EGO PH1400 Operator's Manual
OPERATOR'S MANUAL
56-VOLT LITHIUM-ION
POWER HEAD
MODEL NUMBER PH1400
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
Español p. 47
Français p. 24
FOR USE WITH EGO POWER+
POWER HEAD ATTACHMENTS
56-VOLT LITHIUM-ION POWER HEAD—PH14002
TABLE OF CONTENTS
Safety Symbols ..........................................4
Safety Instructions ......................................5-8
Introduction .............................................8
Specifications ...........................................9
Packing List .............................................9
Description .........................................10-11
Assembly ...........................................13-16
Operation ...........................................17-19
Maintenance ...........................................20
Troubleshooting .........................................21
Warranty ...........................................22-23
56-VOLT LITHIUM-ION POWER HEAD—PH1400 3
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR'S MANUAL
WARNING:
Some dust created by power cutting contains chemicals known to
the state of California to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
Lead from lead-based paints
Crystalline silica from bricks and cement and other masonry products, and
Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
56-VOLT LITHIUM-ION POWER HEAD—PH14004
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger.
The instructions and warnings they give are no substitutes for proper accident
prevention measures.
WARNING:
Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, fire, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL:
Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
WARNING!
The operation of any power tools can result in foreign
objects being thrown into your eyes, which can result in severe eye
damage. Before beginning power tool operation, always wear safety
goggles or safety glasses with side shield and a full face shield when
needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use eye protection
which is marked to comply with ANSI Z87.1.
56-VOLT LITHIUM-ION POWER HEAD—PH1400 5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate it.
Safety Alert Indicates a potential personal injury hazard.
Read &
Understand
Operator's
Manual
To reduce the risk of injury, user must read and
understand the operator’s manual before using
this product.
Eye Protection
Always wear safety goggles or safety glasses
with side shields and a full face shield when
operating this product.
Recycle Symbols
This product uses lithium-ion (Li-ion) batteries.
Local, state, or federal laws may prohibit disposal
of batteries in ordinary trash. Consult your
local waste authority for information regarding
available recycling and/or disposal options.
IPX4
Ingress Protection
Degree
Protection from splashing water
V Volt Voltage
mm Millimeter Length or size
cm Centimeter Length or size
in. Inch Length or size
kg Kilogram Weight
lb Pound Weight
Direct Current Type or a characteristic of current
56-VOLT LITHIUM-ION POWER HEAD—PH14006
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
When using electric gardening appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric shock, and personal injury,
including the following:
READ ALL INSTRUCTIONS
DANGER!
Do not rely on the tool’s insulation against electric shock. To reduce
the risk of electrocution, never operate the tool in the vicinity of any wires or cables
which may carry electric current.
CAUTION!
Wear appropriate personal hearing protection during use. Under some
conditions and durations of use, noise from this product may contribute to hearing loss.
Avoid Dangerous Environment - Don’t use appliances in damp or wet
locations.
Keep Children Away - All visitors should be kept at a distance away from work
area.
Dress Properly - Do not wear loose clothing or jewelry. They can be caught in
moving parts. Use of rubber gloves and substantial footwear is recommended
when working outdoors. Wear protective hair covering to contain long hair.
Use Safety Glasses - Always use face or dust mask if operation is dusty.
Use Right Appliance - Do not use appliance for any job except that for which it
is intended.
Don’t Force Appliance - It will do the job better and with less likelihood of a risk
of injury at the rate for which it was designed.
Don’t Overreach - Keep proper footing and balance at all times.
Stay Alert - Watch what you are doing. Use common sense. Do not operate the
appliance when you are tired.
Store Idle Appliances Indoors - When not in use, appliances should be stored
indoors in a dry and high or locked-up place with the battery pack removed - out
of reach of children.
Maintain Appliance with Care - Keep the appliance clean for best performance
and to reduce the risk of injury. Follow instructions for lubricating and changing
accessories. Keep handles dry, clean, and free from oil and grease.
Check Damaged Parts - Before further use of the appliance, a guard or other
56-VOLT LITHIUM-ION POWER HEAD—PH1400 7
part that is damaged should be carefully checked to determine that it will operate
properly and perform its intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting, and any other condition
that may affect its operation. A guard or other part that is damaged should be
properly repaired or replaced by an authorized service center unless indicated
elsewhere in this manual.
Do not charge the battery pack in rain, or in wet locations.
