D400/D401 INSTALLATION MANUAL
SOME DETACHABLE POWER CORD SOCKETS HAVE THIS FUSE SYMBOL
WHICH INDICATES THERE IS A REPLACEABLE FUSE WITHIN THE SOCKET.
FOR SAFETY PURPOSES REPLACE ONLY WITH SPECIFIED FUSE.
IMPORTANT SAFETY INFORMATION
Read Information—All the safety and operating information should be read before the appliance is operated.
Follow Information—All operating and use information should be followed.
Retain Information—The safety and operating information should be retained for future reference.
Heed Warnings—All warnings on the appliance and in the operating instructions should be heeded.
Wall Mounting—Mounting of this appliance should be done only by an authorized installer.
Ventilation—The appliances should be situated so that their location or position does not interfere with their proper ventilation.
These appliances should never be placed near or over a radiator or heat register. These appliances should not be placed in a built-in
installation such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.
Non-Use Periods—Appliances that are left unattended and unused for long periods of time should be de-energized.
Power Sources—The appliances should be connected to a power supply only of the type described in the operating instruc-
tions or as marked on each appliance. If you are not sure of the type of power supply to your home, consult your authorized ELAN dealer
or local power company.
Grounding or Polarization—Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one blade
wider than the other blade. A grounding type plug has two blades and a third grounding prong. The polarized wide blade and the third prong are provided for your safety. If the
provided plug does not fit your outlet, consult an electrician for replacement of the obsolete outlet.
© ELAN Home Systems 2005 • All rights reserved. Page 1
D400/D401 INSTALLATION MANUAL
ELAN HOME SYSTEMS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Water and Moisture—To reduce the risk of electric shock or fire, these appliances should not be used near water ––for
example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
Power Cord Protection—Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point where they
exit from the apparatus.
Telephones—Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of
electrical shock from lightning. Do not use a telephone to report a gas leak if the leak is in the vicinity of the ELAN electronic equipment
because of risk of fire or explosion.
Cleaning—Unplug the apparatus from the power outlet before cleaning. Use only a dry cloth to clean the apparatus.
Power Lines—An outdoor antenna should be located away from power lines. When installing an outside antenna system, extreme
care should be taken to avoid touching power lines or circuits, as contact with them may be fatal.
Outdoor Antenna Grounding—If an outside antenna or cable system
is connected to these audio products, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the U.S. National Electrical Code, and Section 54 of the
Grounding
Diagram
ANTENNA
LEAD-IN WIRE
Canadian Electrical Code, provide information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode.
See the grounding diagram (right).
Overloading—Do not overload wall outlets and extension cords, as this could
result in fire or electric shock.
Object and Liquid Entry—Never insert objects of any kind through the
NEC - NATIONAL ELECTRICAL CODE
CEC - CANADIAN ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMPS
ANTENNA LEAD-IN WIRE
(CEC SECTION 54-200)
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(CEC SECTION 54-200)
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(CEC SECTION 10-700)
(NEC ARTICLE 250, PARTH)
openings of these appliances, as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Care should be taken so that
objects do not fall and liquids are not spilled into the appliance through openings in the enclosure.
Servicing—Do not attempt to service these appliances yourself, as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
Damage Requiring Service—These appliances should be serviced by qualified service personnel when:
• A power supply connection or a plug has been damaged or
• If liquid has been spilled into the appliance or objects have fallen into the appliance or
• The appliance has been exposed to water or moisture or
• The appliance does not appear to operate normally or exhibits a marked change in performance or
• The appliance has been dropped or the enclosure damaged.
Replacement Parts—When replacement parts are required, be sure the service technician has used replacement parts speci-
fied by the manufacturer or that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards. The Master Control Unit battery should be replaced only after turning the power off and only by an authorized
installer.
Safety Check—Upon completion of any service or repairs to this audio product, ask the service technician to perform safety
checks to determine that the audio product is in proper operating condition.
Lightning Storms—Unplug this apparatus during lightning storms or when unused for long periods of time.
Attachments and Accessories—Use only attachments/accessories specified by the manufacturer.
Cart, Stand, Tripod, Bracket or Table—Use only with a cart, stand, tripod, bracket or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip over.
