Electrolux HD-Line

Digital freezers 1400 lt

The Electrolux HD-Line offers one of the most comprehensive choices of refrigerated storage cabinets
available. Constructed internally and externally in stainless steel, operating over refrigeration or freezer
temperature ranges, with solid or glass doors, and in a choice of either 650 or 1400 liter capacity. The freezer
model detailed on this sheet has a capacity of 1400 liters.

EASY TO INSTALL

• Mounted on adjustable stainless
steel feet, with castors available as
an option.

• Choice of doors to suit varying
kitchen requirements.

• Operating temperature that can
be adjusted from -15 °C to -24 °C.

• Suitable for ambient
temperatures up to +43 °C.

EASY TO CLEAN

• Constructed from the highest
quality AISI 304 stainless steel
with radiused corners to the
interior base, which is pressed
from a single sheet.

• Evaporator unit is inset into the
top of the refrigerated chamber to
provide an obstruction free interior.

728425

EASY TO USE

• Forced air circulation for rapid
cool down and even temperature
uniformity.

• Accommodates GN 2/1
containers or shelves on anti-tilt
runners.

• External temperature display.

• Interior light.

• Lockable door.

Electrolux HD-Line

Digital freezers 1400 lt

EASY TO MAINTAIN

• Heavy-duty construction that
avoids use of any plastic parts.

• Single refrigeration unit
(compressor, condenser and
evaporator) that can be removed
in a single piece from either the
top or back.

• Evaporator cover is easily
removable for maintenance.

EASY ON THE ENVIRONMENT

• 20% reduction in energy
consumption compared to
previous models.

• Cabinet fitted with up to 75 mm
thickness of cyclopentane
insulation for best insulating
performance with 100%
environmental protection.

• Refrigerant type: R404a.

• CFC and HCFC free.

• All models comply with the
standards required by the main
international approval bodies and
are H marked.

RH14FD2F

728425

TECHNICAL DATA

Operating temperature - min/max °C -24/-15
Operating mode Ventilated
External material
panels 304 AISI
Gross capacity (D.I.N. 8952) - l. 1400
Cooling unit Built-In
Control type Digital
External dimensions - mm
width 1500
depth/with open doors 810, 1463
height 2050
N° and type of door 2
Door hinges 1 Left+1 Right
N° and type of grids (included) 8, GN 2/1
Compressor power - HP 1
N° defrost in 24 hrs. 4/28'
Refrigerant type R404a
Refrigerant quantity - g. 400
Refrigeration power - W 1150
Refrigerant power
at evaporation temperature - °C -34
Power - kW
installed-electric 0.96
Net weight - kg. 248

HAB0502009-10-20Subject to change without notice
