Ego PST3040 User Manual
NEXUS POWER STATION
NEXUS POWER STATION
RESET
PURE SINE WAVE
OPERATOR’S MANUAL
56-VOLT
Français p. 33
NEXUS POWER STATION
Español p. 67
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
MODEL NUMBER PST3040/ PST3040-FC
TABLE OF CONTENTS
FCC Statement ...........................................4
Safety Symbols ..........................................5
Safety Instructions .....................................6-10
Introduction ............................................11
Specications ..........................................11
Packing List ............................................12
Description .........................................13-18
Operation ........................................... 19-26
Maintenance ...........................................27
Troubleshooting ...................................... 28-29
Warranty ...........................................30-31
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC2
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
WARNING: To reduce the risk of injury, re, or electric shock, the user must read
and understand the operator’s manual for their USB accessories and AC devices in
addition to this Operator’s Manual. Ensure compatibility before using this power station.
Do not use this product if a part is damaged or missing.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 3
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures: Reorient or relocate the receiving antenna. Increase
the separation between the equipment and receiver. Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC4
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May
be used in conjunction with other symbols or pictographs.
WARNING: The operation of any power tools can result in foreign objects being
thrown into your eyes, which can result in severe eye damage. Before beginning power
tool operation, always wear safety goggles or safety glasses with side shields and a
full face shield when needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use eye protection
which is marked to comply with ANSI Z87.1.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate it.
V Volt Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
/DC
/AC
°F
°C
lb Pound Weight
kg Kilogram Weight
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC6
Direct Current Type or a characteristic of current
Alternating
Current
Fahrenheit
Temperature
Celsius
Temperature
Read &
Understand
Operator’s
Manual
Safety Alert Indicates a potential personal injury hazard.
Type or a characteristic of current
Temperature
Temperature
To reduce the risk of injury, user must read
and understand operator’s manual before
using this product.
Always wear safety goggles or safety glasses
Eye Protection
WIFI Indicates WIFI connection.
Bluetooth Indicates Bluetooth connection.
with side shields and a full face shield when
operating this product.
WARNING: Read and understand all instructions. Failure to
follow all instructions listed below may result in electric shock, re
and/or serious personal injury.
WARNING: Do not allow any liquid to get inside the power station, or electric
shock may occur.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 7
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using this product, basic precautions should always be
followed, including the following:
Read all the instructions before using the product.
NEVER leave the power station on and unattended. Unattended operation of this
product could result in personal injury or property damage. Switch off the power
station when not in use.
To reduce the risk of injury, close supervision is necessary when the product is
used near children.
Do not put ngers or hands into the product.
Use of an attachment not recommended or sold by power station manufacturer
may result in a risk of re, electric shock, or injury to persons.
To reduce risk of damage to the electric plug and cord, pull the plug rather than
the cord when disconnecting the power station.
ALWAYS ensure that the power station charger-in cord is easily accessible during
operation to allow for quick disconnection from the mains.
Inspect extension cords before use and replace with new cord if required. Contact
with worn or damaged extension cords could result in electrocution.
Do not operate the power pack with a damaged cord or plug, or a damaged output
cable.
Do not use a power station or appliance that is damaged or modied. Damaged or
modied products may exhibit unpredictable behavior resulting in re, explosion
or risk of injury.
When charging the battery, work in a well-ventilated area and do not restrict
ventilation in any way.
ALWAYS operate the power station in a clean, dry, well ventilated area. Make
sure hands are dry before touching this product. Water can conduct electricity!
Water which comes in contact with electrically charged components can transmit
electricity resulting in electrical shock to anyone contacting them.
Do not expose the power station to rain or wet conditions. Water entering the
power station will increase the risk of electric shock.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC8
Do not insert battery packs into charging ports, plug the power station in, or plug
any device into the power station’s power receptacle if moisture is detected on or
in the power station.
Place the power station on a stable, at surface where it will not fall or tip over.
Do not use the power station to power medical or other critical devices.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
Do not expose the power station to re or excessive temperature. Exposure to re
or temperature above 212°F (100°C) may cause explosion.
