Digital Video Recorder

User

Manua

SP-8HDSET

EFB Elektronik GmbH www.efb-elektronik.de

Digital Video Recorder User Manual

User Manual

About this Manual

This Manual is applicable to HD-TVI Digital Video Recorder (DVR). The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the company website Please use this user manual under the guidance of professionals. Legal Disclaimer REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.

Regulatory Information FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply

therefore with the applicable harmonized European standards listed under the EMC Directive

2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection

Digital Video Recorder User Manual

points. For more information see: www.recyclethis.info

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery

information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

Warnings Follow these

safeguards to prevent serious injury or death.

Cautions Follow these precautions to prevent potential injury or material damage.

Warnings

 Proper configuration of all passwords and other security settings is the responsibility of the installer

and/or end-user.

 In the use of the product, you must be in strict compliance with the electrical safety regulations of the

nation and region. Please refer to technical specifications for detailed information.

 Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source

with 100 to 240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information.

 Do not connect several devices to one power adapter as adapter overload may cause over-heating or a

fire hazard.

 Please make sure that the plug is firmly connected to the power socket.  If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and

then please contact the service center.

Digital Video Recorder User Manual

Chapter 1 Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

• Ensure unit is installed in a well-ventilated, dust-free environment.

• Unit is designed for indoor use only.

• Keep all liquids away from the device.

• Ensure environmental conditions meet factory specifications.

• Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

• Use the device in conjunction with an UPS if possible.

• Power down the unit before connecting and disconnecting accessories and peripherals.

• A factory recommended HDD should be used for this device.

• Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer.

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol

Description

Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.

Provides additional information to emphasize or supplement important points of the main text.

ATTENTION!

 If you want to expand your video system, please use only original accessories!

 The use of NOT original accessories can cause considerable damage to the

device and leads to a loss of warranty!

 Original accessories you can get from your local dealer.

Accessories Item no.:

 SP-8HDKAM - Full HD Camera Extension  SP 8HDKAB - Camera connection cable

Digital Video Recorder User Manual

Product Key Features

General

 Connectable to HD-TVI and analog cameras;  Connectable to the Coaxitron camera/dome with long transmission distance;  Connectable to IP cameras;

The IP camera connection is not supported.

 Each channel supports dual-stream. Main stream supports up to 1080P resolution and sub-stream

supports up to WD1 resolution;

The DVR supports up to 1080p lite (960×1080) resultion.

 Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.  Encoding for both video stream and video & audio stream; audio and video synchronization during

composite stream encoding;

 Watermark technology.

Local Monitoring

 HDMI/VGA output at up to 1920×1080 resolution;  1/4/6/8/9/16/25/36-screen live view is supported, and the display sequence of screens is adjustable;  Live view screen can be switched in group and manual switch and automatic cycle live view are also

provided, the interval of automatic cycle can be adjusted;

 Quick setting menu is provided for live view;  The selected live view channel can be shielded;  Motion detection, video-tampering detection, video exception alarm, video loss alarm and VCA alarm

functions;

 Privacy mask;  Several PTZ protocols supported; PTZ preset, patrol and pattern;  Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

 1 SATA hard disk can be connected; disk with a maximum of 3TB storage capacity;  S.M.A.R.T. and bad sector detection;  HDD sleeping function;  HDD property: read-only, read/write (R/W);

Recording and Playback

 Holiday recording schedule configuration;  Cycle and non-cycle recording modes;  Normal and event video encoding parameters;  Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm and Event;  8 recording time periods with separated recording types;  Pre-record and post-record for motion detection triggered recording, and pre-record time for schedule

and manual recording;

 Searching record files by events (alarm input/motion detection);  Customization of tags, searching and playing back by tags;  Locking and unlocking of record files;  Local redundant recording;

Digital Video Recorder User Manual

 Searching and playing back record files by camera number, recording type, start time, end time, etc.;  Smart playback to go through less effective information;  Zooming in for any area when playback;  Multi-channel reverse playback;  Supports pause, fast forward, slow forward, skip forward, and skip backward when playback, locating by

dragging the mouse on the progress bar;

 4/8-ch synchronous playback;

Backup

 Export data by a USB device;  Export video clips when playback;  Management and maintenance of backup devices.

Alarm and Exception

 Configurable arming time of alarm input/output;  Alarm for video loss, motion detection, video tampering, abnormal signal, video input/recording

resolution mismatch, illegal login, network disconnected, IP confliction, record exception, HDD error, and HDD full, etc.;

 Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and

alarm output;

 Support coaxial alarm;  Automatic restore when system is abnormal.

Other Local Functions

 Manual and automatic video quality diagnostics;  Operable by mouse and remote control;  Three-level user management; admin user can create many operating account and define their operating

permission, which includes the permission to access any channel;

 Completeness of operation, alarm, exceptions and log writing and searching;  Manually triggering and clearing alarms;  Importing and exporting of configuration file of devices;  Getting cameras type information automatically.

Network Functions

 1 self-adaptive 10M/100M network interface is supported;  TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, UPnP™ and HTTPS are supported;  Extranet access by HiDDNS;  Support access by Cloud P2P;  TCP, UDP and RTP for unicast;  Auto/Manual port mapping by UPnPTM;  Remote search, playback, download, locking and unlocking the record files, and downloading files

broken transfer resume;

 Remote parameters setup; remote import/export of device parameters;  Remote viewing of the device status, system logs and alarm status;  Remote keyboard operation;  Remote locking and unlocking of control panel and mouse;  Remote HDD formatting and program upgrading;  Remote system restart and shutdown;  Support upgrading via remote FTP server;

Digital Video Recorder User Manual

 Alarm and exception information can be sent to the remote host;  Remotely start/stop recording;  Remotely start/stop alarm output;  Remote PTZ control;  Remote JPEG capture;  Two-way audio and voice broadcasting;  Embedded WEB server.

Development Scalability

 SDK for Windows and Linux system;  Source code of application software for demo;  Development support and training for application system.

Digital Video Recorder User Manual

Table of Contents

Chapter 1 Preventive and Cautionary Tips..................................................................... ..................... 4

Chapter 2 Introduction ........................................................................................................................ 11

2.1 Front Panel ........................................................ ......................................... ............................ ....... 11

2.2 USB Mouse Operation ................................................................... .......................................... ..... 12

2.3 Input Method Description............................................................................................................. . 13

2.4 Rear Panel .............................................................................................................. ....................... 14

Chapter 3 Getting Started ................................................................................................................... 15

3.1 Starting Up and Shutting Down the DVR...................................................................................... 15

3.2 Activating the Device ........................................................................... ....................................... .. 16

3.3 Using the Wizard for Basic Configuration.............................................................. ....................... 17

3.4 Login and Logout ........................................................................................................................ .. 21

3.4.1 User Login ............................................................ ......................................... ...................... 21

3.4.2 User Logout ......................................................................................................... ................ 21

3.5 Live View ...................................................................... ......................................... ....................... 22

3.6 Introduction of Live View ............................................................................................................ . 22

3.7 Operations in Live View Mode............................................... ............................................ ........... 23

3.7.3 Using the Mouse in Live View............................................................................................. 23

3.7.4 HDMI and VGA Non-Simultaneous Output ........................................................................ 24

3.7.5 Quick Setting Toolbar in Live View Mode .......................................................................... 25

3.8 Adjusting Live View Settings ............................................................... ....................................... .. 26

3.9 Manual Video Quality Diagnostics .......................................................................................... ...... 28

3.10 User Logout .................................................................................................................. ................. 29

Chapter 4 PTZ Controls ..................................................................................................................... . 29

4.1 Configuring PTZ Settings.................................................... ......................................... ................. 29

4.2 Setting PTZ Presets, Patrols and Patterns .................................................................................... .. 31

4.2.1 Customizing Presets............................................................................................................. 31

4.2.2 Calling Presets .................................................................. ......................................... .......... 31

4.2.3 Customizing Patrols .......................................................................................................... ... 32

4.2.4 Calling Patrols ..................................................................................................................... 33

4.2.5 Customizing Patterns .......................................................................... ................................. 34

4.2.6 Calling Patterns...................................................... .............................................................. 35

4.2.7 Customizing Linear Scan Limit .......................................................................................... . 35

4.2.8 Calling Linear Scan ............................................................................................................. 36

4.2.9 One-touch Park .................................................................................................................... 37

4.3 PTZ Control Panel ..................... .......................................... ......................................... ................. 38

Chapter 5 Recording Settings............................................................................................................. . 39

5.1 Configuring Encoding Parameters................................................................................................. 39

5.2 Configuring Recording Schedule ................................................................................................. . 42

5.3 Configuring Motion Detection Recording ........................................................ ............................ . 45

5.4 Configuring Manual Recording .................... ........................................ ....................................... .. 46

Digital Video Recorder User Manual

5.5 Configuring Holiday Recording ............................. .......................................... ............................. 47

5.6 Files Protection.............................................................................................................................. 49

5.7 Configuring 1080p Lite ................................................................................................................. 51

