Page 1
ELATION
|
|
DTW BAR 1000™
user manual
DTW BAR 1000
™
user manual
Page 2
www.elationlighting.com
©2016 ELATION PROFESSIONAL all rights reserved. Information, specifications,
diagrams, images, and instructions herein are subject to change without notice.
ELATION PROFESSIONAL logo and identifying product names and numbers herein
are trademarks of ELATION PROFESSIONAL. Copyright protection claimed includes
all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this
document may be trademarks or registered trademarks of their respective
companies and are hereby acknowledged. All non-ELATION brands and product
names are trademarks or registered trademarks of their respective companies.
ELATION PROFESSIONAL and all affiliated companies hereby disclaim any and all
liabilities for property, equipment, building, and electrical damages, injuries to any
persons, and direct or indirect economic loss associated with the use or reliance of
any information contained within this document, and/or as a result of the improper,
unsafe, insufficient and negligent assembly, installation, rigging, and operation of
this product.
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
DOCUMENT VERSION
Please check www.elationlighting.com for the latest revision/update of this manual.
Date
07/07/16 1
Document
Version
Software
Version
01 / 02 / 03 / 05 / 06 / 07
≥1.05
10 / 12 / 15 / 36 / 41 / 45
DMX
Channel Modes
Notes
Initial release.
2 DTW BAR 1000™ User Manual
Page 3
CONTENTS
General Information
4
Warranty
6
Safety Instructions
7
General Guidelines
8
Fixture Overview
9
Fixture Installation
10
Fixture Menu
12
DMX Channel Functions And Values
17
Cleaning and Maintenance
22
Technical Specifications
23
Optional Accessories
25
www.elationlighting.com
3 DTW BAR 1000™ User Manual
Page 4
www.elationlighting.com
GENERAL INFORMATION
INTRODUCTION
Congratulations, you have just purchased one of the most innovative and
reliable lighting fixtures on the market today! The fixture has been designed to
perform reliably for years when the guidelines in this booklet are followed. Please
read and understand the instructions in this manual carefully and thoroughly
before attempting to operate this unit. These instructions contain important
information regarding safety during use and maintenance.
UNPACKING
Every fixture has been thoroughly tested and has been shipped in perfect
operating condition. Carefully check the shipping carton for damage that may
have occurred during shipping. If the carton appears to be damaged, carefully
inspect your unit for damage and be sure all accessories necessary to operate
the unit have arrived intact. In the event damage has been found or parts are
missing, please contact our customer support team for further instructions. Please
do not return this unit to your dealer without first contacting customer support at
the number listed below. Please do not discard the shipping carton in the trash.
Please recycle whenever possible.
BOX CONTENTS
(1) powerCON Cable
(1) Frost Filter
(1) Glare Shield
(3) Frost Filter/Glare Shield Mounting Screws
Manual & Warranty Card
4 DTW BAR 1000™ User Manual
Page 5
www.elationlighting.com
CUSTOMER SUPPORT
Elation Professional® provides a customer support line, to provide set up help and
to answer any question should you encounter problems during your set up or
initial operation. You may also visit us on the web at www.elationlighting.com for
any comments or suggestions. For service related issue please contact Elation
Professional®.
ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST
Voice: 323-582-3322 Fax: 323-832-9142
E-mail: support@elationlighting.com
ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
Voice: +31 45 546 85 30 Fax: +31 45 546 85 96
E-mail: support@elationlighting.eu
WARRANTY REGISTRATION
Please complete and mail in the enclosed warranty card or register online:
http://www.elationlighting.com/Login.aspx to validate your purchase. All
returned service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number must be
clearly written on the outside of the return package. A brief description of the
problem as well as the R.A. number must also be written down on a piece of
paper and included in the shipping container. If the unit is under warranty, you
must provide a copy of your proof of purchase invoice. Items returned without a
R.A. number clearly marked on the outside of the package will be refused and
returned at customer’s expense. You may obtain a R.A. number by contacting
customer support.