The power station is not intended for any use other than charging USB electronics
(up to 2.1 Amp for each USB port) or AC devices (up to continuous 2000W for 3 AC
ports combined). Any other use may result in system shut down or even damage.
Use power station only with EGO 56V portable battery packs. Use of any other
battery packs may create a risk of injury and re.
The power station is not intended for use in a commercial repair facility.
For the power station charger, basic precautions should always be followed,
including the following:
1) SAVE THESE INSTRUCTIONS - This manual contains important safety and
operating instructions for battery charger Models CH1700/CH1700-FC.
2) Before using battery charger, read all instructions and cautionary markings on
battery charger, battery, and product using battery.
3)
4) Dry location use only.
5) Do not expose to rain.
Do not disassemble the power station, take it to a qualied service person when
service or repair is required. Incorrect reassembly may result in a risk of re or
electric shock.
CAUTION: To reduce risk of injury, charge only EGO 56V, maximum
10000 mAh Li-Ion portable type rechargeable batteies. Other types of
batteries may burst causing personal injury and damage.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 9
Have your power station or the charger serviced by a qualied repairperson using
only identical replacement parts. This will ensure that the safety of the power
station is maintained.
To reduce the risk of electric shock, unplug the power station from the outlet
before attempting any instructed servicing.
Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you lend someone this tool, lend them these
instructions also to prevent misuse of the product and possible injury.
SAVE THESE INTRUCTIONS!
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC10
INTRODUCTION
Congratulations on your selection of the EGO Nexus Power Station. It has been
designed, engineered and manufactured to give you the best possible dependability
and performance.
Should you experience any problem you cannot easily remedy, please contact the EGO
customer service center 1-855-EGO-5656.
This manual contains important information on to the safe assembly, operation and
maintainance of your product. Read it carefully before using the product. Keep this
manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE
SPECIFICATIONS
Input Voltage
USB Output
Discharging
AC Output
Input 120V ~, 60Hz 170W
Charging
Operation Temperature Range 5°F - 104°F (-15°C - 40°C)
Storage Temperature Range -4°F - 158°F (-20°C - 70°C)
Weight (Without battery pack) 30.2 lb (13.7 kg)
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 11
Output
Charging Temperature
Range
56V
5V
Max.2.1A (each USB port)
120V ~ 60Hz
2000W, 3000W Peak (3 AC
ports combined)
56V
41°F-104°F (5°C-40°C)
PACKING LIST
PART NAME QUANTITY
Power Station 1
Charger 1
Power Cord 2
Front Waterproof Cover 1
Back Waterproof Cover 1
Screws 7
Operator’s Manual 1
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC12
DESCRIPTION
KNOW YOUR POWER STATION (Fig.1a & 1b & 1c)
The safe use of this product requires an understanding of the information on the tool
and in this operator’s manual, as well as knowledge of the project you are attempting.
Before the use of this product, familiarize yourself with all its operating features and
safety rules.
1a
Charger
Cover
Power Cords
Handle
Velcro Straps
LCD Screen
Waterproof Cover for USB Ports
Screw
NEXUS POWER STATION
PURE SINE WAVE
Cover Release Button
Front Waterproof Cover
Screw
Back Waterproof Cover
Electric Contacts
Latch
Battery-mounting Slots
Waterproof Cover for AC Ports
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 13
1b
Charger Socket
Fuse (80A)
Fuse Compartment Cover
Air Outles
1c
USB Button
USB Ports
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC14
Power Button
WIFI/Bluetooth
Setting Button
NEXUS POWER STATION
NEXUS POWER STATION
RESET
RESET
AC Button
Reset Button
AC Ports
Air Inlets
Charger
The power station can charge up to four EGO portable batteries through the supplied
charger and the power cords.
Handle
To help lift the power station.
Cover
To support the charger, as well as a cover for power-cord storage.
Velcro Straps
To secure the charger to the cover for compact convenience.
Power Cords
There are two power cords. One is for connecting the charger with the power station;
the other is for connecting the charger with the power supply. The power station can
charge EGO portable battery(s) once the connections are completed.
LCD Screen
To display the working status of the power station.
