Elation Chorus Line 16 Users Manual

ELATION

|

CHORUS LINE 16

|

user manual

CHORUS LINE 16™

user manual

©2018 ELATION PROFESSIONAL all rights reserved. Information, specifications,

Date

Document

Version

Software

Version ≥

DMX

Channel Modes

Notes

10/19/17

1

1.02

16 / 18 / 78

Initial release.

01/26/18

1.2

1.03

NO CHANGE

Added sACN, Pixel Flip, Art-Net/Kling-Net
dual control.

07/25/18

1.4

1.08

NO CHANGE

Updated manual format.

diagrams, images, and instructions herein are subject to change without notice. ELATION
PROFESSIONAL logo and identifying product names and numbers herein are trademarks
of ELATION PROFESSIONAL. Copyright protection claimed includes all forms and matters
of copyrightable materials and information now allowed by statutory or judicial law or
hereinafter granted. Product names used in this document may be trademarks or
registered trademarks of their respective companies and are hereby acknowledged. All
non-ELATION brands and product names are trademarks or registered trademarks of their
respective companies.

ELATION PROFESSIONAL and all affiliated companies hereby disclaim any and all
liabilities for property, equipment, building, and electrical damages, injuries to any persons,
and direct or indirect economic loss associated with the use or reliance of any information
contained within this document, and/or as a result of the improper, unsafe, insufficient and
negligent assembly, installation, rigging, and operation of this product.

Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040

323-582-3322 | 323-832-9142 fax | www.elationlighting.com | [e-mail]

Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands

[phone] | [phone] fax | www.elationlighting.eu | [e-mail]

Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000

[phone]

DOCUMENT VERSION

Due to additional product features and/or enhancements, an updated
version of this document may be available online.
Please check www.elationlighting.com for the latest revision/update of this
manual, before beginning installation and/or programming.

2

CONTENTS

General Information

4

Limited Warranty (USA Only)

5

Safety Guidelines

6

Maintenance Guidelines

8

Fixture Overview

9

Installation Guidelines

10

System Menu

13

DMX Channel Functions and Values

15

Pixel Control

21

Tec hni ca l S pe ci ficat io ns

22

Optional Accessories

24

3

GENERAL INFORMATION

INTRODUCTION

This fixture has been designed to perform reliably for years when the information in this
manual are followed. Please read and understand all the instructions and guidelines
carefully and thoroughly before operating this unit. This manual contains important
information regarding safety, installation, use, and maintenance.

UNPACKING

Each fixture has been thoroughly tested and shipped in perfect operating condition.
Carefully check the outer shipping carton for signs of any damage that may have occurred
during shipping. If the outer carton appears to be damaged, carefully inspect the fixture for
damage and be sure all included accessories have arrived intact. In the event damage has
been found and/or parts are missing, please contact our customer support team for further
instructions. Please do NOT return this fixture to your dealer without first contacting
customer support at the number listed below. Please do NOT discard the outer shipping
carton in the trash. Please recycle whenever possible.

CUSTOMER SUPPORT

Elation Professional provides a customer support line to provide set up help and answer
any set up or operation questions. You may also visit us on the web at

www.elationlighting.com for any comments or suggestions. For service related issue please

contact Elation Professional.

ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST

Voice: 323-582-3322 Fax: [phone]

E-mail: [e-mail]

ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET

Voice: [phone] Fax: [phone]
E-mail: [e-mail]

WARRANTY REGISTRATION / RETURNS

Please register online: http://www.elationlighting.com/Login.aspx to validate your purchase.
All returned service items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. The R.A. number must be clearly written
on the outside of the return package. A brief description of the problem as well as the R.A.
number must also be written down on a piece of paper and included in the shipping
container. If the unit is under warranty, you must provide a copy of your proof of purchase
invoice. Items returned without a R.A. number clearly marked on the outside of the package
will be refused and returned at customer’s expense. You may obtain a R.A. number by
contacting customer support.

4

LIMITED WARRANTY (USA ONLY)

A. Elation Professional hereby warrants, to the original purchaser, Elation Professional products to
be free of manufacturing defects in material and workmanship for a period of two years (730 days),
and Elation Professional product rechargeable batteries to be free of manufacturing defects in
material and workmanship for a period of six months (180 days), from the original date of purchase.
This warranty excludes discharge lamps and all product accessories. This warranty shall be valid
only if the product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service, send the product only to the Elation Professional factory. All shipping
charges must be pre-paid. If the requested repairs or service (including parts replacement) are
within the terms of this warranty, Elation Professional will pay return shipping charges only to a
designated point within the United States. If any product is sent, it must be shipped in its original
package and packaging material. No accessories should be shipped with the product. If any
accessories are shipped with the product, Elation Professional shall have no liability what so ever
for loss and/or or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the product serial number and/or labels are altered or removed; if the
product is modified in any manner which Elation Professional concludes, after inspection, affects
the reliability of the product; if the product has been repaired or serviced by anyone other than the
Elation Professional factory unless prior written authorization was issued to purchaser by Elation
Professional; if the product is damaged because not properly maintained as set forth in the product
instructions, guidelines and/or user manual.
D. This is not a service contract, and this warranty does not include any maintenance, cleaning or
periodic check-up. During the periods as specified above, Elation Professional will replace defective
parts at its expense, and will absorb all expenses for warranty service and repair labor by reason of
defects in material or workmanship. The sole responsibility of Elation Professional under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the
sole discretion of Elation Professional. All products covered by this warranty were manufactured
after January 1, 1990, and bare identifying marks to that effect.
E. Elation Professional reserves the right to make changes in design and/or performance
improvements upon its products without any obligation to include these changes in any products
theretofore manufactured.
F. N o w a r r a nty, whether expressed or implied, is given or made with respect to any accessory
supplied with the products described above. Except to the extent prohibited by applicable law, all
implied warranties made by Elation Professional in connection with this product, including
warranties of merchantability or fitness, are limited in duration to the warranty periods set forth
above. And no warranties, whether expressed or implied, including warranties of merchantability or
fitness, shall apply to this product after said periods have expired. The consumer’s and/or dealer’s
sole remedy shall be such repair or replacement as is expressly provided above; and under no
circumstances shall Elation Professional be liable for any loss and/or damage, direct and/or
consequential, arising out of the use of, and/or the inability to use, this product.
G. This warranty is the only written warranty applicable to Elation Professional products and supersedes
all prior warranties and written descriptions of warranty terms and conditions heretofore published.

5

SAFETY GUIDELINES

PROTECTION CLASS 1 - FIXTURE MUST BE PROPERLY GROUNDED

THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT.
DO NOT ATTEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID
YOUR MANUFACTURES WARRANTY. DAMAGES RESULTI NG FROM
MODIFICATIONS TO THIS FIXTURE AND/OR THE DISREGARD OF
SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID
THE MANUFACTURES WARRANTY AND ARE NOT SUBJECT TO ANY
WARRANTY CLAIMS AND/OR REPAIRS.

DO NOT PLUG FIXTURE INTO A DIMMER PACK!
NEVER OPEN THIS FIXTURE WHILE IN USE!
UNPLUG POWER BEFORE SERVICING FIXTURE!
NEVER TOUCH FIXTURE DURING OPERATION, AS IT MAY BE HOT!
KEEP FLAMMABLE MATERIALS AWAY FROM FIXTURE!

NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!
RETINA INJURY RISK - MAY INDUCE BLINDNESS!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!

INDOOR / DRY LOCATIONS USE ONLY!
DO NOT EXPOSE FIXTURE TO RAIN AND/OR MOISTURE!

This fixture is a sophisticated piece of electronic equipment. To guarantee a smooth
operation, it is important to follow all instructions and guidelines in this manual. Elation
Professional is not responsible for injury and/or damages resulting from the misuse of this
fixture due to the disregard of the information printed in this manual. Only qualified and/or
certified personnel should perform installation of this fixture and only the original rigging
parts (omega brackets) included with this fixture should be used for installation. Any
modifications to the fixture and/or the included mounting hardware will void the original
manufactures warranty and increase the risk of damage and/or personal injury.

6

SAFETY GUIDELINES

DO NOT TOUCH the fixture housing during operation. Turn OFF the power and allow

approximately 15 minutes for the fixture to cool down before serving.

DO NOT shake fixture, avoid brute force when installing and/or operating fixture.

DO NOT operate fixture if the power cord is frayed, crimped, damaged and/or if any of the

power cord connectors are damaged and do not insert into the fixture securely with ease.
NEVER force a power cord connector into the fixture. If the power cord or any of its
connectors are damaged, replace it immediately with a new one of similar power rating.

DO NOT block any air ventilation slots.

All fan and air inlets must remain clean and never blocked.

Allow approx. 6” (15cm) between fixture and other devices or a wall for proper cooling.

When installing fixture in a suspended environment, always use mounting hardware that is no
less than M10 x 25 mm, and always install fixture with an appropriately rated safety cable.

Always disconnect fixture from main power source before performing any type of service
and/or cleaning procedure. Only handle the power cord by the plug end, never pull out the
plug by tugging the wire portion of the cord.

During the initial operation of this fixture, a light smoke or smell may emit from the interior of
the fixture. This is a normal process and is caused by excess paint in the interior of the casing
burning off from the heat associated with the lamp and will decrease gradually over time.

Consistent operational breaks will ensure fixture will function properly for many years.

ONLY use the original packaging and materials to transport the fixture in for service.

7

MAINTENANCE GUIDELINES

DISCONNECT POWER BEFORE PERFORMING ANY MAINTENANCE!

CLEANING

Frequent cleaning is recommended to insure proper function, optimized light output, and

an extended life. The frequency of cleaning depends on the environment in which the

fixture operates: damp, smoky or particularly dirty environments can cause greater

accumulation of dirt on the fixture’s optics. Clean the external lens surface at least every 20

days with a soft cloth to avoid dirt/debris accumulation.

NEVER use alcohol, solvents, or ammonia-based cleaners.

MAINTENANCE

Regular inspections are recommended to insure proper function and extended life.

There are no user serviceable parts inside this fixture, please refer all other service issues to

an authorized Elation service technician. Should you need any spare parts, please order

genuine parts from your local Elation dealer.

Please refer to the following points during routine inspections:

A detailed review by an approved electrical engineer every three months, to make sure the

circuit contacts are in good condition and prevent overheating.

Be sure all screws and fasteners are securely tightened at all times. Lose screws may fall out

during normal operation resulting in damage or injury as larger parts could fall.

Check for any deformations on the housing, color lenses, rigging hardware and rigging

points (ceiling, suspension, trussing). Deformations in the housing could allow for dust to

enter into the fixture. Damaged rigging points or unsecured rigging could cause the fixture

to fall and seriously injure a person(s).

Electric power supply cables must not show any damage, material fatigue or sediments.

NEVER remove the ground prong from the power cable.

8

FIXTURE OVERVIEW

1. LCD Menu Display, MENU, UP, DOWN, ENTER Buttons

2. Tilt Lock

3. Fuse

4. powerCON IN/OUT

5. 5pin DMX IN/OUT

6. RJ45 Ethernet IN/OUT

INCLUDED ITEMS

(2) Replacement Lens Covers
(2) Omega Brackets
(1) Safety Cable
(1) Power Cable

9

INSTALLATION INSTRUCTIONS

FLAMMABLE MATERIAL WARNING

Keep fixture minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics.

ELECTRICAL CONNECTIONS

A qualified electrician should be used for all electrical connections and/or installations.

USE CAUTION WHEN POWER LINKING OTHER MODEL FIXTURES AS THE
POWER CONSUMPTION OF OTHER MODEL FIXTURES MAY EXCEED THE MAX
POWER OUTPUT ON THIS FIXTURE. CHECK SILK SCREEN FOR AMX AMPS.

DO NOT INSTALL THE FIXTURE IF YOU ARE NOT QUALIFIED TO DO SO!

Fixture MUST be installed following all local, national, and country commercial electrical
and construction codes and regulations.

Before rigging/mounting a single fixture or multiple interconnected fixtures for custom
matrix designs to any metal truss/structure or placing the fixture(s) on any surface, a
professional equipment installer MUST be consulted to determine if the metal
truss/structure or surface is properly certified to safely hold the combined weight of the
fixture(s), clamps, cables, and accessories.

Fixture ambient operating temperature range is 15° to 113°F. (-15° to 45°C)
Do not use the fixture under or above this temperature.

Fixture(s) should be installed in areas outside walking paths, seating areas, or away from
areas were unauthorized personnel might reach the fixture by hand.

NEVER stand directly below the fixture(s) when rigging, removing or servicing.
Overhead fixture installation must always be secured with a secondary safety attachment,
such as an appropriately rated safety cable that can hold 10 times the weight of the fixture.

Allow approximately 15 minutes for the fixture to cool down before serving.

10

INSTALLATION INSTRUCTIONS

CLAMP MOUNTING

The fixture can be placed on the flat surface or truss mounted. When mounting this fixture

to truss be sure to secure (2) appropriately rated clamps (not included) to the (2) Omega

Brackets (included) Be sure to attach the Safety Cable (included) to the fixture using the

safety cable rigging points integrated into the bottom of the fixture. (See image below)

SAFETY CABLE RIGGING POINT

SAFETY CABLE

The fixture includes an integrated safety cable rigging point. (see image below)

ALWAYS ATTACH A SAFETY CABLE WHEN INSTALLING FIXTURE IN A SUSPENDED

ENVIRONMENT TO ENSURE THE FIXTURE WILL NOT DROP IF THE CLAMP FAILS.

11

INSTALLATION INSTRUCTIONS

OVERHEAD RIGGING

Overhead rigging requires extensive experience, including amongst others calculating
working load limits, installation material being used, and periodic safety inspection of all
installation material and the fixture. If you lack these qualifications, do not attempt the
installation yourself. Improper installation can result in bodily injury and property damage.
Fixture is fully operational in the specific mounting positions illustrated below.

POWER LINKING

USE CAUTION WHEN POWER LINKING OTHER MODEL FIXTURES AS THE
POWER CONSUMPTION OF OTHER MODEL FIXTURES MAY EXCEED THE MAX
POWER OUTPUT ON THIS FIXTURE. CHECK SILK SCREEN FOR AMX AMPS.

KLING-NET / ART-NET CONNECTION

When connecting fixture to a network switch to control multiple devices, a Gigabit
Ethernet Switch that supports IGMP (Internet Group Management Protocol) is required.

Using a Gigabit Ethernet Switch that does not support IGMP can cause erratic behavior
of all connected devices to the switch. Click link below for more information about IGMP.

https://en.wikipedia.org/wiki/Internet_Group_Management_Protocol

12

SYSTEM MENU

Update'

Wait...'

Chorus16'

Reset...'

The fixture comes with an easy to navigate system menu. The control panel (see image
below) located on the back of the fixture provides access to the main system menu and is
where all necessary system adjustments are made to the fixture. During normal operation,
pressing MODE button once will access the fixture’s main menu. Once in the main menu
you can navigate through the different functions and access the sub-menus with the UP
and DOWN buttons. Once you reach a field that requires adjusting, press the ENTER
button to activate that field and use the UP and DOWN buttons to adjust the field. Pressing
the ENTER button once more will confirm your setting. You may exit the main menu at any
time without making any adjustments by pressing the MODE/ESC button.

LCD CONTROL PANEL LOCKOUT

When the Key Lock menu is set to ON, the LCD display will turn OFF after 30 seconds and

the (4) button Control Panel will be LOCKED. To unlock the (4) button LCD control panel,

press and hold the MODE button.

INFORMATION DISPLAYED DURING INITIAL POWER ON

When the fixture is initially powered ON, the display shows the following information:

13

S Y S T E M M E N U

Supports Software Version: ≥ V1.08

Features are subject to change without any prior written notice.

MAIN MENU

SUB MENU

OPTIONS / VALUES (Default Settings in BOLD)

DESCRIPTION

Receive

Set DMX Address

001 ~ XXX

DMX Address Setting

User Mode

User Mode

Standard, Basic, Extend, User A, User B, User C

Set DMX Channel Mode

Edit A

Max. Chan
:
Chase Fade

Edit User Defined
Channel Assignments

Edit B

Edit C

Function

Status

Remote Add

ON/OFF

Set Fixture Address Via DMX Control

NoDMX Mode

Hold / Auto / Blackout

Function If NO DMX Detected

Pan Invert

ON / OFF

Pan Reverse Movement

Tilt Invert

ON / OFF

Tilt Reverse Movement

Pan Degree

630/540

Pan Degree Select

Feedback

ON/OFF

Movement Feedback

Move. Spd

Speed 1 ~ 4

Movement Mode Select

Stand By

OFF, 01M~99M, 15M

Stand By Mode

Fixture ID

ServicePIN

PIN=XXX

Service PIN 050

RDM PID

XXXXX

RDM PID Code

NOTE: ServicePIN must be entered in order to set fixture IP Address and Universe

Unit IP Addr

XXX.XXX.XXX.XXX.

Enter Fixture's IP Address

Universe

000-255

Enter Universe Number

ProtocolSet

ArtNet, SACN

Set Network Protocol

KlingNet

Enable / Disable

Enable KlingNet Protocol

Net Switch

ON / OFF

Activate NET OUT Port.

Fan. Set

Head Fan

Auto, High, Low

Fan Speed Set

LCD. Set

Backlight

02~60m 05m

LCD Backlight Shut Off Time

FlipDisplay

ON / OFF

Flip/Reverse LCD Display 180º

Key Lock

ON / OFF

Control Front Panel Buttons Key Lock

Disp Flash

ON / OFF

Display flashes when NO DMX

Dim Curve

Standard, Stage, TV, Architectur, Theatre

Set Dimmer Curve Mode

Tem p. C/ F

Fahrenheit/Celsius

Tem p er at ur e Sw it ch B etw een F˚/ C˚

Init. Effect

PAN =XXX

Initial Effect Position

Disp. Set
Chan. Value

PAN...

Value of each Channel Displayed

Slave Set

Slave 1, Slave 2, Slave 3

Set Slave Mode Preset

Auto. Pro

Alone, Master

Set Auto Program Mode

Pixel

Standard, Flip

Set Pixel Flip Mode

DFSE

ON / OFF

Restore Factory Settings

Information

Time. Info

Current

XXXX (Hours)

Fixture Run Time From Power ON

To ta l Ti me

XXXX (Hours)

Fixture Total Run Time

Last Clear

XXXX (Hours)

Clear Fixture Last Run Time

Timer PIN

PIN= 066

Enter PIN to Access Clear Last. Menu

Clear Last

ON / OFF

Reset Fixture Last Run Time

Tem p. I nfo

Head Temp.

XXX F° / C°

Tem p er at ur e in F ix ture H ea d

Error Info

Error Record 1 ~ Error Record 10

Display 10 Recent Error Messages

Model. Info

ChorusLine16

Display Model Name

Software Version

1U01 - 5U01

≥V1.08

Software Versions

14

DMX CHANNEL FUNCTIONS AND VALUES

Supports Software Versions: ≥ V1.08

Features are subject to change without any prior written notice.

*Direction of effects and Pixel Control depends on orientation of the fixture head and Tilt/Pixel Flip settings.

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

1 1 1

0-255

TILT MOVEMENT [8 BIT]

TILT Movement [127]

2 2

0-255

TILT MOVEMENT [16 BIT]

Fine Control of TILT Movement [127]

2 3

0-255

RED [ALL LEDs]

0 to 100% [255]

3 4

0-255

GREEN [ALL LEDs]

0 to 100% [255]

4 5

0-255

BLUE [ALL LEDs]

0 to 100% [255]

5 6

0-255

WHITE [ALL LEDs]

0 to 100% [0]

3

0-255

RED [PIXEL #1]

0 to 100% [255]

4

0-255

GREEN [PIXEL #1]

0 to 100% [255]

5

0-255

BLUE [PIXEL #1]

0 to 100% [255]

6

0-255

WHITE [PIXEL #1]

0 to 100% [0]

7

0-255

RED [PIXEL #2]

0 to 100% [255]

8

0-255

GREEN [PIXEL #2]

0 to 100% [255]

9

0-255

BLUE [PIXEL #2]

