MultiEdge Series
15", 1 6" & 17" THIN BEZEL LCD MONITORS
WITH INTEGRATED SPEAKERS
The Compact Way
To Higher Performance
The MultiEdge Series offers corporate and administrative users a selection of LCD monitors that integrate all the key advantages of EIZO’s display technology in a choice of practical
screen sizes.
Primary benefits include a thin bezel design that saves space on the desktop, built-in stereo
speakers for multimedia capability, and digital/analog connectors. Accurate color control and
wide-ranging adjustment of brightness and contrast make it easy to fine-tune the image as required
for the application in use. On performance alone, these monitors are convincing replacements for
17" and 19" CRTs, quite apart from the obvious benefit of their compact size. Flexible placement
options and the thin bezel profile also make them ideal for multi-panel tiling.
Available in three sizes — 15", 16" and 17" — the MultiEdge Series gives an impressive
look to the desktop while delivering the performance quality, space efficiency and greater productivity sought by today’s professional users.
THE MULTI-PANEL ADVANTAGE
The compact design of the MultiEdge Series is ideal for
multi-display systems, because it puts more viewing
area into less workspace and provides near-seamless
viewing between monitors. Enabling several open
applications to be seen simultaneously, such systems
are increasingly recognized as an effective means to
greater productivity. Users can handle more programs,
compare more information, and track more data,
without constant task-switching between windows. In
almost any professional work environment, that saves
space and time while making work much easier.
DIGITAL AND ANALOG INPUT
Inclusion of both DVI-D and D-Sub 15-pin
connectors allows the monitors to be used with a
computer incorporating either
a digital or an analog graph-
DVI-D
Connector
the same time. The user can alternate between the
two connectors via a button on the front bezel.
INTEGRATED SPEAKERS
Space-efficient and multimedia ready,
these monitors feature built-in stereo
speakers with volume and mute controls
and an external headphone jack.
D-Sub 15-pin
Connector
ics card — or both, if two
computers are connected at
ADVANCED COLOR CONTROL
MultiEdge monitors offer an expanded color space
on par with that established by the European
Broadcasting Union. The ColorManagement function, pioneered by EIZO, takes advantage of this
expansion to give the user independent adjustment
and control of hue, gain, saturation and color
temperature.
sRGB MODE
Compatibility with the international sRGB color
space enables color matching with applications and
peripherals like scanners, printers and digital cameras.
This ensures color consistency in daily office tasks as
well as in online shopping, since sRGB is also the
default color space for the Web.
IMAGE CLARITY
Wide viewing angles make sure that the on-screen
image remains bright and clear, with consistent color
levels, even when seen from an oblique position. Contrast and brightness settings are among the highest in
their respective classes, producing more distinct
images with sharper detail.
AUTO ADJUSTMENT
This feature automatically centers the displayed
image via a one-touch button on the front panel.
FREE MOUNT CAPABILITY
Compliance with VESA mounting
standards affords the user the
option of mounting on the wall
or an adjustable arm. Panelintegrated power supply units
make installation easy, since
there is no separate power brick or cord.
LOW POWER CONSUMPTION
All models consume less than half the power required
by a CRT of comparable viewing size. Power saving
functions reduce consumption to less than 3 watts in
standby mode.
MODEL IDENTIFICATION
The ScreenManager® on-screen display
menu shows the model name, serial
number, and total usage hours.
SAFETY LOCK SUPPORT
All models include a slot for
connection of a security cable
(sold separately). The slot supports Kensington’s Microsaver
®
security system.
INTERNATIONAL STANDARDS
The MultiEdge Series satisfies a wide range of current industry standards relating to low emissions,
ergonomics, recycling, safe usage and power management. These include TCO’99, TÜV/Ergonomics, the CE
®
Mark, Energy 2000, and the EPA Energy Star
Program.
PROTECTION SHEETS
Optional high-transparency sheets, available in three
sizes to match each model, protect the screen surface
from dust and scratches.