Chapter 6 Playback ............................................................................................................................. . 52

6.1 Playing Back Record Files ................................................................... ....................................... .. 52

6.1.1 Instant Playback ................................................................................................................... 52

6.1.2 Playing Back by Normal Search .......................................................................................... 52

6.1.3 Playing Back by Event Search .............................................. ............................................ ... 55

6.1.4 Playing Back by Tag ........................................................................................................... . 56

6.1.5 Playing Back by Smart Search ............................................................................................. 58

6.1.6 Playing Back by System Logs ............................................................................................. 59

6.1.7 Playing Back by Sub-Periods.............................................................................................. . 60

6.1.8 Playing Back External File ........................................................................................ .......... 61

6.2 Auxiliary Functions of Playback .................................................................................................. . 62

6.2.1 Playing Back Frame by Frame ............................................................................................ . 62

6.2.2 Digital Zoom....................................................................................................................... . 62

6.2.3 Reverse Playback of Multi-channel ..................................................................................... 63

Chapter 7 Backup ............................................................................................................................. ... 64

7.1 Backing up Record Files ......................................... ......................................... ............................. 64

7.1.1 Backing up by Normal Video Search ................................................................................... 64

7.1.2 Backing up by Event Search ................................................................................................ 66

7.1.3 Backing up Video Clips ...................................................................................................... . 67

7.2 Managing Backup Devices ..................................................................................... ....................... 68

Chapter 8 Alarm Settings .................... ......................................... .......................................... ............. 69

8.1 Setting Motion Detection............................................................................................................... 69

8.2 Detecting Video Loss.................................................................................................................... . 71

8.3 Detecting Video Tampering ........................................................................................................... 72

8.4 Setting All-day Video Quality Diagnostics .................................................................................... 74

8.5 Handling Exceptions .............................................................................................. ....................... 75

8.6 Setting Alarm Response Actions ................................................................................................... 76

Network Settings ............................................................................................................................................ 77

8.7 Configuring General Settings ....................................................................................................... . 77

8.8 Configuring Advanced Settings ................ ..................................................................................... 78

8.8.1 Configuring PPPoE Settings ................................................. ............................................ ... 78

8.8.2 Configuring Cloud P2P ........................................................................................................ 78

8.8.3 Configuring DDNS .............................................................................................................. 79

8.8.4 Configuring NTP Server ..................................................................................................... . 84

8.8.5 Configuring NAT ................................................................................................................. 85

8.8.6 Configuring More Settings................................................................................................... 86

8.8.7 Configuring HTTPS Port ..................................................................................................... 87

8.8.8 Configuring Email ............................................................................................................... 89

8.9 Checking Network Traffic ............................................................................................................. 90

8.10 Configuring Network Detection .................................................................................................... 91

8.10.1 Testing Network Delay and Packet Loss.............................................................................. 91

Digital Video Recorder User Manual

8.10.2 Exporting Network Packet ................................................................. .................................. 91

8.10.3 Checking Network Status..................................................................................................... 92

8.10.4 Checking Network Statistics ................................................................................................ 93

Chapter 9 HDD Management.............................................................................................................. 94

9.1 Initializing HDDs .................................................... ......................................... ............................. 94

9.2 Managing Network HDD ............................................................................................................. . 95

9.3 Managing HDD Group ..................................................................................... ............................. 97

9.3.1 Setting HDD Groups................................................................................................... ......... 97

9.3.2 Setting HDD Property.......................................................................................................... 99

9.4 Configuring Quota Mode.......................................................................................................... ... 100

9.5 Checking HDD Status ................................................................................................................. 101

9.6 Checking S.M.A.R.T Information ....................................................... ........................................ 102

9.7 Detecting Bad Sector ....................... ............................................................................................ 103

9.8 Configuring HDD Error Alarms .................................................................................................. 104

9.9 Checking and Editing Firmware .................................................................................................. 104

9.10 Configuring OSD Settings ........................................................................................................... 105

9.11 Configuring Privacy Mask........................................................................................................... 106

9.12 Configuring Video Parameters ........................................................................ ............................ 107

Chapter 10 DVR Management and Maintenance ............................................................................. 109

10.1 Viewing System Information ....................................................................................................... 109

10.2 Searching Log Files ......................... ....................................... ............................................ ......... 109

10.3 Importing/Exporting IP Camera Info .......................................................................................... . 111

10.4 Importing/Exporting Configuration Files .................................................................................... 112

10.5 Upgrading System ...................................................................................................................... . 112

10.5.1 Upgrading by Local Backup Device ................................................................................. . 112

10.5.2 Upgrading by FTP ............................................................................................................. 113

10.6 Restoring Default Settings .......................................................................................................... . 113

Chapter 11 Others ............................................................................................................................. ... 115

11.1 Configuring General Settings ...................................................................................................... 115

11.2 Configuring DST Settings ................................. ......................................... ................................. 116

11.3 Configuring More Settings ............................................ ......................................... ..................... 116

11.4 Managing User Accounts............................................................................................................. 117

11.4.1 Adding a User .................................................................... ......................................... ....... 117

11.4.2 Deleting a User .................................................................................................................. 119

11.4.3 Editing a User ...................................................................................................... .............. 120

Chapter 12 Appendix ................................................................................................................ ........... 121

12.1 Specifications ......................................................................................................... ..................... 121

12.2 Glossary....................................................................................................................................... 122

12.3 Troubleshooting.......................................................................................................................... . 123

Digital Video Recorder User Manual

Chapter 2 Introduction

2.1 Front Panel

Figure 2. 1 Front

Panel

Table 2. 1 Description of Front Panel

No.

Icon

Description

Turns red when DVR is powered up.

Turns red when data is being read from or written to HDD.

Flickers blue when network connection is functioning properly.

Digital Video Recorder User Manual

2.2 USB Mouse Operation

A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this DVR. To use a USB mouse: Steps:

1. Plug USB mouse into one of the USB interfaces on the front panel of the DVR.

2. The mouse should automatically be detected. If in a rare case that the mouse is not detected, the possible

reason may be that the two devices are not compatible, please refer to the recommended the device list from your provider.

The operation of the mouse:

Table 2. 2 Description of the Mouse Control

Name

Action

Description

Left-Click

Single-Click

Live view: Select channel and show the quick set menu. Menu: Select and enter.

Double-Click

Live view: Switch between single-screen and multi-screen.

Click and Drag

PTZ control: Wheeling. Privacy mask and motion detection: Select target area. Digital zoom-in: Drag and select target area. Live view: Drag channel/time bar.

Right-Click

Single-Click

Live view: Show menu. Menu: Exit current menu to upper level menu.

Scroll-Wheel

Scrolling up

Live view: Previous screen. Menu: Previous item.

Scrolling down

Live view: Next screen. Menu: Next item.

Digital Video Recorder User Manual

2.3 Input Method Description

Figure 2. 2 Soft

Keyboard

Description of the buttons on the soft keyboard:

Table 2. 3 Description of the Soft Keyboard Icons

Icon

Description

Icon

Description

…

Number

…

English letter

Lowercase/Uppercase

Backspace

Switch the keyboard

Space

Positioning the cursor

Exit

Symbols

Reserved

Digital Video Recorder User Manual

2.4 Rear Panel

The rear panel vaires according to different models. Please refer to the actual product. The following figures are for reference only.

Figure 2.

Table 2. 4 Description of Front Panel

No.

Item

Description

VIDEO IN

BNC interface for TVI and analog video input. Up to 8 ch.

HDMI

HDMI video output connector.

VGA

DB15 connector for VGA output. Display local video output and menu.

AUDIO OUT

RCA connector.

AUDIO IN

RCA connector.

Network Interface

Connector for network

USB Port

Universal Serial Bus (USB) port for additional devices.

GND

Ground

Power Supply

12 VDC power supply.

Digital Video Recorder User Manual

Chapter 3 Getting Started

3.1 Starting Up and Shutting Down the DVR

Before you start: Check that the voltage of the extra power supply is the same with the DVR’s requirement, and the ground connection is working properly. Starting up the DVR Steps:

1. Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an

Uninterruptible Power Supply (UPS) be used in conjunction with the device.

2. Turn on the power switch on the rear panel, and the Power indicator LED should turn on indicating that the

unit begins to start up.

3. After startup, the Power indicator LED remains on.

Shutting down the DVR

Steps: There are two proper ways to shut down the DVR. To shut down the DVR:

 OPTION 1: Standard shutdown

1. Enter the Shutdown menu.

Menu > Shutdown

Figure 3. 1 Shutdown

2. Select the Shutdown button.

3. Click the Yes button.

Figure 3. 2 Shutdown Tips

Rebooting the DVR While in the Shutdown menu (Figure 3. 1), you can also reboot the DVR. Steps:

Digital Video Recorder User Manual

1. Enter the Shutdown menu by clicking Menu > Shutdown.

2. Click the Logout button to log out or the Reboot button to reboot the DVR.

3.2 Activating the Device

Purpose: For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. You can also activate the device via Web Browser, SADP or Client Software. Steps:

1. Input the same password in the text field of Create New Password and Confirm New Password.

Figure 3. 3 Settings Admin

Password

STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

2. Click OK to save the password and activate the device.

For the old version device, if you update it to the new version, the following dialog box will pop up once the device starts up. You can click YES and follow the wizard to set a strong password.

