Page 1
B5705-5
User manual Built-In Electric Oven
Page 2
Contents2
Contents
Operating Instructions 3
Safety instructions 3
Description of the Appliance 4
General Overview 4
Control Panel 5
Oven Features 5
Oven accessories 6
Before Using for the first time 7
Setting and changing the time 7
Cleaning for the first time 8
Using the Oven 9
Switching the Oven On and Off 9
Rapid heat up 11
Oven Functions 11
Inserting accessories 12
Grilling set 13
Inserting/Removing the Fat Filter 13
Clock Functions 14
Other Functions 19
Uses, Tables and Tips 20
Baking 20
Roasting 27
Grill sizes 28
Defrosting 29
Drying 30
Making preserves 30
Cleaning and Care 31
Outside of the appliance 31
Oven interior 32
Accessories 32
Fat Filter 32
Oven lighting 32
Oven roof 33
Oven carriage door 34
Oven door glass 34
What to do if … 37
Disposal 38
Service 39
Thank you for choosing one of our high-quality products.
To ensure optimal and regular performance of your appliance please read this instruc-
tion manual carefully. It will enable you to navigate all processes perfectly and most ef-
ficiently.
To refer to this manual any time you need to, we recommend you to keep it in a safe
place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
The following symbols are used in this user manual:
1
Important information concerning your personal safety and information on how to
avoid damaging the appliance.
3 General information and tips
2 Environmental information
Page 3
3Operating Instructions
Operating Instructions
1 Safety instructions
Electrical safety
• This appliance must be only connected by a registered electrician.
• In the event of a fault or damage to the appliance: Take the fuses out or switch off.
• Repairs to the appliance must only be carried out by qualified service engineers.
Considerable danger may result from improper repairs. If repairs become necessary,
please contact our Customer Services or your dealer.
Child Safety
• Never leave children unsupervised when the appliance is in use.
Safety during use
• This appliance is not intended for use by children or other persons whose physical,
sensory or mental capabilities or lack of experience and knowledge prevents them
from using the appliance safely without supervision or instruction by a responsible
person to ensure that they can use the appliance safely.
• This appliance should be used only for normal domestic cooking, roasting and baking
of food.
• Be careful if connecting electrical appliances to sockets near to this appliance. Electrical leads must not be caught under the hot oven door.
• Warning: Risk of burns! The oven interior becomes hot during use.
• If you use ingredients containing alcohol in the oven, a slightly flammable mixture of
alcohol and air may ensue. In this case, be careful when opening the door. Do not
handle any sources of heat, sparks or naked flames when doing so.
3 Information on acrylamides
According to the latest scientific knowledge, intensive browning of food, especially in
products containing starch, can constitute a health risk due to acrylamides. Therefore we
recommend cooking at the lowest possible temperatures and not browning foods too
much.
How to avoid damage to the appliance
• Do not place aluminium foil over the floor of the oven and do not place baking trays,
pans etc. on the floor as the resulting build-up of heat can damage the oven enamel.
• Fruit juices which drip from baking trays leave stains which cannot be removed. Use a
deep tray for very moist cakes.
• Do not place loads on the open oven carriage door.
• Never pour water directly into the oven when it is hot. This could cause damage and
discoloration to the enamel.
• Rough handling, especially around the edges of the front panel, can cause the glass to
break.
• Do not store any flammable materials inside the oven. These could ignite when the
oven is switched on.
Page 4
Description of the Appliance4
• Do not store any moist foods inside the oven. This could cause damage to the enamel.
• After switching off the cooling fan, do not keep uncovered dishes in the oven. Mois-
ture may condense in the oven interior or on the glass doors and may get into the
units.
3 Note on enamel coating
Changes in the colour of the oven’s enamel coating as a result of use do not affect the
appliance’s suitability for normal and correct use. They therefore do not constitute a defect in the sense of the warranty law.
Description of the Appliance
General Overview
Oven carriage
door
Control panel
Door
handle
Page 5
5Description of the Appliance
Control Panel
Oven Features
Function buttons
Oven Functions
Temperature / Time Selection
Temperature / Time Display
Oven Power Indicator Oven Power Indicator
Top heat and heating elements
Oven lighting
Fat Filter
Fan heating element
Fan
Bottom Heat
Page 6
Description of the Appliance6
Oven levels
On the oven carriage door there are two racks
with five holes to insert accessories.
Inside of door
On the inside of the oven carriage door you
will find the numbers of the different oven
shelf levels
You will also find some brief information
about the ovens functions, recommended
shelves and temperatures for cooking the
most popular dishes.
Oven accessories
Rack
For cookware, cake tins, roasts and food to be
grilled.
Rack frame
For resting the baking tray and drip tray on.
Baking tray
For cakes and biscuits.
Page 7
7Before Using for the first time
Roasting Pan
For baking and roasting or as a pan for collecting fat.
Support shelf
Shelf for the drip pan for baking and grilling.
Before Using for the first time
Setting and changing the time
3 The oven only operates when the time has been set.
When the appliance has been connected to the
electrical supply or when there has been a power cut, the function indicator Time of
day flashes automatically.