Use only with the battery packs and chargers listed below:
BATTERY PACK CHARGER
BA1120, BA1400, BA2240,
BA2800, BA4200
CH2100
CH5500
This 56V power head PH1400 may be used with only the following EGO
attachments:
ATTACHMENT TYPE MODEL NUMBER
Extension Pole EP7500
Edger EA0800
String Trimmer STA1500
Pole Saw PSA1000
Do not dispose of the battery in a fire. The cells may explode. Check with
local codes for possible special disposal instructions.
Do not open or mutilate the battery. Released electrolyte is corrosive and
may cause damage to the eyes or skin. It may be toxic if swallowed.
Exercise care in handling batteries in order not to short the battery with
conducting materials such as rings, bracelets, and keys. The battery or
conductor may overheat and cause burns.
Replacement Parts - When servicing, use only identical EGO replacement parts.
Use of any other accessory or attachment may increase the risk of injury.
Battery tools do not have to be plugged into an electrical outlet;
therefore, they are always in operating condition. Be aware of possible
hazards even when the tool is not operating. Take care when performing
maintenance or service.
Remove or disconnect the battery pack before servicing, cleaning or
removing material from the appliance.
56-VOLT LITHIUM-ION POWER HEAD—PH14008
Do not wash with a hose; avoid getting water in motor and electrical
connections.
If situations occur that are not covered in this manual, use care and
good judgment. Contact the EGO Customer Service Center for assistance.
Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you lend this tool to someone else, also lend
these instructions to them to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS!
ADDITIONAL SPECIFIC SAFETY RULES CAN BE FOUND IN THE
APPLICABLE ATTACHMENT’S OPERATOR’S MANUAL
INTRODUCTION
Congratulations on your selection of the EGO 56-Volt Lithium-Ion Power Head. It
has been designed, engineered and manufactured to give you the best possible
dependability and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on the safe assembly, operation and
maintenance of your product. Read it carefully before using the product. Keep this
manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP THEM IN A
SAFE PLACE FOR FUTURE REFERENCE
56-VOLT LITHIUM-ION POWER HEAD—PH1400 9
SPECIFICATIONS
Voltage 56V
PACKING LIST
PART NAME QUANTITY
Power Head 1
Adjustable Front-Assist Handle 1
Operator's Manual 1
56-VOLT LITHIUM-ION POWER HEAD—PH140010
DESCRIPTION
KNOW YOUR POWER HEAD (Fig.1)
The safe use of this product requires an understanding of the information on the tool and
in this operator’s manual, as well as knowledge of the project you are attempting. Before
using this product, familiarize yourself with all operating features and safety rules.
1
Wing Knob
Shaft-Release Button
Coupler
Adjustable Front-Assist Handle
High/low-Speed Switch
Power-head
Shaft
Ejection
Mechanism
Electric
Contacts
Battery-Release
Button
Rubber Pad
Protection
Latch
Trigger
Lock-off Button
Air Inlet
Air Outlet
Rear Handle
56-VOLT LITHIUM-ION POWER HEAD—PH1400 11
ADJUSTABLE FRONT-ASSIST HANDLE
Adjusts for ease of operation and to help prevent loss of control.
REAR HANDLE
Ergonomic handle with overmold improves comfort and grip.
LOCK-OFF BUTTON
Helps to prevent accidental or unauthorized activation of the trigger. It must be
depressed before the trigger can be activated.
VARIABLE-SPEED TRIGGER
To turn the tool On and Off and control speed.
HIGH/LOW-SPEED SWITCH
Provides high and low speeds for different tasks as needed.
COUPLER
Aids in quick connection of the attachment shafts.
SHAFT-RELEASE BUTTON
For releasing the attachment shaft.
WING KNOB
Tightens the coupler and attachment shaft connection.
BATTERY-RELEASE BUTTON
Releases the battery pack from the tool.
LATCH
Locks the battery pack when installing it on the tool.
56-VOLT LITHIUM-ION POWER HEAD—PH140012
EJECTION MECHANISM
Aids in battery removal.
RUBBER PAD
Helps to protect the housing from impacts during use.
56-VOLT LITHIUM-ION POWER HEAD—PH1400 13
ASSEMBLY
WARNING:
If any parts are damaged or missing, do not operate this product
until the parts are replaced. Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING:
Do not attempt to modify this product or create accessories not
recommended for use with this power head. Any such alteration or modification is
misuse and could result in a hazardous condition leading to possibly serious personal
injury.
WARNING:
Always remove the battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when the product is not in use.
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from the box. Make sure that
all items listed in the packing list are included.
WARNING:
Do not use this product if any parts on the Packing List are already
assembled to your product when you unpack it. Parts on this list are not assembled to
the product by the manufacturer and require customer installation. Use of a product
that may have been improperly assembled could result in serious personal injury.