Digital Video Recorder User Manual

Figure 3. 4

Warning

3.3 Using the Wizard for Basic Configuration

By default, the Setup Wizard starts once the device has loaded.

Figure 3. 5 Start Wizard

Interface

Operating the Setup Wizard:

1. The Start Wizard can walk you through some important settings of the device. If you don’t want to use the Start Wizard at that moment, click Exit. You can also choose to use the Start Wizard next time by leaving the “Start wizard when device starts?” checkbox checked.

2. Click Next to enter the date and time settings window.

Figure 3. 6 Date and Time Settings

3. After the time settings, click Next button which will take you back to the General Network Setup Wizard window, as shown in Figure 3. 7.

Digital Video Recorder User Manual

Figure 3. 7 General Network Configuration

4. Click Next button after you configured the basic network parameters. Then you will enter the Cloud P2P interface. Configure the Cloud P2P according to your need.

Figure 3. 8 Advanced Network Configuration

5. Click Next button to enter the Advanced Network Parameter interface. You can enable PPPoE, enable DDNS and set other ports according to your need.

Digital Video Recorder User Manual

Figure 3. 9 Advanced Network Parameters

6. Click Next button after you configured the network parameters Array Management

7. Click Next button after configuring the advanced network parameters, which will take you to the HDD Management window, shown in Figure 3. 10.

Figure 3. 10 HDD Management

8. To initialize the HDD, click the Init button. Initialization will remove all the data saved in the HDD.

9. Click Next to enter the IP Camera Management window (only supported by HDVR series).

10. Click Search to search the online IP Camera and the Security status shows whether it is active or inactive.

Before adding the camera, make sure the IP camera to be added is in active status. If the camera is in inactive status, you can click the inactive icon of the camera to set the password to

activate it. You can also select multiple cameras from the list and click the One-touch Activate to activate the cameras in batch. Click the Add to add the camera.

Digital Video Recorder User Manual

Figure 3. 11 IP Camera Management

11. After finishing IP Camera settings, click Next to enter the Record Settings window.

12. Click the icon , and you can enable the continuous recording or motion Detection recording for all

channels of the device.

Figure 3. 12 Record Settings

13. Click OK to complete the wizard settings.

Digital Video Recorder User Manual

3.4 Login and Logout

3.4.1 User Login

Purpose: If the device has logged out, you must login the device before operating the menu and other functions. Steps:

1. Select the User Name in the dropdown list.

Figure 3. 13 Login Interface

2. Input Password.

3. Click OK to log in.

In the Login dialog box, if you have entered the wrong password for 7 times, the current user account will be locked for 60 seconds.

Figure 3. 14 User Account Protection

3.4.2 User Logout

Purpose: After logging out, the monitor turns to the live view mode and if you want to perform some operation, you need to enter user name and password log in again. Steps:

1. Enter the Shutdown menu. Menu > Shutdown

Digital Video Recorder User Manual

Figure 3. 15

Logout

2. Click Logout.

After you have logged out the system, menu operation on the screen is invalid. It is required to input a user name and password to unlock the system.

3.5 Live View

3.6 Introduction of Live View

Live view shows you the video image getting from each camera in real time. The DVR will automatically enter Live View mode when powered on. It is also at the very top of the menu hierarchy, thus hitting the ESC many times (depending on which menu you’re on) will bring you to the Live View mode.

Live View Icons In the live view mode, there are icons at the right top of the screen for each channel, showing the status of the record and alarm in the channel, so that you can know whether the channel is recorded, or whether there are alarms occur as soon as possible.

Table 3. 1 Description of Live View Icons

Icons

Description

Alarm (video loss, tampering, motion detection or sensor alarm)

Record (manual record, schedule record, motion detection or alarm triggered record)

Alarm & Record

Event/Exception (motion detection, sensor alarm or exception information. For details, see Chapter 8.5 Handling Exceptions.)

Digital Video Recorder User Manual

3.7 Operations in Live View Mode

In live view mode, there are many functions provided. The functions are listed below.

• Single Screen: show only one screen on the monitor.

• Multi-screen: show multiple screens on the monitor simultaneously.

• Auto-switch: the screen is auto switched to the next one. And you must set the dwell time for each screen on

the configuration menu before enabling the auto-switch. Menu>Configuration>Live View>Dwell Time.

• Start Recording: normal record and motion detection record are supported.

• Quick Set: select the output mode to Standard, Bright, Gentle or Vivid.

• Playback: play back the recorded videos for current day.

The priority level for the main output is HDMI/VGA. See the table below.

Table 3. 2 Priorities of Interfaces

S.N

VGA/HDMI

Main output

1 √ VGA/HDMI

3.7.3 Using the Mouse in Live View

Table 3. 3 Mouse Operation in Live View

Name

Description

Enter the main menu of the system by right clicking the mouse.

Single Screen

Switch to the single full screen by choosing channel number from the dropdown list.

Multi-screen

Adjust the screen layout by choosing from the dropdown list.

Previous Screen

Switch to the previous screen.

Next Screen

Switch to the next screen.

Start/Stop Auto-switch

Enable/disable the auto-switch of the screens.

The dwell time of the live view configuration must be set before using Start Auto-switch.

Start Recording

Start recording of all channels, Normal Record and Motion Detection Recording are selectable from the dropdown list.

Quick Set

Output Mode is configurable with Standard, Bright, Gentle and Vivid options.

Playback

Enter the playback interface and start playing back the video of the selected channel immediately.

PTZ Control

A shortcut to enter the PTZ control interface of the selected camera.

Digital Video Recorder User Manual

Figure 3. 16 Right-click Menu

The Add IP Camera is not supported

3.7.4 HDMI and VGA Non-Simultaneous Output

DVR support HDMI and VGA non-simultaneous output. Steps:

1. Enter the Configuration Menu

Menu > Configuration

2. Click More Settings to enter the more settings interface.

Figure 3. 17 More Settings Interface

Digital Video Recorder User Manual

3.7.5 Quick Setting Toolbar in Live View Mode

On the screen of each channel, there is a quick setting toolbar which shows when you point the mouse to the bottom of the screen.

Figure 3. 18 Quick Setting Toolbar

Table 3. 4 Description of Quick Setting Toolbar Icons

Icons

Description

Icons

Description

Icons

Description

Enable/Disable

Manual Record

Instant Playback

Mute/Audio on

PTZ Control

Digital Zoom

Image Settings

Close Live View

Instant Playback only shows the record in last five minutes. If no record is found, it means there is no record

during the last five minutes.

Digital Zoom can zoom in the selected area to the full screen. Click and draw to select the area to zoom in, as

shown in Figure 3. 19.

Figure 3. 19 Digital

Zoom

Image Settings icon can be selected to enter the Image Settings menu.

Four modes are selectable according to the real situation:

• Standard: for general lighting conditions (default).

• Indoor: the image is relatively smoother.

• Dim Light: the image is smoother than the other two modes.

Digital Video Recorder User Manual

• Outdoor: the image is relatively clearer and sharper. The degree of contrast and saturation is high.

Figure 3. 20 Image

Settings

You can adjust the image parameters, including brightness, contrast, saturation, hue, sharpness and denoising. You can also click Default to restore the default settings and click Copy to copy the image settings to other analog cameras. Refer to the Chapter 9.12 Configuring Video Parameters for details.

3.8 Adjusting Live View Settings

Purpose: Live View settings can be customized according to different needs. You can configure the output interface, dwell time for screen to be shown, mute or turning on the audio, the screen number for each channel, etc. Steps:

1. Enter the Live View Settings interface.

Menu> Configuration> Live View

Figure 3. 21 Live View-General

The settings available in this menu include:

• Video Output Interface: Designates the output to configure the settings

• Live View Mode: Designates the display mode to be used for Live View.

• Dwell Time: The time in seconds to dwell between switching of channels when enabling auto-switch in

Live View.

• Enable Audio Output: Enables/disables audio output for the selected camera in the live view mode.

Digital Video Recorder User Manual

• Volume: Adjust the volume of the audio output.

• Event Output: Designates the output to show event video; if available, you can select a different video

output interface from the Video Output Interface when an event occurs.

• Full Screen Monitoring Dwell Time: The time in seconds to show alarm event screen.

2. Set the camera order.

1) Select View tab.

Figure 3. 22 Live View- Camera Order

2) Click a window to select it, and then double-click a camera name in the camera list you would like to

display. Setting an ‘X’ means the window will not display any camera.

3) You can also click to start live view of all channels in order and click to stop live view of all

channels. Click or to go to the previous or next page.

4) Click the Apply button.

