EGO PAD1500, PAD1500-FC Operator's Manual
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
POWER INVERTER
OPERATOR’S MANUAL
56-VOLT
POWER INVERTER
MODEL NUMBER PAD1500/ PAD1500-FC
USB
150W
120V-1.25A
Español p. 33
Français p. 17
56-VOLT POWER INVERTER2
TABLE OF CONTENTS
FCC Statement ...........................................4
Safety Symbols ..........................................5
Safety Instructions ......................................6-8
Introduction .............................................9
Specications ...........................................9
Packing List .............................................9
Description ............................................10
Operation ...........................................11-12
Maintenance ...........................................13
Troubleshooting .........................................14
Warranty ...........................................15-16
56-VOLT POWER INVERTER 3
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
WARNING: To reduce the risk of injury, re, electric shock, user must read and
understand the operator’s manual for their USB accessories and AC devices in addition
to this instruction sheet. Ensure compatibility before using the power inverter. Do not
use this product if a part is damaged or missing.
56-VOLT POWER INVERTER4
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures: Reorient or relocate the receiving antenna. Increase
the separation between the equipment and receiver. Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.
56-VOLT POWER INVERTER 5
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May
be used in conjunction with other symbols or pictographs.
56-VOLT POWER INVERTER6
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate it.
V Volt Voltage
A Amperes Current
lb Pound Weight
kg Kilogram Weight
Alternating
Current
Type of current
Direct Current Type or a characteristic of current
Safety Alert Indicates a potential personal injury hazard.
Read &
Understand
Operator’s Manual
To reduce the risk of injury, user must read
and understand the operator’s manual before
using this product.
WARNING: Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, re and/or serious personal injury.
WARNING: To ensure safety and reliability, all repairs should be performed by a
qualied service technician.
56-VOLT POWER INVERTER 7
IMPORTANT SAFETY INSTRUCTIONS
Read all the instructions before using the product.
To reduce the risk of injury, close supervision is necessary when the product is
used near children.
Do not put ngers or hands into the product.
Use of an attachment not recommended or sold by the manufacturer may result in
a risk of re, electric shock, or injury to persons.
Do not use a battery pack or appliance that is damaged or modied. Damaged or
modied batteries may exhibit unpredictable behavior resulting in re, explosion
or risk of injury.
When charging the battery, work in a well ventilated area and do not restrict
ventilation in any way.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
Do not expose the battery pack to re or excessive temperature. Exposure to re
or temperature above 212°F (100°C) may cause explosion.
Do not expose the power inverter to rain or wet conditions. Water entering the
power inverter will increase the risk of electric shock.
The power inverter is not intended for any use other than charging small (up to
4.2 Amp for two USB ports combined) USB electronics or small (up to 150W) AC
devices. Any other use may result in damage.
Switch off the power inverter when not in use.
Use only with batteries listed below:
POWER INVERTER BATTERY PACKS
PAD1500
PAD1500-FC
BA1120, BA1120-FC,
BA1400, BA1400-FC,
BA2240, BA2240-FC,
BA2800, BA2800-FC,
BA4200, BA4200-FC
56-VOLT POWER INVERTER8
Use the power inverter only with specically designated battery packs. Use of any
other battery packs may create a risk of injury and re.
Do not disassemble the power inverter, take it to a qualied service person when
service or repair is required. Incorrect reassembly may result in a risk of re or
electric shock.
Have your power inverter serviced by a qualied repairperson using only identical
replacement parts. This will ensure that the safety of the power inverter is
maintained.
Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you lend this tool to someone else, also lend these
instructions to them to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS!
56-VOLT POWER INVERTER 9
INTRODUCTION
Congratulations on your selection of a new generation of 56V Lithium-ion power
inverter. It has been designed, engineered and manufactured to give you the best
possible dependability and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on to the safe assembly, operation and
maintainance of your power inverter. Read it carefully before using the power inverter.
Keep this manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE
SPECIFICATIONS
Input Voltage
56V
USB Output 5V, Max.4.2A (two USB ports combined)
AC Output 120V~ Max.150W
Weight (Without battery pack) 1.17lb. (0.53kg)
Operation Temperature 32°F-104°F (0°C-40°C)
Storage Temperature -4°F -158°F (-20°C-70°C)
PACKING LIST
PART NAME QUANTITY
Power Inverter 1
56-VOLT POWER INVERTER10
DESCRIPTION
KNOW YOUR POWER INVERTER (Fig. 1)
WARNING: The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual, as well as knowledge of the
project you are attempting. Before use of this product, familiarize yourself with all its
operating features and safety rules.
USB
150W
120V-1.25A
1
Spring Latch
Electric Contacts
AC Port
USB Port2
USB Port1
Power Button
Handle
POWER BUTTON
To switch on/off the power inverter.
USB PORT1/ USB PORT2
To connect a USB device.
AC PORT
To connect an AC device.
56-VOLT POWER INVERTER 11
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufcient to inict serious injury.
WARNING: Do not modify or attempt to repair the power inverter except as
indicated in the instructions for use and care.
WARNING: This device is intended to be used indoors only. Do not use outdoors
under any conditions.