IMPORTANT NOTICE!
There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself; doing so will void your manufactures warranty. Damages resulting from
modifications to this fixture and/or the disregard of safety and general user
instructions found in this user manual void the manufactures warranty and are
not subject to any warranty claims and/or repairs.
5 DTW BAR 1000™ User Manual
Page 6
www.elationlighting.com
LIMITED WARRANTY
A. Elation Professional® hereby warrants, to the original purchaser, Elation Professional® products to
be free of manufacturing defects in material and workmanship for a period of two years (730 days),
and Elation Professional® product rechargeable batteries to be free of manufacturing defects in
material and workmanship for a period of six months (180 days), from the original date of purchase.
This warranty excludes discharge lamps and all product accessories. This warranty shall be valid only if
the product is purchased within the United States of America, including possessions and territories. It is
the owner’s responsibility to establish the date and place of purchase by acceptable evidence, at
the time service is sought.
B. For warranty service, send the product only to the Elation Professional® factory. All shipping
charges must be pre-paid. If the requested repairs or service (including parts replacement) are within
the terms of this warranty, Elation Professional® will pay return shipping charges only to a designated
point within the United States. If any product is sent, it must be shipped in its original package and
packaging material. No accessories should be shipped with the product. If any accessories are
shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or
damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the product serial number and/or labels are altered or removed; if the
product is modified in any manner which Elation Professional® concludes, after inspection, affects
the reliability of the product; if the product has been repaired or serviced by anyone other than the
Elation Professional® factory unless prior written authorization was issued to purchaser by Elation
Professional®; if the product is damaged because not properly maintained as set forth in the product
instructions, guidelines and/or user manual.
D. This is not a service contract, and this warranty does not include any maintenance, cleaning or
periodic check-up. During the periods as specified above, Elation Professional® will replace
defective parts at its expense, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of Elation Professional® under
this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at
the sole discretion of Elation Professional®. All products covered by this warranty were manufactured
after January 1, 1990, and bare identifying marks to that effect.
E. Elation Professional® reserves the right to make changes in design and/or performance
improvements upon its products without any obligation to include these changes in any products
theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory
supplied with the products described above. Except to the extent prohibited by applicable law, all
implied warranties made by Elation Professional® in connection with this product, including
warranties of merchantability or fitness, are limited in duration to the warranty periods set forth above.
And no warranties, whether expressed or implied, including warranties of merchantability or fitness,
shall apply to this product after said periods have expired. The consumer’s and/or dealer’s sole
remedy shall be such repair or replacement as is expressly provided above; and under no
circumstances shall Elation Professional® be liable for any loss and/or damage, direct and/or
consequential, arising out of the use of, and/or the inability to use, this product.
G. This warranty is the only written warranty applicable to Elation Professional® products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
6 DTW BAR 1000™ User Manual
Page 7
is an extremely sophisticated piece of electronic equipment. To
guarantee a smooth operation, it is important to follow the guidelines in this
manual. The manufacturer of this device will not accept responsibility for
lting from the misuse of this fixture due to the disregard of the
. It’s essential this device be
perform all electrical
SAFETY INSTRUCTIONS
www.elationlighting.com
This fixture
damages resu
information printed in this manual.
This device falls under PROTECTION CLASS 1
grounded properly. Only qualified personnel should
connections.
INDOORS USE ONLY!
DO NOT EXPOSE FIXTURE RAIN AND MOISTURE!
UNPLUG POWER BEFORE SERVICING FIXTURE!
DO NOT PLUG FIXTURE INTO A DIMMER PACK!
NEVER TOUCH FIXTURE DURING OPERATION, AS IT MAY BE HOT!
NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!
For proper operation, follow the Installation guidelines described in this manual. Only qualified
and certified personnel should perform installation of this fixture and only the original rigging parts
(brackets) included with this fixture should be used for installation. Any modifications will void the
original manufactures warranty and increase the risk of damage and/or personal injury.