Digital Video Recorder User Manual

3.9 Manual Video Quality Diagnostics

Purpose: The video quality of the analog channels can be diagnosed manually and you can view the diagnostic results from a list. Steps:

1. Enter the Manual Video Quality Diagnostics interface.

Menu> Manual >Manual Video Quality Diagnostics

Figure 3. 23 Video Quality Diagnostics

2. Check the checkboxes to select the channels for diagnostics.

3. Click the button Diagnose, and the results will be displayed on a list. You can view the video status and

diagnostics time of the selected channels.

Figure 3. 24 Diagnostics Result

 Connect the camera to the device for the video quality diagnostics.  Three exception types can be diagnosed: Blurred Image, Abnormal Brightness and Color Cast.

Digital Video Recorder User Manual

3.10 User Logout

Purpose: After logging out, the monitor turns to the live view mode and if you want to do some operation, you need to enter user name and password to log in again. Steps:

3. Enter the Shutdown menu. Menu>Shutdown

Figure 3. 25

Shutdown

4. Click Logout.

Chapter 4 PTZ Controls

4.1 Configuring PTZ Settings

Purpose: Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done before you control the PTZ camera. Steps:

1. Enter the PTZ Settings interface. Menu >Camera> PTZ

Digital Video Recorder User Manual

Figure 4. 1 PTZ

Settings

2. Choose the camera for PTZ setting in the Camera dropdown list.

3. Click the PTZ Parameters button to set the PTZ parameters.

Figure 4. 2 PTZ-

General

4. Enter the parameters of the PTZ camera.

All the parameters should be exactly the same as the PTZ camera parameters.

For the Coaxitron camera/dome connected, you can select the PTZ protocol to VISION-C (Coaxitron). Make sure the protocol selected here is supported by the connected camera/dome. When the Coaxitron protocol is selected, all the other parameters like the baud rate, data bit, stop bit, parity and flow control are not configurable.

Digital Video Recorder User Manual

5. Click Apply button to save the settings.

4.2 Setting PTZ Presets, Patrols and Patterns

Before you start: Please make sure that the presets, patrols and patterns should be supported by PTZ protocols.

4.2.1 Customizing Presets

Purpose: Follow the steps to set the Preset location which you want the PTZ camera to point to when an event takes place. Steps:

1. Enter the PTZ Control interface. Menu>Camera>PTZ

Figure 4. 3 PTZ

Settings

2. Use the directional button to wheel the camera to the location where you want to set preset; and the zoom and focus operations can be recorded in the preset as well.

3. Enter the preset No. (1~255) in the preset text field, and click the Set button to link the location to the preset. Repeat the steps2-3 to save more presets. You can click the Clear button to clear the location information of the preset, or click the Clear All button to clear the location information of all the presets.

4.2.2 Calling Presets

Purpose: This feature enables the camera to point to a specified position such as a window when an event takes place.

Digital Video Recorder User Manual

Steps:

1. Click the button PTZ in the lower-right corner of the PTZ setting interface; Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar, or

select the PTZ option in the right-click menu to show the PTZ control panel.

2. Choose Camera in the dropdown list.

3. Click the button to show the general settings of the PTZ control.

Figure 4. 4 PTZ Panel - General

4. Click to enter the preset No. in the corresponding text field.

5. Click the Call Preset button to call it.

When the Coaxitron camera/dome connected and the PTZ protocol is selected to VISION-C (Coaxitron), you can call the preset 95 to enter the menu of the connected Coaxitron camera/dome. Use the directional buttons on the PTZ control panel to operate the menu.

4.2.3 Customizing Patrols

Purpose: Patrols can be set to move the PTZ to different key points and have it stay there for a set duration before moving on to the next key point. The key points are corresponding to the presets. The presets can be set following the steps above in Customizing Presets. Steps:

1. Enter the PTZ Control interface.

Menu>Camera>PTZ

Digital Video Recorder User Manual

Figure 4. 5 PTZ

Settings

2. Select patrol No. in the drop-down list of patrol.

3. Click the Set button to add key points for the patrol.

Figure 4. 6 Key point Configuration

4. Configure key point parameters, such as the key point No., duration of staying for one key point and speed of patrol. The key point is corresponding to the preset. The Key Point No. determines the order at which the PTZ will follow while cycling through the patrol. The Duration refers to the time span to stay at the corresponding key point. The Speed defines the speed at which the PTZ will move from one key point to the next.

5. Click the Add button to add the next key point to the patrol, or you can click the OK button to save the key point to the patrol. You can delete all the key points by clicking the Clear button for the selected patrol, or click the Clear All button to delete all the key pints for all patrols.

4.2.4 Calling Patrols

Purpose: Calling a patrol makes the PTZ to move according the predefined patrol path. Steps:

1. Click the button PTZ in the lower-right corner of the PTZ setting interface;

Digital Video Recorder User Manual

Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar, or select the PTZ option in the right-click menu to show the PTZ control panel.

2. Click the button to show the general settings of the PTZ control.

Figure 4. 7 PTZ Panel - General

3. Select a patrol in the dropdown list and click the Call Patrol button to call it.

4. You can click the Stop Patrol button to stop calling it.

4.2.5 Customizing Patterns

Purpose: Patterns can be set by recording the movement of the PTZ. You can call the pattern to make the PTZ movement according to the predefined path. Steps:

1. Enter the PTZ Control interface. Menu > Camera > PTZ

Figure 4. 8 PTZ

Settings

2. Choose pattern number in the dropdown list.

3. Click the Start button and click corresponding buttons in the control panel to move the PTZ camera, and

Digital Video Recorder User Manual

click the Stop button to stop it. The movement of the PTZ is recorded as the pattern.

4.2.6 Calling Patterns

Purpose: Follow the procedure to move the PTZ camera according to the predefined patterns. Steps:

1. Click the button PTZ in the lower-right corner of the PTZ setting interface; Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar, or

select the PTZ option in the right-click menu to show the PTZ control panel.

2. Click the button to show the general settings of the PTZ control.

Figure 4. 9 PTZ Panel - General

3. Click the Call Pattern button to call it.

4. Click the Stop Pattern button to stop calling it.

4.2.7 Customizing Linear Scan Limit

Purpose: The Linear Scan can be enabled to trigger the scan in the horizantal direction in the predefined range.

This function is supported by some certain models. Steps:

1. Enter the PTZ Control interface. Menu > Camera > PTZ

Digital Video Recorder User Manual

Figure 4. 10 PTZ

Settings

2. Use the directional button to wheel the camera to the location where you want to set the limit, and click the Left Limit or Right Limit button to link the location to the corresponding limit.

The speed dome starts linear scan from the left limit to the right limit, and you must set the left limit on the left side of the right limit, as well the angle from the left limit to the right limit should be no more than 180º.

4.2.8 Calling Linear Scan

Purpose: Follow the procedure to call the linear scan in the predefined scan range. Steps:

1. Click the button PTZ in the lower-right corner of the PTZ setting interface; Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar to

enter the PTZ setting menu in live view mode.

2. Click the button to show the one-touch function of the PTZ control.

Figure 4. 11 PTZ Panel - One-touch

Digital Video Recorder User Manual

3. Click Linear Scan button to start the linear scan and click the Linear Scan button again to stop it. You can click the Restore button to clear the defined left limit and right limit data and the dome needs to reboot to make settings take effect.

4.2.9 One-touch Park

Purpose: For some certain model of the speed dome, it can be configured to start a predefined park action (scan, preset, patrol and etc.) automatically after a period of inactivity (park time). Steps:

1. Click the button PTZ in the lower-right corner of the PTZ setting interface; Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar to

enter the PTZ setting menu in live view mode.

2. Click the button to show the one-touch function of the PTZ control.

Figure 4. 12 PTZ Panel -

One-touch

3. There are 3 one-touch park types selectable, click the corresponding button to activate the park action. Park (Quick Patrol): The dome starts patrol from the predefined preset 1 to preset 32 in order after the park

time. The undefined preset will be skipped.

Park (Patrol 1): The dome starts move according to the predefined patrol 1 path after the park time. Park (Preset 1): The dome moves to the predefined preset 1 location after the park time.

The park time can only be set through the speed dome configuration interface, by default the value is 5s.

4. Click the button again to inactivate it.

Digital Video Recorder User Manual

4.3 PTZ Control Panel

To enter the PTZ control panel, there are two ways supported. OPTION 1: In the PTZ settings interface, click the PTZ button on the lower-right corner which is next to the Back button. OPTION 2: In the Live View mode, you can press the PTZ Control button on the front panel or on the remote control, or

choose the PTZ Control icon , or select the PTZ option in the right-click menu. Click the Configuration button on the control panel, and you can enter the PTZ Settings interface.

In PTZ control mode, the PTZ panel will be displayed when a mouse is connected with the device. If no mouse is connected, the icon appears in the lower-left corner of the window, indicating that this

camera is in PTZ control mode.

