Open Cupboard Base - 24"

EMPower

Open Cupboard Base - 24"

169030 (A V24)EMPower Open Cupboard

Short Form Specification

Base, 24" wide

EMPower

NAME #

SIS #

AIA #

Main Features

•Unit to be installed below Electrolux top models.

•Constructed in Stainless steel with Scotch Brite finish.

•Right-angled side edges to allow flush fitting between

units.

•Supplied with 6" (150 mm) height adjustable, removable

legs.

•Unit may be installed on castors.

•Base compartment for storage of pots, pans, sheet pans,

etc.

•Included Accessories: 4 pins for connection to top units.

Optional Accessories

•Connection kit used to join open gas

burner ranges (169105, 169106, 169134,

169135), convection oven base (169110),
fryer (169109), pasta cooker (169123) and
open cupboards (169028 – 169031).
Cannot be used for refrigerated bases
and static oven base.

•EMPower kit of 2 side supports for shelf

grids for 24" and 36" open cupboard
bases

•EMPower shelf grid for 24" open

cupboard base

•Portioning Shelf 12" PNC 169173 ❑

•Portioning Shelf 16" PNC 16917 4 ❑

•Portioning Shelf 24" PNC 169175 ❑

•Kit of 4 wheels (2 swivelling with brake)

for open gas burner ranges, convection
oven bases, fryers, pasta cookers and
EMPower open cupboards

PNC 169041 ❑

PNC 169089

❑

PNC 169091 ❑

PNC 206135

❑

Item No.

EMPower unit to be Electrolux Open Cupboard 24" (610 mm).
EMPower unit to be installed below Electrolux top EMPower
units. Construction in Stainless Steel. Right-angled side edges
to allow flush fitting between EMPower units. Supplied with 6"
(150 mm) height adjustable, removable legs. EMPower unit
may be installed on castors.

APPROV AL:

Electrolux Professional, Inc.

www.electroluxusa.com/professional

10200 David T aylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401

Open Cupboard Base - 24"

EMPower

EMPower

Open Cupboard Base - 24"

Front

Key Information:

External dimensions, Width:

169030 (A V24)24 1/32" (610 mm)
External dimensions, Depth:29 15/16" (7 60 mm)
External dimensions, Height:26 11/16" (678 mm)
Net weight:44 lbs (20 kg)
Shipping width:26 " (660 mm)
Shipping depth:35 7 /16" (900 mm)
Shipping height:34 1/4" (870 mm)
Shipping weight:55 lbs (25 kg)
Shipping volume:18.25 ft³ (0.52 m³)

Top

Side

Open Cupboard Base - 24"

The company reserves the right to make modifications to the products

without prior notice. All information correct at time of printing.

EMPower

2016.07 .21