Never look directly into the light source of this fixture to prevent risk of injury to your retina, which
may induce blindness. Those suffering from EPILEPSY should avoid looking directly into the light
source of this unit at all times.
The fan and air inlets must remain clean and never blocked. Allow approx. 6” (15cm) between
this fixture and other devices or a wall for proper cooling.
Always disconnect from main power source before performing any type of service and/or
cleaning procedure. Only handle the power cord by the plug end, never pull out the plug by
tugging the wire portion of the cord.
Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If
the power cord is damaged, replace it immediately with a new one of similar power rating.
7 DTW BAR 1000™ User Manual
Page 8
www.elationlighting.com
GENERAL GUIDELINES
NEVER OPEN THIS FIXTURE WHILE IN USE!
During the initial operation of this fixture, a light smoke or smell may emit from the
interior of the fixture. This is a normal process and is caused by excess paint in the
interior of the casing burning off from the heat associated with the lamp and will
decrease gradually over time.
This fixture is a professional lighting effect designed for INDOOR / DRY LOCATIONS
ONLY on stage, in nightclubs, theatres, etc.
Please make sure there are NO FLAMMABLE MATERIALS close to the fixture while
operating, to prevent any fire hazard.
The fixture must be installed in a location with adequate ventilation, at least 1.5
feet (.5m) from adjacent surfaces. Be sure no air ventilation slots are blocked.
DO NOT attempt installation and/or operation without knowledge how to do so.
DO NOT permit operation by persons who are not qualified to operate this type of
fixture. Most damages are the result of operations by nonprofessionals.
Consistent operational breaks may ensure the fixture will function properly for
many years to come.
DO NOT shake fixture, avoid brute force when installing and/or operating fixture.
Always install the fixture with an appropriate safety cable. When installing the
fixture in a suspended environment, always use mounting hardware that is no less
than M10 x 25 mm, also be sure the hardware is insert in the pre-arranged screw
holes in the bracket of the fixture.
Use the original packaging and materials to transport the fixture in for service.
DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power
and allow approximately 15 minutes for the fixture to cool down before replacing
or serving.
8 DTW BAR 1000™ User Manual
Page 9
FIXTURE OVERVIEW
SAFETY CABLE
www.elationlighting.com
1. 3pin DMX IN
2. powerCON IN
3. RJ45 NET IN
4. LCD Menu Control Display
5. powerCON OUT
6. 3pin DMX OUT
7. 5pin DMX IN
8. FUSE
9. RJ45 NET OUT
RIGGING POINT
10.Mode Button
11.UP Button
12.DOWN Button
13.ENTER Button
14.5pin DMX OUT
9 DTW BAR 1000™ User Manual
Page 10
Keep fixture at least 5.0 ft (1.5m) away from any
A qualified electrician should be used for all
FIXTURE INSTALLATION
www.elationlighting.com
FLAMMABLE MATERIAL WARNING
flammable materials, decorations, pyrotechnics, etc.
ELECTRICAL CONNECTIONS
electrical connections and/or installations.
CAUTIONS
For added protection, mount the fixture in areas outside walking paths, seating
areas, or in areas were unauthorized personnel might reach the fixture.
Ambient operating temperature range for this fixture is 5° to 113°F. (-15° to 45°C)
Do not use the fixture under or above this temperature.
Before mounting the fixture to any surface, make sure the installation area can
hold a minimum point load of 10 times the weight of the fixture.
Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable.
Never stand directly below the device when mounting, removing or servicing.
POWER LINKING
Max number of units that can be power linked is 7 units @110V and 15 units @240V.
CLAMP MOUNTING
The fixture provides an integrated dual yoke bracket. Make sure to secure
appropriately rated clamps to the mounting bracket using M10 screws when
mounting this fixture to truss.