Figure 4. 13 PTZ

Panel

Table 4. 1 Description of the PTZ panel icons

Icon

Description

Icon

Description

Icon

Description

Direction button and

the auto-cycle button

Zoom+, Focus+,

Iris+

Zoom-, Focus-, Iris-

The speed of the

PTZ movement

Light on/off

Wiper on/off

3D-Zoom

Image Centralization

Switch to the PTZ

control interface

Switch to the

one-touch control

interface

Switch to the general

settings interface

Previous item

Next item

Start pattern / patrol

Stop the patrol /

pattern movement

Exit

Minimize windows

Digital Video Recorder User Manual

Chapter 5 Recording Settings

5.1 Configuring Encoding Parameters

Before you start:

1. Make sure that the HDD has already been installed. If not, please install a HDD and initialize it.

(Menu>HDD>General)

Figure 5. 1 HDD-

General

2. Click Advanced to check the storage mode of the HDD.

1) Whether the HDD mode is Quota, please set the maximum record capacity. For detailed information, see

Chapter 9.4 Configuring Quota Mode.

2) If the HDD mode is Group, you should set the HDD group. For detailed information, see Chapter Fehler!

Verweisquelle konnte nicht gefunden werden. Configuring HDD Group for Recording.

Figure 5. 2 HDD-

Advanced

Steps:

1. Enter the Record settings interface to configure the encoding parameters:

Menu>Record>Parameters

Digital Video Recorder User Manual

Figure 5. 3 Record Parameters

2. Set the parameters for recording.

1) Select the Record tab to configure.

2) Select a camera number in the camera dropdown list.

You can configure the stream type, the resolution, the video quality and other parameters on demand for Main Stream (Continuous) and Main Stream (Event) respectively.

 The resolution of 1920*1080 (1080p Lite) is supported.

3. Click More Settings to configure more parameters.

Figure 5. 4 More Settings of Record Parameters

• Pre-record: The time you set to record before the scheduled time or event. For example, when an

alarm triggered the recording at 10:00, if you set the pre-record time as 5 seconds, the camera records it at 9:59:55.

• Post-record: The time you set to record after the event or the scheduled time. For example, when

Digital Video Recorder User Manual

an alarm triggered the recording ends at 11:00, if you set the post-record time as 5 seconds, it records till 11:00:05.

• Expired Time: The time for keeping the record files in the HDDs, once exceeded, the files will be

deleted. The files will be saved permanently if the value is set as 0. The actual keeping time for the files should be determined by the capacity of the HDDs.

• Redundant Record: Enabling redundant record means you save the record in the redundant HDD.

See Chapter 5.8 Configuring Redundant Recording.

• Record Audio: Enable this feature to record the sound and disable it to record the video without

sound.

• Video Stream: Main stream and sub-stream are selectable for recording. When you select

sub-stream, you can record for a longer time with the same storage space.

• Enable 960 Mode: The option is supported by analog cameras. Enabling the 960 mode to enable

the WD1 resolution for the main stream, otherwise, the resolution supports up to 4CIF. And the option does not supported by TVI cameras, while the WD1 resolution is available all the time.

 The Redundant Record option is only available when the HDD mode is Group.  Redundant HDD is required for the redundant record function. For detailed information, see Chapter

11.4.2 Setting HDD Property.

 For network cameras, the parameters of Main Stream (Event) are not editable.

4. Click Apply to save the settings.

5. Optionally, you can click Copy to copy the settings to other analog channels if needed.

You can copy the same settings to the cameras with same signal, e.g., the channel No. 1-3 connect to the TVI cameras, and the channel No.4 connects to an analog camera, and then the settings of channel No. 1 can be only copied to channel 2 and 3.

Figure 5. 5 Copy Camera Settings

6. Set encoding parameters for sub-stream.

1) Select the Substream tab.

Digital Video Recorder User Manual

Figure 5. 6 Sub-stream Encoding

2) Select a camera in the camera dropdown list.

3) Configure the parameters.

4) Click Apply to save the settings.

5) (Optional) If the parameters can also be used to other cameras, click Copy to copy the settings to other

channels.

5.2 Configuring Recording Schedule

 The DVR support continuous, motion and event triggered recording types, and other models support

continuous, alarm, motion, motion | alarm, motion & alarm and event triggered recording types.

 In this chapter, we take the record schedule procedure as an example, and the same procedure can be applied

to configure schedule for both continuous recording.

Purpose: Set the record schedule, and then the camera will automatically start/stop recording according to the configured schedule. Steps:

1. Enter the Record Schedule interface.

Menu> Record> Schedule

Digital Video Recorder User Manual

Figure 5. 7 Record

Schedule

Different recording types are marked in different color icons.

Continous: scheduled recording. Event: recording triggered by all event triggered alarm. Motion: recording triggered by motion detection. Alarm: recording triggered by alarm. M/A: recording triggered by either motion detection or alarm. M&A: recording triggered by motion detection and alarm.

2. Choose the camera you want to configure in the Camera dropdown list.

3. Check the checkbox of Enable Schedule.

4. Configure the record schedule. Edit the schedule

1) Click Edit.

2) In the message box, you can choose the day to which you want to set schedule.

3) To schedule an all-day recording, check the checkbox after the All Day item.

Figure 5. 8 Edit Schedule- All Day

4) To arrange other schedule, leave the All Day checkbox blank and set the Start/End time.

Digital Video Recorder User Manual

Figure 5. 9 Edit Schedule- Set Time Period

Up to 8 periods can be configured for each day. And the time periods cannot be overlapped with each other.

 To enable Event, Motion, Alarm, M | A (motion or alarm) and M & A (motion and alarm) triggered recording, you must configure the motion detection settings, alarm input settings or VCA settings as well. For detailed information, refer to Chapter 8.1, Chapter 8.8 and Chapter 9.  The VCA settings are only available to the smart IP cameras.

Repeat the above steps 1)-4) to schedule recording for other days in the week. If the schedule can also be set to other days, click Copy.

Figure 5. 10 Copy Schedule to Other

Days

The Holiday option is available when you enable holiday schedule in Holiday settings. See Chapter 5.5 Configuring Holiday Record.

5) Click OK to save setting and back to upper level menu. Draw the schedule

1) Click on the color icon to select a record type in the event list on the right-side of the interface.

Digital Video Recorder User Manual

Figure 5. 11 Draw the Schedule

2) Click and drag the mouse on the schedule.

3) Click on the other area except for the schedule table to finish and exit the drawing. You can repeat step 4 to set schedule for other channels. If the settings can also be used to other channels, click Copy, and then choose the channel to which you want to copy.

5. Click Apply in the Record Schedule interface to save the settings.

5.3 Configuring Motion Detection Recording

Purpose: Follow the steps to set the motion detection parameters. In the live view mode, once a motion detection event takes place, the DVR can analyze it and do many actions to handle it. Enabling motion detection function can trigger certain channels to start recording, or trigger full screen monitoring, audio warning, notifying the surveillance center, sending email and so on. Steps:

1. Enter the Motion Detection interface. Menu>Camera>Motion

Figure 5. 12 Motion

Detection

Digital Video Recorder User Manual

2. Configure Motion Detection:

1) Choose camera you want to configure.

2) Check the checkbox after Enable Motion Detection.

3) Drag and draw the area for motion detection by mouse. If you want to set the motion detection for all the

area shot by the camera, click Full Screen. To clear the motion detection area, click Clear.

Figure 5. 13 Motion Detection- Mask

4) Click the , and the message box for channel information pops up.

Figure 5. 14 Motion Detection Settings

5) Select the channels which you want the motion detection event to trigger recording.

6) Click Apply to save the settings.

7) Click OK to back to the upper level menu.

8) Exit the Motion Detection menu.

3. Configure the schedule. Please refer to the step 4 of Chapter 5.2 Configuring Recording Schedule, while you may choose Motion as the record type.

5.4 Configuring Manual Recording

Purpose: Follow the steps to set parameters for the manual record. Using manual record, you don’t need to set a schedule for recording. Steps:

1. Enter the Manual settings interface. Menu> Manual

Digital Video Recorder User Manual

Figure 5. 15 Manual Record

2. Enable manual record. Click the status icon before camera number to change it to . Or click the status icon of Analog to enable manual record of all channels.

3. Disable manual record. Click the status icon to change it to .

Or click the status icon of Analog to disable manual record of all channels.

After rebooting all the manual records enabled are canceled.

5.5 Configuring Holiday Recording

Purpose: Follow the steps to configure the record schedule on holiday for that year. You may want to have different plan for recording on holiday. Steps:

1. Enter the Record setting interface. Menu>Record

2. Choose Holiday on the left bar.

Figure 5. 16 Holiday Settings

3. Enable Edit Holiday schedule.

1) Click to enter the Edit interface.

Digital Video Recorder User Manual

Figure 5. 17 Edit Holiday Settings

2) Check the checkbox of Enable.

3) Select Mode from the dropdown list.

There are three different modes for the date format to configure holiday schedule. By Month, By Week, and By Date are selectable.

4) Set the start and end date.

5) Click Apply to save settings.

6) Click OK to exit the Edit interface.

4. Configure the record schedule. Please refer to the Chapter 5.2 Configuring Record Schedule, while you may choose Holiday in the Schedule dropdown list, or you can draw the schedule on the timeline of Holiday.

