ElectrIQ SILENT 12 User Manual

Page 1 of 13

SILENT 12

PORTABLE AIR CONDITIONER

USER MANUAL

Thank you for choosing ElectriQ

Please read this user manual before using this innovative Air Conditioner and keep it

safe for future reference.

Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals

Page 2 of 13

SAFETY INSTRUCTIONS 3

FEATURES AND PARTS LIST 4

INSTALLATION 5

OPERATION AND SETTINGS 7

WATER-DRAINAGE 9

MAINTENANCE 10

TROUBLESHOOTING 11

APPENDIX 12

TECHNICAL DATA 12

Page 3 of 13

SAFETY INSTRUCTIONS

Important!

• Carefully read the instructions before operating the unit

• This appliance is for indoor use only.

• Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.

• Installation must be in accordance with regulations of the country where the unit is used.

• If you are in any doubt about the suitability of your electrical supply have it checked and, if

necessary, modified by a qualified electrician.

• This air conditioner has been tested and is safe to use. However, as with any electrical
appliances - use it with care.

• Disconnect the power plug from socket before dismantling, assembling or cleaning.

• Avoid touching any moving parts of the appliance.

• Never insert fingers, pencils or any other objects though the guard

• This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities. It is also not intended for use by those with a lack of
experience and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
Do not leave children unsupervised with this appliance.

• Do not clean the unit by spraying it or immersing it in water.

• Never connect the unit to an electrical outlet using an extension cord. If an outlet is not

available, one should be installed by a qualified electrician.

• Never operate this appliance if the cord or plug is damaged. Ensure the power cord is not
stretched or exposed to sharp object/edges.

• A damaged supply cord should be replaced by the manufacturer or a qualified electrician in
order to avoid a hazard.

• Any service other than regular cleaning or filter replacement should be performed by an
authorized service representative. Failure to comply could result in a voided warranty.

• Do not use the appliance for any other purposes than its intended use.

• The air conditioner unit must always be stored and transported upright, otherwise
irreparable damage may be caused to the compressor; if in doubt we suggest waiting
at least 24 hours before starting the unit.

• Avoid restarting the air conditioning unit unless 3 minutes have passed since being turned off.
This prevents damage to the compressor.

• Never use the mains plug as a switch to start and turn off the air conditioning unit. Use the
provided ON/OFF switch located on the control panel.

• Always place the unit on a dry and stable surface.

• The appliance should not be installed in laundry or wet rooms

Energy Saving and Unit Safety Protection Tips

• Do not cover or restrict the airflow from the outlet or inlet grills.

• For maximum performance the minimum distance from a wall or objects should be 50cm.

• Keep the filters clean. Under normal conditions, filters should only need cleaning once every

three weeks (approximately). Since the filters remove airborne particles, more frequent
cleaning maybe necessary, depending on the air quality.

• For the initial startup set the fan speed to maximum and the thermostat to 4-5 degrees lower
than the current temperature. After, set the fan switch to low and set the thermostat to your
desired setting.

• To protect the unit we recommend not using the cooling function when the ambient temperature
is higher than 35℃.

Page 4 of 13

FEATURES AND PARTS LIST

1. Features

- Self-evaporative system - no external water tank needed

- Designer inspired luxury model

- LED screen, indicates temperature and operation mode

- On/Off timer function – allows you to choose when the unit operates

- Compressor protection technology

2. Parts list:
