EKF PC3-ALLEGRO User Manual

User Guide

PC3-ALLEGRO •

CompactPCI

PlusIO CPU Card

Intel

Core™ i7-3xxx Processor Quad-Core (Ivy Bridge)

Document No. 7106 • Edition 31 • 19 June 2017

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Contents

About this Manual ........................................................... 5

Edition History......................................................... 5

Related Documents ..................................................... 6

Nomenclature ......................................................... 6

Trade Marks .......................................................... 6

Legal Disclaimer - Liability Exclusion ......................................... 6

Standards ............................................................ 7

Overview............................................................. 8

Technical Features .......................................................... 10

Feature Summary ..................................................... 10

Performance Rating.................................................... 13

Operating Conditions .................................................. 13

Power Requirements ................................................... 13

Block Diagram........................................................ 14

Top View Component Assembly .......................................... 15

Front Panel Connectors ................................................. 16

Front Panel Switches & Indicators ......................................... 16

On-Board Connectors & Sockets .......................................... 17

Pin Headers .......................................................... 17

Jumpers ............................................................ 17

Microprocessor ....................................................... 18

Thermal Considerations ................................................. 19

Main Memory ........................................................ 20

Graphics Subsystem ................................................... 22

LAN Subsystem ....................................................... 23

Serial ATA Interface (SATA) .............................................. 24

PCI Express® Interface.................................................. 25

Universal Serial Bus (USB) ............................................... 26

Utility Interfaces ...................................................... 26

Real-Time Clock....................................................... 27

SPI Flash ............................................................ 27

Reset............................................................... 28

Watchdog........................................................... 30

Front Panel LEDs ...................................................... 31

PG (Power Good) LED ............................................. 32

GP (General Purpose) LED .......................................... 32

HD (Hard Disk Activity) LED......................................... 33

EB (Ethernet Backplane) LED ........................................ 33

Hot Swap Detection ................................................... 34

Power Supply Status (DEG#, FAL#) ........................................ 34

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Mezzanine Side Board Options ........................................... 35

CompactPCI® PlusIO ................................................... 37

Installing and Replacing Components............................................ 42

Before You Begin...................................................... 42

Installing the Board .................................................... 43

Removing the Board ................................................... 44

EMC Recommendations................................................. 45

Replacement of the Battery .............................................. 46

Technical Reference ......................................................... 47

Local PCI Devices ...................................................... 47

Local SMB Devices ..................................................... 48

Hardware Monitor LM87 ................................................ 49

Board Control and Status Registers ........................................ 50

Write/Read Control Register 0 ....................................... 51

Read/Clear Status Register 0 ........................................ 52

Read/Clear Status Register 1 ........................................ 53

Read PLD Revision Register ......................................... 54

GPIO Usage.......................................................... 55

GPIO Usage QM77 PCH ........................................... 55

Configuration Jumpers ................................................. 57

Configuration PCI Express Switch (DS-P) ............................... 57

Loading UEFI BIOS Setup Defaults (P-GP)............................... 59

Manufacturer Mode Jumper (P-MFG) ................................. 60

RTC Reset (P-RTC) ................................................ 61

Connectors .......................................................... 62

Caution ....................................................... 62

Front Panel Connectors ............................................ 63

DisplayPort Connectors ...................................... 64

Screw Locking Option for mDP Connectors ....................... 66

VGA Video Connector ....................................... 69

USB Connectors ............................................ 70

Ethernet Connectors ........................................ 73

Mezzanine Connectors ............................................ 74

Expansion Interface J-EXP..................................... 75

High Speed Expansion Connector J-HSE .......................... 76

PCI Express® Expansion Header J-PCIE ........................... 78

SDVO/DisplayPort Expansion Header J-SDVO ...................... 79

Pin Headers & Debug ............................................. 83

Front Panel Handle Microswitch Header P-FPH ..................... 83

PLD Programming Header P-ISP ................................ 84

Processor Debug Header XDP1................................. 85

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Backplane Connectors ............................................. 86

CompactPCI

J1 ........................................ 86

CompactPCI

J2 (PlusIO) ...................................... 87

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

About this Manual

This manual describes the technical aspects of the PC3-ALLEGRO, required for installation and system integration. It is intended for the experienced user only.

