Page 1
Item
Model
ProjectName
Food Processors
603295
K120
K120 two speed food processor
has a vertical spindle and is
designed for use in catering
kitchens and the food preparation
industry. This allows mixing and
mincing easily and fast which
preserves the texture and flavour
of the products.
FEATURES
V Lower housing made of aluminium with bead
blast finish.
V The transparent polycarbonate cover can be
removed without tools and is dishwasher safe.
V The motor drives the angled cutter of speeds
of 1500 and 3000 rpm.
V The speed of rotation allows all sorts of
preparations to be carried out in a matter of
seconds:
- Mincing meats (tartare, sausage meat, pâtés,
stuffing, mousses, etc.)
- Chopping condiments (parsley, garlic, onions,
shallots, spices, etc.).
- Preparation of mayonnaise, mashes, flavoured
butters, purées, compotes, etc.
- Liquidising frozen foodstuffs, fish soups with
shellfish, etc.
- Preparation of all types of pastry.
- Pastrywork (almond paste, sugared almonds,
half and half, etc.).
Page 2
Specifications
MODEL
K120F4
603295
K120F4SR
603296
External dimensions - mm
width 416 416
depth 680 680
height 517 517
Mincing capacity - kg/cycle
meats 5 5
Preparation mayonnaise/sauces - kg/cycle
mayonnaise 6 6
Power - kW
installed-electric 2.2 2.2
Net weight - kg. 58 58
Supply voltage 400...415 V, 3, 50 400...415 V, 3, 50
V The stainless steel bowl is supplied complete with
a leak resistant spout and has a transparent lid with
a watertight seal and a large central rotating shaft
that allows liquids to be mixed without overflowing.
V The spout allows products to be added in
mid-cycle without stopping the machine.
V The blades are angled and the base of the bowl is
conical to ensure consistent mixing every time.
V Operator safety is guaranteed by the presence of
a magnetic microswitch which stops the machine
whenever the lid or the bowl are not correctly
positioned.
V A safety device stops the machine from restarting
after a power cut until the operator presses the start
button.
V The touch control panel allows the entire machine
to be cleaned with a jet of water (IP66 water
protection).
Page 3
Included accessories
CODE DESCRIPTION
K120F4
603295
K120F4SR
603296
653270 11.5 LITRE S/S BOWL FOR CUTTER-MIXER 1 1
653299 SERRATED BLADE ROTOR -11.5L CUTTER-MIXER 1
653179 SMOOTH BLADE ROTOR FOR 11.5 CUTTER-MIXER 1
Optional accessories
CODE DESCRIPTION
K120F4
603295
K120F4SR
603296
653270 11.5 LITRE S/S BOWL FOR CUTTER-MIXER ✓ ✓
653277 EQUIPPED SCRAPER FOR 11.5L CUTTER-MIXER ✓ ✓
653017 S/S MOBILE STAND ✓ ✓
653299 SERRATED BLADE ROTOR -11.5L CUTTER-MIXER ✓ ✓
653538 SERRATED ROTOR-MEAT-11.5L CUTTER-MIXER ✓ ✓
653179 SMOOTH BLADE ROTOR FOR 11.5 CUTTER-MIXER ✓ ✓
Page 4
ABE010
www.dito-electrolux.com
Food Processors
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
Installation drawings
XXX
I - Electrical connection 400...415 V, 3, 50 400...415 V, 3, 50
MODEL
K120F4
603295
K120F4SR
603296
603295, 603296
I
I
416
505
1167
820
726
680
430