Disconnect Device—Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device
shall remain operable.
Page 2 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
D400/D401 INSTALLATION MANUAL
Table of Contents
Safety Information ............................................................................................................ 1
1. Introduction ................................................................................................................. 4-7
D400 Front/Rear ............................................................................................................. 5
Specifications ................................................................................................................. 5
Features .......................................................................................................................... 6
Class ‘T’ Explained ......................................................................................................... 7
2. Connections and Applications ......................................................................... 8-15
Multiple Stereo Speakers .............................................................................................. 8
Multiple Mono Speakers .................................................................................................... 9
Powering a Passive Subwoofer ................................................................................... 10
Powering a Passive Subwoofer w/ Satellite Speakers ............................................... 11
System Expansion - Stereo ......................................................................................... 12
System Expansion - Mono .......................................................................................... 13
Volume Controls ........................................................................................................... 14
Parallel Speaker Outputs ............................................................................................. 14
Triggers ......................................................................................................................... 15
3. Setup ............................................................................................................................... 16
4. Troubleshooting .......................................................................................................... 18
Warranty .................................................................................................................Back Page
2428 Palumbo Dr.
Lexington, KY USA 40509
Voice 859-269-7760
Tech Support 800-622-3526
www.elanhomesystems.com
© ELAN Home Systems 2005 • All rights reserved. Page 3
D400/D401 INSTALLATION MANUAL
1. Introduction
Thank You!
Thank you for purchasing this unique product.
The ELAN D400 Digital Power Amplifier has been
designed specifically for custom installers to
provide a perfect solution for multi-room, wholehouse applications. Two channels of clean, powerful audio can be loaded with multiple speakers
to create a low-impedance, high power scenario;
perfect when high volume is required. ‘Class-T’
Digital Technology and ACE™ (Automatic Clip
Eliminator™) allow efficient use of power, ensuring
clean, accurate audio at all volume levels in any
application.
The ELAN Story
Located in Lexington, KY, USA, ELAN Home
Systems has designed innovative multi-room
audio/video systems since 1989. ELAN systems
were the first to integrate music, intercom and TV
distribution features that used the homeowner’s
stereos, telephones, and televisions to create the
whole-house entertainment experience. These
systems allow people to move from room to room,
controlling centrally located equipment with ease
ELAN’s product line includes:
• Power Amplifiers
• Multi-Room Controllers
• Intelligent Keypads
• LCD Color Touch Panels
• In-Wall and In-Ceiling Speakers
• Outdoor Speakers
• System Controllers
• Volume Controls
• Telephone-Based Intercom Controllers
• Video Switchers
• Digital Music Management Systems
• Accessories for Home Systems Installation
ELAN has introduced nearly 300 new products in
the last eight years and has been honored with
over 50 industry awards.
ELAN HOME SYSTEMS
Safety Concerns
Use only grounded outlets when powering this
product. Making any modification to the power
cord could cause unsafe operation and will void
the manufacturer's warranty.
AC Power Considerations
The D400 requires 7 Amps of AC currect. When
designing any whole house system using multichannel amplifiers, make sure to provide adequate provisions for all electronic equipment to
be installed. This may require additional outlets
and/or circuit breakers to be installed. Consult a
licensed electrician in this case.
ALL CONNECTIONS SHOULD BE MADE
WITH THE AMPLIFIER TURNED OFF
AND UNPLUGGED FROM POWER.
DAMAGE CAN OCCUR TO EQUIPMENT
IF IMPROPER CONNECTIONS ARE MADE!
THIS AMPLIFIER IS NOT BRIDGEABLE!
DO NOT TRY TO BRIDGE
OR COMBINE OUTPUTS!
DAMAGE TO THE AMP WILL OCCUR.
