EN 56-volt lithium-ion cordless power head 6
DE 19
FR 33
ES 47
PT 62
IT 76
NL 90
DK 104
SE 117
FI 130
NO 143
RU 156
PL 170
CZ 184
SK 197
HU 210
RO 224
SL 238
LT 251
LV 264
GR 277
TR 292
ET 305
A
789106435
12
11
18
12
1413
15
16
17
B
B-3 B-4
B-2
B-1
B-5
B-6
CD
C-1
C-2
C-3
C-4
E
F
G
I
K
H
J
L
NM
M-1
M-2
O
O-1
O-2
O-3
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
Residual risk! People with electronic devices, such
as pacemakers, should consult their physician(s) before
using this product. Operation of electrical equipment
in close proximity to a heart pacemaker could cause
interference or failure of the pacemaker.
WARNING: To ensure safety and reliability, all
repairs and replacements should be performed by a
qualied service technician.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols and the explanations
with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate
any danger. The instructions and warnings they give are no
substitutes for proper accident prevention measures.
WARNING: Be sure to read and understand all
safety instructions in this Operator’s Manual, including all
safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to follow all
instructions listed below may result in electric shock, re,
and/or serious personal injury.
Safety Alert
Read &
Understand
Operator’s
Manual
Wear Eye
Protection
Recycle
Symbols
Do Not
Expose To
Rain
VVoltVoltage
mmMillimeterLength or size
cmCentimeterLength or size
in.InchLength or size
Indicates a potential personal
injury hazard.
To reduce the risk of
injury, user must read and
understand operator’s manual
before using this product.
Always wear safety goggles
or safety glasses with side
shields and a full face shield
when operating this product.
This product uses lithium ion (Li - ion) batteries. Local,
state, or federal laws may
prohibit disposal of batteries
in ordinary trash. Consult
your local waste authority
for information regarding
available recycling and/or
disposal options.
Do not use in the rain or
leave outdoors while it is
raining.
EN
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER,
WARNING, OR CAUTION. May be used in conjunction with
other symbols or pictographs.
WARNING: The operation of any power
tools can result in foreign objects being thrown
into your eyes, which can result in severe
eye damage. Before beginning power tool
operation, always wear safety goggles or
safety glasses with side shields and a full face
shield when needed. We recommend a Wide
Vision Safety Mask for use over eyeglasses or
standard safety glasses with side shields.
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may
appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate it.
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E
kgKilogramWeight
lbPoundWeight
Direct
Current
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings and
instructions. Failure to follow the warnings and instructions
may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Type or a characteristic of
current
5
WORK AREA SAFETY
EN
◾ Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
◾ Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, petrol or dust. Power tools
create sparks which may ignite the dust or fumes.
◾ Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
ELECTRICAL SAFETY
◾ Power tool plugs must match the outlet. Never
modify the plug in anyway. Do not use any
adaptor plugs with earthed (grounded) power
tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
◾ Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
◾ Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
◾ Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
◾ When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
◾ If operating a power tool in a damp location
is unavoidable, use a Ground-fault circuit
interrupter protected supply. Use of GFCI reduces therisk of electric shock.
PERSONAL SAFETY
◾ Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol, or medication.
A moment of inattention while operating power tools
may result in serious personal injury.
◾ Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
◾ Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your
nger on the switch or energizing power tools that
have the switch on invites accidents.
◾ Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
◾ Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
◾ Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
◾ If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Useof dust
devices can reduce dust-related hazards.
POWER TOOL USE AND CARE
◾ Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
◾ Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
◾ Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool
accidentally.
◾ Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are dangerous
in the hands of untrained users.
◾ Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
◾ Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E6
◾ Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
◾ This 56V power head PH1400E may be used with
only the following EGO attachments:
ATTACHMENT TYPEMODEL NUMBER
Extension Pole EP7500
Edger EA0800
Brush CutterBCA1200
Line TrimmerSTA1500
Pole SawPSA1000
Pole Hedge TrimmerHTA2000
BATTERY TOOL USE AND CARE
◾ Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used
with another battery pack.
◾ Use power tools only with specically
designated battery packs listed below. Use of any
other battery packs may create a risk of injury and re.
BATTERY
BA1120E, BA2240E, BA2800,
BA3360, BA4200
CHARGER
CH5500E,
CH2100E
◾ When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects
that can make a connection from one terminal to
another. Shorting thebattery terminals together may
cause burns or a re.
◾ Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from thebattery may cause irritation or burns.
SERVICE
◾ Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
◾ If situations occur that are not covered in this manual,
use care and good judgment. Contact the EGO Service
Center for assistance.
