EJEAS E200 User Manual

E200

www.ejeas.com

User Manual

Operation method:

1、 Power On: Long Press power button 3 secods,device light shine then headset

have invoice tip of "power on".

2、 Power off : Shortly press power button+volume 0.3s, power off quickly.
3、 paring with mobile : Power off situation , long press "power button" 6 seconds

until red & blue light shining , voice tip and open mobile bluetooth , search E200 ,
press connection with mobile ,then pairing successfully .First pairing successfully ,

Charging port/
Connect with walkie talkie

Earpiece

Power button

Volum button

Microphone

1

Device

TOP

Electricity prompt、Answer/Reject incoming calls、
Hang up call、Last Code Redial

Volum

button

Music play / pause、Last Music、Music stop

Power

button

Call volume adjustment、Voice dialing

Set up intercom、Exit Talkback

Music volume adjustment、Next music

Talkback volume adjustment

next time ,don't need connect again , using it and auto-connecting mobile, or
unconnected and standby , shortly "volume button" , E200 automatic connect
paired mobile.

4.Connect mobile again :power on and auto mati c co nnect , if Connected
successfully has voice tip ,if unconnect , press volume button shortly .(In the
case of the phone has been paired with the second use)

5.Electricity prompt: in the shutdown state , press the power button to start
power prompt.

6.Phone control:
Answer incoming calls: incoming calls automatically (8s later) or call short

press start key.

Reject call: call status, double-click the power button.
Hang up call: call state, short press the power button.
Call volume adjustment: long press the volume key to adjust the volume.
Last Code Redial: Double-click the power button.
Voice dialing: connection standby, double-click the volume key.

7.Music control:
Music play / pause: long press the power button 1s.
Music volume adjustment: long press the volum e ke y to adj ust to the

maximum sound, tone tip within 3 seconds to maintain the maximum sound ,
and then go to the minimum.
Music Up and down: Double-click the power button/double-click the volume
button.

Music stop: long press the power button 1s.

8.pairing &talking:

2pcs E200 connect and talk ,must be paired then talk , 2pcs E200 pair and talk ,
power on , long press volume button 2 seconds , red & blue shine , then shortly
press one of E200 "VOLUME BUTTON". E200 automatic search and pair ,only
blue light shine of 2 pcs E200 when paired successfully , voice tip of pairing
successfully .
Same 2pcs E200 paired successfully would never be paired again , just need
shortly power button .

9.Talkback control:
Set up intercom: short press the power button
Talkback volume adjustment: long press the volume button to cycle adjust

To adjust to the maximum sound , the tone within 3 seconds to maintain
the maximum sound, and then go to the minimum , if the maximum , then
release after the sound, then press the volume key to the minimum volume .
Exit Talkback: Short press the power button.

2

TOP

Description