Page 4 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
D400 Front/Rear
D400/D401 INSTALLATION MANUAL
D400 Front
D400 Rear
Power
Switch
AC Power
Plug
Blue Signal
Presence
LEDs
L
L
R
Red Channel
Clipping
LEDs
Channel Select
Down/Up
Buttons
RR
Speaker
Outputs
Channel
Display
CH 2
L
Select
ALL ON
Trigger
Volume
Level
Display
VOL 54
Trigger
Out
Volume
Down/Up
Buttons
Power
LED
Line Inputs/
Loop Outputs
Specifications
Audio Section
Power Rating - RMS
Output Power . . . . . . 2 x 80W RMS @ 8 Ohms (Both Channels Driven)
Output Power . . . . . 2 x 135W RMS @ 4 Ohms (Both Channels Driven)
Output Power . . . . . 2 x 200W RMS @ 2 Ohms (Both Channels Driven)
Frequency Response . . 20Hz to 20kHz, +/-.5dB into 8 Ohms
Full Power Bandwidth . . . . . . . . . . . . . . . . . . 10Hz to 50kHz
Signal-To-Noise . . . . . . . . . . . . . . . . . . > 102dB (A-weighted)
Channel Separation . . . >-70dB (channel to channel @1kHz)
Total Harmonic Distortion . . . . . . . . . . . . . . . < .01% @ 1kHz
< 0.04% @ 10kHz
Intermodulation Distortion . . . . . . . . . . . . . . . . . . . . .< 0.1%
Voltage Gain (AV) . . . . . . . . Continuously Variable from 0 - 27
Slew Rate . . . . . . . . . . . . . . . . . . . . . . . . > 20V/microsecond
Input Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . 49k Ohms
Input Sensitivity . . . . . . 0.9V RMS (150W @ 4 Ohms-Vol Max)
© ELAN Home Systems 2005 • All rights reserved. Page 5
Connectors
Input/Loop Outputs . . . . . . . . . . . . . . . . . . .Gold RCA Phono
Speaker Output . . . . . . . . . . . . . . . . .Five-Way Binding Posts
Power
AC Power Requirements . . . . . . . . . . . . 120 VAC, 750 Watts
Power Supply . . . . Ultra-High Efficiency Toroidal Transformer
Triggers
Remote Trigger Inputs . . . . . . . . . . . . . . . . . 5 to 24 Volts DC
Trigger Loop Output . . . . . . . . . . . . . . . . . . . . +12VDC @0.1A
Dimensions/Weight
Dimensions. . . . . . . . 17 x 1¾ x 15 (in)/43.18 x 4.46 x 38.10 (cm)
Rack Face . . . . . . . . . . . . . . . . . 19 X 1¾ (in)/48.26 x 4.46(cm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 lbs/10 kg
D400/D401 INSTALLATION MANUAL
Features
‘Class-T’ Design
‘Class-T’ Digital Technology allows the D400 to
deliver its full rated power from both channels
simultaneously and is 85% efficient so that the
amplifier does not waste energy producing excessive heat.
ELAN HOME SYSTEMS
Digital Level Set/Lockout
All channel levels are matched to within 0.3dB,
making setup easy, accurate, and repeatable.
Level settings are stored within the D400's nonvolatile memory upon exiting setup. This means
that settings are preserved even when a power
outage occurs.
ACE™ (Automatic Clip Eliminator)
Microprocessor-controlled dynamic leveling circuit
eliminates clipping without audio degradation typical with traditional compressor-based clipping circuits. Each amplified output is continuously monitored for signal clipping. Extremely fast transients
are ignored but if ACE sees a consistent clipping
trend, it turns the respective channel down by one
increment. This action is repeated until no more
clipping is detected. Once clipping is absent for
five seconds, ACE will slowly and unnoticeably
begin to restore the original gain settings. This
translates into accurate, high quality audio reproduction at all volume levels.
Vacuum Florescent Display
Blue Signal Presence LEDs show when audio is
present on each input. Red Clipping LEDs indicate distortion, and make fine tuning the amplifier
very straightforward. The Signal Level and Power
LEDs feature adjustable brightness.
A special multi-button key press can be used
to lock the volume settings so that they can not
be tampered with. The user may view their settings when the system is locked, but is unable to
change them.
Advanced Amplifier Protection
Each channel of the D400 is coupled to its respective modular speaker terminal via a high-power
relay. If the processing circuitry senses a fault
condition (over heating, shorted output, etc.), it will
completely disconnect the amplifier channel from
the output load. Faulted conditions will be indicated on the front panel display. After powering down
and finding and correcting the problem causing the
fault condition, the D400 will resume normal operation upon power up.