Edition History

Ed. Contents/

Changes

Author Date

1 User Manual PC3-ALLEGRO, english, preliminary edition

Text #7106, File: pc3_ug.wpd

mib 2013-09-09

2 Error corrected on pg.44 , upper and lower table mib 2013-09-25

3 Reworked section “Watchdog” gn 2013-12-06

4 Power Requirements updated mib 2013-12-11

5 Reworked sections Serial ATA Interface and High Speed Expansion

Connector J-HSE

mib 2014-01-10

6 Modified block diagram - RIO SATA configured to 3G by default jj 15 January 2014

7 Table Feature Summary updated jj 17 February 2014

8 Table Power Requirements updated mib 3 April 2014

9 Table CompactPCI J2 updated mib 20 June 2014

10 Added list of local pci devices, SDVO option removed on J-SDVO mib 21 July 2014

11 Added photos PC3 w. PCL Side Card Assembly jj 31 July 2014

12 Added photo PC3 w. PCL Side Card Assembly Exploded View jj 11 August 2014

13 Added ‘Board Control and Status Registers’, updated links mib 21 August 2014

14 Added note on operation in systems with a 64-bit CompactPCI

backplane mib 4 September 2014

15 Added additional function of HD LED mib 18 September 2014

16 Added Power Requirements mib 12 December 2014

17 Clarified resetting of UEFI BIOS settings to factory defaults gn 16 January 2015

18 Universal V(I/O) on CPCI Interface mib 27 January 2015

19 Added power requirements mib 5 February 2015

20 Updated description of BCSR Status Registers 0 and 1, cleanup section

“Watchdog”

gn 7 April 2015

21 Added photos PC3-ALLEGRO with C47-MSATA & C48-M2 jj 27 May 2015

22 Updated LM87 Information mib 28 May 2015

23 Table 'Feature Summary' BIOS replaced by Firmware (UEFI)

Table 'Reference Documents' UEFI & ACPI specifications

jj 14 August 2015

24 Removed redundant Operating Conditions mib 3 September 2015

25 4HP Front panel illustration fixed marking for backplane Ethernet LED = EB,

added 8HP and 12HP front panel illustrations

jj 23 September 2015

26 Table 'Feature Summary', added RT OS support jj 30 September 2015

27 Completed Information about SATA on J-HSE mib 22 January 2016

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Ed. Contents/

Changes

Author Date

28 Fixed typo in block diagram regarding J2 PCIe resources jj 29 November 2016

29 Screw locking options for mDP connectors jj 13 December 2016

30 Added Celeron® CPU to table 'Feature Summary' jj 6 April 2017

31 Added photo USB cable connector fixation jj 19 June 2017

Related Documents

Related Information PC3-ALLEGRO

PC3-ALLEGRO Home www.ekf.com/p/pc3/pc3.html

PC3-ALLEGRO Product Information www.ekf.com/p/pc3/pc3_pi.pdf

Nomenclature

Signal names used herein with an attached '#' designate active low lines.

Trade Marks

Some terms used herein are property of their respective owners, e.g.

< Chief River, Ivy Bridge, Panther Point, Core i7: ® Intel < CompactPCI, CompactPCI PlusIO, CompactPCI Serial: ® PICMG < Windows XP, Windows 7: ® Microsoft < EKF, ekf system: ® EKF

EKF does not claim this list to be complete.

Legal Disclaimer - Liability Exclusion

This manual has been edited as carefully as possible. We apologize for any potential mistake. Information provided herein is designated exclusively to the proficient user (system integrator, engineer). EKF can accept no responsibility for any damage caused by the use of this manual.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Standards

Reference Documents

Term Document Origin

CFast™ CFast™ Specification Rev. 1.0 www.compactflash.org

CompactPCI

CompactPCI Specification, PICMG® 2.0 R3.0, Oct. 1, 1999 www.picmg.org

CompactPCI

PlusIO

CompactPCI PlusIO Specification, PICMG® 2.30 R1.0, November 11, 2009

www.picmg.org

CompactPCI

Serial

CompactPCI Serial Specification, PICMG® CPCI-S.0 R1.0, March 2, 2011

www.picmg.org

DisplayPort VESA DisplayPort Standard Version 1.1a

January 11, 2008 VESA Mini DisplayPort Connector Standard Version 1 October 26, 2009

www.vesa.org

DVI Digital Visual Interface Rev. 1.0

Digital Display Working Group

www.ddwg.org

Ethernet IEEE Std 802.3, 2000 Edition standards.ieee.org

LPC Low Pin Count Interface Specification, Revision 1.1 developer.intel.com/design/

chipsets/industry/lpc.htm

HD Audio High Definition Audio Specification Rev.1.0 www.intel.com/design/chipsets/

hdaudio.htm

PCI Express® PCI Express

Base Specification 3.0 www.pcisig.com

SATA Serial ATA 2.5/2.6 Specification

Serial ATA 3.0 & 3.1 Specification

www.sata-io.org

UEFI Unified Extensible Firmware Interface

UEFI Specification Version 2.5 ACPI Specification Version 6.0

www.uefi.org

USB Universal Serial Bus 3.0 Specification, Revision 1.0

November 12, 2008

www.usb.org

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Overview

The PC3-ALLEGRO is a rich featured high performance 4HP/3U CompactPCI® PlusIO CPU board, equipped with a 3rd Generation Intel

Core™ i7 Ivy Bridge + ECC (dual- or quad-core) mobile processor based on 22nm technology. The PC3-ALLEGRO front panel is provided with two Gigabit Ethernet jacks, two USB 3.0 receptacles, and two Mini-DisplayPort connectors for attachment of high resolution digital displays, configured e.g. as extended desktop (option VGA).