Figure 5. 18 Edit Schedule- Holiday

Up to 8 periods can be configured for each day. And the time periods cannot be overlapped each other.

In the time table of the channel, both holiday schedule and normal day schedule are displayed. Repeat the above step 4 to set Holiday schedule for other channel. If the holiday schedule can also be used to other channels, click Copy and choose the channel you want to apply the settings.

Digital Video Recorder User Manual

5.6 Files Protection

Purpose: You can lock the recorded files or set the HDD property to Read-only to protect the record files from being overwritten. Protect file by locking the record files Steps:

1. Enter Playback setting interface. Menu> Export

Figure 5. 19

Export

2. Select the channels you want to investigate by checking the checkbox to .

3. Configure the record type, file type, start time and end time.

4. Click Search to show the results.

Figure 5. 20 Export- Search

Result

5. Protect the record files.

1) Find the record files you want to protect, and then click the icon which will turn to ,

indicating that the file is locked.

The record files of which the recording is still not completed cannot be locked.

Digital Video Recorder User Manual

2) Click to change it to to unlock the file and the file is not protected.

Protect file by setting HDD property to Read-only Before you start: To edit HDD property, you need to set the storage mode of the HDD to Group. See Chapter 9.3 Managing HDD Group. Steps:

1. Enter HDD setting interface. Menu> HDD

Figure 5. 21 HDD

General

2. Click to edit the HDD you want to protect.

Figure 5. 22 HDD General-

Editing

3. Set the HDD to Read-only.

4. Click OK to save settings and back to the upper level menu.

 You cannot save any files in a Read-only HDD. If you want to save files in the HDD, change the property

to R/W.

 If there is only one HDD and is set to Read-only, the DVR cannot record any files. Only live view mode is

available.

 If you set the HDD to Read-only when the DVR is saving files in it, then the file will be saved in next R/W

HDD. If there is only one HDD, the recording will be stopped.

Digital Video Recorder User Manual

5.7 Configuring 1080p Lite

Purpose: When 1080p Lite Mode is enabled, 1080p lite (real time) is supported.

Steps:

1. Enter the Record menu

Menu > Record

2. Click Advanced to enter the advanced interface.

Figure 5. 23 Advanced Interface

3. Check the checkbox of 1080p Lite Mode and click Apply to pop up the attention box.

Figure 5. 24

Attention

4. Click Yes to reboot the device to have new settings taken effect.

Digital Video Recorder User Manual

Chapter 6 Playback

6.1 Playing Back Record Files

6.1.1 Instant Playback

Purpose:

Play back the recorded video files of a specific channel in the live view mode. Channel switch is supported.

Instant playback by channel Steps:

Choose a channel in live view mode and click the button in the quick setting toolbar.

In the instant playback mode, only record files recorded during the last five minutes on this channel will be played back.

Figure 6. 1 Instant Playback

Interface

6.1.2 Playing Back by Normal Search

Playback by Channel

Enter the Playback interface.

Mouse: right click a channel in live view mode and select Playback from the menu, as shown in the following

Digital Video Recorder User Manual

figure:

Figure 6. 2 Right-click Menu under Live View

The DVR provide no Aux Monitor option

Playback by Time

Purpose: Play back video files recorded in specified time duration. Multi-channel simultaneous playback and channel switch are supported. Steps:

1. Enter playback interface. Menu>Playback

2. Check the checkbox of channel(s) in the channel list and then double-click to select a date on the calendar.

Figure 6. 3 Playback Calendar

If there are record files for that camera in that day, in the calendar, the icon for that day is displayed as . Otherwise it is displayed as

Digital Video Recorder User Manual

Playback Interface

You can select the main stream or sub stream from the dropdown list for playback. You can also use the toolbar in the bottom part of Playback interface to control playing progress, as shown in the following figure.

Figure 6. 4 Playback Interface

Click the channel(s) if you want to switch playback to another channel or execute simultaneous playback of multiple channels.

Toolbar of Playback

Table 6. 1 Detailed Explanation of Playback Toolbar

Button

Operation

Button

Operation

Button

Operation

Audio on/ Mute

Start/Stop clipping

Lock File

Add default tag

Add customized tag

File management for

video clips, locked

files and tags

Reverse play/ Pause

Stop

Digital Zoom

30s forward

30s reverse

Pause / Play

Fast forward

Previous day

Slow forward

Full Screen

Exit

Next day

Save the clips

Process bar

Scaling up/down the

time line

Digital Video Recorder User Manual

 The indicates the start time and end time of the record files.  represents normal recording (manual or schedule); represents event recording (motion,

alarm, motion | alarm, motion & alarm).

 Playback progress bar: use the mouse to click any point of the progress bar to locate special frames.

6.1.3 Playing Back by Event Search

Purpose: Play back record files on one or several channels searched out by restricting event type (motion detection, alarm input ). Channel switch is supported.

 DVR does not support VCA type. Steps:

1. Enter the playback interface.

Menu>Playback

2. Click and select to enter the Event Playback interface.

3. Select Alarm Input, Motion, Line Crossing Detection, Intrusion Detection as the event type, and specify

the start time and end time for search.

Figure 6. 5 Video Search by Motion

Detection

4. Click Search, and the record files matching the search conditions will be displayed on a list.

5. Select and click button to play back the record files.

You can click Back to return to the search interface. If there is only one channel triggered, clicking button takes you to Full-screen Playback interface of this

channel. If several channels are triggered, clicking button takes you to the synch playback interface. Check

checkbox to select one channel for playback or select multiple channels for synchronous playback.

The max. number of channels for synchronous playback supported varies to different models.

Digital Video Recorder User Manual

Figure 6. 6 Select Channels for Synchronous Playback

6. Event playback interface. You can select the main stream or sub stream from the dropdown list for playback.

The toolbar in the bottom part of Playback interface can be used to control playing process.

Figure 6. 7 Interface of Playback by Event

Pre-play and post-play can be configured for the playback of event triggered record files.

Pre-play: The time you set to play back before the event. For example, when an alarm triggered the recording at 10:00, if you set the pre-play time as 5 seconds, the video plays back from 9:59:55. Post-play: The time you set to play back after the event. For example, when an alarm triggered the recording ends at 11:00, if you set the post-play time as 5 seconds, the video plays back till 11:00:05.

7. You can click or button to select the previous or next event. Please refer to Table 6.1 for the

description of buttons on the toolbar.

6.1.4 Playing Back by Tag

Purpose:

Digital Video Recorder User Manual

Video tag allows you to record related information like people and location of a certain time point during playback. You are also allowed to use video tag(s) to search for record files and position time point. Before playing back by tag:

1. Enter Playback interface.

Menu>Playback

2. Search and play back the record file(s). Refer to Chapter 6.1.2 Playing Back by Channel for the detailed

information about searching and playback of the record files.

Figure 6. 8 Interface of Playback by

Time

Click button to add default tag. Click button to add customized tag and input tag name.

Max. 64 tags can be added to a single video file.

3. Tag management.

Click button to check, edit and delete tag(s).

Figure 6. 9 Tag Management

Interface

Digital Video Recorder User Manual

Steps:

1. Select the Tag from the drop-down list in the Playback interface.

2. Choose channels, edit start time and end time, and then click Search to enter Search Result interface.

You can enter keyword in the textbox to search the tag on your command.

Figure 6. 10 Video Search by Tag

3. Click button to play back the file. You can click the Back button to back to the search interface.

Pre-play and post-play can be configured.

You can click or button to select the previous or next tag. Please refer to Table 6.1 for the description of buttons on the toolbar.

6.1.5 Playing Back by Smart Search

Purpose: The smart playback function provides an easy way to get through the less effective information. When you select the smart playback mode, the system will analyze the video containing the motion or VCA information, mark it with green color and play it in the normal speed while the video without motion will be played in the 16-time speed. The smart playback rules and areas are configurable. Steps:

1. Enter the Playback interface. Menu>Playback

2. Select the Smart in the drop-down list on the top-left side.

3. Select a camera in the camera list.

Digital Video Recorder User Manual

Figure 6. 11 Smart Playback

Interface

4. Select a date in the calendar and click the button to play.

The Result Filter function is supported by the IP camera only.

6.1.6 Playing Back by System Logs

Purpose: Play back record file(s) associated with channels after searching system logs. Steps:

1. Enter Log Information interface. Menu>Maintenance>Log Information

Figure 6. 12 System Log Search

Interface

2. Click Log Search tab to enter Playback by System Logs.

Digital Video Recorder User Manual

Set search time and type and click Search button.

Figure 6. 13 Result of System Log Search

3. Choose a log with record file and click button to enter Playback interface.

If there is no record file at the time point of the log, the message box “No result found” will pop up.

4. Playback management. The toolbar in the bottom part of Playback interface can be used to control playing process.

Figure 6. 14 Interface of Playback by Log

6.1.7 Playing Back by Sub-Periods

Purpose: The video files can be played in multiple sub-periods simultaneously on the screens. Steps:

1. Enter Playback interface. Menu>Playback

2. Select Sub-periods from the drop-down list in the upper-left corner of the page to enter the Sub-periods Playback interface.