Single Rack Height Design
The D400’s single rack height design uses space
very efficiently while still producing an abundance
of power.
Page 6 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
‘Class-T’ Digital Technology
Explained
The ultimate objective of any audio amplifier
design is to make a high fidelity amp with high
efficiency and high reliability. There are several
basic audio power amp topologies that have been
developed to attain these objectives: Class-A,
Class-B, Class-AB, Class-H, Class-G and
Class-D are the most common. The D400 utilizes proprietary Class-T topology from Tripath™.
Class-T combines the best attributes of several of
these designs and minimizes deficiencies in each
design, as well.
Class-A, Class-B and Class-AB amps have been
around for over fifty years. Basically, these classifications designate the amount of time that the
amp’s output devices conduct during one full cycle
of a periodic signal. Class-A amps are in a state
of conduction 100% of the time. Class-B amps
have a complimentary pair of outputs, which are
biased so that each output is conducting only 50%
of the time. Class-AB amps also have complimentary output pairs but they are biased so that each
output is conducting slightly more than 50% of the
time: this lowers crossover distortion. The vast
majority of audio amps in use today are Class-AB.
A well-designed Class-AB amplifier has good linearity (high fidelity) and poor efficiency (less than
50%). Class-H and Class-G are both voltage-supply varying techniques which are usually applied to
Class-AB type, linear amplifiers. These techniques
give marginal improvement in efficiency at the cost
of a more complex and less reliable power supply.
Class-D amplifiers use output devices which
switch on and off at a fixed frequency. This frequency is usually more than ten times higher than
the highest frequency to be amplified. A passive
filter reconstructs the wave form passing through
the amplifier and removes switching artifacts
that distort sound. Class-D amplifiers use output
devices that are either ON or OFF; never in a state
of mid-conduction. This mid-conduction state is
what causes linear switching amplifiers to be as
inefficient as they are (less than 50% efficiency).
Class-D amplifiers are approximately 85% efficient:
a 35% increase!
D400/D401 INSTALLATION MANUAL
ON/OFF timing results and crossover distortion
issues. Ground Bounce caused by high-current
switching of the output transistors manifests itself
as noise on the audio output. In some Class-D
amplifiers, this high-frequency noise is not completely filtered out, resulting in high frequency
distortion.
Advantages of Class-T Design
Class-T is a combination of Adaptive Digital Signal
Processing and Spread-Spectrum Switching. This
design takes the efficiency of a Class D amp and
combines it with the fidelity of a Class AB amplifier
by dramatically improving signal integrity.
Class-T offers the following improvements over
Class-D:
1. Class-D has a fixed output switching frequency.
Class-T has an adaptive switching frequency
which is dependent upon both input signal
frequency and magnitude. Switching artifacts
are removed in this way, reducing distortion.
The switching signal is constantly being
optimized to match the input signal in order to
yield the highest possible fidelity.
2. Class-D amplifiers have nominal switching
frequencies between 200kHz and 300kHz which
creates artifacts in the 20 to 50kHz audio band.
This can be heard as audible noise. Class-T
amplifiers have nominal switching frequencies
between 600kHz and 700kHz; artifacts from this
frequency are not audible.
3. Class-T design constantly monitors the output
transistors and adaptively corrects for varia tions between and within these transistors.
The Class-T design also monitors and corrects
for ground bounce that the transistors produce
when switching large currents.
4. Typical power efficiency with a Class-T amplifier
is 85% (unreachable by Class-AB amps).Typical
THD + Noise is less than 0.04% (unreachable
by Class-D amps.) Truly the best of both worlds!
As mentioned, each of these amplifier designs
has drawbacks. Class-D amps have tendencies
toward high distortion rates. Crossover distortion, ground bounce, and high frequency artifacts
create most of the distortion in these designs.