The PC3-ALLEGRO is equipped with up to 16GB RAM with ECC support. 8GB memory-down are provided for rugged applications, and another 8GB are available via the DDR3 ECC SO-DIMM socket. The PC3-ALLEGRO backplane connectors comply with the PICMG® CompactPCI® PlusIO system slot specification, suitable for a rear I/O module or hybrid CompactPCI® Serial Systems. Several low profile mezzanine modules are available as mass storage solution.

CompactPCI® PlusIO (PICMG 2.30) is a new standard for rear I/O across J2, specified by the PICMG®. High speed signal lines (PCI Express®, SATA, Gigabit Ethernet and USB) are passed from the PC3-ALLEGRO through the special UHM connector to the backplane, for usage either on a PlusIO rear I/O transition module, or CompactPCI® Serial card slots.

CompactPCI® Serial (PICMG CPCIS.0) defines a completely new card slot, based on PCI Express®, SATA, Gigabit Ethernet and USB serial data lines. On a hybrid backplane, both card styles can reside, CompactPCI® and CompactPCI® Serial, with the PC3-ALLEGRO in the middle as system slot controller for both backplane segments.

The PC3-ALLEGRO is equipped with a set of local expansion interface connectors, which can be optionally used to attach a mezzanine side board. A variety of expansion cards is available, e.g. providing legacy I/O and additional PCI Express® based I/O controllers such as SATA, USB 3.0 and Gigabit Ethernet, or a third video output. Most mezzanine side cards can accommodate in addition a 2.5-inch drive.

Typically, the PC3-ALLEGRO and the related side card would come as a readily assembled 8HP unit. As an alternate, low profile Flash based mezzanine storage modules are available that fit on the PC3-ALLEGRO while maintaining the 4HP profile. The C48-M2 module e.g. is equipped with two M.2 SATA Solid State Drives (SSD), suitable for installation of any popular operating system.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Technical Features

Feature Summary

< CompactPCI® PlusIO (PICMG® CPCI 2.30) System Slot Controller < J1 Connector for Full CompactPCI® Classic 32-Bit Support, universal V(I/O) (3.3V or 5V) < J2 Connector (UHM High Speed) for CompactPCI® PlusIO Support < 4 x PCIe < 4 x SATA < 4 x USB < 2 x GbE

< Proven Intel® Mobile CPU Technology < 3rd Generation Intel® Core™ Mobile + ECC CPU, Code Name Ivy Bridge < i7-3612QE Processor 2.1GHz • 35W TDP Standard Voltage Quad-Core < i7-3555LE Processor 2.5GHz • 25W TDP Low Voltage Dual-Core < i7-3517UE Processor 1.7GHz • 17W TDP Ultra Low Voltage Dual-Core <

i5-3610ME Processor 2.7GHz • 35W TDP Standard Voltage Dual-Core

< i3-3120ME Processor 2.4GHz • 35W TDP Standard Voltage Dual-Core < i3-3217UE Processor 1.6GHz • 17W TDP Ultra Low Voltage Dual-Core

< Celeron® 1047UE Processor 1.4GHz • 17W TDP Ultra Low Voltage Dual-Core < Intel®

QM77 Panther Point

Platform Controller Hub (PCH)

< Integrated HD Graphics Engine, 3 Independent Displays, Enhanced Media Processing < Up to 3 Display Configuration (Front Panel: Dual mDP or Single VGA Connector Option) < Max Resolution 2560 x 1600 (DisplayPort), 1920 x 1200 (VGA) < 3rd Display via Side Card PCS-BALLET

< Integrated Memory Controller up to 16GB DDR3 +ECC 1600 < DDR3 +ECC Soldered Memory up to 8GB < DDR3 +ECC SO-DIMM Memory Module Socket up to 8GB

< SATA 6G &3G for Mass Storage < 2 + 2 SATA Channels 6Gbps/3Gbps for Mezzanine Storage Modules (Connector HSE) < CompactFlash® Card with C40-SCFA Mezzanine Module Option (4HP Maintained) < CFast™ Card with C41-CFAST Mezzanine Module Option (4HP Profile Maintained) < SATA 1.8-Inch Solid State Drive with C42-SATA Mezzanine Card Option (4HP Maintained) < Dual mSATA Modules with C47-MSATA RAID Mezzanine Card Option (4HP Maintained) < 4 x SATA RAID Channels to UHM Connector J2, for RIO Module or CPCI Serial Backplane Usage, limited to