1. To change a time that has already been set,
press the Selection button repeatedly until
the function indicator Time of day flashes.
2. Using the / control knob, set the current
time.
Page 8
Before Using for the first time8
After approx. 5 seconds, the flashing stops and
the clock displays the time of day set.
The appliance is now ready to use.
3 The time can only be modified, if the child safe-
ty device is deactivated, none of the Minute
Minder , Duration or End clock functions and no oven function is set.
Cleaning for the first time
Before you use the appliance for the first time, you should clean it thoroughly.
1 Important: Do not use sharp or abrasive cleaning materials. These could damage the
surface.
3 For metal fronts, use normal commercially available cleaning agents.
1. Open the oven carriage door. The oven light comes on.
2. Remove all accessories and clean with a warm solution of water and washing-up liquid.
3. Also wipe the oven out with a warm solution of water and washing-up liquid and then dry it.
4. Wipe the front of the appliance with a damp cloth.
Page 9
9Using the Oven
Using the Oven
3 The oven is equipped with retractable buttons for “Oven functions” and “Temperature
selection”. To use, press the relevant button. The button then sticks out.
Switching the Oven On and Off
Switching the oven on
Turn the oven functions selector to the desired
function. The power indicator light lights up.
The temperature display shows the suggested
temperature for the oven function selected.
The oven starts to heat up.
When the temperature set is reached, an audi-
ble signal sounds.
Changing the oven temperature
Turn the / knob to raise or lower the temperature.
The setting changes in 5 °C steps.
Temperature / Time
Display
Heat indicator
Speedcook
Oven Power Indicator
Oven Power Indicator
Page 10
Using the Oven10
Checking the temperature
Press Rapid heat up and Selection buttons at the same time.
The current oven temperature appears in the
temperature display.
Switching the oven off
To turn the oven off, turn the oven functions
selector to the OFF position.
3 Cooling fan
The fan switches on automatically in order to keep the appliance’s surfaces cool. When
the oven is switched off, the fan continues to run to cool the appliance down, then
switches itself off automatically.
3 Heat indicator
Indicates warming up
When the oven function has been switched on
the bars that slowly light up one after the other
indicate how far the oven has heated up.
Fast heat indicator
When the fast heat function has been
switched on the bars that flash one after
the other indicate that fast heat is operating. In
addition the bars next to the symbol light
up.
Page 11
11Using the Oven
Residual heat indicator
When the oven has been switched off, the bars
that are still lit indicate the remaining residual
heat in the oven.
Rapid heat up
After an oven function is selected, using the additional function Rapid heat up the
empty oven can be pre-heated in a relatively short time.
1 Important: Do not put the food to be cooked into the oven, until Rapid heat up is
completed and the oven is operating using the desired function.
1. Set the desired oven function (e. g., Conventional ). If necessary, change the suggested
temperature.
2. Press the Rapid heat up button. The bars next to the symbol light up.
When the bars flash one after another it shows that Rapid heat up is operating.
When the temperature set is reached, the bars of the heat indicator light up and the bars
next to the symbol go out. An audible signal sounds.
The oven now continues heating according to the pre-set oven function and tempera-
ture. You can now place the food in the oven.
3 The Rapid heat up function can be switched on with the oven functions True fan , Fan
baking , Conventional and Rotitherm .
Oven Functions
The oven has the following functions:
Oven function Application
True fan To bake on three oven levels maximum at the same time.
Decrease the oven temperatures (20-40 °C) compared with Conventional.
Fan baking For baking on one oven level dishes that require more intensive
browning and a crispy base.
Set the oven temperatures 20-40 °C lower than when using Conventional.
Conventional For baking and roasting on one oven level.
Rotitherm For roasting larger joints of meat or poultry on one level.
The function is also suitable for gratinating and browning.
Dual grill For grilling flat food items in large quantities and for toasting.
Single grill For grilling flat food items placed in the middle of the grill and for
toasting.
Page 12
Using the Oven12
Inserting accessories
Inside the oven carriage door there are five levels to insert accessories.
Inserting the side rails
Take the rack (1) and slide it into the oven level
you want. Push the rack down (2) until it clicks
into place.
3 Oven levels are counted from the bottom to
the top.
Inserting the baking tray or drip pan into
the rack frame:
Place the baking tray or drip pan on the rungs
of the rack frame.
3 Insert the baking tray or drip pan only by using
the rack frame.
Inserting the side rail and drip pan together:
If you want to use the rack and the drip pan together, first insert the drip pan on the rack
frame and then place the rack on the next level
up.
Defrost For defrosting e. g. flans and gateaux, butter, bread, fruit or other
frozen foods.
Base heat For baking cakes with crispy or crusty bases.
Oven function Application
Page 13
13Using the Oven
Grilling set
The grilling set includes the support shelf and the drip pan. The support shelf can be
used on either side.
1 Warning: Risk of burning when removing the drip pan from a hot oven.
Put the support shelf all the way in
The support shelf sits in the grease tray.
Place the drip pan in the oven carriage door at
the level you want.
3 For roasting larger pieces of meat or poultry on
one level.
