Elastix NLX-microUCS Quick Start Manual

Quick Start Guide V.02.10

NLX-microUCS APPLIANCE

Unified Communications Server

Quick Start Guide

2

Quick Start Guide

3

Introduction

The Elastix NLX-microUCS appliance puts at your fingertips all the tools you need
to handle your communications requirements: from telephony, to email, fax, IM,
and more. Information related to the Elastix software and updates can be found at
www.elastix.com

This guide

This guide offers important information about the NLX-microUCS, including
technical specifications and steps to getting started using your new appliance.

Package contents

1 Appliance
2 AC Adapter

(with interchangeable clips)

3 Read This First sheet

Technical Specifications

*: Represents an estimate in a basic scenario. For more information visit http://elx.ec/benchmark

Default Settings

Table 1 below lists the default configurations each NLX-microUCS comes pre­installed with.

PARAMETER

VALUE

Networking

Hostname

elx.localdomain.com

Primary DNS

192.168.1.1

eth0 (static)

IP Address

192.168.1.251

Netmask

255.255.255.0

Gateway

192.168.1.1

Log In credentials

Admin Interface (webUI)

Username

admin

Password

palosanto

Linux console Username

root

Password

palosanto

MySQL Username

root

Password

palosanto

Serial Console connection

Bits per second

115200

Data bits

8

Parity

None

Stop bits

1

Flow control

None

Table 1. NLX-microUCS Appliance Default Settings

Physical

• Height 1.11” (28.3 mm)

• Width 6.49” (165 mm)

• Depth 3.77” (95.8 mm)

• Weight 0.25 Kg (0.55 lb)

Hardware

• CPU 400 MHz

• RAM 256 MB

• Hard Drive 8 GB (SD)

• Network Interface 1 x 10/100 Mbps Ethernet

• USB Ports 1

• Other ports Serial Console

Software

• Operating System Elastix lite (32 bits)

Telephony

• Extensions Up to 15 *

• Concurrent Calls Up to 4 *

Power Supply

• Nominal Power 3 W

• Operating Voltage 110-220 V Auto switching