10 DTW BAR 1000™ User Manual
Page 11
www.elationlighting.com
MOUNTING POINTS
Overhead mounting requires extensive experience, including amongst others
calculating working load limits, installation material being used, and periodic safety
inspection of all installation material and the device. If you lack these qualifications,
do not attempt the installation yourself. Improper installation can result in bodily
injury. Fixture is fully operational in the specific mounting positions as illustrated below.
SAFETY CABLE
ALWAYS USE A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE IN A SUSPENDED
ENVIRONMENT TO ENSURE THE FIXTURE WILL NOT DROP IF THE CLAMP FAILS.
11 DTW BAR 1000™ User Manual
Page 12
Update
DTW Bar
SOFTWARE
www.elationlighting.com
FIXTURE MENU
ON-BOARD SYSTEM MENU
The fixture comes with an easy to navigate system menu. The next section will detail
the functions of each command in the system menu.
LCD MENU CONTROL PANEL
The control panel (see image below) located on back of the fixture allows you to
access the main menu and make all necessary adjustments to the fixture. During
normal operation, pressing MODE button once will access the fixture’s main menu.
Once in the main menu you can navigate through the different functions and
access the sub-menus with the UP and DOWN buttons. Once you reach a field that
requires adjusting, press the ENTER button to activate that field and use the UP and
DOWN buttons to adjust the field. Pressing the ENTER button once more will confirm
your setting. You may exit the main menu at any time without making any
adjustments by pressing the MODE button.
NOTE: the LCD Menu Control Display will shut OFF and lockout after 30 seconds of no
use. Press and hold the MODE button for 10 seconds to unlock the LCD display.
INFORMATION DISPLAYED DURING INITIAL POWER ON
When the fixture is initially powered ON, the display shows the following information:
12 DTW BAR 1000™ User Manual
Wait...
1000
V1.08
Fixture Software Version
(Greater than or equal to)
Page 13
ELATION© DTWBAR 1000™
S Y S T E M M E N U
Features are subject to change without any prior written notice.
MENU
OPTIONS / VALUES (Default Settings in BOLD)
DESCRIPTION
www.elationlighting.com
DMX MODE
ADDR:xxx
CH:xx
SLAVE
M O D E
AUTO RUN
FQN:xx
01STATIC
-
15FLOW1
DimCurve
Flip
NO DMX
Manual
ADDR:001 - 512
CH:01, 02, 03, 05, 06, 07,
10, 12, 15, 36, 41, 45
Set unit to Slave Mode.
FQN:01-99
01-15
Standard, Stage, TV, Architec, Theatre Set desired Dimming Curve.
ON, OFF
Hold, Blackout, Program Define how fixture reacts when NO DMX signal present.
WW000-255 CW000-255
A000-255STR:00-99
Set DMX Address.
Set DMX Channel Mode.
Set the number of times each internal macro will
repeat before moving to the next macro.
Select Internal Program Macro.
See PROGRAM MACROS for more details.
Set starting LED.
See FLIP Section for more details.
Set Warm White, Cool White, Amber,and Strobe Values
manually.
Macros
Whitebal
Net Set
Fix ID
Net Set
Pro Set
Net Set
Net Swi
Default
00-07
WW000-255 CW000-255 A000-255
Fix ID
Ser PIN
Fix ID
IP Addr
Fix ID
Universe
K - Net, ArtNet Set Protocol (Kling-Net or ArtNet)
ON, OFF Set Ethernet Switch.
OFF, ON Reset fixture to factory default settings.
Ser PIN
Pass=000
000.000
000.000
0
Select Internal Color Macro.
See COLOR MACROS for more details.
Adjust White Balance for each LED.
NOTE: Reset to Default does NOT change these values.
Enter Passcode 050 to access
IP Address and Universe Network Menus.
Set fixture IP Address.
Set fixture Universe.
13 DTW BAR 1000™ User Manual
Page 14
ELATION© DTWBAR 1000™
P R O G R A M M A C R O S
Features subject to change without any prior written notice.