MultiEdge Series
THIN BEZEL LCD MONITORS WITH INTEGRATED SPEAKERS
Panel Size and Type
Available Cabinet Colors
Pixel Pitch
Display Colors
Viewing Angles
Scanning Frequency (H, V)
Recommended Resolution
Brightness
Contrast Ratio
Response Time
Dot Clock
Input Signals
Input Terminals
Active Display Size (H × V)
Viewable Image Size
Plug & Play
Screen Control
Power Requirements
Power Management
Power Consumption
Power Save Mode
OSD Languages
Dimensions (W × H × D)
Net Weight
Audio
Tilt
Certifications and Standards
Supplied Accessories
FlexScan
43 cm (17") TFT color LCD panel
Gray, Black
0.264 mm × 0.264 mm
16.7 million
H: 170°, V: 170°
Analog: 24.8 – 80 kHz, 50 – 75 Hz
Digital: 31.5 – 64 kHz, 60 Hz (VGA Text: 70 Hz)
1280 × 1024
230 cd/m2 (typical)
400:1 (typical)
40 ms (typical)
Analog: 135 MHz, Digital: 108 MHz
RGB Analog, DVI Standard 1.0
D-Sub mini 15 pin, DVI-D 24 pin (switchable)
338 mm × 270 mm
432 mm (diagonal)
VESA DDC 2B
ScreenManager®,
One Touch Auto Adjustment Function
AC 100 -120V/200-240V, 50-60 Hz
VESA DPMS, DVI-DMPM
45 watts (typical)
Less than 3 watts
English, French, German, Italian, Spanish, Swedish
With Stand: 380 mm × 416 mm × 178 mm
Without Stand: 380 mm × 353 mm × 58 mm
With Stand: 5.8 kg, Without Stand: 4.5 kg
Dual 1-watt built-in speakers,
input/headphone jacks
30° Up, 3° Down
TCO‘991, TÜV/Ergonomics, TÜV/GS,
c-Tick, CE, CB, UL 1950,
CSA C22.2 No.950, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B,
EPA ENERGY STAR®, Energy 2000
AC power cord, user’s manual, signal cable
(D-Sub mini 15 pin), audio cable, 4 screws
for mount option, warranty registration card
®
L565
FlexScan
41 cm (16") TFT color LCD panel
Gray, Black
0.248 mm × 0.248 mm
16.7 million
H: 160°, V: 130°
Analog: 24.8 – 80 kHz, 50 – 75 Hz
Digital: 31.5 – 64 kHz, 60 Hz (VGA Text: 70 Hz)
1280 × 1024
250 cd/m2 (typical)
400:1 (typical)
45 ms (typical)
Analog: 135 MHz, Digital: 108 MHz
RGB Analog, DVI Standard 1.0
D-Sub mini 15 pin, DVI-D 24 pin (switchable)
317 mm × 253 mm
406 mm (diagonal)
VESA DDC 2B
ScreenManager®,
One Touch Auto Adjustment Function
AC 100 -120V/ 200-240V, 50-60 Hz
VESA DPMS, DVI-DMPM
45 watts (typical)
Less than 3 watts
English, French, German, Italian, Spanish, Swedish
With Stand: 370 mm × 398 mm × 157 mm
Without Stand: 370 mm × 333 mm × 54 mm
With Stand: 5.0 kg, Without Stand: 4.0 kg
Dual 1-watt built-in speakers,
input/headphone jacks
30° Up, 3° Down
TCO‘991 , TÜV/Ergonomics, TÜV/GS,
c-Tick, CE, CB, UL 1950,
CSA C22.2 No.950, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B,
EPA ENERGY STAR®, Energy 2000
AC power cord, user’s manual, signal cable
(D-Sub mini 15 pin), audio cable, 4 screws
for mount option, warranty registration card
®
L465
FlexScan
38 cm (15") TFT color LCD panel
Gray, Black
0.297 mm × 0.297 mm
16.7 million
H: 160°, V: 150°
Analog: 24 - 60 kHz, 55 - 75 Hz
Digital: 31.5 - 48 kHz, 60 Hz (VGA Text: 70 Hz)
1024 × 768
300 cd/m2 (typical)
450:1 (typical)
25 ms (typical)
Analog: 80 MHz, Digital: 65 MHz
RGB Analog, DVI Standard 1.0
D-Sub mini 15 pin, DVI-D 24 pin (switchable)
304 mm × 228 mm
380 mm (diagonal)
VESA DDC 2B
ScreenManager®,
One Touch Auto Adjustment Function
AC 100 -120V/ 200-240V, 50-60 Hz
VESA DPMS, DVI-DMPM
35 watts (typical)
Less than 3 watts
English, French, German, Italian, Spanish, Swedish
With Stand: 340 mm × 369 mm × 157 mm
Without Stand: 340 mm × 301 mm × 48 mm
With Stand: 4.1 kg, Without Stand: 3.2 kg
Dual 1-watt built-in speakers,
input/headphone jacks
30° Up, 3° Down
TCO‘991, TÜV/Ergonomics, TÜV/GS,
c-Tick, CE, CB, UL 1950,
CSA C22.2 No.950, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B,
EPA ENERGY STAR®, Energy 2000
AC power cord, user’s manual, signal cable
(D-Sub mini 15 pin), audio cable, 4 screws
for mount option, warranty registration card
®
L365
1
Gray cabinet only.
With current LCD technology, a panel may contain a limited number of missing or flickering pixels.
Specifications are subject to change without notice.
ENERGY STAR is a U.S. registered mark. As an ENERGY STAR® Partner, Eizo Nanao
Corporation has determined that the products specified herein meet the ENERGY STAR
guidelines for energy efficiency.
Published on chlorine-free paper.
Copyright© 2002 Eizo Nanao Corporation. All rights reserved. All product names are
trademarks or registered trademarks of their respective companies. EIZO, FlexScan, and
ScreenManager are registered trademarks of Eizo Nanao Corporation.
(020202) Printed in Japan, 2,2002, 6K
®