Imperfectly matched transistors lead to inexact
© ELAN Home Systems 2005 • All rights reserved. Page 7
D400/D401 INSTALLATION MANUAL
2. Connections & Applications
ELAN HOME SYSTEMS
Multi-Speaker Applications
The D400 is specifically designed for multi-speaker applications. This amplifier is two Ohm stable
and provides three sets of speaker terminals for
easy connection of multiple speakers. With coolrunning Class-T Digital Technology, Buffered Loop
Outputs, and advanced Trigger options, the D400
can provide ample power for even the most power
hungry applications.
WIRING CONSIDERATIONS
Speaker Wires
Audio Cables RCA Type Patch Cables
Triggers 2 Conductor Wire
w/ Mono Mini-Plug
14-18 AWG Speaker Wire
Multiple Stereo Speakers in a Zone
The D400 is set up to easily power three stereo
pairs of eight Ohm speakers (or any other combination that adds up to more than a two Ohm load).
This makes it ideal for powering large areas with
multiple speakers that will all play the same audio
signal. Examples include large outdoor areas,
ballroom/party rooms, gymnasiums, hallways, or
any other area with multiple speakers.
Audio
Source
D400 Rear
L
R
RCA Patch
Cables
Multiple-Speaker Stereo Zone
• Audio Source to Line Inputs
• All Speakers Ramp Volume Up/Down
Simultaneously
Page 8 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
Multiple Mono Speakers in a Zone
Use RCA Y Cables to connect the D400's Input and Buffered Loop Output as
shown below to create 6 mono channels. This is particulary useful for large
areas where stereo imaging is not possible.
D400 Rear
D400/D401 INSTALLATION MANUAL
Audio
Source
L
R
RCA “Y”
Cable
RCA Mono
Cable
Multiple Mono Speakers
• Use RCA “Y” Cable to Combine L & R Audio
• Audio Source to Line Input 1
• Line Output 1 to Line Input 2
All Speakers Volume Ramps Up/Down Together
© ELAN Home Systems 2005 • All rights reserved. Page 9
D400/D401 INSTALLATION MANUAL
Powering a Passive Subwoofer
Connect one pair of the D400's Speaker Outputs to the speaker Input terminals
of a passive subwoofer as shown below.
D400 Rear
ELAN HOME SYSTEMS
Audio
Source
L
R
RCA Patch
Cables
Subwoofer
HI LEVEL INPUT
Subwoofer
• Audio Source to Line Inputs
• Speaker Outputs 1 & 2 to Subwoofer Hi-Level Inputs
Subwoofer Volume Increases/Decreases w/ Audio Source
Page 10 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
Powering a Passive Subwoofer w/ Satellite Speakers
The high power capabilities of the D400 make it an excellent chice for subwoofer/
satellite (sub/sat) applications. Run a pair of speaker outputs from the D400 to
the subwoofer speaker inputs. Run speaker wire from the subwoofers line-level
Outputs to the satellite speakers as shown below..
D400 Rear
D400/D401 INSTALLATION MANUAL
Audio
Source
L
R
RCA Patch
Cables
HI LEVEL INPUT
Subwoofer
HI LEVEL OUTPUT
Subwoofer/Satellite
• Audio Source to Line Inputs
• Speaker Outputs 1 & 2 to Subwoofer Hi-Level Inputs
• Subwoofer Hi-Level Outputs to Satellite Speakers
Subwoofer/Satellite Volume Increases/Decreases
w/ Audio Source
© ELAN Home Systems 2005 • All rights reserved. Page 11
D400/D401 INSTALLATION MANUAL
System Expansion-Stereo
ELAN Engineers had flexibility and system expansion in mind when they
designed the D400. To add additional stereo rooms or zones to a basic system, simply add an another D400. To expand zones or subzones to include
additional channels of amplification, use the Loop Outputs to send audio to
additional D400s or other amplifiers.
D400 Rear
ELAN HOME SYSTEMS
Audio
Source
L
R
RCA Patch
Cables
D400 Rear
RCA Patch
Cables
System Expansion-Stereo
• Audio Source to Line Inputs of D400 #1
• Line Outputs to Line Inputs of D400 #2
All Speakers Connected to Both Amps Volume
Ramps Up/Down Together
Page 12 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
System Expansion-Mono
To add additional mono rooms or zones to a basic system, simply add an
another D400. Use RCA "Y" cables to combine an audio source's signal to
the inputs of D400 #1. Use a mono RCA cable to send that signal to additional
amplifiers as shown below.
