Elastic Networks StormPort 400 Installation Manual
Elastic Networks
StormPort 400 Modem
Installation Guide
Document Version: Standard
Document Revision: 1.00
Publication Date: September 2000
08-01137-01
2
©2000 Elastic Networks
The StormPort 400 Modem Installation Guide is copyrighted and all rights are reserved. This document
maynot,in whole orin part,be copied,photocopied,reproduced,translated,or reducedtoany electronic
mediumor machinereadableform withoutprior consentin writingfrom Elastic Networks.EtherLoop is
a trademark of Elastic Networks. IBMis thetrademarkofInternational Business Machines,
Incorporated; Windows95,WindowsNTand Windows 3.1 are trademarks of Microsoft, Incorporated;
Quadra 610,OS7.5, Mac, and Macintosh aretrademarks of Apple Computer.
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
Elastic Networks
StormPort 400 Modem
Installation Guide
Publication Number: 08-01137-01
Document Version: Standard
Document Revision: 1.00
Publication Date: September 2000
2000 Elastic N et work s
All rights reserved
Allinformationcontainedinthisdocumentis subjecttochangewithoutnotice. E lasticNetworksreservesthe rightto makechanges
to equipment design or program components, as progress in engineering, manufacturing methods, or other circumstances may
warrant.
EtherLoop is a trademarkof ElasticNetworks.
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
ii
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
Publication history
September 2000
Document revised to reflect changes in the modem name from "Elite" to
"StormPort 400."
June 2000
Document revised to reflect changes in the type and usage of Inline and
Wall Mount filters.
April 2000
Standard document released for general publication.
November 1999
Standard document (Revision 1.00) released for general publication.
October 1998
Standard document initial release for general publication.
iii
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
iv
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
Contents
About this document vii
Safety Considerations vii
StormPort 400 Modem Requirements viii
Installing the StormPort 400 Mo dem 1-1
The StormPort 400 Modem 1-2
Materials I nc luded w ith the StormPort 400 Modem 1-3
Installing the Modem 1-5
Dip S witches 1-6
LED Panel 1-6
Installing the Inlin e Filter 1-8
Appendix A: Troubleshooting A-1
Appendix B: Regulatory Information B-1
FCC Compliance Information B-1
FCC Information to User B-2
Industry Canada Compliance Information B-4
v
Customer Instructions B-2
Appendix C. Warranty and Disclaimers C-1
Coverage C-1
Exclusions C-2
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
vi Contents
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
vii
About this document 1-
This document provides instructions for installing, using and troubleshooting
the StormPort 400 Modem. Before installing or using the modem, be sure to
read the Safety Considerations and StormPort 400 Modem Requirements in
this section.
Safety Considerations
!
The StormPort 400 Modem complies with the regulatory requirements of CSA
C22.2#950-M95 for Canada and UL 1950 Edition 3 for the United States.
Although this product is designed with your complete safety in mi nd, there are
precautions you should adhere to for your individual safety as well as the saf ety
of your equipment. These precautions include, but are not limited to th e
following:
• Read and understand all instructions.
• Place your m odem on a stable surface. Dropping the modem can cause
damage that is not covered under the m anufacturer’s warranty.
• Donotdisassemble the modem! Opening the unit may expose you to electrical
shock!
• Use caution when installing or modifying telephone lines.
• Do not use modem near water to avoid shock hazard.
• Never install telephon e jacks in wet lo ca tions unless the jack is specifically
designed for wet locations.
• Never touch uninsulated telephone wires or terminals unless the telephone
line has been disconnec ted.
• Avoid installing telephone wiring during an electrical storm.
• Do not place objects on top o f modem.
Revision 1.00 StormPort 400 Modem Installation Guide 08-01137-01