SAVE THESE INSTRUCTIONS
ADDITIONAL SPECIFIC SAFETY RULES CAN BE
FOUND IN THE APPLICABLE ATTACHMENT’S
OPERATOR’S MANUAL
SPECIFICATIONS
Voltage
Weight (Without battery pack)TBD
56 V
PACKING LIST
PART NAMEQUANTITY
Power Head1
Adjustable Front-Assist Handle1
Operator’s Manual1
DESCRIPTION
KNOW YOUR POWER HEAD (Fig. A)
1. Air Outlet
2. Air Inlet
3. Rear Handle
4. Lock-off Button
5. High/low-Speed Switch
6. Threshold Ring
7. Adjustable Front-Assist Handle
8. Coupler
9. Shaft-Release Button
10. Wing Knob
11. Barrier Bar
12. Trigger
13. Battery-Release Button
14. Rubber Pad Protection
15. Latch
16. Electric Contacts
17. Ejection Mechanism
18. Shoulder Strap (special accessory)
ASSEMBLY
WARNING: If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING: Always remove the battery pack from
the product when you are assembling parts, making
adjustments, cleaning, or when the product is not in use.
EN
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E
7
INSTALLING AN ATTACHMENT TO THE POWER HEAD
EN
WARNING: Read and understand entire Operator’s
Manual for each optional attachment used on this power
head and follow all warnings and instructions. Failure to
follow all instruc tions could result in electric shock, re
and/or serious personal injury.
WARNING: This 56V power head PH1400E is
designed to be used only with the EGO attachment
models that are specied in this Operator’s Manual or
subsequently introduced by EGO for use with this power
head. Use of other, unauthorized attachments could cause
serious personal injuries or property damage.
WARNING: Never install, remove, or adjust any
attachment while the power head is running or with
the battery installed. Failure to stop the motor and
remove the battery can cause serious personal injury.
NEVER OPERATE THE POWER HEAD WITHOUT AN
ATTACHMENT.
The attachment connects to the power head by means of
a coupler device.
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Remove the end cap from the attachment. Align the
arrow on the attachment shaft with the arrow on
the coupler and push the attachment shaft into the
coupler until you hear a clear “click” sound, which
indicates that the attachment shaft is mounted into
place (Fig. B).
Fig. B parts description see below:
B-1 Attachment Shaft B-4 Arrow on the Coupler
Arrow on the
B-2
Attachment Shaft
Shaft-Release
B-5
Button
B-3 Wing KnobB-6 Power-head Shaft
4. Pull the shaft of the attachment to verify it is securely
locked into the coupler. If not, rotate the attachment
shaft from side to side in the coupler until it snaps
into place.
5. Tighten the wing knob securely.
WARNING: Be certain the wing knob is fully
tightened before operating equipment; check it
periodically for tightness during use to avoid serious
personal injury.
REMOVING THE ATTACHMENT FROM THE POWER
HEAD
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Press the shaft-release button, with the button
depressed, pull or twist the attachment shift out of
the coupler.
MOUNTING AND ADJUSTING THE FRONT-ASSIST
HANDLE
1. Stop the motor and remove the battery pack, if installed.
2. Loosen the wing nut to separate the adjustable frontassist handle (Fig. C).
Fig. C parts description see below:
C-1 Lock PoleC-3
Front-Assist Handle
with Barrier Bar
C-2 Clamping Block C-4 Wing Nut
3. Push the front-assist handle onto the shaft between the
threshold ring and the coupler (Fig. D).
4. Insert the clamping block into the handle slot (Fig. E).
5. Mount the lock pole, and pre-tighten them with the wing
nut. Make sure that the front-assist handle is upwards
and points toward the top of the rear handle (Fig. F).
6. Adjust the front-assist handle between the threshold ring
and the coupler to make sure your front arm is straight
when operating (Fig. G) and then lock the lever of the
lock pole (Fig. H).
WARNING: Never operate the tool without the front-
assist handle rmly in place.
WARNING: Only x the front-assist handle between
the threshold ring and the coupler.
MOUNTING THE SHOULDER STRAP
1. Loosen and remove the bolt in the hook of the strap
(Fig. I & J).
2. Attach the hook onto the shaft between the threshold
ring and the rear handle as Fig. K shown and lock it
with the bolt (Fig. L).
WARNING: Only x the hook of the strap between
the threshold ring and the rear handle.