Front/Back Waterproof Cover
The front and back waterproof covers are not assembled when shipping. They are
separately stored in the package. The users can mount them with the screws provided,
as needed.
Latch
To help securely lock the battery when installing the battery on the power station.
Charger Socket
To connect the power station to the charger with the provided power cord.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 15
Power Button
To turn on/off the power station.
Reset Button
To recover the power station when it is overloaded.
AC and USB Ports
To connect with AC and USB devices. There are 3 AC ports and 4 USB ports.
AC and USB Button
To switch on/off the AC and USB port output.
WIFI/Bluetooth Setting Button
To congure WIFI/Bluetooth connection and indicate conguration status.
KNOW THE ICONS AND INDICATORS ON THE LCD SCREEN (Fig. 2)
2
Over-heat Icon WIFI Icon Bluetooth Icon USB Icon AC Icon Peak-power Indicator Overload Reminder
Battery
Indicator
Area
complete
Output
Indicator
Charging
Indicator
Charge-
Indicator
Countdown Timer
Rated Power IndicatorLow-power Indicator
Warning Indicator
Overload Indicator
Actual Output
Power Indicator
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC16
Output Indicator
Illuminates to show that the power station is in the discharging process when the AC/
USB button is switched on.
Charging Indicator
Illuminates to show the power station is in the charging process.
Charge-complete Indicator
The charge-complete indicator, together with the charging indicator will illuminate to
indicate that the charging is completed.
Actual Output Power Indicator
Illuminates different numbers of the segments to indicate the actual output power
when a device is connected to the output port.
Rated Power Indicator (600W, 1200W, 2000W)
The rated maximum continuous output power depends on the attached battery(s) on
the Nexus power station.
Peak-power Indicator (3000W)
When the actual output power is over 2000W, but less than 3000W, for LESS THAN
3 seconds, this indicator will illuminate, as well all the segments of the actual output
power.
Overload Indicator
This indicator is separated into 3 segments. When the actual output power is over the
rated power, the corresponding segment will illuminate in red. The overload reminder
“PRESS AND HOLD RESET BUTTON” and the warning indicator “ ” will illuminate in
red at the same time. Remove the device and then press and hold the reset button to
reactivate the power station.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 17
Low-power Indicator
Illuminates when the available battery charge is 10% or less of the rated total battery
charge during discharging. No available time will be displayed on the LCD screen and
the power station will stop discharging when all batteries are fully discharged.
Warning Indicator
Illuminates when a problem occurs and the power station cannot work properly.
Battery Indicator Area
Each indicator includes three aspects:
The upper and lower polygonal areas indicate the status of the associated battery;
The circled power indicator in segments indicates the remaining battery charge;
The battery number indicates the battery position.
Over-heat Icon
Illuminates when the Nexus is overheated. The system will shut down.
WIFI Icon
Illuminates when the Nexus is connected to a WIFI Network.
Bluetooth Icon
Illuminates when the Nexus is connected to cell phone via Bluetooth.
USB/AC Icon
Illuminates to indicate that the USB/AC port has been turned on.
Countdown Timer
This timer indicates the remaining time of charging or discharging process. When the
Nexus stops working or is in low power condition, no timer will be displayed.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC18
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufcient to inict serious injury.
WARNING: Do not use any attachments or accessories not recommended by the
manufacturer of this product. The use of attachments or accessories not recommended
can result in serious personal injury.
WARNING: Do not modify or attempt to repair the Nexus power station except
indicated in the instructions for use and care.
CAUTION: This device is not intended for use in a commercial repair facility.
CAUTION: The device shall be stored indoors and protected from the elements.
The unit shall not be charged outdoors. When in use, steps should be taken to reduce
the exposure to rain, sleet, snow, and the like.
APPLICATION
You may use this product for power emergencies, camping, and any time you need
power for long periods of time.
The Nexus power station provides 4 USB ports and 3 AC ports. Each USB port can
supply a 5V DC, up to 2.1Amp output to power the USB devices like your cell phone,
tablets, etc. The 3 AC ports combined can supply a 120V AC, continuous 2000W (Peak
3000W for less than 3s) output to power AC devices, such as full-size refrigerator, TV,
laptop, etc.