MACRO
OPTIONS / VALUES
DESCRIPTION
www.elationlighting.com
01.STATIC
02.DREAM
03.METEOR
04.FADE
05.CHANGE
06.FLOW 1
07.FLOW 2
08.FLOW 3
09.FLOW 4
CL: BLAC, WW, CW, A, WA
F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
Static Colors
Fade Adjustable
All Color Dreaming Sequence
Speed & Fade Adjustable
All Color Flow Sequence
Speed & Fade Adjustable
All Color Fade Sequence
Speed & Fade Adjustable
All Color Change Sequence
Speed & Fade Adjustable
All Color Chase Sequence
Speed & Fade Adjustable
All Color Chase Sequence
Speed & Fade Adjustable
All Color Chase Sequence
Speed & Fade Adjustable
All Color Chase Sequence
Speed & Fade Adjustable
10.FLOW 5
11.FLOW 6
12.FLOW 7
13.FLOW 8
14.FLOW 9
15.FLOW 1
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
SP00-99 F00-99
C1:BLAC, WW, CW, A
C2:BLAC, WW, CW, A
SP00-99 F00-99
C1:BLAC, WW, CW, A
C2:BLAC, WW, CW, A
SP00-99 F00-99
All Color Chase Sequence
Speed & Fade Adjustable
All Color Chase Sequence
Speed & Fade Adjustable
All Color Chase Sequence
Speed & Fade Adjustable
2 Selectable Color Chase
Speed & Fade Adjustable
2 Selectable Color Chase
Speed & Fade Adjustable
Seven Color Chase
Speed & Flash Adjustable
14 DTW BAR 1000™ User Manual
Page 15
ELATION© DTWBAR 1000™
C O L O R M A C R O S
Actual colors may vary and subject to change without notice.
MACRO # COLOR MACRO
www.elationlighting.com
00
01
02
03
04
05
06
07
OFF
WARM WHITE
COOL WHITE
AMBER
WARM WHITE + COOL WHITE
WARM WHITE + AMBER
COOL WHITE + AMBER
WARM WHITE + COOL WHITE + AMBER
NO FUNCTION
DIMMING CURVES
The DimCurve menu allows you to select one of the following preset dimming curves:
Standard, Stage, TV, Architectural, Theatre, or Default.
(See diagram below for more details)
Dimmer
15 DTW BAR 1000™ User Manual
Page 16
PIXEL FLIP
Select the desired starting LED module and chase direction from one of the following
modes below via UP/DOWN buttons and then press ENTER to confirm.
Flip = OFF Flip = ON
www.elationlighting.com
WHITE BALANCE
Select the desired white balance settings for each LED separately.
WW000-255 CW000-255 A000-255
NOTE: Reset to Default does NOT change these values.
16 DTW BAR 1000™ User Manual
Page 17
ELATION© DTW BAR 1000™
DMX Channel Values / Functions (44 DMX Channels)
www.elationlighting.com
DMX CHANNEL FUNCTIONS AND VALUES
Features are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE
1CH 2CH 3CH 5CH 6CH 7CH 10CH 12CH 15CH 36CH 41CH 45CH
1 1 0-255
1 1 1 1 1 0-255
2 2 2 2 2 0-255
3 3 3 3 3 0-255
4
1 1 0-255
2 2 0-255
3 3 0-255
4 4 0-255
5 5 0-255
6 6 0-255
7 7 0-255
8 8 0-255
9 9 0-255
10 10 0-255
11 11 0-255
12 12 0-255
VALUE FUNCTION
DIM TO WARM - All LEDS [1-12]
1,800K - 3,200K (0=Black - 255=100%)
COOL WHITE - All LEDs [1-12]
Cool White (0=Black - 255=100%)
WARM WHITE - All LEDs [1-12]
Warm White (0=Black - 255=100%)
AMBER - All LEDs [1-12]
Amber (0=Black - 255=100%)
COLOR MACROS
0-30 NO Function
31-61 WARM WHITE
62-92 COOL WHITE
93-123 AMBER
124-154 WARM WHITE + COOL WHITE
155-185 WARM WHITE + AMBER
186-216 COOL WHITE + AMBER