0 to 100% [255]

10

0-255

WHITE [PIXEL #2]

0 to 100% [0]

11

0-255

RED [PIXEL #3]

0 to 100% [255]

12

0-255

GREEN [PIXEL #3]

0 to 100% [255]

13

0-255

BLUE [PIXEL #3]

0 to 100% [255]

14

0-255

WHITE [PIXEL #3]

0 to 100% [0]

15

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

15

0-255

RED [PIXEL #4]

0 to 100% [255]

16

0-255

GREEN [PIXEL #4]

0 to 100% [255]

17

0-255

BLUE [PIXEL #4]

0 to 100% [255]

18

0-255

WHITE [PIXEL #4]

0 to 100% [0]

19

0-255

RED [PIXEL #5]

0 to 100% [255]

20

0-255

GREEN [PIXEL #5]

0 to 100% [255]

21

0-255

BLUE [PIXEL #5]

0 to 100% [255]

22

0-255

WHITE [PIXEL #5]

0 to 100% [0]

23

0-255

RED [PIXEL #6]

0 to 100% [255]

24

0-255

GREEN [PIXEL #6]

0 to 100% [255]

25

0-255

BLUE [PIXEL #6]

0 to 100% [255]

26

0-255

WHITE [PIXEL #6]

0 to 100% [0]

27

0-255

RED [PIXEL #7]

0 to 100% [255]

28

0-255

GREEN [PIXEL #7]

0 to 100% [255]

29

0-255

BLUE [PIXEL #7]

0 to 100% [255]

30

0-255

WHITE [PIXEL #7]

0 to 100% [0]

31

0-255

RED [PIXEL #8]

0 to 100% [255]

32

0-255

GREEN [PIXEL #8]

0 to 100% [255]

33

0-255

BLUE [PIXEL #8]

0 to 100% [255]

34

0-255

WHITE [PIXEL #8]

0 to 100% [0]

16

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

35

0-255

RED [PIXEL #9]

0 to 100% [255]

36

0-255

GREEN [PIXEL #9]

0 to 100% [255]

37

0-255

BLUE [PIXEL #9]

0 to 100% [255]

38

0-255

WHITE[ PIXEL #9]

0 to 100% [0]

39

0-255

RED [PIXEL #10]

0 to 100% [255]

40

0-255

GREEN [PIXEL #10]

0 to 100% [255]

41

0-255

BLUE [PIXEL #10]

0 to 100% [255]

42

0-255

WHITE [PIXEL #10]

0 to 100% [0]

43

0-255

RED [PIXEL #11]

0 to 100% [255]

44

0-255

GREEN [PIXEL #11]

0 to 100% [255]

45

0-255

BLUE [PIXEL #11]

0 to 100% [255]

46

0-255

WHITE [PIXEL #11]

0 to 100% [0]

47

0-255

RED [PIXEL #12]

0 to 100% [255]

48

0-255

GREEN [PIXEL #12]

0 to 100% [255]

49

0-255

BLUE [PIXEL #12]

0 to 100% [255]

50

0-255

WHITE [PIXEL #12]

0 to 100% [0]

51

0-255

RED [PIXEL #13]

0 to 100% [255]

52

0-255

GREEN [PIXEL #13]

0 to 100% [255]

53

0-255

BLUE [PIXEL #13]

0 to 100% [255]

54

0-255

WHITE [PIXEL #13]

0 to 100% [0]

17

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

55

0-255

RED [PIXEL #14]

0 to 100% [255]

56

0-255

GREEN [PIXEL #14]

0 to 100% [255]

57

0-255

BLUE [PIXEL #14]

0 to 100% [255]

58

0-255

WHITE [PIXEL #14]

0 to 100% [0]

59

0-255

RED [PIXEL #15]

0 to 100% [255]

60

0-255

GREEN [PIXEL #15]

0 to 100% [255]

61

0-255

BLUE [PIXEL #15]

0 to 100% [255]

62

0-255

WHITE [PIXEL #15]

0 to 100% [0]

63

0-255

RED [PIXEL #16]

0 to 100% [255]

64

0-255

GREEN [PIXEL #16]

0 to 100% [255]

