Eizo EV2780 User Manual

27" Ultra Slim Monitor

Increase Connectivity in Style with USB Type-C

USB Type-C with Power Delivery

The FlexScan EV2780 comes with a USB Type-C port. With a
single USB Type-C cable you can transmit both video and
audio signals, transfer data, and also charge a laptop or smart­phone at the same time. What’s more, the EV2780 has an
internal power unit so no external AC adapter is required.

Ultra-Thin Bezels on All Four Sides

The monitor features 1 mm ultra-slim bezels on the sides and top
with black borders of 5.7 mm. Electrostatic switches are placed
on the front of the monitor for easy adjustment of monitor set­tings. Furthermore the bezels are flush with the screen surface,
making a completely flat screen perfect for multi-monitor
configurations.

Top bezel

1 mm

1 mm

Bottom bezel: Old vs New

20. 5 mm

6.7 mm

1 mm

Check compatibility:

http://www.eizoglobal.com/support/compatibility/device/usb-type-c/USB-Type-c-compatibility.pdf

20. 5 mm

15.3 mm

EV2780Previous 27 inch model

1 mm

Best Positioning with Flexible Stand

155 mm

90°

90°

Picture by Picture

The FlexScan EV2780 lets you
view data from two input
sources at once such as a
Windows and a Mac computer
with no distracting bezel in
between.

Windows macOS

Height Adjustment Rotation

30°

Tilt Swivel

5°

344°

30°

Multiple Inputs, Audio, and USB 3.0

HDMI DisplayPort USB Type-C Headphones USB 3.0

Flicker-Free Viewing

Due to the way brightness is controlled on LED backlights, some
people perceive flicker on their screen which causes eye fatigue.
The FlexScan EV series utilizes a hybrid solution to regulate
brightness and make flicker unperceivable without any draw­backs like compromising color stability – even on low brightness
settings.

Auto Brightness Control

To prevent eye fatigue, a brightness sensor called Auto EcoView
detects the changes in the ambient brightness that occurs
throughout the day and automatically adjusts the screen to the
ideal brightness level.

1% - 100% Brightness Range

In a dimly-lit work environment, a monitor with low brightness
settings is more comfortable to use. With its LED backlight, the
monitor is adjustable to 1 cd/m² which is less than 1% of the
maximum.

Significantly Reduce Blue Light

In the visible light spectrum, blue light has wave lengths adjacent
to ultraviolet light. Compared to the factory preset setting of
6500 K of typical LCD monitors, Paper Mode is closer to the
spectral distribution with long reddish wavelengths so it reduces
the amount of blue light, a cause of eye fatigue, and helps
prevent eyestrain when reading documents.

White on White

The aesthetically-pleasing design of the monitor extends even to
the cables. White cables come bundled with the white cabinet;
and black cables with the black cabinet version of the FlexScan
EV2780. Additionally the attached Cable Holder neatly holds
the cables behind the stand.

Clear View from All Angles

The monitor uses an LED-backlit IPS (in-plane switching) LCD
panel with 178° viewing angle that minimizes color shift and
contrast changes when viewing the screen at an angle. This
means that two people sitting at the one computer can easily see
the screen – and it also makes the EV2780 perfect for multi-mon­itor configurations.

Screen InStyle

EIZO’s Screen InStyle is a newly developed software that allows
you to easily manage monitor settings such as power, color,
brightness and gamma by using your mouse instead of monitor
control buttons. But what makes Screen InStyle truly unique is
that it allows you to manage multiple connected monitors from
the one place – meaning that settings placed on one monitor will
automatically be set to all connected monitors.

EIZO Monitor Configuration for Administators

EIZO Monitor Configurator lets system administrators control
the settings of all FlexScan EV monitors with a USB connection.
The settings of one monitor can be saved as an xml file and
applied to other monitors via USB or office network.

LED Backlights - Less Power, Longer Life

Compared to CCFL backlights, LED backlights last longer and
consume less power. They are also mercury-free for minimal
environmental impact.

5-Year Warranty

A manufacturer’s 5-year warranty covers all
components including the LCD panel to ensure a
long service life. This warranty is 2-years or 67%
longer than the standard 3-year warranty of most
monitor brands for significantly lower running costs.

Compliance with International Labels

Zero Bright Pixels

EIZO guarantees this product will be free from bright
sub-pixels for six months from purchase date.

SPECIFICATIONS

Model Variations

Cabinet Colors

Panel Type

Backlight

Panel Size

Native Resolution

Viewable Image Size (H × V)

Pixel Pitch

Display Colors

Viewing Angles (H / V, typical)

Brightness (typical)

Contrast Ratio (typical)

Response Time (typical)

Panel Input Terminals

Digital Scanning Frequency (H / V)

USB Function

USB Standard

Speakers

Audio Output Terminals

Sound Adjustment

Power Requirements

Maximum Power Consumption

Typical Power Consumption

Power Save Mode

Power Management

Preset Modes

Auto EcoView

OSD Languages

Dimensions (Landscape, W × H × D)

Dimensions (Without Stand, W × H × D)

Net Weight

Net Weight (Without Stand)

Height Adjustment Range

Tilt

Swivel

Pivot

Hole Spacing (VESA Standard)

Certifications & Standards
(Please contact EIZO for the latest
information.)

Supplied Accessories
(May vary by country. Please
contact EIZO for details.)

Warranty

With FlexStand, Without Stand

White, Black

IPS

LED

27.0" / 68.5 cm

2560 × 1440 (16:9 aspect ratio)

596.7 × 335.7 mm

0.233 × 0.233 mm

16.77 million

178°, 178°

2

350 cd/m

1000:1

5 ms (Gray-to-gray)

USB Type-C × 1 (with HDCP),
DisplayPort × 1 (with HDCP), HDMI × 1
(with HDCP)

USB Type-C: 31 - 89 kHz, 29 - 31 Hz
and 59 - 61 Hz
DisplayPort: 31 - 89 kHz, 59 - 61 Hz
HDMI: 31 - 89 kHz, 29 - 31 Hz, 49 - 51
Hz and 59 - 61 Hz

1 port for upstream (USB Type-C)
2-port USB hub

USB 3.1 Gen1

1.0 W +1.0 W

3.5 mm headphone jack

Volume

AC 100 - 240 V, 50 / 60 Hz

96 W

23 W

0.5 W or less

Power Save (VESA DPM, DisplayPort
Rev. 1.1a, and DVI DMPM)

Color mode (Paper, Movie, sRGB,
User1, User2)

Yes

English, German, French, Italian,
Japanese, Simplified Chinese, Spanish,
Swedish, Traditional Chinese

611.6 × 390.2 - 545.2 × 245 mm

611.6 × 359 × 48.5 mm

8.1 kg / 17.9 lbs

5.3 kg / 11.7 lbs

155 mm

35° Up, 5° Down

344°

90° (both clockwise and counter
clockwise)

100 × 100 mm

TCO Displays 7, EPEAT Gold (US),
TUV/Ergonomics, TUV/GS, RCM, CE,
CB, cTUVus, FCC-B, CAN ICES-3 (B),
TUV/S, VCCI-B, EPA Energy Star,
RoHS, WEEE, China RoHS, CCC, EAC

AC power cord, signal cable (USB
Type-C - USB Type-C), CD-ROM (PDF
user's manual), setup guide

Five Years
(Zero bright sub-pixels for six months
from date of purchase.)