217-247 WARM WHITE + COOL WHITE + AMBER
248-255 NO Function
DIM TO WARM - LEDS [1]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [2]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [3]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [4]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [5]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [6]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [7]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [8]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [9]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [10]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [11]
1,800K - 3,200K (0=Black - 255=100%)
DIM TO WARM - LEDS [12]
1,800K - 3,200K (0=Black - 255=100%)
17 DTW BAR 1000™ User Manual
Page 18
ELATION© DTW BAR 1000™
DMX Channel Values / Functions (44 DMX Channels)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
www.elationlighting.com
Features are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE
1CH 2CH 3CH 5CH 6CH 7CH 10CH 12CH 15CH 36CH 41CH 45CH
VALUE FUNCTION
1 1 1 0-255
2 2 2 0-255
3 3 3 0-255
4 4 4 0-255
5 5 5 0-255
6 6 6 0-255
7 7 7 0-255
8 8 8 0-255
9 9 9 0-255
10 10 10 0-255
11 11 11 0-255
COOL WHITE - LED [1]
WARM WHITE - LED [1]
AMBER - LED [1]
COOL WHITE - LED [2]
WARM WHITE - LED [2]
AMBER - LED [2]
COOL WHITE - LED [3]
WARM WHITE - LED [3]
AMBER - LED [3]
COOL WHITE - LED [4]
WARM WHITE - LED [4]
12 12 12 0-255
13 13 13 0-255
14 14 14 0-255
15 15 15 0-255
16 16 16 0-255
17 17 17 0-255
18 18 18 0-255
19 19 19 0-255
20 20 20 0-255
21 21 21 0-255
AMBER - LED [4]
COOL WHITE - LED [5]
WARM WHITE - LED [5]
AMBER - LED [5]
COOL WHITE - LED [6]
WARM WHITE - LED [6]
AMBER - LED [6]
COOL WHITE - LED [7]
WARM WHITE - LED [7]
AMBER - LED [7]
18 DTW BAR 1000™ User Manual
Page 19
ELATION© DTW BAR 1000™
DMX Channel Values / Functions (44 DMX Channels)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
Cool White (0=Black - 255=100%)
Warm White (0=Black - 255=100%)
Amber (0=Black - 255=100%)
1,800K - 3,200K (0=Black - 255=100%)
www.elationlighting.com
Features are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE
1CH 2CH 3CH 5CH 6CH 7CH 10CH 12CH 15CH 36CH 41CH 45CH
VALUE FUNCTION
22 22 22 0-255
23 23 23 0-255
24 24 24 0-255
25 25 25 0-255
26 26 26 0-255
27 27 27 0-255
28 28 28 0-255
29 29 29 0-255
30 30 30 0-255
31 31 31 0-255
32 32 32 0-255
COOL WHITE - LED [8]
WARM WHITE - LED [8]
AMBER - LED [8]
COOL WHITE - LED [9]
WARM WHITE - LED [9]
AMBER - LED [9]
COOL WHITE - LED [10]
WARM WHITE - LED [10]
AMBER - LED [10]
COOL WHITE - LED [11]
WARM WHITE - LED [11]
33 33 33 0-255
34 34 34 0-255
35 35 35 0-255
36 36 36 0-255
37 0-255
0-30 NO Function
31-61 WARM WHITE
62-92 COOL WHITE
37 38
93-123 AMBER
124-154 WARM WHITE + COOL WHITE
155-185 WARM WHITE + AMBER
186-216 COOL WHITE + AMBER
217-247 WARM WHITE + COOL WHITE + AMBER
248-255 NO Function
AMBER - LED [11]
COOL WHITE - LED [12]
WARM WHITE - LED [12]
AMBER - LED [12]
DIM TO WARM - All LEDS [1-12]
COLOR MACROS
19 DTW BAR 1000™ User Manual
Page 20
ELATION© DTW BAR 1000™