65

0-255

BLUE [PIXEL #16]

0 to 100% [255]

66

0-255

WHITE [PIXEL #16]

0 to 100% [0]

7 67

COLOR TEMP

8-255

2,700K -7,000K [127]

18

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

6 8 68

COLOR PRESETS

0

OFF [0]

1-4

COLOR PRESET 01

5-8

COLOR PRESET 02

9-12

COLOR PRESET 03

13-16

COLOR PRESET 04

17-20

COLOR PRESET 05

21-24

COLOR PRESET 06

25-28

COLOR PRESET 07

29-32

COLOR PRESET 08

33-36

COLOR PRESET 09

37-40

COLOR PRESET 10

41-44

COLOR PRESET 11

45-48

COLOR PRESET 12

49-52

COLOR PRESET 13

53-56

COLOR PRESET 14

57-60

COLOR PRESET 15

61-64

COLOR PRESET 16

65-68

COLOR PRESET 17

69-72

COLOR PRESET 18

73-76

COLOR PRESET 19

77-80

COLOR PRESET 20

81-84

COLOR PRESET 21

85-88

COLOR PRESET 22

89-92

COLOR PRESET 23

93-96

COLOR PRESET 24

97-100

COLOR PRESET 25

101-104

COLOR PRESET 26

105-108

COLOR PRESET 27

109-112

COLOR PRESET 28

113-116

COLOR PRESET 29

117-120

COLOR PRESET 30

121-124

COLOR PRESET 31

125-128

COLOR PRESET 32

19

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

6 8 68

COLOR PRESETS [continued]

129-132

COLOR PRESET 33

133-136

COLOR PRESET 34

137-140

COLOR PRESET 35

141-144

COLOR PRESET 36

145-148

COLOR PRESET 37

149-152

COLOR PRESET 38

153-156

COLOR PRESET 39

157-160

COLOR PRESET 40

161-164

COLOR PRESET 41

165-168

COLOR PRESET 42

169-172

COLOR PRESET 43

173-176

COLOR PRESET 44

177-180

COLOR PRESET 45

181-184

COLOR PRESET 46

185-188

COLOR PRESET 47

189-192

COLOR PRESET 48

193-196

COLOR PRESET 49

197-200

COLOR PRESET 50

201-204

COLOR PRESET 51

205-208

COLOR PRESET 52

209-212

COLOR PRESET 53

213-216

COLOR PRESET 54

217-220

COLOR PRESET 55

221-224

COLOR PRESET 56

225-228

COLOR PRESET 57

229-232

COLOR PRESET 58

233-236

COLOR PRESET 59

237-240

COLOR PRESET 60

241-244

COLOR PRESET 61

245-248

COLOR PRESET 62

249-252

COLOR PRESET 63

253-255

COLOR PRESET 64

20

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

7 9 69

SHUTTER / STROBE

0-31

LED OFF

32-63

LED ON

64-95

Strobe Effect SLOW to FAST

96-127

LED ON

128-159

Pulse Effect in Sequences

160-191

LED ON

192-223

Random Strobe Effect SLOW to FAST

224-255

LED ON [255]

8

10

70

0-255

DIMMER INTENSITY

Dimmer 0 to 100% [0]

9

11

71

0-255

DIMMER INTENSITY FINE

Dimmer FINE Adjustment [0]

10

12

72

0-255

ZOOM

Zoom 0% (7 Degrees) to 100% (42 Degrees) [127]

11

13

73

PROGRAM MACROS NOTE: Color Must Be Selected To
Engage Macros.