3G SATA by CPCI PlusIO Specification

< Hardware RAID Enabled by Marvell 88SE9230 ARM Powered Subsystem < RAID Configuration Level 0/1/10

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Feature Summary

< USB 3.0 XHCI SuperSpeed & USB 2.0 EHCI Support < 2 x USB 3.0 F/P Connectors < 6 x USB 2.0 to Mezzanine Connectors < 4 x USB 2.0 to J2 (Backplane)

< Gigabit Ethernet Controllers < 2 x GbE F/P RJ-45 Jacks < 2 x GbE to Backplane Connector J2

< PCI Express® Based Design for Component Interconnect < PCI Express® for System Expansion by Mezzanine and Backplane or RIO < 4 x PCI Express® Gen2 Lanes to CPCI PlusIO Backplane J2 Connector < 4 x PCI Express® Gen2 Lanes to Mezzanine Connector

< Set of Mezzanine Connectors for Storage Module or Side Card < Legacy I/O Mezzanine Expansion Connector EXP (USB, HD Audio, LPC) < High Speed I/O Mezzanine Expansion Connector HSE (4 x SATA, 4 x USB) < PCI Express® Mezzanine Expansion Connector PCIE (4 Lanes) < Third Display Mezzanine Expansion Connector DP < Variety of Mezzanine Expansion Boards (Side Cards) Available < Most Mezzanines Optionally Equipped with 2.5-Inch Single- or Dual-Drive < Low Profile Storage Modules Maintain 4HP F/P Width < Side Cards with Additional Front Panel I/O Connectors (8HP & 12HP Assembly

< Phoenix® UEFI (Unified Extensible Firmware Interface) with CSM* < Fully Customizable by EKF < Secure Boot on Request < Windows®, Linux and other (RT)OS' Supported

* CSM (Compatibility Support Module) emulates a legacy BIOS environment, which allows to boot a legacy operating system such as DOS, 32-bit Windows and some RTOS'

< Best Suited e.g. for Industrial, Transportation & Instrumentation Applications < Long Term Availability < Rugged Solution < Coating, Sealing, Underfilling Available on Request

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Feature Summary

< Regulation & Environmental < RoHS compliant < EC Regulations EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1) < Operating Temperature: 0°C to +70°C (Industrial Temperature Range on Request) < Storage Temperature: -40°C to +85°C, max. Gradient 5°C/min < Humidity 5% ... 95% RH non Condensing < Altitude -300m ... +3000m < Shock 15g 0.33ms, 6g 6ms < Vibration 1g 5-2000Hz < MTBF 104 x 10

h (11.9 years) @ 50°C

< Designed & Manufactured in Germany < ISO 9001 Certified Quality Management

< RT OS Board Support Packages & Driver < LynxOS - on request < On Time RTOS-32 - on request < OS-9 - on request < QNX 4.x, 6.x - on request < Real-Time Linux (RT Patch) - on request < RTX - on request < VxWorks 6.9 - under development < VxWorks 7.0 - on request < Others - on request

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Performance Rating

tbd

Operating Conditions

Thermal & Environmental Conditions

< Operating Temperature 0°C to +70°C (-40°C to +85°C on Request)

< Storage temperature: -40°C to +85°C, max. Gradient 5°C/min < Humidity 5% ... 95% RH non Condensing < Altitude -300m ... +3000m < Shock 15g 0.33ms, 6g 6ms < Vibration 1g 5-2000Hz

EC Regulations < EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1)

< 2002/95/EC (RoHS)

MTBF 104 x 103 h (11.9 years) @ 50° C

Power Requirements

Board

Load Current [A] at +3.3V (+0.17V/-0.1V) Load Current [A] at +5V (+0.25V/-0.15V)

Maximum Performance

LFM / HFM / Turbo

Windows 7 Idle

LFM / HFM / Turbo

Maximum Performance

LFM / HFM / Turbo

Windows 7 Idle

LFM / HFM / Turbo

PC3-68XX 5.0 / 5.0 / 5.0

2.7 / 2.7 / 2.7

6.9 / 7.1 / 8.7 0.8 / 0.8 / 0.8

PC3-48XX 4.1 / 4.1 / 4.1

2.7 / 2.7 / 2.7

4.3 / 5.1 / 5.5 0.8 / 0.8 / 0.8

PC3-22XX TBD / TBD / TBD

TBD / TBD / TBD

TBD / TBD / TBD TBD / TBD / TBD

PC3-046X

- / 2.65 / -

1.9 / 1.9 / -

- / 2.45 / - 0.7 / 0.7 / -

Intel SpeedStep Frequence Modes LFM: Low Frequency Mode, HFM: High Frequency Mode.