DMX Channel Values / Functions (44 DMX Channels)
www.elationlighting.com
Features are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE
1CH 2CH 3CH 5CH 6CH 7CH 10CH 12CH 15CH 36CH 41CH 45CH
4 5 38 39
4 4 5 6 39 40 0-255
5 5 6 7 40 41 0-255
41 42
13
14
VALUE FUNCTION
0-31 NO Function
32-95 Variable Strobe Effect SLOW to FAST
96-127 LEDs ON
128-159 Pulse Effect In Sequence SLOW to FAST
160-191 LEDs ON
192-223 Random Strobe Effect SLOW to FAST
224-255 LEDs ON
0-20 STANDARD
21-40 STAGE
41-60 TV
61-80 ARCHITECTURAL
81-100 THEATRE
101-255 Default to Unit Setting
0-30 NO Function
31-61 WARM WHITE
62-92 COOL WHITE
93-123 AMBER
124-154 WARM WHITE + COOL WHITE
155-185 WARM WHITE + AMBER
186-216 COOL WHITE + AMBER
217-247 WARM WHITE + COOL WHITE + AMBER
248-255 NO Function
0-31 NO Function
32-95 Variable Strobe Effect SLOW to FAST
96-127 LEDs ON
128-159 Pulse Effect In Sequence SLOW to FAST
160-191 LEDs ON
192-223 Random Strobe Effect SLOW to FAST
224-255 LEDs ON
SHUTTER / STROBE
MASTER DIMMER
0 to 100%
MASTER DIMMER FINE (16 bit)
0 to 100%
DIMMING CURVE MODES
COLOR MACROS
SHUTTER / STROBE
20 DTW BAR 1000™ User Manual
Page 21
ELATION© DTW BAR 1000™
DMX Channel Values / Functions (44 DMX Channels)
www.elationlighting.com
Features are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE
1CH 2CH 3CH 5CH 6CH 7CH 10CH 12CH 15CH 36CH 41CH 45CH
8 43
9 44
10 45
2 6 7 15
VALUE FUNCTION
PROGRAM MACROS
0-10 NO Function
11-26 Program 01
27-43 Program 02
44-60 Program 03
61-76 Program 04
77-93 Program 05
94-110 Program 06
111-126 Program 07
127-143 Program 08
144-160 Program 09
161-176 Program 10
177-193 Program 11
194-210 Program 12
211-255 NO Function
PROGRAM SPEED
0-255 Program Speed SLOW to FAST
PROGRAM FADE
0-255 0-100%
0-20 STANDARD
21-40 STAGE
41-60 TV
61-80 ARCHITECTURAL
81-100 THEATRE
101-255 Default to Unit Setting
DIMMING CURVE MODES
21 DTW BAR 1000™ User Manual
Page 22
www.elationlighting.com
CLEANING AND MAINTENANCE
CAUTION
Disconnect power before cleaning or maintenance.
CLEANING
Frequent cleaning is recommended to insure proper function, optimized light output,
and an extended life. The frequency of cleaning depends on the environment in
which the fixture operates: damp, smoky or particularly dirty environments can
cause greater accumulation of dirt on the fixture’s optics.
Clean the external lens surface at least every 20 days with a soft cloth to avoid
dirt/debris accumulation.
Never use alcohol, solvents, or ammonia based cleaners.
MAINTENANCE
Regular inspections are recommended to insure proper function and extended life.
There are no user serviceable parts inside this fixture, please refer all other service
issues to an authorized Elation service technician. Should you need any spare parts,
please order genuine parts from your local Elation dealer.
Please refer to the following points during routine inspections:
A detailed electric check by an approved electrical engineer every three
months, to make sure the circuit contacts are in good condition and prevent
overheating.
