ELECTROLUX CF85 User Manual

CaFamosa

Kaffee-Espresso-Vollautomat
Fully Automatic Espresso-Maker
Macchina per espresso completamente automatica
Volautomatische koffie- en espressomachine
Täysin automaattinen espressokahviasema

Gebrauchsanweisung
Operating instructions
Istruzioni per l’uso
Gebruiksaanwijzing
Käyttöohje

1

B

M

A

C

D

E

O

G

F

H

L

N

J

K

P

2

A
B

C
D

E

F

G
H

J
K

L

M

N

O

P

2

3

4

5

6

78

9/B 10

11 /B

12

9/A

11 /A

13

3

14 15/A

15/B

16/A

16/B

4

17

19/A 19/B

21

18/A

22

18/B

20

23

g

Features (Figure 1)

g

A Fresh Water Tank, Lid
B Filler Opening for Ground Coffee with

Lid

C Cup Rack
D Bean Container with Lid (inside: grind-

ing texture adjustment)

E Selector Dial for Steam and Hot Water
F Swivelling Nozzle for Steam and Hot

Water

G Height Adjustable Outlet
H Spouts
J Drip Grille
K Drip Catcher
L Spent Coffee Drawer with Spent Cof-

fee Container

M Float
N Rating Plate (on the underside of the

appliance)

O Controls and Indicators (see Figure 2)
P Measuring Spoon

Controls (Figure 2)

A Power Indicator: Illuminates when the

appliance is switched on

B Main Switch: Switches the appliance

on and off

C Indicator For 1 Cup of Strong Coffee
D Indicator For 1 Cup of Normal Coffee
E Button For 1 Cup of Coffee
F Button For 2 Cups of Coffee
G Indicator For Ground Coffee
H Button For Ground Coffee
J Indicator For “Flushing“
K Button For Flushing
L Indicator For “Cleaning“
M Indicator For “Descaling“
N Indicator For “Water Tank“
O Indicator For Emptying or Refitting The

“Drip Catcher and Spent Coffee Con­tainer“

P Selector Dial For Amount of Water per

Cup
Indicator illuminates:
Indicator flashes:

18

Dear customer,

Please read these operating instruc­tions through carefully. Above all,
observe the safety instructions! Please
keep these operating instructions for
later reference, and pass them on to
any subsequent owners of the appli­ance.

The form and function of your AEG
coffee machine guarantee you

• straightforward operation and

• excellent, individual taste

• with the easiest of maintenance and
care.
The excellent, individual taste is
achieved by

• The pre-brewing system: prior to the
actual brewing process, the ground
coffee is moistened to extract its full
aroma,

• The individually adjustable quantity of
water per cup that can be varied
between a small espresso and a large
“frothy“ coffee,

• The grinding texture that can be
adjusted to suit the roasting of the
beans,

• The facility to choose between normal
or strong coffee,

• And last but not least, through the
guaranteed crema, that small crown of
froth that makes an espresso incompa­rable for connoisseurs.
Incidentally: The time that the water is
in contact with the ground coffee is
considerably shorter for espressos than
for conventional filter coffee. As a
result, less bitterness is released from
the coffee, it is this that makes
espresso coffee so much pleasanter!

g

Table of Contents

Safety Instructions

1. Before Using for the First Time

1.1. Setting Up the Appliance

1.2. Cable Compartment (Figure 3)

1.3. Adjusting the Water Hardness

1.4. Adjusting the Safety Cut-Out

2. Prior to Making Coffee
Filling the Water Tank (Figure 4)

2.1.

2.2. Filling the Bean Container
(Figure 5)

2.3. Adjusting the Grinding Texture
(Figure 6)

2.4. Switching On the Appliance
(Figure 7)

2.5.

“Flushing“ the Appliance (Figure 8)

3. Making Coffee

3.1. Adjusting the Amount of Water
(Figure 9/B)

3.2. One Cup of Normal Coffee from
Beans (Figure 10)

3.3. One Cup of Strong Coffee from
Beans (Figure 11/A)

3.4. One Cup of Extra Strong Coffee
from Beans (Figure 11/B)

3.5. Two Cups of Normal Coffee
from Beans (Figure 12)

3.6. One or Two Cups of Coffee from
Ground Coffee (Figure 13, 14)

4. Frothing Milk (for Cappuccino)
(Figure 15, 16)

5. Preparing Hot Water (Figure 16)

6. Switching Off the Appliance

7. Emptying the Water Tank, Drip
Catcher and Spent Coffee Con­tainer (Figure 17, 18)

8. Cleaning
Exterior Cleaning (Figure 19, 20)

8.1.

8.2. Internal Cleaning: “Clean“ Indi­cator Illuminates (Figure 21)

9. Descaling the Appliance: “Des­cale“ Indicator Illuminates (Fig­ure 22, 23)

10. What to do if ...

11. Protecting the Environment

12. In the Case of Need for Service

1 Safety Instructions

• The appliance may only be connected
to a mains supply on which the volt­age, type of supply, and frequency
match the information given on the
rating plate (see underside of the
appliance)!

• Never allow children to operate the
appliance unsupervised.

• Never bring the mains lead into con­tact with the hot parts of the appli­ance.

• Never pull the plug from the socket by
means of the mains lead!

• Do not use the appliance if:
– the mains lead is damaged or

– the housing shows visible signs of

damage.

• The coffee outlet, swivelling nozzle,
and cup rack will become hot during
use due to the nature of their func­tions. Keep children away!

• Only fill the water tank with cold
water, do not use hot water, milk or
other liquids.

• Do not place frozen or caramelised
coffee beans in the bean container,
only use roasted coffee beans! Remove
any foreign bodies from the coffee
beans. Otherwise the guarantee will be
void.

• Only put ground coffee in the ground
coffee filler opening.

• Observe the cleaning and descaling
instructions.

• Prior to maintaining or cleaning,
switch off the appliance and unplug it
from the mains!

• Never immerse the appliance in water.

• Do not allow any liquid to enter the
housing via the ventilation holes on
the cup rack.

• Do not wash the parts of the appliance
in a dishwasher.

• Do not leave the appliance switched on
longer than necessary.

• Do not expose the appliance to the
weather.