The Nexus power station is equipped with a charger to charge up to four EGO portable
batteries.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 19
CHARGING EGO PORTABLE BATTERIES (Fig. 3)
3
Battery
Supplied Power Cords
Supplied Charger
Power Supply
1. Connect the supplied charger between the power supply (120V~, 60Hz) and
the Nexus power station with the two supplied power cords. Make sure that the
connections are secure and reliable.
2. Align the raised ribs of the battery pack with the mounting slot in the Nexus
power station; slide the battery pack down onto the Nexus. Make sure that the
battery is securely attached to the Nexus.
3. The Nexus power station will communicate with the battery pack and begin
charging the battery.
4. The charging indicators on the LCD screen will illuminate and the power button
will slowly blink green. The screen displays the remaining charge time in
hours and minutes until the battery will be fully charged. When the charging is
completed, the charge-complete indicator will also illuminate and the power
button will shine solid green.
NOTE: During the charging process, the LCD screen may turn black no display. You
can press any of the Power/USB/AC/Reset buttons or reattach the battery to reactivate
the display.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC20
5. While charging, the upper and lower polygonal areas in the corresponding
battery-indicator area will illuminate and the last segment of the circled power
indicator will ash, with other segments shinning. For more than two batteries
mounted on the power station, charging will occur sequentially. The upper and
lower polygonal areas of the symbol associated with each battery to be charged
will illuminate and the power indicator will communicate the present battery
capacity.
POWERING THE AC/USB DEVICES
NOTICE:
battery should be charged in a location where the temperature is greater than 41°F
(5°C) and less than 104°F (40°C).
1. Mount battery(s) securely onto any battery-mounting slot of the Nexus power
For optimum performance, fully charge all EGO batteries before use. The
station (Fig. 5). The Nexus can work with only one battery, but output power may
be limited.
5
NEXUS POWER STATION
RESET
PURE SINE WAVE
2. Press the AC/USB cover-release button to open the corresponding cover (see Fig.
1c); connect the USB and/or AC devices to any ports on the Nexus power station.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 21
3. Press the power button to turn on the Nexus power station. The Nexus power
station will be in the self-check mode and all indicators on the LCD screen will
illuminate for less than 1 second. Then the LCD screen will recover to normal
indication.
For example, 2 batteries BA1400T are located in position 1 and 4. They have 70%
and 30% capacity respectively. The rated maximum output power is 1200W. The LCD
screen will display as shown in Fig. 6. The time “88 hours” indicated on the LCD screen
is estimated automatically, based on the rated power.
6
4. Press the AC and/or USB button (see Fig. 1c), as appropriate, to charge the AC
and/or USB devices. When the device that is connected is turned on, the time
displayed will change and the corresponding actual output power indicator will
illuminate certain segments based on the actual output power.
For example, for 1000W device (within 1200W), the estimated available runtime is 10
mins, with several number of segments indicating the actual output power (Fig. 7).
7
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC22
Actual Output Power Indicator
OVERLOAD CONDITION
When the actual output power is over the rated power, the corresponding segment in
the overload indicator will illuminate in red. For example, for a 1400W device (over the
maximum capacity of 1200W), the available running time will display as invalid and
the corresponding overload indicator will shine in RED (Fig. 8). At the same time, the
reminder “PRESS AND HOLD RESET BUTTON”, the warning indicator “ ” and the
square contour around the USB/AC Icon will illuminate in red.
8
Contour of the USB/AC Icon
Third segment of the
overload indicator
Second segment of
the overload indicator
First segment of the
overload indicator
NOTICE: The overload indicator is separated into 3 segments.
The rst segment will illuminate in red when the rated power is 600W and the
actual output power is over 600W;
The rst and second segments will illuminate in red when rated power is 1200W
and the actual output power is over 1200W;
All of the three segments will illuminate in red when rated power is 2000W and
the actual output power is over the rated power (2000W continuous and 3000W
peak).
When an overload occurs, remove all devices and press and hold the reset button to
reactivate the Nexus power station.
OVERHEAT CONDITION
When the Nexus power station is overheated, the overheat icon will illuminate in red.