The power inverter provides two USB ports and one AC port. The two USB ports
combined supply a maximum of 5V DC, up to 4.2 A output to power small USB devices,
like your cell phone, MP3 player, etc. The AC port supplies a 120V AC, max.150W output
to power the small AC devices, such as a laptop computer.
NOTE: Fully charge your EGO POWER+ battery pack before rst use. The battery
should be charged in a location where the temperature is greater than 41°F (5°C) and
less than 104°F (40°C).
1. Align the mounting slots on the power inverter with the ribs on the battery pack,
then move the power inverter towards the battery pack until it snaps into position
(Fig. 2).
NOTE: Make sure that the spring latch on the power inverter snaps into place and the
battery pack is secured to the tool before beginning operation.
2
Mounting slot
Assemble
Separate
56-VOLT POWER INVERTER12
2. Connect the small USB or AC device to the power inverter.
3. Press and hold the power button until the green light in the button illuminates.
The power inverter will begin charging the device.
4. When not using or after charging, disconnect the device from the power inverter,
then press and hold the power button until the green light turns off.
5. Hold the battery pack with one hand and pull the power inverter with the other
hand to separate them.
WARNING:
Always be aware of the location of your feet and children or pets
around you when separating the battery pack from the power inverter. Serious injury
could result if the battery pack falls. NEVER remove the battery pack at a high location.
WARNING:
Do not insert a nail, wire, etc. into the AC power supply port, or the
risk of electric shock may occur.
NOTE:
The product may not supply power to some USB devices.
Do not insert a nail, wire, etc. into the USB power supply port. Otherwise a circuit
short may cause smoke and re.
If the devices connected to the power inverter draw more than the rated output
of the ports (Total 4.2A for USB ports and maximum 150W for AC port), the power
inverter will shut off automatically and the power button will ash red. In this
situation, devices should be removed. To reactivate the power inverter, press and
hold the power button until green light is illuminated.
When switching on the power inverter, if the USB output current is less than
500mA and the AC output power is less than 5W, the system will shut off
automatically in 1 minute.
When switching on the power inverter, if the USB output current is beyond 500mA
or the AC output power is beyond 5W, but then the USB output current is less than
500mA and the AC output is less than 5W for 3 hours, the system will shut off
automatically.
56-VOLT POWER INVERTER 13
MAINTENANCE
WARNING:
To avoid serious personal injury, always remove the battery pack
from the tool when cleaning or performing any maintenance.
WARNING:
When servicing, use only identical EGO replacement parts. Use of
any other parts may create a hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualied service technician.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their use.
Use a clean cloth to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time allow brake uids, gasoline, petroleum-based
products, penetrating oils, etc. to come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may result in serious personal injury.
STORING THE UNIT
Remove the battery pack from the power inverter.
Clean the tool thoroughly before storing it.
Store the unit in a dry, well-ventilated area, locked-up or up high, out of the reach
of children. Do not store the unit on or adjacent to fertilizers, gasoline, or other
chemicals.
56-VOLT POWER INVERTER14
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The power inverter stops
working during use.
Battery capacity is
depleted.
The battery pack is too
hot.
Charge the battery.
Cool the battery pack
until its temperature
drops below 152°F
(67°C).
Red LED light on the
power button ashes for 1
minute, then shuts off.
The device(s) you are
powering draws more
than the rated output of
the ports.
Remove the device and
reactivate the power
inverter.
Red LED light on the
power button shines for 1
minute, then shuts off.
The device is too hot. Cool the power inverter
until its temperature
drops below 221°F
(105°C).
56-VOLT POWER INVERTER 15
WARRANTY
EGO WARRANTY POLICY
5 year limited warranty on EGO outdoor power equipment and portable power.
3 year limited warranty on EGO Power+ System battery packs and chargers.
Please contact EGO Customer Service Toll-Free at 1-855-EGO-5656 any time you
have questions or warranty claims.
LIMITED SERVICE WARRANTY
FOR FIVE YEARS from the date of original retail purchase, this EGO product is warranted
against defects in material or workmanship. Defective product will receive free repair.
FOR THREE YEARS from the date of original retail purchase, the EGO Power+ System
battery pack and charger are warranted against defects in material or workmanship.
Defective product will receive free repair.
a) This warranty applies only to the original purchaser from an authorized EGO
retailer and may not be transferred. Authorized EGO retailers are identied online
at http://egopowerplus.com/pages/warranty-policy.
b) The warranty period for any EGO product, battery pack and charger used for
industrial, professional or commercial purpose is one year.
c) The warranty period for reconditioned or factory certied products used for
residential purpose is 1 year, for industrial, professional or commercial purpose is
90 days.
d) The warranty period for routine maintenance parts, such as, but not limited
to, blades, trimmer heads, chain bars, saw chains, belts, scraper bars, blower
nozzles, and all other EGO accessories is 90 days for residential purpose, 30 days
for industrial, professional or commercial purpose. These parts are covered for
90/30 days from manufacture defects in normal working conditions.
e) This warranty is void if the product has been used for rental purpose.
f) This warranty does not cover the damage resulting from modication, alteration
or unauthorized repair.
Loading...