D400 Rear
D400/D401 INSTALLATION MANUAL
Audio
Source
L
R
RCA “Y”
Cable
RCA Mono
Patch Cable
D400 Rear
RCA Mono
Patch Cable
RCA Mono
Patch Cable
System Expansion-Mono
• Use RCA “Y” Cable to Combine L & R Audio
• Audio Source to Line Input 1 of D400 #1
• Line Output 1 to Line Input 2 of D400 #1
• Line Output 2 of D400 #1 to Line Input #1 of D400 #2
• Line Output 1 to Line Input 2 of D400 #2
All Speakers Connected to Both Amps Volume
Ramps Up/Down Together
© ELAN Home Systems 2005 • All rights reserved. Page 13
D400/D401 INSTALLATION MANUAL
Volume Controls
Although it is possible to construct a simple stereo system utilizing one pair of
speakers and a volume control, this amplifier is designed to run best directly
connected to multiple speakers that all ramp volume up and down together.
Most applications that are utilizing the full power potential of this amplfier are
NOT APPROPRIATE for volume controls! Damage may occur to volume controls and the D400 if incorrectly configured.
ELAN HOME SYSTEMS
VCs
Parallel Speaker Outputs
The D400 is a two channel amplifier with six speaker output terminals. Each
pair of terminals is internally wired in parallel with the other pairs. Speaker
outputs 1, 3, and 5 are common; speaker outputs 2, 4, and 6 are common.
Please remember that when additional pairs of speakers are connected to the
amplifier, the impedance drops in half and the output of the amplifier increases
significantly. This is critical when determining the maximum power handling of
a particular speaker.
Parallel
L
L
R
L
RR
Page 14 © ELAN Home Systems 2005 • All rights reserved.
Parallel
ELAN HOME SYSTEMS
r
D400/D401 INSTALLATION MANUAL
Triggers
The ALL ON trigger port automatically un-mutes
the D400 when a 3-24 VDC signal is present and
mutes it when the signal is absent. The Front
Display of the D400 will show “M” when a channel
is in Mute.
The 12 Volt DC Trigger Out is used to turn on other
equipment, additional D400s, other amps, or to
perform automated functions desired by the user.
ALL ON
To Mute/Un-Mute the D400, simply connect a
system-wide 3-24 Volt DC Triggering Source to
the ALL ON Trigger Input using a 3.5mm mono
interconnect cable. Examples of triggering
sources include an ELAN Multi-Zone Controller’s
SYSTEM TRIGGER OUT or REMOTE OUT, an A/V
receiver’s switched outlet connected to a power
supply, or a +12VDC TRIGGER OUT from another
ELAN D Series amplifier.
D400 RearTriggering
Source
TRIGGER OUT
Whenever the D400 is powered On, the TRIGGER
OUT becomes active. This output sends a
+12VDC 100mA signal to other devices with a
Trigger input. Examples of proper usage of the
+12VDC TRIGGER OUT include muting/un-muting
another D Series amplifier, triggering the switched
outlets of a Z•Power Controller, or triggering an IR
sequence using VIA!
D400 #1 Rear
3.5mm Mono
Interconnect
Cable
®
products.
D400 #2 Rear
3.5mm Mono
Interconnect
Cable
D400 #3 Rea
3-24VAC/DC
Trigger Out
3.5mm Mono
Interconnect Cable
TRIGGER INPUTS
ACCEPT
3 TO 24 VDC
© ELAN Home Systems 2005 • All rights reserved. Page 15
D400/D401 INSTALLATION MANUAL
r
3. Setup
ELAN HOME SYSTEMS
Blue Signal
Presence
LEDs
Channel Select
Red Channel
Clipping
LEDs
Down/Up
Buttons
Channel
Select
Display
CH 2
Volume
Level
Display
VOL 54
Volume
Down/Up
Buttons
Powe
LED
Setting Channel Levels
Each amp channel can be individually adjusted
from the front panel. Pressing the C button will
toggle between the amp channels — Left and
Right channels can be adjusted independently.