Add 200/600mA (link only/active) @1Gbps per Ethernet Port.

For Intel Celeron-1047UE there is no Turbo Mode at all and no low Frequency Mode at workload.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Block Diagram

Simplified Block Diagram

PC3-ALLEGRO

PICMG CompactPCI PlusIO

®®

CPU Card

Backplane

CompactPCI

PlusIO

PCI

33/66MHz

VGA

Front

Panel

I/O

GbE

DP1

Front Panel Stuffing Alternates -

either Mini DisplayPort or VGA

USB3

82579

SPI

Flash

GbE

PCIe

SPI

DP2

GbE

Intel® Chief River Platform

82574

DDR3 ECC Soldered

DDR3 ECC SODIMM

FDI

DDR3 1333/1600

Dual Channel

up to 16GB

PCIe

Gen3

PCIe

Gen3

DP3

Mezzanine

Side

Card

PCIe

Gen2

Switch

USB2

8608

LPC/Audio/SMB/GPIO

DMI2

4 x 5GT/s

SATA 6G/3G

2/2

GbE

SATA

RAID

USB2

PCIe

PCIe Gen2

PCIe

Gen2

QM77

Mobile

PCH

Panther

Point

Ivy Bridge

ECC

Embedded

Mobile

CPU

2/4-Core

PCIe

to PCI

Bridge

PCI

PCIe Gen3

8112

9230 4

82574

configured

SATA

by default

according

CPCI

PlusIO

specification

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Top View Component Assembly

PC3-ALLEGRO

Ivy Bridge

CPU

2 Channel ECC DDR3

SODIMM ECC DDR3

SDVO/DP

PCIE

EXP

HSE

Dual

GbE

VGA

P-GP

P-FPH

P-RTC

BAT

P-MFG

2 x

USB

3.0

QM77

PCH

Mobile

Soldered ECC DDR3

UHM

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Front Panel Connectors

ETH1/2 Dual Gigabit Ethernet RJ-45 receptacles with integrated indicator LEDs

mDP1/2 Mini DisplayPort digital video output receptacle (VGA connector available as

alternate)

USB1/2 Universal Serial Bus 3.0 type A receptacles

VGA VGA analog video output connector (Mini DisplayPort connectors available as

alternate)

Front Panel Switches & Indicators

EB LED indicating Backplane Ethernet activity

FPH Front Panel Handle with integrated switch (programmable function, power event

button by default)

GP General Purpose bicolour LED

HD LED indicating any activity on SATA ports

PG Power Good/Board Healthy bicolour LED

RST System Reset Button (Option)

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

On-Board Connectors & Sockets

J-EXPT J-EXPB

Utility EXPansion Interface Connector (LPC, USB, HD Audio, SMBus), available either from top (T) or bottom (B) 1) of the board, interface to optional side board

J-HSE High Speed Expansion Connector (4 x SATA, 4 x USB), interface to optional low

profile mezzanine module or side board

J-PCIE PCI Express® Expansion Interface Connector, interface to optional side board

J-SDVO Digital Display Interface Connector (DisplayPort)

J1/J2

CompactPCI

Bus 32-bit (universal V(I/O)), 33MHz, PlusIO

SODM1 204-pin DDR3 ECC Memory Module SDRAM PC3-12800 Socket (ECC SODIMM)

XDP CPU Debug Port

Connector populated on customers request only

Pin Headers

P-FPH Pin header suitable for Front Panel Handle switch cable harness

P-ISP PLD glue logic device programming connector, not populated

Jumpers

DS-P Switches to configure link width and speed on J-PCIE

P-GP Jumper to reset UEFI BIOS Setup to EKF Factory Defaults

P-MFG Jumper to enter Manufacturing Mode, not populated

P-RTC Jumper to reset RTC circuitry (part of PCH), not populated

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Microprocessor

The PC3-ALLEGRO is equipped with Intel® CoreTM i7 or i5 3rd generation mobile ECC processor (code name Ivy Bridge). These low power processors provide integrated graphics and memory controller, which results in a very efficient platform design. The CoreTM processors almost can be considered as a single-chip solution, since all functions of a typical north-bridge have been moved to the CPU.

The CoreTM i7 and i5 processor family includes beside the Standard-Voltage (SV) also several Ultra Low-Voltage (ULV) and Low-Voltage (LV) processors as listed below. The processors are housed in a Micro FC-BGA package for direct soldering to the PCB, i.e. the chip cannot be removed or changed by the user.