Put the support shelf on a high level
Secure the support shelf with the edge of the
drip pan.
Place the drip pan in the oven carriage door at
the level you want.
3 For grilling flat foods in large quantities and for
toasting.
Inserting/Removing the Fat Filter
Only use the fat filter when roasting to protect
the rear heating elements from fat splashes.
Inserting the fat filter
Hold the fat filter by the grip and insert
the two mounts downwards into the
opening on the rear wall of the oven
(fan opening).
Taking out the fat filter
Hold the fat filter by the grip and unhook it.
Page 14
Using the Oven14
Clock Functions
Duration
To set how long the oven is to be in use.
End
To set the switch-off time for an oven function.
Minute Minder
To set a countdown. A signal sounds after the time has elapsed.
This function does not affect the functioning of the oven.
Time of day
To set, change or check the time
(See also section “Before Using for the First Time”).
3 How to use the clock functions
• After a clock function has been selected, the corresponding function indicator flashes
for about 5 seconds. During this period, the desired times can be set or modified using
the / dial.
• When the desired time has been set, the function indicator continues to flash for
approx. 5 seconds. After that the function indicator is then lit. The set time begins to
run in the background.
• When the clock functions Duration and End have been completed, the oven
functions dial must be turned back to ”0“.
• Using the Display button, you can switch between the oven temperature and the
time.
Temperature / Time Display
Change display
Clock function indicators
Selector Button
Page 15
15Using the Oven
3 Checking the time set or remaining.
Press the Selection button repeatedly, until the appropriate clock function flashes
and the time set or remaining is displayed.
Minute Minder
1. Press the Selection button repeatedly until
the function indicator Minute Minder flashes.
2. Using the / control knob set the desired
countdown (max. 99.00minutes).
The function indicator Minute Minder lights
up.
When 90% of the time set has elapsed, an audible signal sounds.
When the time has elapsed, ”0.00“ and the
function indicator flash.
An audible signal sounds.
To stop the flashing and the audible signal:
Press any button.
Page 16
Using the Oven16
Duration
1. Select the oven function and temperature.
2. Press the Selection button repeatedly until
the function indicator Duration flashes.
3. Using the / control knob set the desired
cooking time.
The function indicator Duration lights up
and the oven comes on immediately.
When the time has elapsed, ”0.00“ and the
function indicator flash.
An audible signal sounds for 2 minutes. The
oven switches itself off.
To stop the flashing and the audible signal:
Turn the oven functions dial to ”0”.
Page 17
17Using the Oven
End
1. Select the oven function and temperature.
2. Press the Selection button repeatedly until
the End function indicator flashes.
3. Using the / control knob set the desired
switch-off time.
The function indicator End lights up and
the oven comes on immediately.
When the time has elapsed, ”0.00“ and the
function indicator flash.
An audible signal sounds for 2 minutes. The ovenswitches itself off.
To stop the flashing and the audible signal:
Turn the oven functions dial to ”0”.
Page 18
Using the Oven18
Duration and End combined
3 Duration and End can be used simultaneously, if the oven is to be switched on
and off automatically at a later time.
1. Select the oven function and temperature.
2. Using the Duration function, set the time
that the dish needs to cook.
In this example, 1 hour.
3. Using the End function, set the time at
which the dish should be ready.
In this case, 14:05.
The Duration and End function indicators light up and the temperature is shown in
the display.
In this example, 200°C.
The oven switches on automatically at the time
calculated.
In this case, at 13:05.
And switches itself off again when the cook
time entered has elapsed.
In this case, at 14:05.
Page 19
19Using the Oven
Other Functions
Switching off the display
2 You can save energy by switching off the clock display.
Switching off the clock display
1. Turn the / control knob to the right and
hold it.
2. In addition press the Selection button until
the display goes out.
3 As soon as the appliance is switched on again,
the display comes on automatically.
When the appliance is next switched off, the
clock display goes out again.
To have the clock display on permanently again,
you must set the clock again.
Switching on the clock display
1. Turn the / control knob to the right and hold it.
2. In addition press the Selection button, until the display appears again.
Oven’s child safety device
The oven is fitted with a child safety device. As soon as the child safety device is activated, the oven cannot be switched on.
3 For the child safety device to be activated, none of the oven functions must be currently
selected.
Activating the child safety device
1. Turn the / dial to the left and hold it.
2. In addition press the Selection button until
“SAFE” appears ”in the“ display.
The child safety device is now activated.
Deactivating the child safety device
1. Turn the / dial to the left and hold it.
2. In addition press the Selection button until “SAFE” disappears ”from“ the display.
The child safety device is now deactivated and the oven is again ready for use.
Page 20
Uses, Tables and Tips20
Oven automatic cut-out
3 If not switched off after a certain time, or if the temperature is not modified, the oven
switches off automatically.
The last temperature set flashes in the temperature display.
The oven switches off when the oven temperature is:
Switching on after an automatic cut-out
Switch the oven off completely.
It can then be switched on again.
3 The automatic cut-out is cancelled if the clock function Duration or End is set.
Uses, Tables and Tips
Baking
Oven function: True fan or Conventional
Baking tins
• For Conventional , dark metal and non-stick tins are suitable.