The C button to the left cycles downward, the one
on the right cycles upward. When the desired
channel is displayed on the front panel, use the V
buttons to adjust the level for the selected channel. The V button to the left lowers the volume,
the one on the right raises the volume. Factory
Default is 50.
Set the levels by first lowering them all the way
down, then raise the volume of any keypads
or volume controls to maximum. Slowly adjust
Volume Up for this channel until the red clipping
LEDs begin to light up, then drop the level one or
two steps. Follow this procedure for all channels.
Lockout Mode
The Lockout feature is designed to disable all front
panel functions. Use this feature once the system is fine-tuned and ready-to-go. By locking the
D400’s front panel, level adjustments cannot be
inadvertantly changed.
To place the D400 in Lockout Mode:
1. With the Front Display dark, Press C- and Vsimultaneously.
2. Continue pressing C- and V-. The Front Display
will show the Volume setting momentarily.
3. Four seconds later, the Front Display will read
LOCK. Release the buttons.
4. Follow the same procedure to Unlock the amp.
Please Note: If the user tries to change settings
while in Lockout Mode, the Front Display will read
“VOLUME LOCK IS ON”.
Page 16 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
Factory Default
When your D400 arrives, it is set to a FACTORY
DEFAULT condition. At some point during the life
of this amplifier it may be necessary to put the
unit back into Factory Default mode. If this unit is
moved to a different location or speaker type or
load are changed, the FACTORY DEFAULT procedure should be used:
1. Turn the D400 OFF using the rear Power
Switch.
2. Turn the unit back ON. The Front Display will
read ELAN.
3. Press and hold C+, C-, V+, and V- (all the
front panel buttons at once) while ELAN is
displayed.
4. The Front Display will now read “FACTORY
DEFAULT”.
The Factory default settings are:
• All channels Volume defaults to 50.
• Lockout feature is Disabled.
• ACE ™ Automatic Clip Eliminator is Enabled.
D400/D401 INSTALLATION MANUAL
Display Brightness Levels
The blue Signal and Power LED brightness levels
on the Display can be increased or decreased
from the Front Panel. Press and hold C+ and V+
to cycle between High, Low, and Off. The red
Clipping LEDs cannot be adjusted.
© ELAN Home Systems 2005 • All rights reserved. Page 17
D400/D401 INSTALLATION MANUAL
4. Troubleshooting
SYMPTOM CAUSE SOLUTION
ELAN HOME SYSTEMS
No Audio From One or More
Channels
2. Break/Short in Speaker Cable Check Continuity of Each Speaker
"M" Flashes on Display,then
Volume Setting
"E" Message Displayed
on Front Panel
Audio “Hum”
Test AC Outl et Using Ground
1. Loose/Bad peaker Cable S
Connection
3. Speaker is defective Swap with Known Good Speaker
4. RCA Patch Cable Defective Swap with Known Good Patch
5. Source not Sending Audio Verify Source is Powered Up and
Channel is in MUTE
Amplifier in Protection Mode
1.Ground Potential Difference
Between Source Components
(Ground Loop)
Check Cable Ends at Binding
Posts and Speaker Te rminals
Cable Using Multimeter.
If Short or Open is Indicated, Check
Wiring for Proper Connections.
Cable.
Playing. Check any Tape Monitor
Settings on A/V Receiver.
Make sure triggering device’s
remote output is connected and
producing voltage.
Find short or low-impedance
condition. Correct overheating or
AC power issues. Once issue is
found and resolved, cycle power to
D400. This
caused by 1. 2.,3., and/or 4 above.
Plug All Sources into Same AC
Outlet.
Tes t e r.
condition could be
2. Faulty/Damaged Cables Check Source Equipment Cables
For Damaged Cables and Faulty
Connections.
3. Faulty Wiring Make Sure Any Volume Controls
Are Not Hooked Up Backwards.
Check for Shorts in Wiring
(See item 2 in “No Audio…”)
Distorted Audio at Normal
Volume Levels
2. Defective/Incompatible
3. Volume Control Miswired Check for Proper Input/Output
1. Input Gain Too Hig h Reduce Gain to the Channel in
Question. Ensure Red Clipping
LEDs are not Pulsing or On
Constantly.
