OPERATOR'S MANUAL
LINE TRIMMER ATTACHMENT
MODEL NUMBER STA1500
LINE TRIMMER ATTACHMENT
FOR USE ONLY WITH THE 56V LITHIUM-ION
POWER HEAD PH1400E
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
B
2. Line trimmer Shaft
3. Cutting Line
4. Trimmer Head
(Bump Head)
5. Release Tab
1. End Cap
7. Guard
6. Line-cutting
Blade
8. Hex Wrench
9. Multi-Function Wrench
A
C
E
G
I
D
H
J
F
14 cm
N
O
LK
M
LINE TRIMMER ATTACHMENT — STA1500
5
READ ALL INSTRUCTIONS!
READ OPERATOR’S MANUAL
Residual risk! People with electronic devices, such
as pacemakers, should consult their physician(s) before
using this product. Operation of electrical equipment
in close proximity to a heart pacemaker could cause
interference or failure of the pacemaker.
WARNING: To ensure safety and reliability, all
repairs and replacements should be performed by a
qualied service technician.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention
to possible dangers. The safety symbols and the
explanations with them deserve your careful attention
and understanding. The symbol warnings do not, by
themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident
prevention measures.
WARNING: Be sure to read and understand all
safety instructions in this Operator’s Manual, including all
safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to follow all
instructions listed below may result in electric shock, re,
and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER,
WARNING, or CAUTION. May be used in conjunction with
other symbols or pictographs.
WARNING: The operation of any
power tools can result in foreign objects
being thrown into your eyes, which can
result in severe eye damage. Before
beginning power tool operation, always
wear safety goggles or safety glasses with
side shields and a full face shield when
needed. We recommend a Wide Vision
Safety Mask for use over eyeglasses or
standard safety glasses with side shields.
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may
appear on this product. Read, understand, and follow all
instructions on the machine before attempting to
assemble and operate it.
Safety Alert
Indicates a potential
personal injury hazard.
Read
Operator’s
Manual
To reduce the risk of injury,
user must read and
understand operator’s manual before using this product.
Wear Eye
Protection
Always wear safety goggles
or safety glasses with side
shields and a full face shield
when operating this product.
Wear
hearing
protection
Always wear ear protection
when operating this product.
No Cutting
Blade
Do not install metal or
plastic cutting blades.
Keep
Bystanders
Away
Ensure that other people
and pets remain at least
15m away from the line
trimmer when it is in use.
15m
Keep
Bystanders
Away
Ensure that other people
and pets remain at least
15m away from the line
trimmer when it is in use.
XX
NOISE dB
Noise Sound pressure level.
IPX4
Ingress
Protection
Degree
Protection from splashing
water
V Volt Voltage
mm Millimeter Length or size
cm Centimeter Length or size
in. Inch Length or size
kg Kilogram Weight