• For True fan bright metal tins are also suitable.
Oven levels
• Baking with Conventional is possible on one oven level.
• With True fan you can bake on up to 3 baking trays at the same time:
1 baking tray:
e.g. oven level 3
30 - 120°C after 12.5 hours
120 - 200°C after 8.5 hours
200 - 250°C after 5.5 hours
250 - max°C after 3.0 hours
Page 21
21Uses, Tables and Tips
1 cake tin:
e.g. oven level 1
2 baking trays:
e.g. oven level 1 and 3
3 baking trays:
Oven levels 1, 3 and 5
General instructions
• Only use the baking tray and drip pan with the rack frame for the oven carriage.
• With Conventional or True fan you can also bake in two cake tins next to one
another on the oven shelf at the same time. This does not significantly increase the
baking time.
3 When frozen foods are used the trays inserted may distort during cooking. This is due to
the large difference in temperature between the freezing temperature and the temperature in the oven. Once the trays have cooled the distortion will disappear again.
Page 22
Uses, Tables and Tips22
Notes on the baking charts
The following charts give the required temperature settings, cooking times and oven levels for a selection of dishes.
• Temperatures and baking times are for guidance only, as these will depend on the
consistency of the mixture, the quantity and the type of baking tin.
• For the first time, we recommend you apply the lower temperature setting and only
choose a higher temperature if necessary, e.g. if you want a browner effect or if cooking time is taking too long.
• If you cannot find the settings for a particular recipe of your own, look for the one
that is most similar.
• When baking cakes on baking trays or in tins on more than one level, baking time can
be extended by 10-15 minutes.
• Moist products (pizzas, fruit flans, etc.) are baked on one level.
• Differences in the height of the items can cause differences in the degree of browning
at the beginning of the baking process. You should not change the temperature
setting if this occurs. Different rates of browning even out as baking progresses.
• Your new oven may bake or roast differently to your previous appliance. If this is the
case, adjust your normal settings (temperature, cooking times) and oven levels to the
recommendations in the following charts.
2 With longer baking times, you can switch the oven off about 10 minutes before the end
of the baking time, in order to utilise the residual heat.
Unless otherwise stated, the values given in the tables assume that cooking is started
with the oven cold.
Baking table
Baking on one oven level
Type of
baking
Oven function
Oven
level
Temperature
°C
Time
Hr: Mins.
Baking in tins
Ring cake or brioche True fan 1 150-160 0:50-1:10
Madeira cake/fruit cakes True fan 1 140-160 1:10-1:30
Sponge cake True fan 1 140 0:25-0:40
Sponge cake Conventional 1 160 0:25-0:40
Flan base - short pastry True fan 3 170-180
1)
0:10-0:25
Flan base - sponge mixture True fan 3 150-170 0:20-0:25
Apple pie Conventional 1 170-190 0:50-1:00
Apple pie (2tins Ø20cm,
diagonally off set)
True fan 1 160 1:10-1:30
Apple pie (2tins Ø20cm,
diagonally off set)
Conventional 1 180 1:10-1:30
Savoury flan (e. g, quiche
lorraine)
True fan 1 160-180 0:30-1:10
Page 23
23Uses, Tables and Tips
Cheesecake Conventional 1 170-190 1:00-1:30
Cakes/pastries/breads on baking trays
Plaited bread/bread crown Conventional 3 170-190 0:30-0:40
Christmas stollen Conventional 3 160-180
1)
0:40-1:00
Bread (rye bread)
-first of all
-then
Conventional 1
230
1)
160-180
0:25
0:30-1:00
Cream puffs/eclairs Conventional 3 160-170
1)
0:15-0:30
Swiss roll Conventional 3 180-200
1)
0:10-0:20
Cake with crumble topping
(dry)
True fan 3 150-160 0:20-0:40
Buttered almond cake/sugar
cakes
Conventional 3 190-210
1)
0:15-0:30
Fruit flans
(made with yeast dough/
sponge mixture)
2)
True fan 3 150 0:35-0:50
Fruit flans
(made with yeast dough/
sponge mixture)
2)
Conventional 3 170 0:35-0:50
Fruit flans made with short
pastry
True fan 3 160-170 0:40-1:20
Yeast cakes with delicate
toppings (e. g, quark, cream,
custard)
Conventional 3 160-180
1)
0:40-1:20
Pizza (with a lot of topping)
2)
True fan 1 180-200
1)
0:30-1:00
Pizza (thin crust) True fan 1 200-220
1)
0:10-0:25
Unleavened bread True fan 1 200-220 0:08-0:15
Tarts (CH) True fan 1 180-200 0:35-0:50
Biscuits
Short pastry biscuits True fan 3 150-160 0:06-0:20
Viennese whirls True fan 3 140 0:20-0:30
Viennese whirls Conventional 3 160
1)
0:20-0:30
Biscuits made with sponge
mixture
True fan 3 150-160 0:15-0:20
Pastries made with egg
white, meringues
True fan 3 80-100 2:00-2:30
Macaroons True fan 3 100-120 0:30-0:60
Type of
baking
Oven function
Oven
level
Temperature
°C
Time
Hr: Mins.
