Eiki V-2500 User Manual
EIKI VISUAL SYSTEM PRESENTER
V-2500
OWNER’S INSTRUCTION MANUAL
EIKI INDUSTRIAL CO., LTD.
WARNING
To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture.
The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated ‘dangerous voltage” within the unit’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an quilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the unit.
IMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions should be read before the unit is
operated.
2. Retain Instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the unit manufacturer as they may
cause hazards.
7. Water and Moisture - Do not use this unit near water - for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub: in a wet basement: or near a swimming pool; and the like.
8. Accessories - Do not place this unit on an unstable can, stand, tripod, bracket, or table. The unit
may fall, causing serious injury to a child or adult, and serious damage to the unit. Use only with a
can, stand, tripod, bracket, or table recommended by the manufacturer’s instructions, and should
use a mounting accessory recommended by the manufacturer.
9. A unit and ca~ combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the unit and ca~ combination to overturn.
10. Ventilation - Slots and openings in the unit are provided for ventilation and to ensure reliable
operation of the unit and to protect it from overheating, and these openings must not be blocked or
covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other
similar surface. This unit should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been adhere to.
11. Power Sources - This unit should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product
dealer or local power company.
12. Grounding polarization - This unit may be equipped with a three-wire grounding-type plug, a play
having a third(grounding) pin. This plug will only fit into a grounding-type power outlet. This is a
safety features. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
13. Power-Cord protection - Power-supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from the unit.
14. Lighting - For added protection for this unit during a lighting storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect cable system.
this will prevent damage to the unit due to lighting and power-line surges.
15. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles
as this can result in a risk of fire or electric shock.
16. Object and Liquid Entry - Never push objects of any kind into this unit through openings as they
may touch dangerous voltage points or shod-out pads that could result in a fire or electric shock.
Never spill liquid of any kind on the unit.
17. Servicing - Do not attempt to service this unit yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service - Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the following conditions.
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the unit.
c) If the unit has been exposed to rain or water.
d) If the unit does not operate normally by following the operating instructions, Adjust only these
controls that are covered by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician
to restore the unit to its normal operation.
e) If the unit has been dropped or damaged in any way.
f) When the unit exhibits a distinct change in performance - this indicates a need for service.
19. Replacement pans - When replacement pans are required, be sure the service technician has used
replacement pans specified by the manufacturer or have the same characteristics as the original
pan. Unauthorized substitutions may result in fire, electric shock, or other hazards.
20. Safety Check - Upon completion of any service or repairs to this unit. ask the service technician to
perform safety checks to determine that the unit is in proper operating condition.
21. Heat - The unit should be situated away from heat sources such as radiators, heat registers, stoves,
or other products(including amplifiers) that produce heat.
SAVE THESE INSTRUCTIONS
TABLE OF CONTENTS
1. DESCRIPTION AND CONTROLS 2-3
2. SETTING-UP REMOTE CONTROL UNIT 4
3. ORERATION OF REMOTE CONTROL 5
4. SETTING-UP THE UNIT 6
5. HOW TO CONNECT TO A TV MONITOR AND EXTERNAL EQUIPMENT 7
6. HOW TO USE AUTO FOCUS 8
7. HOW TO DISPLAY 9
8. TROUBLESHOOTING 9
9. SPECIFICATIONS 10-11