For example, if there are 4 batteries located on the Nexus power station, the rated
power is 2000W.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 23
When the Nexus power station itself is overheating, the overheat icon, the warning
indicator “ ” and the square outline around the USB/AC Icon will illuminate
in red and the available running time will display as invalid (Fig. 9). The Nexus
power station will stop discharging.
9
Square outline around of the USB/AC IconOver-heat Icon
Warning Indicator
When fewer than four attached batteries are overheated, only the upper and lower
polygonal areas of the overheated battery indicator will ash (Fig. 9) while other
battery indicators shine normally. The Nexus power station can discharge
normally.
10
When overheating occurs, detach the battery from the Nexus power station and
move it to a cool place to cool thoroughly.
5. After discharging, disconnect the devices from the Nexus power station, press the
AC and/or USB button to stop the output, and then close the corresponding cover.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC24
6. Press the power button to turn off the power station.
NOTICE:
Charging EGO portable batteries and powering the AC and/or USB devices cannot
be carried out at the same time. Only one function can be used at a time.
Do not insert the provided charger’s plug into the Nexus AC port.
If the USB devices connected to the Nexus power station need more than the
rated output (Max. 2.1A for each DC port), the output of each port will remain at a
current of 2.1A.
If the battery is not functioning normally for any reason other than overheating,
the battery indicator will not register the battery. Try reattaching the battery.
When the Nexus power station is removed from lower temperature to room
temperature for immediate starting, there may be some water vapour inside
it, resulting in incomplete LCD screen display. Just wait until the water vapour
disappears thoroughly, the LCD display will return normal.
WARNING: Do not insert a nail, wire, etc. into the USB power supply port.
Otherwise a circuit short may cause smoke and re.
WARNING: Do not insert a nail, wire, etc. into AC power supply port, or the risk
of electric shock may occur.
WARNING: Do not connect any of the AC ports with the AC outlets on your home
walls, otherwise electric shock or serious damage may occur.
EGO CONNECT
This Nexus power station can work with IOS and Android phones and provide a variety
of connected features in EGO CONNECT.
1. Go to Apple Store (IOS Phone) or Google Play (Android Phone) to search and
download “EGO Power+” App for installation.
2. Follow the instructions in the App to create an account before use; you can also
log in directly using your existing account for EGO powerplus.com.
NOTICE: EGO Power+ App will work with Android version 5.0 and above and IOS 11
and above.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 25
Bluetooth CONNECTION
Make sure that your phone’s Bluetooth function is turned on and Nexus is nearby.
We suggest that you have Nexus added to MY GARAGE in EGO Power+ App before
connecting.
1. Turn on your Nexus power station.
2. Go to EGO CONNECT in the EGO Power+ App. The App will automatically search
for a connectable Nexus nearby.
3. Select the Nexus you wish to connect, then follow instructions in the App to
complete the connection.
4. After successful connection, follow the instructions in the App to begin your
remote conguration.
WIFI REMOTE CONNECTION
Nexus is WIFI enabled and can support remote access with the EGO Power+ App.
Before you can access Nexus remotely, you need to rst add Nexus to your home WIFI:
1. Make sure that the Nexus is nearby and powered on, and make sure that your
phone is currently connected to the WIFI you wish add Nexus to.
2. Add Nexus to MY GARAGE before connecting it to WIFI.
3. You can initiate the Nexus WIFI connection after adding Nexus to MY GARAGE or
go to the EGO CONNECT Nexus page and select the WIFI icon above the page. The
App will lead you through the following processes.
NOTICE: Public WIFI or company WIFI may have rewalls that block Nexus WIFI
access.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC26
MAINTENANCE
WARNING:
the battery pack from the tool when cleaning or performing any maintenance.
WARNING:
any other parts may create a hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualied service technician.
To avoid serious personal injury, always turn tool off and remove
When servicing, use only identical EGO replacement parts. Use of
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their use.
Use a clean cloth to remove dirt, dust, oil, grease, etc.
WARNING:
products, penetrating oils, etc. to come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may result in serious personal injury.
