
Loading capacity - kg.
light vegetables 2-3 2-3
heavy vegetables 6 6
Rotation speed - rpm 300 300
Power - kW
installed-electric 0.9 0.9
Net weight - kg. 82 82
Supply voltage 230 V, 1N, 50 230 V, 1N, 50
Programmable cycle times ✓
Optional accessories
CODE DESCRIPTION
LVA100B
660072
LVA100D
660071
921014 BASKET W/SMALL HOLES F.VEGETABLE
WASHER
✓ ✓
V Drainage solenoid valve for rapid
opening and closing to guarantee easy and
efficient well drainage.
V Water inlet solenoid valve for rapid fill of
the well.
V Manual and 3 automatic washing cycles
available.
V Cycle time can be set by the operator in
the model 660071.
V Possibility to regulate the washing water
power according to the type of product to
be treated and reducing damaging in
delicate vegetable during washing / drying
operations.
V IPX5 water protection.
Page 3
Installation drawings
XXX
I - Electrical connection 230 V, 1N, 50 230 V, 1N, 50
C - Water drain 40mm 40mm
B - Cold water inlet 3/4" 3/4"
MODEL
LVA100B
660072
LVA100D
660071
660072, 660071
I
C
B
C
I
B
LVA/100
Ø40
3/4'' M
35
46
604
46
120
82
220
700
755
86
564
46
349
80
49
1684
176
981
900
700
3/4'' F
3/4'' F
INLET PIPE
L=2.15m
L=1.15m
Ø40(int)
1500
MAX 290
Page 4
AGCA010
www.dito-electrolux.com
Veg.washer/Spin dryer
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