Inspect the tool carefully to make sure that no breakage or damage occurred
during shipping.
Do not discard the packing material until you have carefully inspected and
satisfactorily operated the tool.
If any parts are damaged or missing, please return the product to the place of
purchase.
56-VOLT LITHIUM-ION POWER HEAD—PH140014
INSTALLING AN ATTACHMENT TO THE POWER HEAD
WARNING:
Read and understand entire Operator’s Manual for each optional
attachment used on this power head and follow all warnings and instructions. Failure to
follow all instructions could result in electric shock, fire and/or serious personal injury.
WARNING:
This 56V power head PH1400 is designed to be used only with the
EGO attachment models that are specified in this Operator’s Manual or subsequently
introduced by EGO for use with this power head. Use of other, unauthorized
attachments could cause serious personal injuries or property damage.
WARNING:
Some accessories have specific requirements related to safety.
Always pay special attention to such instructions in the manual that accompanies each
accessory.
WARNING:
Never install, remove, or adjust any attachment while the power
head is running or with the battery installed. Failure to stop the motor and remove the
battery can cause serious personal injury. NEVER OPERATE THE POWER HEAD WITHOUT
AN ATTACHMENT.
The attachment connects to the power head by means of a coupler device.
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Remove the end cap from the attachment. Align the arrow on the attachment
shaft with the arrow on the coupler and push the attachment shaft into the
coupler until you hear a clear “click” sound, which indicates that the attachment
shaft is mounted into place (Fig.2).
2
Arrow on the Coupler
Arrow on the Attachment Shaft
Attachment Shaft
Shaft-Release Button
Power-head Shaft
Wing Knob
56-VOLT LITHIUM-ION POWER HEAD—PH1400 15
4. Pull the shaft of the attachment to verify that it is securely locked into the coupler.
If not, rotate the attachment shaft from side to side in the coupler until it snaps
into place.
5. Tighten the wing knob securely.
WARNING:
Be certain that the wing knob is fully tightened before operating
equipment; check it periodically for tightness during use to avoid serious personal
injury.
REMOVING THE ATTACHMENT FROM THE POWER HEAD
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Press the shaft-release button and, with the button depressed, pull or twist the
attachment shaft out of the coupler.
MOUNTING AND ADJUSTING THE
FRONT-ASSIST HANDLE
WARNING:
Always remove the
battery pack from the product when you
are assembling parts, making adjustments,
cleaning, or when the product is not in use.
1. Stop the motor and remove the
battery pack, if installed.
2. Loosen the four screws in the frontassist handle with the supplied hex
wrench and remove the screws and
lower clamp from the front-assist
handle (Fig. 3).
3. Attach the front-assist handle and
lower clamp on the power-head
shaft and secure them by pretightening the four screws. Turn the
front-assist handle upwards so that
it points toward the top of the rear handle (Fig. 4).
3
Lower Clamp
Front-Assist Handle
Screws
4
Coupler
Power-head Shaft
Rear Handle
Housing
56-VOLT LITHIUM-ION POWER HEAD—PH140016
4. Adjust the front-assist handle position between the rear handle housing and the
coupler on the power-head shaft (Fig. 4).
5. Tighten the four screws so that the handle cannot be rotated on the shaft.
WARNING:
Never operate the tool without the front-assist handle firmly in place.
56-VOLT LITHIUM-ION POWER HEAD—PH1400 17
OPERATION
WARNING:
Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses with side shield
marked to comply with ANSI Z87.1. Failure to do so could result in objects being thrown
into your eyes and other possible serious injuries.
WARNING:
Do not use any attachments or accessories not recommended by the
manufacturer of this product. The use of attachments or accessories not recommended
can result in serious personal injury.
INSTALLING/REMOVING THE BATTERY PACK
WARNING:
Always remove the battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when not in use. Removing the
battery pack will prevent accidental starting that could cause serious personal injury.
NOTE: Fully charge the battery pack before first use.
To install battery pack (Fig. 5)
1. Align the ribs of the battery pack
with the mounting slots in the power
head's battery port.
2. Press the battery pack towards
the power head until it snaps into
position.
NOTE: Make sure that the latch on the
bottom of the battery pack snaps in place
and the battery pack is secured to the power head before beginning operation. Failure
to securely seat the battery pack could cause the battery pack to fall out, resulting in
serious personal injury.
5
Mounting Slot
Rib
56-VOLT LITHIUM-ION POWER HEAD—PH140018
To remove battery pack (Fig. 6)
WARNING:
Always be aware of the
location of your feet and children or pets
around you when pressing the batteryrelease button. Serious injury could result
if the battery pack falls. NEVER remove
the battery pack at a high location.