The processors supported by the PC3-ALLEGRO are running at core clock speeds up to 2.1GHz for quad core and up to 2.5GHz on dual core devices. Due to Enhanced Intel® SpeedStep® and Intel® Turbo Boost Technology each core can decrease or increase its nominal operating frequency. The clock speed is chosen depending on the power states of the processor cores/graphics engine, the currently required performance, and the actual core temperature.

Power is applied across the

CompactPCI

connectors J1 (3.3V, 5V). The processor core voltage is generated by a switched voltage regulator, sourced from the 5V plane. The processor signals its required core voltage by 7 dedicated pins according to Intels IMVP-7 voltage regulator specification.

Intel® CoreTM Processors Supported

Processor

Number

Physical

Cores

Core Clock nom./max.

Cache Gfx

Clock

Junction

Temp.

TDP CPU ID Stepping SPEC

Code

i7-3612QE 4 2.1/3.1GHz 4MB 650MHz +105°C 35W 306A9h E-1 SR0ND

i7-3555LE 2 2.5/3.2GHz 4MB 550MHz +105°C 25W 306A9h L-1 SR0T5

i7-3517UE 2 1.7/2.8GHz 4MB 350MHz +105°C 17W 306A9h L-1 SR0T6

i5-3610ME 2 2.7/3.3GHz 3MB 650MHz +105°C 35W 306A9h L-1 SR0QK

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Thermal Considerations

In order to avoid malfunctioning of the PC3-ALLEGRO, take care of appropriate cooling of the processor and system, e.g. by a cooling fan suitable to the maximum power consumption of the CPU chip actually in use. The processor contains digital thermal sensors (DTS) that are readable via special CPU registers. DTS allows to get the temperatures of each CPU core separately.

Two further temperature sensors, located in the system hardware monitor LM87, allows for acquisition of the boards surface temperature and the thermal state of the onboard system memory channel. Beside this the LM87 also monitors most of the supply voltages. A suitable software on Microsoft Windows® systems to display both, the temperatures as well as the supply voltages, is Speedfan, which can be downloaded from the web. After installation, both temperatures and voltages can be observed permanently from the Windows® taskbar.

The PC3-ALLEGRO is equipped with a passive heatsink. Its height takes into account the 4HP limitation in mounting space of a

CompactPCI

board. In addition, a forced vertical airflow through the system enclosure

(e.g. bottom mount fan unit) is strongly recommended (>20m

/h or 2m/s (400LFM) around the CPU slot). Be sure to thoroughly discuss your actual cooling needs with EKF. Generally, the faster the CPU speed the higher its power consumption. For higher ambient temperatures, consider increasing the forced airflow to 3m/s (600LFM) or more.

The table showing the supported processors above give also the maximum power consumption (TDP = Thermal Design Power) of a particular processor. Fortunately, the power consumption is by far lower when executing typical Windows® or Linux tasks. The heat dissipation increases when e.g. rendering software like the Acrobat Distiller is executed.

The Core

i7 processors support Intel's Enhanced SpeedStep® technology. This enables dynamic switching between multiple core voltages and frequencies depending on core temperature and currently required performance. The processors are able to reduce their core speed and core voltage in multiple steps down to 1200MHz (800MHz for LV/ULV processors). Additional a reduction of the graphics core clock and voltage is possible. This leads to an obvious reduction of power consumption resulting in less heating. This mode of lowering the processor core temperature is called TM2 (TM=Thermal Monitor).

Another way to reduce power consumption is to modulate the processor clock. This mode (TM1) is achieved by actuating the 'Stop Clock' input of the CPU. A throttling of 50% e.g. means a duty cycle of 50% on the stop clock input. However, while saving considerable power consumption, the data throughput of the processor is also reduced. The processor works at full speed until the core temperature reaches a critical value. Then the processor is throttled by 50%. As soon as the high temperature situation disappears the throttling will be disabled and the processors runs at full speed again.

These features are controllable by BIOS menu entries. By default the BIOS of the PC3-ALLEGRO enables mode TM2 which is the most efficient.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Main Memory

The PC3-ALLEGRO features two channels of DDR3 SDRAMs with support of ECC (Error Correction Code). One channel is realized with 18 memory devices soldered to the board (Memory Down) and delivers a capacity of up to 8GB with a clock frequency of 1600MHz (PC3-12800).

The 2nd channel provides a socket for installing a 204-pin ECC SODIMM module thus allowing a simple expansion of system memory (max. module height = 1.25 inch). Supported are unbuffered DDR3 ECC SODIMMs (72-bit) with VDD=1.5V featuring on-die termination (ODT), according the PC3-12800 specification. Minimum module size is 512MB; maximum module size is 8GB. Please note that standard DDR3 SODIMMs without ECC feature do not work on PC3-ALLEGRO.