Page 24
Uses, Tables and Tips24
Baking on more than one oven level
Biscuits made with yeast
dough
True fan 3 150-160 0:20-0:40
Puff pastries True fan 3 170-180
1)
0:20-0:30
Rolls True fan 3 160
1)
0:20-0:35
Rolls Conventional 3 180
1)
0:20-0:35
Small cakes (20per tray) True fan 3 140
1)
0:20-0:30
Small cakes (20per tray) Conventional 3 170
1)
0:20-0:30
1) Pre-heat the oven
2) Use the drip tray or roasting tray
Type of baking
True fan True fan
Temperature
in °C
Time
Hours:
Mins.
Shelf positions from bottom
2 levels 3 levels
Cakes/pastries/breads on baking trays
Cream puffs/Eclairs 1/4 --- 160-180
1))
1) Pre-heat the oven
0:35-0:60
Dry streusel cake 1/3 --- 140-160 0:30-0:60
Biscuits/small cakes/pastries/rolls
Short pastry biscuits 1/3 1/3/5 150-160 0:15-0:35
Viennese whirls 1/3 1/3/5 140 0:20-0:60
Biscuits made with sponge
mixture
1/3 --- 160-170 0:25-0:40
Biscuits made with egg
white, meringues
1/3 --- 80-100 2:10-2:50
Macaroons 1/3 --- 100-120 0:40-1:20
Biscuits made with yeast
dough
1/3 --- 160-170 0:30-0:60
Puff pastries 1/3 --- 170-180
1)
0:30-0:50
Rolls 1/4 --- 160 0:30-0:55
Small cakes (20per tray) 1/4 --- 140
1)
0:25-0:40
Type of
baking
Oven function
Oven
level
Temperature
°C
Time
Hr: Mins.
Page 25
25Uses, Tables and Tips
Tips on Baking
Fan baking table
Baking results Possible cause Remedy
The cake is not browned
enough underneath
Wrong oven level Place cake lower
The cake sinks (becomes
soggy, lumpy, streaky)
Oven temperature too high Use a slightly lower setting
Baking time too short Set a longer baking time
Baking times cannot be reduced by setting higher temperatures
Too much liquid in the mixture Use less liquid.
Pay attention to mixing times,
especially if using mixing machines
Cake is too dry Oven temperature too low Set oven temperature higher.
Baking time too long Set a shorter baking time
Cake browns unevenly Oven temperature too high and
baking time too short
Set a lower oven temperature
and a longer baking time
Mixture is unevenly distributed Spread the mixture evenly on
the baking tray
Grease filter is inserted Take out the grease filter
Cake does not cook in the
baking time given
Temperature too low Use a slightly higher oven set-
ting
Grease filter is inserted Take out the grease filter
Type of baking Shelf position
Temperature
°C
Time
Hr: Mins.
Pizza (thin crust) 1 180 - 200
1)
20 - 30
Pizza (with a lot of topping) 1 180 - 200 20 - 30
Tarts 1 180 - 200 45 - 60
Spinach flan 1 160 -180 45 - 60
Quiche Lorraine 1 170 - 190 40 - 50
Quark flan, round 1 140 - 160 60 - 90
Quark flan on tray 1 140 - 160 50 - 60
Apple cake, covered 1 150 - 170 50 - 70
Vegetable pie 1 160 - 180 50 - 60
Unleavened bread 1 250 - 270
1)
10 - 20
Puff pastry flan 1 160 - 180
1)
40 - 50
Page 26
Uses, Tables and Tips26
Bakes and gratins table
Frozen ready meals table
Flammekuchen (Pizza-like dish
from Alsace)
1 250 - 270
1)
12 - 20
Piroggen (Russian version of calzone)
1 180 - 200
1)
15 - 25
1) Pre-heat the oven
Dish Oven function
Shelf
position
Temperature
°C
Time
Hours mins.
Pasta bake Conventional 1 180-200 0:45-1:00
Lasagne Conventional 1 180-200 0:25-0:40
Vegetables au gratin
1)
1) Pre-heat the oven
Rotitherm 1 160-170 0:15-0:30
Baguettes topped with
melted cheese
1)
Rotitherm 1 160-170 0:15-0:30
Sweet bakes Conventional 1 180-200 0:40-0:60
Fish bakes Conventional 1 180-200 0:30-1:00
Stuffed vegetables Rotitherm 1 160-170 0:30-1:00
Food to be
cooked
Oven function
Shelf
position
Temperature
°C
Time
Frozen pizza Conventional 3
as per manufac-
turer’s instruc-
tions
as per manufac-
turer’s instruc-
tions
Chips
1)
(300-600 g)
1) Comments: Turn chips 2 or 3 times during cooking
Rotitherm 3 200-220
as per manufac-
turer’s instruc-
tions
Baguettes Conventional 3
as per manufac-
turer’s instruc-
tions
as per manufac-
turer’s instruc-
tions
Fruit flans Conventional 3
as per manufac-
turer’s instruc-
tions
as per manufac-
turer’s instruc-
tions
Type of baking Shelf position
Temperature
°C
Time
Hr: Mins.
