electriQ ECOSILENT8, ECOSILENT8E, ECOSILENT10E, ECOSILENT10 User Manual
USER MANUAL
electriQ PORTABLE AIR CONDITIONER
ECOSILENT8
ECOSILENT8E
ECOSILENT10
ECOSILENT10E
8,000 BTU
10,000 BTU
Thank you for choosing electriQ
Please read this user manual before using this innovative Air Conditioner and keep it
safe for future reference.
Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals
CONTENTS
SAFETY
FEATURES AND PARTS LIST
INS TALL ATION
OPER ATION
REMOTE CONTROL
CLEANING AND MAINTENANCE
EMPTYING THE INTERNAL WATER TANK
3
5
6
8
9
10
11
TROUBLESHOOTING
ERROR CODES
SUPPORT
TECHNICAL SPECIFICATION
12
12
13
14
2
SAFETY INSTRUCTIONS
Important!
• Carefully read the instructions before operating the unit
• This appliance is for indoor use only.
• Rating: This unit must be only connected to a 220-240 V / 50 Hz
earthed outlet.
• Installation must be in accordance with regulations of the country where the unit is
used.
• If you are in any doubt about the suitability of your electrical supply have it checked
and, if necessary, modied by a qualied electrician.
• This air conditioner has been tested and is safe to use. However, as with any electrical
appliance - use it with care.
• Disconnect the power from the appliance before dismantling, assembling or cleaning.
• Avoid touching any moving parts of the appliance.
• Never insert ngers, pencils or any other objects though the guard
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities. It is also not intended for use by those with a
lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their
safet y.
• Do not leave children unsupervised with this appliance.
• Do not clean the unit by spraying it or immersing it in water.
• Never connect the unit to an electrical outlet using an extension cord. If an outlet is
not available, one should be installed by a qualied electrician.
• Never operate this appliance if the cord or plug is damaged. Ensure the power cord is
not stretched or exposed to sharp objects/edges.
• A damaged supply cord should be replaced by the manufacturer or a qualied
electrician in order to avoid a hazard.
• Any service other than regular cleaning or lter replacement should be performed by
an authorised service representative. Failure to comply could result in a voided
warranty.
• Do not use the appliance for any purpose other than its intended use.
• The air conditioner unit must always be stored and transported upright, otherwise
irreparable damage may be caused to the compressor; if in doubt we suggest waiting
at least 24 hours before starting the unit.
• Avoid restarting the air conditioning unit unless 3 minutes have passed since being
turned off. This prevents damage to the compressor.
• Never use the mains plug as a switch to start and turn off the air conditioning unit. Use
the provided ON/OFF button located on the control panel.
• Always place the unit on a dry and stable surface.
• The appliance should not be installed in laundry or wet rooms.
32
• The appliance must be placed in a room without sources of ignition (for example: open
ames, an operating gas appliance or an operating electric heater).
• R290 refrigerant gas complies with European environmental directives.
• R290 has a low GWP (Global Warming Potential) of 3.
• The ECOSILENT8 / 8E contains about 220 g of R290 refrigerant gas.
• The ECOSILENT10 / 10E contains about 280 g of R290 refrigerant gas.
• Do not use or store in an unventilated space with an area smaller than 10.6 m2 per unit
(ECOSILENT8 / 8E) or 13.4 m2 per unit (ECOSILENT10 / 10E).
• The room must be such as to prevent stagnation of possible leaks of refrigerant gas as
there could be a danger of re or explosion should the refrigerant come into contact
with electric heaters, stoves or other sources of ignition.
• Refrigerant gas may be odourless.
• Do not use the product and contact the retailer for advice, if damage has occurred to
the unit which may have compromised the refrigerant system.
• Any repairs or maintenance must only be carried out on the unit by a suitably qualied
engineer. Before opening and servicing the unit the authorised engineer must be in
possession of a copy of the manufacturer’s service manual and must follow the safety
information contained within it to ensure all hazards are minimized.
• The refrigerant system should not be perforated or punctured.
Energy Saving and Unit Safety Protection Tips
• Do not cover or restrict the airow from the outlet or inlet grills.
• For maximum performance the minimum distance from a wall or objects should be
50cm.
• Keep the lters clean. Under normal conditions, lters should only need cleaning once
every three weeks (approximately). Since the lters remove airborne particles, more
frequent cleaning maybe necessary, depending on the air quality.
• For the initial start-up set the fan speed to maximum and the thermostat to 5 degrees
lower than the current room temperature. After, set appliance to your desired
settings.
• To protect the unit, we recommend not using the cooling function when the ambient
temperature is higher than 35oC.
4
FEATURES AND PARTS LIST
FE ATURE S
• 3 in 1 Cooling, Fan, Dehumidier great for Rooms up to 20 sqm.
• 5 speed DC fan: balancing quiet operation with performance.
• SmartCool Logic for Improved Energy Efciency.
• 24 Hours Start / Stop Timer
• Digital Thermostat.
• Remote Control.
• Castors and Handles for Enhanced Portability.
• Auto-Restart to retain the settings in the event of power failure.
PART LIST
Control Panel
Louvres
Front Cover
Castors
Upper Air Inlet
Exhaust Outlet
Lower Air Inlet
Power Cable
Top Cov er
Rear Housing
Carry Handle
Exhaust Hose Window Slide Bar
54
