Page 1
Item
Model
ProjectName
Meat Mincer/Grater
603539
MMG
The Dito Electrolux meat mincer/graters
are ideal for mincing meat for ragout,
hamburgers, meat balls, sausages as well
as for grating bread, cheese and nuts.
Their versatility makes them an essential
appliance for kitchens of any size.
FEATURES
V Constructed in polished aluminum
and steel with AISI 304 stainless steel
mincing unit, plate, self sharpening
knife, funnel and connection container.
V Micro switch positioned on the
handle prevents accidental contact.
V Easy to use control panel.
V Protection grill is positioned beneath
the grating cylinder to avoid accidental
contact.
V Provided with a helical (ventilated) oil
bath gear motor. The motor is protected
by a thermal fuse.
V The grinding unit can be easily
removed for simple cleaning.
Page 2
Specifications
MODEL
MMG12
603539
MMG22
603540
External dimensions - mm
width 270 280
depth 600 620
height 400 430
Electrical power - kW 0.75 1.1
Net weight - kg. 21 22
Supply voltage 400 V, 3N, 50 400 V, 3N, 50
Meat mincer
Productivity kg/h 150-200 250-300
Loading hopper dimensions mm 275 x 200 x 50 370 x 245 x 50
Collecting tray dimensions mm 235 x 196 x 50 310 x 235 x 50
Grater
Productivity kg/h - cheese 50 130
Productivity kg/h - bread 100 150
Collecting tray dimensions mm Ø 230 x h 100 Ø 230 x h 100
Outlet dimensions mm 95 x 145 x 75 95 x 145 x 75
V Model 603539 has a grater motor that
may run at up to 900 rpm and a meat
mincer motor may run at up to 140 rpm.
Model 603540 has a grater motor that may
run at up to 1.400 rpm and a meat mincer
motor may run at up to 210 rpm.
V Plate diameters of 70 mm for model
603539 and of 82 mm for model 603540.
V Stainless steel meat mincer loading
hopper and stainless steel collecting tray
included.
V Stainless steel perforated grating
cylinder (75 x 140 mm).
Page 3
AEBA010
www.dito-electrolux.com
Meat Mincer/Grater
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
Installation drawings
XXX
I - Electrical connection 400 V, 3N, 50 400 V, 3N, 50
MODEL
MMG12
603539
MMG22
603540
603539
270
400
600
603540
280
430
620
