Elation Light Copilot II User Manual

LIGHT COPILOT II

 

UserInstructions

 (Rev1.024-004-1264)

E-mail: info@ elationlighting.com

Internet: http://www.elationlighting.com

2

1 Introduction

Thank you for your purchase of the LIGHT COPILOT II.

The LIGHT COPILOT II is a lighting controller, which can be used together with the LC-8SP relay
pack. The LIGHT COPILOT II has a total of 16 Channel outputs available for your convenience.
AUDIO and CHASE controls are also available in this unit. A built-in microphone is provided for
easy audio control. The “LATCH” function can override the chase function to keep an individual
channel “on”, while the other channels continue their chase sequence normally. There are 16
built-in programs for chasing effects, which can be operated, in MANUAL mode or in AUTO
mode. This user manual contains important information for you the user, please read it carefully
before use.

Warning

• Keep the unit dry, do not expose it to water or high levels of humid.

• Reduce the risk of electric shock or fire during operation.

• Do not attempt to dismantle or modify the unit.

• Do not make any inflammable liquids, water or metal objects enter the unit.

• No user serviceable parts inside, always consult qualified personnel for repairs.

• Turn off the power if not using this unit for a long period.

• This product can be used by adults only, do not allow children to play with it.

Customer Support: Elation Professional® provides a customer support line, to provide
set up help and to answer any question should you encounter problems during your set
up or initial operation. You may also visit us on the web at www.elationlighting.com for
any comments or suggestions. For service related issue please contact Elation
Professional®. Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m. Pacific
Standard Time.

Voice: [phone]
Fax: [phone]
E-mail: [e-mail]

Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this
unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not attempt any

repairs yourself, doing so will void your manufactures warranty.

Please do not discard the shipping carton in the trash. Please recycle when ever
possible.

3

Safety Warnings!

• To reduce the risk of electrical shock or fire, do not expose this unit to rain or
moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break off the ground prong from the electrical
cord. This prong is used to reduce the risk of electrical shock and fire in case
of an internal short. Do not attempt to operate this unit if the power cord has
been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user serviceable
parts inside.

• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product outdoors voids
all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked on, pinched
by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by the
manufacturer. See page 3 for cleaning details.

• Heat -The appliance should be situated away from heat sources such as
radiators heat registers, stoves, or other appliances (including amplifiers) that
produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the unit.
C. The unit has been exposed to rain or water.

D. The unit does not appear to operate normally or exhibits a marked

change in performance.