Page 27
27Uses, Tables and Tips
Roasting
Oven function: Conventional or Rotitherm
Roasting cookware
• Any heat-resistant ovenware is suitable to use for roasting (please follow the manufacturer's instructions).
• You can use the grill set for roasting
• For all lean meats, we recommend roasting these in a roasting tin or dish with a
lid. The meat will be more succulent.
• All types of meat that can be browned or have crackling, can be roasted in a roasting
tin without the lid.
3 Notes on the roasting chart
The information given in the following chart is for guidance only.
• We recommend using the oven to roast meat and fish only in quantities above 1kg.
• To prevent escaping meat juices or fat from burning on to the pan, we recommend
placing some liquid in the roasting cookware.
• If required, turn the roast (after 1/2 - 2/3 of the cooking time).
• Baste large roasts and poultry with basting stock a number of times during the cook-
ing time. This will give you a better result.
• You can switch the oven off about 10 minutes before the end of the roasting time, in
order to utilise the residual heat.
Roasting table
Type of meat Quantity Ovenfunction
Shelf
position
Tempera-
ture
°C
Time
Hours mins.
Beef
Pot roast 1-1.5 kg Conventional 1 200-250 2:00-2:30
Roast beef or fillet
per cm. of
thickness
- rare
per cm.
of thickness
Rotitherm 1 190-200
1)
0:05-0:06
- medium
per cm.
of thickness
Rotitherm 1 180-190 0:06-0:08
- well done
per cm.
of thickness
Rotitherm 1 170-180 0:08-0:10
Pork
Shoulder, neck, ham
joint
1-1.5 kg Rotitherm 1 160-180 1:30-2:00
Chop, spare rib 1-1.5 kg Rotitherm 1 170-180 1:00-1:30
Meat loaf 750 g-1 kg Rotitherm 1 160-170 0:45-1:00
Page 28
Uses, Tables and Tips28
Grill sizes
Oven function: Single grill or Dual grill with maximum temperature setting
1 Important: Always grill with the oven carriage door closed.
3 An empty oven should always be pre-heated with the grill functions for 5 minutes.
• Use the grilling set for grilling.
• The grilling times are guidelines.
• Grilling is particularly suitable for flat pieces of meat or fish.
Porkknuckle
(pre-cooked)
750 g-1 kg Rotitherm 1 150-170 1:30-2:00
Veal
Roast veal 1 kg Rotitherm 1 160-180 1:30-2:00
Knuckle of veal 1.5-2 kg Rotitherm 1 160-180 2:00-2:30
Lamb
Leg of lamb, roast
lamb
1-1.5 kg Rotitherm 1 150-170 1:15-2:00
Saddle of lamb 1-1.5 kg Rotitherm 1 160-180 1:00-1:30
Game
Saddle of hare, leg of
hare
up to 1 kg Conventional 3 220-250
1)
0:25-0:40
Saddle of venison 1.5-2 kg Conventional 1 210-220 1:15-1:45
Haunch of venison 1.5-2 kg Conventional 1 200-210 1:30-2:15
Poultry
Poultry portions
200-250g
each
Rotitherm 1 200-220 0:35-0:50
Half chicken
400-500g
each
Rotitherm 1 190-210 0:35-0:50
Chicken, poulard 1-1.5 kg Rotitherm 1 190-210 0:45-1:15
Duck 1.5-2 kg Rotitherm 1 180-200 1:15-1:45
Goose 3.5-5 kg Rotitherm 1 160-180 2:30-3:30
Turkey 2.5-3.5 kg Rotitherm 1 160-180 1:45-2:30
Turkey 4-6 kg Rotitherm 1 140-160 2:30-4:00
Fish (steamed)
Whole fish 1-1.5 kg Conventional 1 210-220 0:45-1:15
1) Pre-heat the oven
Type of meat Quantity Ovenfunction
Shelf
position
Tempera-
ture
°C
Time
Hours mins.
Page 29
29Uses, Tables and Tips
Grilling table
Defrosting
Oven function: Defrost (no temperature setting)
• Unwrap the food and place it on a plate on the oven shelf.
• Do not cover with a plate or bowl, as these can substantially lengthen the defrosting
time.
• For defrosting, place the shelf in the 1st oven level from the bottom.
Defrosting table
Food to be grilled Oven level
Grilling time
1st side 2nd side
Burgers 4 8-10 mins. 6-8 mins.
Pork fillet 4 10-12 mins. 6-10 mins.
Sausages 4 8-10 mins. 6-8 mins.
Fillet steaks, veal steaks 4 6-7 mins. 5-6 mins.
Fillet of beef, roast beef
(approx. 1 kg)
3 10-12 mins. 10-12 mins.
Toast
1)
1) Do not pre-heat
3 4-6 mins. 3-5 mins.
Toast with topping 3 6-8 mins. ---
Dish
Defrosting
time
mins.
Further
defrosting
time (mins.)