Be sure all screws and fasteners are securely tightened at all times. Lose screws
may fall out during normal operation resulting in damage or injury as larger parts
could fall.
Check for any deformations on the housing, color lenses, rigging hardware and
rigging points (ceiling, suspension, trussing). Deformations in the housing could
allow for dust to enter into the fixture. Damaged rigging points or unsecured
rigging could cause the fixture to fall and seriously injure a person(s).
Electric power supply cables must not show any damage, material fatigue or
sediments. Never remove the ground prong from the power cable.
22 DTW BAR 1000™ User Manual
Page 23
4010765
www.elationlighting.com
TECHNICAL SPECIFICATIONS
SOURCE
(12) 10W Multi-Chip CW / WW / Amber LEDs
100,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
EFFECTS
Strobe and Chase Effects
Pixel Control
Variable and Selectable Dimming Curves
CONTROL / CONNECTIONS
(12) DMX Channel Modes (1 / 2 / 3 / 5 / 6 / 7 / 1 0 / 1 2 / 15 / 36 / 41 / 45)
4 Button Control Panel and LCD Menu Display
ArtNet + KlingNET Protocol Support
RDM (Remote Device Management)
(2) etherCON RJ45 In/Out
3pin and 5pin DMX In/Out
powerCON Power In/Out
SIZE / WEIGHT
Length: 35.4” (900mm)
Width: 8.1” (206.4mm) *with included shield
Vertical Height: 6.1” (155mm)
Weight: 14.0 lbs. (6.4 kg)
ELECTRICAL / THERMAL
AC 110-240V - 50/60Hz
120W Max Power Consumption
Power Linking: 7pcs @110V / 15pcs @240V
5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
CE | cETLus | IP20
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.
23 DTW BAR 1000™ User Manual
Page 24
PHOTOMETRIC DATA
1 m
3.3 ft
2 m
6.6 ft
3 m
9.8 ft
4 m
13.1 ft
5 m
16.4 ft
lux
fc
lux
fc
lux
fc
lux
fc
lux
fc
3,561
331
1,603
149
905
84
584
54
382
35
WW LEDs
3,447
320
1,587
147
872
81
550
51
379
35
AMBER
LEDs
FULL ON
6,425
597
2,975
276
1,625
151
999
93
686
64
FROST
lux
fc
lux
fc
lux
fc
lux
fc
lux
fc
1,920
178
772
72
344
32
227
21
157
15
WW LEDs
1,887
175
740
69
262
24
211
20
148
14
AMBER
LEDs
FULL ON
3,196
297
918
85
466
43
282
26
193
18
www.elationlighting.com
28° Beam
Diameter
33° Field
Diameter
CW LEDs
0.48 1.6
0.59 1.9
1,166 108
1.01 3.3
1.23 4.0
589 55
1.54 5.1
1.86 6.1
318 30
2.09 6.9
2.48 8.1
201 19
2.62 8.6
3.12 10.2
138 13
38° Beam
Diameter
Diameter
FILTER
1 m 3.3 ft
0.69 2.3
48° Field
CW LEDs
0.79 2.6
651 60
24 DTW BAR 1000™ User Manual
2 m 6.6 ft
1.42 4.7
1.62 5.3
253 24
3 m 9.8 ft
2.14 7.0
2.45 8.0
113 10
4 m 13.1 ft
2.87 9.4
3.27 10.7
77 7
5 m 16.4 ft
3.59 11.8
4.1 13.5
55 5
Page 25
DIMENSIONAL DRAWINGS
www.elationlighting.com
OPTIONAL ACCESSORIES
ORDER CODE ITEM
TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp
PLC3 3' (1m) powerCON PRO Link Cable
AC3PDMX5PRO 5 ft. (1.5m) 3pin PRO DMX Cable
AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable
CAT005 5’ (1.5m) CAT6 etherCON Cable
Additional Cable Lengths Available
25 DTW BAR 1000™ User Manual
Page 26
Loading...
