ElectrIQ P12C-V2 User Manual
USER MANUAL
12,000 BTU PORTABLE AIR CONDITIONER
P12C-V2
Thank you for choosing electriQ
Please read this user manual before using this innovative Air Conditioner and
keep it safe for future reference.
Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals
Page 2 of 15
CONTENTS
SAFETY INSTRUCTIONS
3
FEATURES
5
DIAGRAM AND ACCESSORIES
6
INSTALLATION
7
OPERATION
9
REMOTE CONTROL
11
WATER-DRAINAGE
11
MAINTENANCE
12
TROUBLESHOOTING
13
TECHNICAL DATA
14
SUPPORT
15
Page 3 of 15
SAFETY INSTRUCTIONS
Important!
Carefully read the instructions before operating the unit
This appliance is for indoor use only.
Rating: This unit must be only connected to a 220-240 V
/ 50 Hz earthed outlet.
Installation must be in accordance with regulations of the
country where the unit is used.
If you are in any doubt about the suitability of your electrical supply have it
checked and, if necessary, modified by a qualified electrician.
This air conditioner has been tested and is safe to use. However, as with any
electrical appliance - use it with care.
Disconnect the power plug from socket before dismantling, assembling or
cleaning.
Avoid touching any moving parts within the appliance.
Never insert fingers, pencils or any other objects though the guard
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Do not leave children unsupervised with this appliance.
Do not clean the unit by spraying it or immersing it in water.
Never connect the unit to an electrical outlet using an extension cord. If an outlet
is not available, one should be installed by a qualified electrician.
Never operate this appliance if the cord or plug is damaged. Ensure the power
cord is not stretched or exposed to sharp objects/edges.
The power cord must not be immersed in water, as this could result in electric
shock.
A damaged supply cord should be replaced by the manufacturer or a qualified
electrician in order to avoid a hazard.
Any service other than regular cleaning or filter replacement should be
performed by an authorized service representative. Failure to comply could
result in a voided warranty.
When defrosting and cleaning the appliance, only use tools recommended by
the manufacturer.
Do not use the appliance for any other purpose than its intended use.
The air conditioner unit must always be stored and transported upright,
otherwise irreparable damage may be caused to the compressor; if in
doubt we suggest waiting at least 24 hours before starting the unit.
Avoid restarting the air conditioning unit unless 3 minutes have passed since
being turned off. This prevents damage to the compressor.
Page 4 of 15
Never use the mains plug or an external timer as a
switch to start and stop the air conditioning unit. Use
the provided ON/OFF button located on the control
panel.
Always place the unit on a dry and stable surface.
The appliance should not be installed in laundry or wet
rooms
The appliance must be placed in a room without
sources of ignition (for example: open flames, an
operating gas appliance or an operating electric heater).
R290 refrigerant gas complies with European
environmental directives.
R290 has a low GWP (Global Warming Potential) of 3.
The air conditioner contains about 215 g of R290 refrigerant gas.
Do not use or store in an unventilated space with an area smaller than 10.3m
2
per
unit. The room must be such as to prevent stagnation of possible leaks of
refrigerant gas as there could be a danger of fire or explosion hazard should the
refrigerant come into contact with electric heaters, stoves or other sources of
ignition.
If the appliance is installed, used or stored in an unventilated room, the room must
be such as to prevent stagnation of possible leaks of refrigerant gas as there could
be a danger of fire or explosion should the refrigerant come into contact with
electric heaters, stoves or other sources of ignition.
Refrigerant gas may be odourless.
Do not use the product and contact the retailer for advice, if damage has occurred
to the unit which may have compromised the refrigerant system.
Any repairs or maintenance must only be carried out on the unit by a suitably
qualified engineer. Before opening and servicing the unit the authorized
engineer must be in possession of a copy of the manufacturer’s service manual
and must follow the safety information contained within it to ensure all hazards are
minimized.
The refrigerant system should not be perforated or punctured.
Energy Saving and Unit Safety Protection Tips
Do not cover or restrict the airflow from the outlet or inlet grills.
For maximum performance the air conditioner should be situated at least 50cm
from the walls or other objects.
Keep the filters clean. Under normal conditions, filters should only need
cleaning once every three weeks (approximately). Since the filters remove
airborne particles, more frequent cleaning maybe necessary, depending on the
air quality.
For the initial start-up set the fan speed to maximum and the thermostat to 4-5
degrees lower than the current temperature. After, set the fan switch to low and
set the thermostat to your desired setting.
To protect the unit we recommend the unit should only be used when the room
temperature is between 7°C and 35°C. If the temperature is below this use
electrical heating to raise the temperature above 10⁰C before starting the unit.
FEATURES
FEATURES
Self-evaporative system - no external water tank needed
Powerful but compact
Hidden display on front of the unit
Enhanced design with hot air outlet positioned higher – this allows for improved
performance with the use of a short hose
24 hour programmable timer function – allows you to choose when the unit operates.
2 speed fan, Low and High for best balance
maximum airflow
Compressor protection technology
between quiet operation and
Page 5 of 15