3. Select a date and start playing the video file.

Digital Video Recorder User Manual

4. Select the Split-screen Number from the dropdown list. Up to 16 screens are configurable.

Figure 6. 15 Interface of Sub-periods Playback

According to the defined number of split-screens, the video files on the selected date can be divided into average segments for playback. E.g., if there are video files existing between 16:00 and 22:00, and the 6-screen display mode is selected, then it can play the video files for 1 hour on each screen simultaneously.

6.1.8 Playing Back External File

Purpose: Perform the following steps to look up and play back files in the external devices. Steps:

1. Enter the Playback interface. Menu>Playback

2. Select the External File in the drop-down list on the top-left side. The files are listed in the right-side list.

You can click the button to refresh the file list.

3. Select and click the button to play back it.

Digital Video Recorder User Manual

Figure 6. 16 Interface of External File Playback

6.2 Auxiliary Functions of Playback

6.2.1 Playing Back Frame by Frame

Purpose: Play video files frame by frame, in order to check image details of the video when abnormal events happen. Steps:

• Using a Mouse

Go to Playback interface and click button until the speed changes to Single frame. One click on the playback screen represents playback or adverse playback of one frame. It is also feasible to use button in

toolbar.

6.2.2 Digital Zoom

Steps:

1. Click the button on the playback control bar to enter Digital Zoom interface.

2. Use the mouse to draw a red rectangle and the image within it will be enlarged up to 16 times.

Digital Video Recorder User Manual

Figure 6. 17 Draw Area for Digital Zoom

3. Right-click the image to exit the digital zoom interface.

6.2.3 Reverse Playback of Multi-channel

Purpose: You can play back record files of multi-channel reversely. Up to 16-ch simultaneous reverse playback is supported. Steps:

1. Enter Playback interface. Menu>Playback

2. Check more than one checkboxes to select multiple channels and click to select a date on the calendar.

Figure 6. 18 4-ch Synchronous Playback Interface

3. Click to play back the record files reversely.

Digital Video Recorder User Manual

Chapter 7 Backup

7.1 Backing up Record Files

Before you start: Please insert the backup device(s) into the device.

7.1.1 Backing up by Normal Video Search

Purpose: The record files can be backup to various devices, such as USB devices (USB flash drives, USB HDDs, USB writer) Backup using USB flash drives and USB HDDs Steps:

1. Enter Export interface. Menu>Export>Normal

2. Select the cameras to search.

3. Set search condition and click Search button to enter the search result interface.

Figure 7. 1 Normal Video Search for Backup

4. The matched video files are displayed in Chart or List display mode.

Click to play the record file if you want to check it. Check the checkbox before the video files you want to back up.

The size of the currently selected files is displayed in the lower-left corner of the window.

Digital Video Recorder User Manual

Figure 7. 2 Result of Normal Video Search for Backup

5. Select video files from the Chart or List to export, and click the button Export to enter the Export interface. You can also click Export All to select all the video files for backup and enter the Export interface.

Figure 7. 3 Export by Normal Video Search using USB Flash Drive

6. Select the backup device from the drop-down list and you can also select the file format to filter the files existing in the backup device.

7. Select the save type to MP4 or AVI

8. Click the button Export on the Export interface to start the backup process. On the pop-up message box, select to export the video files or the player to the backup device. Click OK to confirm.

Figure 7. 4 Select File or Player for Backup

Digital Video Recorder User Manual

9. A prompt message will pop up after the backup process is complete. Click OK to confirm.

Figure 7. 5 Export

Finished

The backup of video files using USB writer or SATA writer has the same operating instructions. Please refer to steps described above.

7.1.2 Backing up by Event Search

Purpose: Back up event-related record files using USB devices (USB flash drives, USB HDDs, USB writer). Quick Backup and Normal Backup are supported. Steps:

1. Enter Export interface.

Menu > Export > Event

2. Select the cameras to search.

3. Select the event type to alarm input or motion

Figure 7. 6 Event Search for Backup

4. Set search condition and click Search button to enter the search result interface. The matched video files are displayed in Chart or List display mode.

5. Select video files from the Chart or List interface to export.

Digital Video Recorder User Manual

Figure 7. 7 Result of Event Search

6. Export the video files. Please refer to step5 of Chapter 7.1.1 Backing up by Normal Video Search for

details.

7.1.3 Backing up Video Clips

Purpose: You may also select video clips in playback mode to export directly during Playback, using USB devices (USB flash drives, USB HDDs, USB writer). Steps:

1. Enter Playback interface.

2. During playback, use buttons or in the playback toolbar to start or stop clipping record file(s).

3. Click the to enter the file management interface.

Figure 7. 8 Video Clips Export Interface

7. Export the video clips in playback. Please refer to step5 of Chapter 7.1.1 Backing up by Normal Video Search for details.

Digital Video Recorder User Manual

7.2 Managing Backup Devices

Management of USB flash drives or USB HDD

Steps:

1. Enter the Export interface.

Figure 7. 9 Storage Device Management

2. Backup device management. Click New Folder button if you want to create a new folder in the backup device. Select a record file or folder in the backup device and click button if you want to delete it.

Click Erase button if you want to erase the files from a re-writable CD/DVD. Click Format button to format the backup device.

If the inserted storage device is not recognized:

• Click the Refresh button.

• Reconnect device.

• Check for compatibility from vendor.

Digital Video Recorder User Manual

Chapter 8 Alarm Settings

8.1 Setting Motion Detection

Steps:

1. Enter Motion Detection interface of Camera Management and choose a camera you want to set up motion

detection. Menu> Camera> Motion

Figure 8. 1 Motion Detection Setup Interface

2. Set detection area and sensitivity.

Check checkbox to enable motion detection, use the mouse to draw detection area(s) and drag the sensitivity bar to set sensitivity.

Click to set alarm response actions.

Figure 8. 2 Set Detection Area and Sensitivity

3. Click Trigger Channel tab and select one or more channels which will start to record or become full-screen

monitoring when motion alarm is triggered.

Digital Video Recorder User Manual

Figure 8. 3 Set Trigger Camera of Motion Detection

4. Set arming schedule of the channel. Select Arming Schedule tab to set the channel’s arming schedule. Choose one day of a week and up to eight time periods can be set within each day. Or you can click the Copy button to copy the time period settings to other day(s).

Time periods shall not be repeated or overlapped.

Figure 8. 4 Set Arming Schedule of Motion Detection

5. Click Linkage Action tab to set up alarm response actions of motion alarm (please refer to Chapter 8.6 Setting Alarm Response Actions).

Repeat the above steps to set up arming schedule of other days of a week. Click the OK button to complete the motion detection settings of the channel.

6. If you want to set motion detection for another channel, repeat the above steps or just copy the above settings to it.

You are not allowed to copy the “Trigger Channel” action.

Digital Video Recorder User Manual

8.2 Detecting Video Loss

Purpose: Detect video loss of a channel and take alarm response action(s). Steps:

1. Enter Video Loss interface of Camera Management and select a channel you want to detect. Menu> Camera> Video Loss

Figure 8. 5 Video Loss Setup Interface

2. Set up handling method of video loss. Check the checkbox of “Enable Video Loss Alarm”.

Click button to set up handling method of video loss.

3. Set arming schedule of the channel. Select Arming Schedule tab to set the channel’s arming schedule. Choose one day of a week and up to eight time periods can be set within each day. Or you can click the Copy button to copy the time period settings to other day(s).

Time periods shall not be repeated or overlapped.

Digital Video Recorder User Manual

Figure 8. 6 Set Arming Schedule of Video Loss

Repeat the above steps to set arming schedule of other days of a week. You can also use Copy button to copy an arming schedule to other days.

4. Select Linkage Action tab to set up alarm response action of video loss (please refer to Chapter 8.6 Setting Alarm Response Actions).

5. Click the OK button to complete the video loss settings of the channel. Repeat the above steps to finish settings of other channels, or click the Copy button copy the above settings to them.

8.3 Detecting Video Tampering

Purpose: Trigger alarm when the lens is covered and take alarm response action(s). Steps:

1. Enter Video Tampering interface of Camera Management and select a channel you want to detect video tampering. Menu> Camera> Video Tampering Detection

Figure 8. 7 Video Tempering Interface

Digital Video Recorder User Manual

2. Check the checkbox of “Enable Video Tampering”.

3. Drag the sensitivity bar and choose a proper sensitivity level.

4. Click to set handling method of video tampering. Set arming schedule and alarm response actions of

the channel.

1) Click Arming Schedule tab to set the arming schedule of response action.

2) Choose one day of a week and up to eight time periods can be set within each day.

Time periods shall not be repeated or overlapped.

Figure 8. 8 Set Arming Schedule of Video Tampering

3) Select Linkage Action tab to set alarm response actions of video tampering alarm (please refer to

Chapter 8.6 Setting Alarm Response Actions). Repeat the above steps to set arming schedule of other days of a week. You can also use Copy button to copy an arming schedule to other days.