Check for Physical Damage to
Speaker
Speaker
Ensure speakers have an appropriate power rating for amplifier.
connections at Volume Control.
INPUT Comes from Amplifier,
OUTPUT Goes to Speakers.
Page 18 © ELAN Home Systems 2005 • All rights reserved.
ELAN HOME SYSTEMS
Troubleshooting (cont.)
SYMPTOM CAUSE SOLUTION
D400/D401 INSTALLATION MANUAL
Audio is Unclear, Bass
Response Low
Incorrect Source Playing on
Speakers
Amplifier Will Not Power Up
Audio Very Distorted in Areas
Using Volume Controls
Speakers Out of Phase Verify that + of Amplifier goes to +
of Speaker (and – to -) on ALL
Speaker Leads.
1. Source Connected to Wrong
Input of Amplifier
2. Speakers Connected to
Wrong Speaker Outputs
1. Power Switch is OFF Turn it ON. Switch is Located on
2. Circuit Breaker Tripped
3. Remote Turn-On Miswired Ensure That Any Remote Turn On
1. Impedance-Match Settings
Incorrect
2. Using Incompatible Volume
Control
Verify Source Input Connection
Verify Speaker Connections.
Back of Unit.
The D400 Requires 7 Amps of
120VAC Current. Ensure that the
Combined Current Draw of All
Devices on a Circuit Does Not
Exceed the Circuit's Capacity.
Cables are Connected At Both
Ends. A Cable Plugged into the
D400 Remote In, But Not
Connected to a Source's Remote
Out will Remain in Mute Mode.
Volume Controls not recommended
Volume Controls not recommended
s.
Hum in Speakers When Audio
is Not Present
Ground Loop
Use Triggers to Mute Audio Inputs
When Audio is Not Present
© ELAN Home Systems 2005 • All rights reserved. Page 19
D400/D401 INSTALLATION MANUAL
Notes:
ELAN HOME SYSTEMS
Page 20 © ELAN Home Systems 2005 • All rights reserved.
Limited Warranty
ELAN HOME SYSTEMS L.L.C. ("ELAN") warrants the D400/D401 to be free from defects in materials and
workmanship for the period of two years (2 years) from date of purchase. If within the applicable
warranty period above purchaser discovers that such item was not as warranted above and promptly notifies
ELAN in writing, ELAN shall repair or replace the item at the company's option. This warranty shall not apply
(a) to equipment not manufactured by ELAN, (b) to equipment which shall have been installed by other than an
ELAN authorized installer, (c) to installed equipment which is not installed to ELAN's specifications, (d) to equipment which shall have been repaired or altered by others than ELAN, (e) to equipment which shall have been
subjected to negligence, accident, or damage by circumstances beyond ELAN's control, including, but not
limited to, lightning, flood, electrical surge, tornado, earthquake, or other catastrophic events beyond ELAN's
control, or to improper operation, maintenance or storage, or to other than normal use of service. With respect
to equipment sold by, but not manufactured by ELAN, the warranty obligations of ELAN shall in all respects
conform to the warranty actually extended to ELAN by its supplier. The foregoing warranties do not cover
reimbursement for labor, transportation, removal, installation or other expenses which may be incurred in connection with repair or replacement.
Except as may be expressly provided and authorized in writing by ELAN, ELAN shall not be subject to any other
obligations or liabilities whatsoever with respect to equipment manufactured by ELAN or services rendered by
ELAN.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESSED AND IMPLIED
WARRANTIES EXCEPT WARRANTIES OF TITLE, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
ATTENTION: TO OUR VALUED CONSUMERS
To ensure that consumers obtain quality pre-sale and after-sale support and service, ELAN Home
Systems products are sold exclusively through authorized dealers. ELAN products are not sold
online. The warranties on ELAN products are NOT VALID if the products have been purchased
from an unauthorized dealer or an online E-tailer. To determine if your ELAN reseller is
authorized, please call ELAN Home Systems at (859) 269-7760.
2428 Palumbo Drive Lexington, KY 40509
www.elanhomesystems.com
P/N 9900672 REV: A
Loading...