Do not at any time allow brake uids, gasoline, petroleum-based
TRANSPORTING THE UNIT
CAUTION:
Before transporting your Nexus power station, keep in mind that you should:
1. Disconnect all peripheral devices.
2. Turn off the Nexus power station..
3. Lift the Nexus power station by grasping the side handles with both hands: one on
each handle.
Observe the lifting procedures during transportation.
STORING THE UNIT
Turn the Nexus power station off.
Clean the tool thoroughly before storing it.
Store the unit in a dry, well-ventilated area, locked-up or up high, out of the reach
of children. Do not store the unit on or adjacent to fertilizers, gasoline, or other
chemicals. Do not store or left it outdoors when not in use.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 27
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The Nexus power station
cannot charge EGO
portable batteries when
using the supplied charger.
No power indicator of the
battery displayed.
The overheat ion on the
LCD screen illuminates
in red.
The battery indicator on
the LCD screen is ashing.
The Nexus power station
can work normally.
During charging, you
may notice that charging
alternates between
batteries.
Connection between
the Nexus power
station and the charger
is bad.
The battery is not
mounted correctly.
The Nexus power
station is too hot.
The battery is too hot. Detach the battery
This is designed to
provide optimum output
performance, that the
lower charge battery
will be charged rst
so all batteries will
have similar battery
charge when they start
discharging together.
Reconnect the charger
with the Nexus power
station.
Detach the battery and
reinstall it.
Turn off and cool the
Nexus power station
thoroughly until the AC
ports can work.
from the Nexus power
station. Cool it until
its temperature drops
below 152°F (67°C).
n/a
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC28
PROBLEM CAUSE SOLUTION
The Nexus power station
stops discharging.
Fuse is overloaded.
Replace the fuse with a
new one by a qualied
service technician.
The identical fuse is
80 Amp, illustrated as
Fig.1b shown.
During discharging,
previous generation
batteries will ash in red,
green or orange while the
new generation batteries
(with 5-segment fuel
gauge) show solid green.
The Nexus power
station is in overload
condition.
The Nexus power
station is in overheat
condition.
The battery is in low
voltage, lower to 10%
of the total charge.
This is normal and
does not impact the
functionality and
performance of the
Nexus power station.
Different generations of
EGO batteries will have
different displays.
Remove the device and
press the reset button
to reactivate the Nexus
power station.
Detach the battery
away from the Nexus
power station and move
the power station to a
cool place for thorough
cooling.
Charge the battery.
n/a
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC 29
WARRANTY
EGO WARRANTY POLICY
5-year limited warranty on EGO POWER+ outdoor power equipment and portable power
for personal, household use.
3-year limited warranty on EGO POWER+ System battery packs and chargers for
personal, household use.
2 year/1year limited warranty on EGO outdoor power equipment, portable power,
battery packs, and chargers for professional and commercial use.
The detailed warranty periods by products can be found online at
http://egopowerplus.com/pages/warranty-policy.
Please contact EGO Customer Service Toll-Free at 1-855-EGO-5656 any time you
have questions or warranty claims.
LIMITED SERVICE WARRANTY
EGO products are warranted against defects in material or workmanship from the date
of original retail purchase for the applicable warranty period. Defective product will
receive free repair.
a) This warranty applies only to the original purchaser from an authorized EGO
retailer and may not be transferred. Authorized EGO retailers are identied online
at http://egopowerplus.com/pages/warranty-policy.
b) The warranty period for reconditioned or factory certied products used for
residential purpose is 1 year, for industrial, professional or commercial purpose is
90 days.
c) The warranty period for routine maintenance parts, such as, but not limited
to, blades, trimmer heads, chain bars, saw chains, belts, scraper bars, blower
nozzles, and all other EGO accessories is 90 days for residential purpose, 30 days
for industrial, professional or commercial purpose. These parts are covered for
90/30 days from manufacture defects in normal working conditions.
d) This warranty is void if the product has been used for rental purpose.
e) This warranty does not cover the damage resulting from modication, alteration
or unauthorized repair.
56-VOLT NEXUS POWER STATION - PST3040/ PST3040-FC30
Loading...
