Elcometer 212
English
R
This product meets the Electromagnetic Compatibility Directive. The product is Class B, Group 1
ISM equipment according to CISPR 11.
R
CONTENTS
Section Page
1 About your thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Instrument Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Replacing the batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Taking a reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Error Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
R
Thank you for your purchase of this Elcometer 212 Digital Pocket Thermometer. Welcome to Elcometer.
Elcometer are world leaders in the design, manufacture and supply of inspectio n equipment for coatings
and concrete. Our products cover all aspects of coating inspection, from development th rough application
to post application inspection.
Your Elcometer 212 Digital Pocket Thermometer is a world beating product. With the purchase of this
product you now have access to the worldwide service and support network of Elcometer. For more
information visit our website at www.elcometer.com
1 ABOUT YOUR THERMOMETER
R
2 INSTRUMENT SET-UP
This instrument has four user selectable functions
(switch bank). This block is composed of four slide
switches and a single push button which is located
under the battery compartment.
2.1 UNITS : SWITCH 1
Changes the instrument’s units between Celsius (°C)
R
With the switch away from the battery the instrument enters into ‘Reading Trim Mode’ and the current offset
value is displayed. Use the push button to adjust the offset value around a scroll loop (±2 .0°C or ±3.6°F).
To exit ‘Reading Trim Mode’ set switch 4 back towards the battery.
3 REPLACING THE BATTERIES
The thermometer is supplied with batteries fitted. Replace the batteries when the battery symbol illuminates.
The instrument continues to measure accurately whilst in this condition but we recommend that the batteries
be changed at the earliest convenience.
After some further usage the instrument will detect that there is insufficient
R
4 TAKING A READING
The thermometer is switched on by unfolding the probe until the display illuminates. The probe must not be
rotated more than 180 degrees as damage may occur.
Apply the probe tip to the surface or material to be measured. The sensor is located at the top of the probe,
therefore the minimum depth insert should be 3mm (0.12”). The reading will take a few seconds to stabilise
depending on the nature of the material.
If auto-off is enabled (see “Instrument Set-up” on page 3) the thermometer automatically switches itself off
after 10 minutes to conserve battery power. To switch it back on simply fold back the probe and unfold it
R
6 STORAGE
This gauge incorporates a Liquid Crystal Display. If the display is heated above 50°C (120°F) it may
be damaged. This can happen if the gauge is left in a car parked in strong sunlight.
7 MAINTENANCE
The Elcometer 212 Digital Pocket Thermometer is designed to give many years reliable service under
normal operating and storage conditions.
The thermometer does not contain any user-replaceable components. In the unlikely event of a fault, your
R
8 TECHNICAL SPECIFICATION
Measurement Range: -49.9°C to +299.9°C (or -58°F to +572°F - user selectable)
Resolution: 0.1°C/°F (or 1°C/1°F - user selectable)
Accuracy: ±.0.4°C (-49.9 to ±199.9°C) ±1°C (+200 to 299.9°C)
Probe: K-type Thermocouple
Battery: 2 x 3 volt CR2032 lithium coin cell
Battery Life: 1500 hours
R
9 RELATED EQUIPMENT
In addition to the Elcometer 212 Digital Pocket Thermometer, Elcometer produces a wide range of
environmental measuring equipment and other equipment for measuring the characteristics of surface
coatings. Users of the Elcometer 212 Digital Pocket Thermometer may also benefit from the following
Elcometer products:
• Elcometer 214 Infrared Digital Thermometer
• Elcometer 214L Infrared Digital Thermometer with Laser alignment
• Elcometer 213 Digital Thermometer with replaceable K-type probe