It is recommended to add a SODIMM module with same size as the Memory Down to get best performance (some of the system memory is dedicated to the graphics controller). This typically results in a size of 2x4GB of memory which is recommended to run the operating systems Windows® Vista or Windows® 7.

The memory controller supports symmetric and asymmetric memory organization. The maximum memory performance can be obtained by using the symmetric mode. When in this mode, the memory controller accesses the memory channels in an interleaved way. Since CoreTM i7 processors support Intels Flex Memory Technology, interleaved operation isn't limited to systems using memory channels of equal capacity. In the case of unequal memory population the smaller memory channel dictates the address space of the interleaved accessible memory region. The remainder of the memory is then accessed in non-interleaved mode.

In asymmetric mode the memory always will be accessed in a non-interleaved manner with the drawback of less bandwidth. The only meaningful application of asymmetric mode is the special case when only one memory channel is populated (i.e. the SODIMM socket may be left empty).

The contents of the SPD EEPROM on the SODIMM is used by the BIOS at POST (Power-on Self Test) to get any necessary timing parameters to program the memory controller within the chipset.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Top Side Soldered Memory

Bottom Side Soldered Memory

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Graphics Subsystem

The graphics subsystem is part of the Intel CoreTM i7 processor and the PCH QM77. While the graphics controller is located within the CoreTM i7 processor, the different interfaces like DisplayPort and VGA are moved to the PCH. The PC3-ALLEGRO offers two Mini DisplayPort (mDP) interfaces in the front panel.

Adapters to convert Mini DisplayPort to any other popular interface standard are available.

A 3rd DisplayPort is fed to the on-board connector J-SDVO. EKF expansion boards like PCS-BALLET feature the possibility to gain access to the 3rd DisplayPort interface.

As an option, the PC3-ALLEGRO can be equipped with an ordinary HD D-Sub 15-lead connector (VGA style). This connector is suitable for analog signals only. Nevertheless also flat-panel displays can be attached to the D-Sub connector but with minor reduced image quality.

Independent from the video connector actually in use, Mini DisplayPort, DVI or VGA, the VESA DDC standard is supported. This allows to read out important parameters, e.g. the maximum allowable resolution, from the attached monitor. DDC Power, +3.3V or +5V on DisplayPort or VGA connector respectively, is delivered via a resettable fuse to protect the board from an external short-circuit condition (0.5A).

Graphics drivers for the CoreTM i7 can be downloaded from the Intel web site.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

LAN Subsystem

The Ethernet LAN subsystem is composed of four Gigabit Ethernet ports: One Intel 82579LM Physical Layer Transceiver (PHY) using the PCH QM77 internal MAC and three Intel 82574IT Gigabit Ethernet Controllers. These devices provide also legacy 10Base-T and 100Base-TX connectivity. Two of the Ethernet ports are fed to two RJ45 jacks located in the front panel, the others are attached to the

CompactPCI

PlusIO interface on J2. Each port includes the following features:

< One PCI Express lane per Ethernet port (250MB/s) < 1000Base-Tx (Gigabit Ethernet), 100Base-TX (Fast Ethernet) and 10Base-T (Classic Ethernet)

capability.

< Half- or full-duplex operation. < IEEE 802.3u, 802.3ab Auto-Negotiation for the fastest available connection. < Jumperless configuration (complete software-configurable).

Two bicoloured LEDs integrated into the dedicated RJ-45 connector in the front panel are used to signal the LAN link, the LAN connection speed and activity status. A further bicoloured LED in front panel labelled EB displays the state of the backplane network ports.

Each device is connected by a single PCI Express lane to the PCH. Their MAC addresses (unique hardware number) are stored in dedicated FLASH/EEPROM components. The Intel Ethernet software and drivers for the 82579 and 82574 is available from Intel's World Wide Web site for download.

When managing the board by Intel Active Management Technology (iAMT), the dedicated network port to do so is accessible by the RJ45 connector GbE1 (the upper port within the front panel).

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Serial ATA Interface (SATA)

The PC3-ALLEGRO provides a total of eight serial ATA (SATA) ports, derived from two independent SATA controllers. Two of these ports support data transfer rates of 6Gbps (600MB/s) while all ports are capable to work with 3Gbps (300MB/s) or 1.5Gbps (150MB/s).

The SATA controller that is located within the QM77 Platform Controller Hub hold two 6Gbps and two 3Gbps ports which are fed to the high speed expansion connector J-HSE. This connector allows the installation of low profile expansion boards like C41-CFAST or C42-SATA to attach the popular CFast cards or Micro SATA SSDs (1.8-inch) respectively. Another mezzanine is the C47-MSATA, a carrier for two MSATA SSD modules, that is connected via J-HSE to the 6Gbps ports for fast data storage.