1. Hold the battery pack in the palm of
your hand.
2. Press the battery-release button with your thumb; the battery pack will disengage
from the latch.
3. Grasp the battery pack and remove it from the power head.
WARNING: To avoid serious personal injury, always remove the battery pack and
keep hands clear of the lock-off button and trigger when carrying or transporting the
tool.
STARTING/STOPPING THE
POWER HEAD (Fig.7)
WARNING:
NEVER OPARATE THE
POWER HEAD WITHOUT AN ATTACHMENT.
Do not attempt to start the power head
without an attachment.
To start the power head
1. Press the lock-off button down and
hold it in that position. Depress the trigger to turn on the power head. Release the
lock-off button and continue to squeeze the trigger for continued operation.
2. The rotational speed of the tool is controlled with the variable-speed trigger.
More pressure on the trigger results in higher speed; less pressure on the trigger
results in lower speed. Adjust the speed to suit the task at hand.
NOTICE: The motor runs only when the lock-off button and trigger are both pressed.
6
Press to release
7
High/Low-Speed Switch
Lock-off Button
Trigger
56-VOLT LITHIUM-ION POWER HEAD—PH1400 19
Speed-Adjustment Function (Fig. 7)
The power head has two speeds. Position“1” is for low speed while Position “2” is for
high speed. Push or pull the high/low-speed switch to choose the suitable speed during
operation.
To stop the power head
Release the trigger to stop the power head.
WARNING: Always remove the battery pack from the power head during work
breaks and after finishing work.
56-VOLT LITHIUM-ION POWER HEAD—PH140020
MAINTENANCE
WARNING: Before inspecting, cleaning or servicing the unit, stop the motor,
wait for all moving parts to stop, and remove the battery pack. Failure to follow these
instructions can result in serious personal injury or property damage.
WARNING: When servicing, use only identical replacement parts. Use of any
other parts can create a hazard or cause product damage.
NOTICE: Before each use, inspect the entire product for damaged, missing, or loose
parts such as screws, nuts, bolts, caps, etc. Tighten securely all fasteners and caps
and do not operate this product until all missing or damaged parts are replaced. Please
contact customer service or a qualified service center for assistance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc., come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which can result in serious personal injury.
CLEANING THE POWER HEAD
1. Stop the motor and remove the battery pack.
2. Clean dirt and debris from the power head using a damp cloth with a mild
detergent.
NOTICE: Do not use any strong detergents on the plastic housing or the handle. They
can be damaged by certain aromatic oils such as pine and lemon, and by solvents such
as kerosene.
STORING THE POWER HEAD
1. Remove the battery pack from the power head before storing.
2. Clean all foreign material from the power head.
3. Store it in a place that is inaccessible to children.
4. Keep away from corrosive agents such as garden chemicals and de-icing salts.
56-VOLT LITHIUM-ION POWER HEAD—PH1400 21
TROUBLESHOOTING
See the applicable attachment's operator's manual.
56-VOLT LITHIUM-ION POWER HEAD—PH140022
WARRANTY
EGO WARRANTY POLICY
5 year limited warranty on EGO outdoor power equipment and 3 year limited warranty
on EGO Power+ System battery packs and chargers.
Please contact EGO Customer Service Toll-Free at 1-855-EGO-5656 any time you
have questions or warranty claims.
LIMITED SERVICE WARRANTY
FOR FIVE YEARS from the date of original retail purchase, this EGO product is warranted
against defects in material or workmanship. Defective product will receive free repair.
FOR THREE YEARS from the date of original retail purchase, the EGO Power+ System
battery pack and charger are warranted against defects in material or workmanship.
Defective product will receive free repair.
a) This warranty applies only to the original purchaser from an authorized EGO retailer
and may not be transferred. Authorized EGO retailers are identified online at http://
egopowerplus.com/pages/warranty-policy.
b) The warranty period for any EGO product or part used for industrial, professional or
commercial purpose is one year.
c) This warranty is void if the product has been used for rental purpose.
d) This warranty does not cover the damage resulting from modification, alteration or
unauthorized repair or from use of any not recommended for use with this product.
e) This warranty only covers defects arising under normal usage and does not cover
any malfunction, failure or defect resulting from misuse, abuse (including overloading
of the product beyond capacity and immersion in water or other liquid), accidents,
neglect or lack of proper installation, and improper maintenance or storage.
f) This warranty does not cover normal deterioration of the exterior finish, including but
not limited to scratches, dents, paint chips, or to any corrosion or discoloring by heat,
abrasive and chemical cleaners.
Loading...