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E8
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection. Failure to do
so could result in objects being thrown into your eyes and
other possible serious injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING: NEVER OPERATE THE POWER HEAD
WITHOUT AN ATTACHMENT.
INSTALLING/REMOVING THE BATTERY PACK
NOTE:
Fully charge the battery pack before rst use.
To Install
Align the battery ribs with the mounting slots and press
the battery pack down until you hear a “click” (Fig. M).
Fig. M parts description see below:
M-1 Mounting Slot
M-2 Rib
To Remove
Depress the battery-release button and pull the battery
pack out (Fig. N).
WARNING: To avoid serious personal injury, always
remove the bat tery pack and keep hands clear of the
lock-off button and trigger when carrying or transporting
the tool.
STARTING/STOPPING THE POWER HEAD (Fig. O)
To Start
Press down the lock-off button and hold it in that position.
Depress the trigger to turn on the power head. Different
pressure on the trigger results in variable rotating speed
of the power head. More pressure, higher speed.
To Stop
Release the trigger.
NOTICE: The motor runs only when the lock-off button
and trigger are both pressed.
Speed Adjustment Function (Fig. O)
The power head has two speeds. Position“1” is for low speed
while Position “2” for high speed. Push or pull the high/lowspeed switch to choose the suitable speed during operation.
Fig. O parts description see below:
O-1 Hign/Low-Speed Switch
O-2 Lock-off Button
O-3 Trigger
MAINTENANCE
WARNING: Before inspecting, cleaning or servicing
the unit, stop the motor, wait for all moving parts to stop, and
remove the battery pack. Failure to follow these instructions
can result in serious personal injury or property damage.
WARNING: When servicing, use only identical
replacement parts. Use of any other parts can create a
hazard or cause product damage. To ensure safety and
reliability, all repairs, other than the items listed in these
maintenance instructions, should be performed by a
qualied service technician.
NOTICE: Before each use, inspect the entire product
for damaged, missing, or loose parts such as screws,
nuts, bolts, caps, etc. Tighten securely all fasteners and
caps and do not operate this product until all missing or
damaged parts are replaced. Please contact customer
service or a quali ed service technician.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
CLEANING THE POWER HEAD
1. Stop the motor and remove the battery pack.
2. Clean dirt and debris from the power head using a
damp cloth with a mild detergent.
NOTICE: Do not use any strong detergents on the plastic
housing or the handle. They can be damaged by certain
aromatic oils such as pine and lemon.
EN
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E
9
STORING THE POWER HEAD
EN
1. Remove the battery pack from the power head before
storing.
2. Clean all foreign material from the power head.
3. Store it in a place that is inaccessible to children.
4. Keep away from corrosive agents such as garden
chemicals and de-icing salts.
Protecting the environment
Do not dispose of electrical equipment,
battery charger and batteries/
rechargeable batteries into household
waste!
According to the European law 2012/19/
EU, electrical and electronic equipment
that is no longer usable, and according to
the European law 2006/66/EC, defective
or used battery packs/batteries, must be
collected separately.
If electrical appliances are disposed of in
landlls or dumps, hazardous substances
can leak into the groundwater and get
into the food chain, damaging your health
and well-being.
EC DECLARATION OF CONFORMITY
We, CHERVON EUROPE LTD.
47 CASTLE STREET, READING, RG1 7SR, UNITED KINGDOM
Declare that the product 56V lithium-ion cordless
power head PH1400E
Complies with the essential health and safety requirements of the following Directives:
2006/42/EC, 2014/30/EU, 2011/65/EU, 2000/14/EC
Standards and technical specications referred to:
EN 60335-1, EN 50636-2-91, EN ISO 11806-1, EN ISO
12100, EN ISO 60745-1, EN 55014-1, EN 55014-2
Measured Sound Power Level: TBDdB(A), Guaranteed
Sound Power Level: TBDdB(A)
Conformity assessment procedure of Annex VI is followed
according 2000/14/EC.
Notied Body: Société Nationale de Certication et
d’Homologation
Notied Body number : 0499
Peter Melrose Dong Jianxun
Vice President of Chervon Europe
* (Authorized representative for CHERVON and responsible for technical documentation)
01/09/2016
Quality Manager of Chervon
TROUBLESHOOTING
See the applicable attachment’s operator’s manual.
WARRANTY
EGO WARRANTY POLICY
Please visit the website egopowerplus.com for full terms and conditions of the EGO Warranty policy.
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E10
EN
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E
11
EN
56-VOLT LITHIUM-ION CORDLESS POWER HEAD — PH1400E12
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