Comments
Chicken, 1000 g 100-140 20-30
Place the chicken on an upturned saucer
placed on a large plate
Turn halfway through
Meat, 1000 g 100-140 20-30 Turn halfway through
Meat, 500 g 90-120 20-30 Turn halfway through
Trout, 150g 25-35 10-15 ---
Strawberries, 300g 30-40 10-20 ---
Butter, 250g 30-40 10-15 ---
Cream, 2 x 200 g 80-100 10-15
Cream can also be whipped when still
slightly frozen in places
Gateau, 1400g 60 60 ---
Page 30
Uses, Tables and Tips30
Drying
Oven function: True fan
• Use oven shelves covered with greaseproof paper or baking parchment.
• You get a better result if you switch the oven off halfway through the drying time,
open the door and leave the oven to cool down overnight.
• After this, finish drying the food to be dried.
Making preserves
Oven function: Base heat
• For preserving, use only commercially available preserve jars of the same size.
• Jars with twist-off or bayonet type lids and metal tins are not suitable.
• When making preserves, the first shelf position from the bottom is the one most
used.
• Use the shelf for making preserves. There is enough room on this for up to six 1-litre
preserving jars.
• The jars should all be filled to the same level and clamped shut.
• Place the jars on the baking tray in such a way that they are not touching each other.
• Pour approx. 1/2 litre of water into the baking tray so that sufficient moisture is pro-
duced in the oven.
• As soon as the liquid starts to pearl in the first jars (after about 35-60 minutes with
1 litre jars), switch the oven off or reduce the temperature to 100°C (see table).
Food to be dried
Temperature in
°C
Oven level
Time in hours
(Guideline)
1 level 2 levels
Vegetables
Beans 60-70 3 1 / 4 6-8
Peppers (strips) 60-70 3 1 / 4 5-6
Vegetables for soup 60-70 3 1 / 4 5-6
Mushrooms 50-60 3 1 / 4 6-8
Herbs 40-50 3 1 / 4 2-3
Fruit
Plums 60-70 3 1 / 4 8-10
Apricots 60-70 3 1 / 4 8-10
Apple slices 60-70 3 1 / 4 6-8
Pears 60-70 3 1 / 4 6-9
Page 31
31Cleaning and Care
Preserves table
The times and temperatures for making preserves are for guidance only.
Cleaning and Care
1 Warning: Before cleaning, switch off the appliance and let it cool down.
Warning: For safety reasons, do not clean the appliance with steam jet or high-pressure
cleaning equipment.
Important: Do not use corrosive cleaners, sharp objects or stain removers.
Do not use abrasive substances or metal scrapers to clean the glass oven door, as this
could scratch the surface. This could cause the glass to shatter.
Outside of the appliance
• Wipe the front of the appliance with a soft cloth and a solution of hot water and
washing up liquid.
• For metal fronts, use normal commercially available cleaning agents.
• Please do not use scouring agents and abrasive sponges.
Preserve
Temperature
in°C
Cooking time until
simmering
in mins.
Continue to cook
at 100°C
in mins.
Soft fruit
Strawberries, blueberries, raspberries, ripe gooseberries
160-170 35-45 ---
Unripe gooseberries 160-170 35-45 10-15
Stone fruit
Pears, quinces, plums 160-170 35-45 10-15
Vegetables
Carrots
1)
1) Leave standing in oven when switched off
160-170 50-60 5-10
Cucumbers 160-170 50-60 ---
Mixed pickles 160-170 50-60 15
Kohlrabi, peas, asparagus 160-170 50-60 15-20
Page 32
Cleaning and Care32
Oven interior
Clean the appliance after each use. In this way, dirt is easier to clean off and is not allowed to burn on.
1. When the oven carriage door is opened, the oven lighting automatically switches itself
on.
2. After every use, wipe the oven with a solution of washing-up liquid and allow to dry.
3. Remove oven carriage door for cleaning.
3 Remove stubborn dirt with special oven cleaners.
1 Important: if using an oven cleaner spray, please follow the manufacturer's instructions
exactly.
Accessories
Rinse and dry all accessory parts thoroughly after every use. For easier cleaning, leave to
soak for a while.
Fat Filter
1. Clean the fat filter in hot water and washing up liquid or in the dishwasher.
2. Badly burned on soiling can be removed by boiling the filter in a little water to which 2-
3 tablespoonsful of dishwasher cleaner has been added.
Oven lighting
1 Warning: There is a danger of electric shock! Prior to changing the oven light bulb:
– Switch off the oven!
– Remove the fuses in the fuse box or switch off the circuit breaker.
3 Place a cloth on the oven floor to protect the oven light and glass cover.
Replacing the oven light bulb/cleaning the
glass cover
1. Remove the glass cover by turning it anti-
clockwise and then clean it.
2. If necessary:
Replace bulb with a 40 watt, 230 V, 300 °C
heat-resistant oven light bulb.
3. Refit the glass cover.
Page 33
33Cleaning and Care
Oven roof
To make cleaning the oven roof easier, the upper heating element can be folded down.
Folding down the heating element
1 Warning: Only fold down the heating element,
when the oven is switched off and there is no
longer a risk of burns!
1. Take hold of the heating element at the front
and pull it out forwards over the raised part on
the inner wall of the oven.
