DATASHEET
FO outlet UP, 2 SC-S adapter OM3
Description
Fiber Optical flush-mounted data outlet to accommodate 2 SC-Simplex adapter or 2 LC-Duplex adapter. The data
outlet is equipped with couplings in the classes OM3, OM4 or OS2 including shutter. The highlight of this flush-
mounted data outlet is that it not only has an integrated receptacle for excess fiber lengths, but also has a
receptacle for splice protection (4x crimp or 4x shrink). Depending on the application, the holder can also be
dismantled so that it does not get in the way when pre-assembled cables are installed.
Performance features:
Horizontal and vertical installation in the cable duct or flush mounting
Recording of fiber overlengths
Integrated splice protection for 4 splices
Cover 80mm x 80mm
Data outlet depth of 40mm for installation in flush-mounted boxes or cavity wall boxes
General data
Surface mounted No
Flush mounted (plaster) yes
Duct installation yes
Type of fastening Screw
With bus/coupling yes
Max. Assembly (Adapter) 2
Suitable for adapter SC Simplex/LC Duplex
With label space yes
Centre plate yes
This datasheet was created automatically on 15-05-2019 . Technical changes reserved.
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
fon: +49 521 40 41 8-0
fax: +49 521 40 41 8-50
info@efb-elektronik.de
www.efb-elektronik.de
Page 1/3
DATASHEET
FO outlet UP, 2 SC-S adapter OM3
General data
Central plate according to DIN 49075
Cover frame yes
Cable strain relief yes
Wire stock yes
Outlet direction down
Dust protection cap shutter
Material bearing ring Zinc alloy
Material central plate ABS plastic
Material adapter plates ABS plastic
Dimension 80 x 80 x 40 mm
Mechanical characteristics
Splice holder crimp/ shrink
Available variants
Article no. Title Colour RAL-number Dimensions
FTTH-OUTLET-SC-OM3
FO data outlet UP, 2 SC-S adapter OM3 with shutter,
integrated splice holder
white 9010 80 x 80 x 40 mm
This datasheet was created automatically on 15-05-2019 . Technical changes reserved.
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
fon: +49 521 40 41 8-0
fax: +49 521 40 41 8-50
info@efb-elektronik.de
www.efb-elektronik.de
Page 2/3
DATASHEET
FO outlet UP, 2 SC-S adapter OM3
Technical drawings