0

LEDs ON [0]

1-14

LEDs OFF

15-30

PROGRAM MACRO 01

31-46

PROGRAM MACRO 02

47-62

PROGRAM MACRO 03

63-78

PROGRAM MACRO 04

79-94

PROGRAM MACRO 05

95-110

PROGRAM MACRO 06

111-126

PROGRAM MACRO 07

127-142

PROGRAM MACRO 08

143-158

PROGRAM MACRO 09

159-174

PROGRAM MACRO 10

175-190

PROGRAM MACRO 11

191-206

PROGRAM MACRO 12

207-222

PROGRAM MACRO 13

223-238

PROGRAM MACRO 14

239-255

PROGRAM MACRO 15

12

14

74

0-255

PROGRAM MACRO SPEED

SLOW to FAST Speed [0]

13

15

75

PROGRAM MACRO FADE

0

OFF [0]

1-255

LESS to MORE FADE

21

MODE / CHANNEL

VAL UE

FUNCTION

BASIC
CH: 16

STANDARD

CH: 18

EXTEND

CH: 78

14

16

76

DIMMING CURVE MODES

0-20

STANDARD [20]

21-40

STAGE

41-60

TV

61-80

ARCHITECTURAL

81-100

THEATRE

101-255

Default to Unit Setting

15

17

77

TILT MOVEMENT SPEED

0-225

MAX to MIN SPEED [0]

226-235

Blackout By Movement

236-255

NO FUNCTION

16

18

78

LAMP ON/OFF, RESET, INTERNAL PROGRAMS

0-79

Normal

80-84

ALL Motor Reset

85-99

NO FUNCTION

100-119

Internal Program 1 (scene1~8)

120-139

Internal Program 2 (scene9~16)

140-159

Internal Program 3 (scene17~24)

160-179

Internal Program 4 (scene25~32)

180-199

Internal Program 5 (scene33~40)

200-219

Internal Program 6 (scene41~48)

220-239

Internal Program 7 (scene49~56)

240-255

NO FUNCTION [255]

22

PIXEL CONTROL

The starting pixel position can be flipped to the opposite side of the fixture by selecting
FLIP mode in the FUNCTION / PIXEL sub menu from the control panel.
The fixture features full pixel control in Extended DMX channel mode.
Diagram below illustrates the specific pixel mapping order for both modes.

23

TECHNICAL SPECIFICATIONS

SOURCE

(16) 40W 4-in-1 RGBW LEDs
50,000 Hour Average LED Life*

*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

EFFECTS

Motorized Zoom and 220° Tilt
RGBW Color Mixing and Full Pixel Control
Linear Color Temperature (2,700K - 7,000K)
64 Color Presets and 14 Unique Color Macros
Electronic Strobe and Selectable Dimming Curve Modes

COLOR

RGBW

CONTROL / CONNECTIONS

3 DMX Channel Modes (78 total channels)
DMX, RDM, Kling-Net, Art-Net, sACN Protocol Support
Adjustable Refresh Rate (900-25,000 Hz)
Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
4 Button Touch Control Panel
180° Reversible LCD Menu Display
8 / 16-Bit Resolution Zoom and Tilt Movement
5pin DMX, RJ45 EtherCON, and powerCON Power In/Out

SIZE / WEIGHT

Length: 42.05” (1068mm)
Width: 7.44” (189mm)
Vertical Height: 11.46” (291mm)
Weight: 47.0 lbs. (21.3 kg)

ELECTRICAL / THERMAL

AC 100-250V - 50/60Hz
739W Max Power Consumption
5°F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS

CE | IP30

Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.

24

DIMENSIONAL DRAWINGS

Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.

25

OPTIONAL ACCESSORIES

ORDER CODE

ITEM

DRCCL16

9-Pack Road Case for Chorus Line 16

NARROW CLAMP

Heavy Duty Wrap Around Hook Style Clamp

SCABLE 60

60 lbs. Rating 24 Inch Safety Cable

AC5PDMX5PRO

5 ft. (1.5m) 5pin PRO DMX Cable

PLC3

3 ft. (1m) PowerCON PRO Link Cable

Additional Cable Lengths Available

26

FCC STATEMENT

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

FCC RADIO FREQUENCY INTERFERENCE WARNINGS & INSTRUCTIONS

This product has been tested and found to comply with the limits as per Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This device uses and can radiate radio frequency energy and, if not installed
and used in accordance with the included instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television reception, which
can be determined by turning the device off and on, the user is encouraged to try to correct the
interference by one or more of the following methods:

•! Reorient or relocate the device.

•! Increase the separation between the device and the receiver.

•! Connect the device to an electrical outlet on a circuit different from which the radio receiver is connected.

•! Consult the dealer or an experienced radio/TV technician for help.

27