2. The heating element now folds down.
1 Important: Do not use force to press the heat-
ing element down! The heating element can
break off.
Fastening the heating element
1. Guide the heating element back to the oven
roof.
2. Pull the heating element forwards against the
spring pressure and guide over the raised part
of the inner wall of the oven.
3. Engage in the retaining bracket.
1 Important: The heating element must lie on
both sides above the raised part of the oven inner wall and be properly engaged.
Cleaning the oven roof
Page 34
Cleaning and Care34
Oven carriage door
The oven carriage door of your appliance can be taken off its hinges for cleaning.
Removing the oven carriage door
1. Pull the oven carriage out towards you.
2. Grasp the oven carriage door with both hands
at the sides.
3. Pull the oven carriage door vertically upwards
out of its guide rods.
1 Important: Do not pull the over carriage up
by the door handle.
3 Lay the oven carriage door with the outer side
facing downwards on a soft and level surface,
for example, a blanket, in order to prevent
scratches.
Inserting the oven carriage door
1. Hold the oven carriage door on the handle
side on both sides and with both hands. Place
the oven carriage door vertically downwards
onto its guide rods and let it slide down.
2. Close the oven carriage.
Oven door glass
The oven door is fitted with three panels of glass mounted one behind the other. The inner panels can be removed for cleaning.
3 Only remove the oven door glass panels when the door has been removed.
1 Important! Rough handling, especially around the edges of the front panel, can cause
the glass to break.
Removing the oven door glass
1. Remove the oven door and place on a soft, level surface with the handle facing down-
wards.
Page 35
35Cleaning and Care
2. Take hold of the door trim (B) on the upper
edge of the door at both sides and press inwards to release the clip seal. Then remove the
door trim.
3. Take hold of the side facing. Gently push towards the door handle. The facing is released
from the guide and can be removed. Remove
the facing on both sides.
4. Lift the oven door glass very slightly. Take
hold of the upper edge one after the other and
pull out of the guide.
Cleaning the oven door glass
Clean the door glass panels thoroughly with a solution of water and washing-up liquid.
Then dry them carefully.
Inserting the oven door glass
1. From above insert the door glass panels at an
angle into the door profile at the bottom edge
of the door and lower them one after the other.
3 Insert the smaller panel first, then the larger
panel.
Page 36
Cleaning and Care36
2. Insert the facing at the side of the door frame
so that both vents point towards the door
handle. Press the facing in and slide into place
starting from the door handle. The facing
snaps into place. Check the position again on
both sides.
3. Take hold of the door trim (B) at each side, position it on the inside edge of the door and
push the door trim (B) onto the upper edge of
the door
3 On the open side of the door trim (B) there is a
guide bar (C). This must be pushed between
the outer door panel and the guide bracket (D).
The clip lock (E) must be snapped in.
4. Replace the oven door.
Page 37
37What to do if …
What to do if …
If you are unable to remedy the problem by following the above suggestions,
please contact your local Service Force Centre.
1 Warning! Repairs to the appliance are only to be carried out by qualified service engi-
neers. Considerable danger to the user may result from improper repairs.
3 If the appliance has been operated incorrectly, the engineer's visit will be chargeable,
even during the warranty period.
3 Advice on cookers with metal fronts:
Because of the cold surface at the front of the cooker, opening the oven door during (or
just after) baking or roasting may cause the glass to steam up.
Problem Possible cause Remedy
The oven is not heating up. The oven has not been
switched on.
Switch oven on.
The clock has not been set. Set the current time on the
clock.
The required settings have not
been set.
Check the settings.
The oven’s automatic switchoff has been triggered
See Automatic switch-off
The fuse in the house’s electrical wiring (fuse box) has been
tripped.
Check the fuses. If the fuses trip
repeatedly, please call a qualified
electrician.
The oven lighting is not operating.
The oven light bulb is faulty. Replace oven light bulb.
A fault code that is not listed above appears in the
clock display
Electronic fault Switch the appliance off and on
again via the building’s fuse or
the safety switch in the fuse
box.
If it is displayed again, please
contact the Customer Care Department
Page 38
Disposal38
Disposal
2 Packaging material
The packaging materials are environmentally friendly and can be recycled. The plastic
components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the community waste disposal facilities.
2 Old appliance
The symbol
W on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this
product, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
1 Warning: So that the old appliance can no longer cause any danger, make it unusable
before disposing of it.
To do this, disconnect the appliance from the mains supply and remove the mains
cable from the appliance.
Page 39
39Service
Service
In the event of technical faults, please first check whether you can remedy the problem
yourself with the help of the operating instructions (section “What to do if…”).
If you were not able to remedy the problem yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we require the following information:
– Model description
– Product number (PNC)
– Serial number (S No.)
(for numbers see rating plate)
– Type of fault
– Any error messages displayed by the appliance
So that you have the necessary reference numbers from your appliance at hand, we recommend that you write them in here:
Model description: .....................................
PNC: .....................................
S No: .....................................
Page 40
www.electrolux.com
822 721 471-M-271108-01 Subject to change without notice
Loading...