Four SATA interfaces are provided by a Marvell 88SE9230 Controller available on the Backplane connector J2. Hardware RAID configuration level 0/1/10 is supported. Please be aware that CompactPCI PlusIO Specefication does not support SATA 6G. Therefore J2 SATA channels are configured as SATA 3G.

A LED named HD located in the front panel, signals disk activity status of any of the SATA devices.

Additionally a variety of side cards is available, suitable for mounting on the PC3-ALLEGRO in a 4HP (20.32mm) distance (resulting in 8HP front panel width for the assembly). Some of these side boards can accommodate a SATA drive, e.g. a 2.5-inch SSD.

Available for download from Intel's web site are drivers for popular operating systems, e.g. Windows® XP, Windows® Vista, Windows® 7 and Linux.

To manage the RAID configuration of the 88SE9230 a Windows® application is provided by Marvell that can be downloaded from EKF’s website.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

PCI Express® Interface

The PC3-ALLEGRO is provided with several PCI Express (PCIe) lanes for I/O expansion. Four PCI Express Gen 2 lanes (5GT/s), originating from the QM77, are available at the backplane connector J2. Another four PCI Express lanes are provided by the Intel CoreTM i7 processor to the J-PCIE connector. A small DIP switch (DS-P) located on the backside of the board are used to configure different lane widths to each of both downstream interfaces and to choose the interface transfer rate. Possible settings are

< Single link x 4 lanes to J-PCIE < Four links x 1 lane to J-PCIE < 2.5GT/s or 5GT/s transfer speed

See section “Configuration PCI Express Switch (DS-P)” for details.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Universal Serial Bus (USB)

The PC3-ALLEGRO is provided with twelve USB ports. All of them are USB 2.0 capable, but two ports, routed to front panel connectors, are also supporting the USB 3.0 SuperSpeed standard.

The USB 2.0 interfaces are distributed to the front panel (two ports), two to the expansion board interface connectors J-EXP, four to the high speed expansion connector J-HSE, and four ports are available across the backplane connector J2.

The front panel USB connectors can source a minimum of 1.5A/5V each, over-current protected by two electronic switches. Protection for the USB ports on the expansion interfaces and on the J2 PlusIO connector is located on expansion boards. The USB xHCI and two EHCI controllers handling the USB port operation at SuperSpeed, high-speed, full-speed and low-speed are integrated into the QM77 PCH.

Utility Interfaces

Besides the high speed mezzanine interface connectors J-HSE and J-PCIE, the PC3-ALLEGRO is provided with the utility interface expansion connector socket J-EXP. This connector comprises several interfaces, which may be useful for system expansion on mezzanine cards, as an option:

< HD Audio < LPC (Low Pin Count) < SMBus < 2 x USB

The SMBus is controlled by the QM77 platform controller hub. The SMBus signal lines on the J-EXP utility expansion connector can be switched on/off under software control (PCH GPIO) in order to isolate external components in case of an I2C address conflict.

The HD Audio port requires an additional audio codec, as provided e.g. on the PCS-BALLET side card.

The LPC bus presents an easy way to add legacy interfaces to the system. EKF offers a variety of mezzanine expansion boards (side cards), to be attached on top of the PC3-ALLEGRO, featuring all classic Super-I/O functionality, for example the PCS-BALLET or the CCO-CONCERT. Access to the connectors PS/2 (mouse, keyboard), COM, USB and audio in/out is given directly from the front panel.

User Guide • PC3-ALLEGRO • CompactPCI® PlusIO CPU Board • Intel® i7-3xxx Processor

Real-Time Clock

The PC3-ALLEGRO has a time-of-day clock and 100-year calendar, integrated into the QM77 PCH. A battery on the board keeps the clock current when the computer is turned off. The PC3 uses a BR2032 lithium battery soldered in the board, giving an autonomy of more than 5 years. Under normal conditions, replacement should be superfluous during lifetime of the board.

In applications were the use of a battery is not permitted, a SuperCap can be stuffed instead of the battery.

SPI Flash

The BIOS and iAMT firmware is stored in flash devices with Serial Peripheral Interface (SPI). Up to 16MByte of BIOS code, firmware and user data may be stored nonvolatile in these SPI Flashes.

The SPI Flash contents can be updated by a DOS or Linux based tool. This program and the latest PC3-ALLEGRO BIOS binary are available from the EKF website. Read carefully the enclosed instructions. If the programming procedure fails e.g. caused by a power interruption, the PC3-ALLEGRO may no more be operable. In this case you would possibly have to send in the board, because the Flash device is directly soldered to the PCB and cannot be changed by the user.

+ 62 hidden pages

EKF PC3-ALLEGRO User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