4) Click the OK button to complete the video tampering settings of the channel.

Repeat the above steps to finish settings of other channels, or click the Copy button copy the above settings to them.

5. Click the Apply button to save and activate the settings.

Digital Video Recorder User Manual

8.4 Setting All-day Video Quality Diagnostics

Purpose: The device provides two ways to diagnose the video quality: manual and all-day. Perform the following steps to set the threshold of the diagnosing and the linkage actions. Steps:

1. Enter Video Quality Diagnostics settings interface of Camera Management and select a channel you want to

detect video tampering. Menu> Camera> Video Quality Diagnostics

2. Check the checkbox of Enable Video Quality Diagnostics.

3. Enable and set the threshold of the diagnostic types, there are Blurred Image, Abnormal Brightness, and

Color Cast. Check the corresponding checkbox of the diagnostic type, and adjust the threshold of it by clicking-and-dragging the bar.

The higher the threshold you set, the harder the exception will be detected.

4. Click to set handling method of video quality diagnostics. Set arming schedule and alarm response

actions of the channel.

1) Click Arming Schedule tab to set the arming schedule of response action.

2) Choose one day of a week and up to eight time periods can be set within each day.

Time periods shall not be repeated or overlapped.

Figure 8. 9 Set Arming Schedule of Video Quality

Diagnostics

3) Select Linkage Action tab to set alarm response actions of video quality diagnostics alarm (please refer

to Chapter 8.6 Setting Alarm Response Actions). Repeat the above steps to set arming schedule of other days of a week. You can also use Copy button to copy an arming schedule to other days.

4) Click the OK button to complete the video quality diagnostics settings of the channel.

5. Click the Apply button to save and activate settings.

6. (Optional) you can copy the same settings to other cameras by clicking the Copy button.

Digital Video Recorder User Manual

8.5 Handling Exceptions

Purpose: Exception settings refer to the handling method of various exceptions, e.g.

• HDD Full: The HDD is full.

• HDD Error: Writing HDD error, unformatted HDD, etc.

• Network Disconnected: Disconnected network cable.

• IP Conflicted: Duplicated IP address.

• Illegal Login: Incorrect user ID or password.

• Input/Recording Resolution Mismatch: The input resolution is smaller than the recording resolution.

• Record Exception: No space for saving recorded files.

Steps:

1. Enter Exceptions interface and handle various exceptions.

Menu> Configuration> Exceptions

Figure 8. 10 Exception Settings

Interface

2. Check the checkbox of Enable Event Hint to display the (Event/Exception icon) when an exceptional

event occurs. And click the icon to select the detailed event hint for display.

Click the icon appears in the live view interface, and you can view the detailed information of the exceptional event. Click the button Set, and then you can select the detailed event hint for display.

Figure 8. 11 Detailed Event

3. Set the alarm linkage actions. For details, see Chapter 8.6 Setting Alarm Response Actions.

Digital Video Recorder User Manual

4. Click Apply to save the settings.

8.6 Setting Alarm Response Actions

Purpose: Take alarm response actions will be activated when an alarm or exception occurs, including Full Screen Monitoring, Audible Warning (buzzer), Notify Surveillance Center, Send Email and Trigger Alarm Output. Full Screen Monitoring When an alarm is triggered, the local monitor (HDMI or VGA) display in full screen the video image from the alarming channel configured for full screen monitoring. If alarms are triggered simultaneously in several channels, their full-screen images will be switched at an interval of 10 seconds (default dwell time). A different dwell time can be set by going to Menu > Configuration > Live View. Auto-switch will terminate once the alarm stops and you will be taken back to the Live View interface.

Audible Warning Trigger an audible beep when an alarm is detected.

Notify Surveillance Center Sends an exception or alarm signal to remote alarm host when an event occurs. The alarm host refers to the PC installed with Remote Client.

The alarm signal will be transmitted automatically at detection mode when remote alarm host is configured.

Send Email Send an email with alarm information to a user or users when an alarm is detected.

Figure 8. 12 Set Arming Schedule of Alarm

Output

1. Repeat the above steps to set arming schedule of other days of a week. You can also use Copy button to copy an arming schedule to other days. Click the OK button to complete the arming schedule setting of alarm output.

Digital Video Recorder User Manual

2. Click the Apply button to save the settings.

Network Settings

8.7 Configuring General Settings

Purpose: Network settings must be properly configured before you operate DVR over network. Steps:

1. Enter the Network Settings interface. Menu > Configuration > Network

Figure 8. 13 Network Settings Interface

2. Select the General tab.

3. In the General Settings interface, you can configure the following settings: IPv4 Address, IPv4 Gateway,

MTU and DNS Server. If the DHCP server is available, you can check the checkbox of DHCP to automatically obtain an IP address and other network settings from that server.

The valid value of MTU is from 500 to 1500.

4. After having configured the general settings, click the Apply button to save the settings.

Digital Video Recorder User Manual

8.8 Configuring Advanced Settings

8.8.1 Configuring PPPoE Settings

Purpose: The DVR also allows access by Point-to-Point Protocol over Ethernet (PPPoE). Steps:

1. Enter the Network Settings interface.

Menu > Configuration > Network

2. Select the PPPoE tab to enter the PPPoE Settings interface.

Figure 8. 14 PPPoE Settings Interface

3. Check the PPPoE checkbox to enable this feature.

4. Enter User Name and Password for PPPoE access.

The User Name and Password should be assigned by your ISP.

5. Click the Apply button to save the settings.

6. After successful settings, the system asks you to reboot the device to enable the new settings, and the PPPoE

dial-up is automatically connected after reboot. You can go to Menu > Maintenance > System Info > Network interface to view the status of PPPoE connection.

8.8.2 Configuring Cloud P2P

Purpose: Cloud P2P provides the mobile phone application and as well the service platform page to access and manage your

connected NVR, which enables you to get a convenient remote access to the surveillance system. Steps:

1. Enter the Network Settings interface.

Menu > Configuration > Network

2. Select the Platform Access tab to enter the Cloud P2P Settings interface.

3. Check the Enable checkbox to activate this feature.

4. If required, select the checkbox of Custom and input the Server Address.

5. To turn the Enable Stream Encryption on, you can select its checkbox.

6. Enter the Verification Code of the device.

The verification code consists of 6 capital letters and is located at the bottom of the DVR. You can also use the

Digital Video Recorder User Manual

scanning tool of your phone to quickly get the code by scanning the QR code below.

Figure 8. 15 Cloud P2P Settings Interface

7. Click the Apply button to save and exit the interface.

After configuration, you can access and manage the NVR by your mobile phone on which the Cloud P2P application is installed or by the website (http://www. hicloudcam.com).

For more operation instructions, please refer to the help file on the official website (http://www. hicloudcam.com).

8.8.3 Configuring DDNS

Purpose: If your DVR is set to use PPPoE as its default network connection, you may set Dynamic DNS (DDNS) to be used for network access. Prior registration with your ISP is required before configuring the system to use DDNS. Steps:

1. Enter the Network Settings interface.

Menu > Configuration > Network

2. Select the DDNS tab to enter the DDNS Settings interface.

3. Check the DDNS checkbox to enable this feature.

4. Select DDNS Type. Five different DDNS types are selectable: IPServer, DynDNS, PeanutHull, NO-IP and

HiDDNS.

• IPServer: Input Server Address for IPServer.

Digital Video Recorder User Manual

Figure 8. 16 IPServer Settings Interface

• DynDNS:

1) Enter Server Address for DynDNS (i.e. members.dyndns.org).

2) In the Device Domain Name text field, enter the domain obtained from the DynDNS website.

3) Enter the User Name and Password registered in the DynDNS website.

Figure 8. 17 DynDNS Settings Interface

• PeanutHull: Enter the User Name and Password obtained from the PeanutHull website.

Figure 8. 18 PeanutHull Settings

Interface

• NO-IP:

Enter the account information in the corresponding fields. Refer to the DynDNS settings.

1) Enter Server Address for NO-IP.

2) In the Device Domain Name text field, enter the domain obtained from the NO-IP website

(www.no-ip.com).

3) Enter the User Name and Password registered in the NO-IP website.

Digital Video Recorder User Manual

Figure 8. 19 NO-IP Settings Interface

• HiDDNS:

1) Select the continent/country of the server on which the device is registered.

2) The Server Address of the HiDDNS server appears by default: www.hiddns.com.

3) Enter the Device Domain Name. You can use the alias you registered in the HiDDNS server or

define a new device domain name. If a new alias of the device domain name is defined in the NVR, it will replace the old one registered on the server. You can register the alias of the device domain name in the HiDDNS server first and then enter the alias to the Device Domain Name in the NVR; you can also enter the domain name directly on the NVR to create a new one.

Figure 8. 20 HiDDNS Settings

Interface

 Register the device on the HiDDNS server.

1) Go to the HiDDNS website: www.hiddns.com.

Digital Video Recorder User Manual

Figure 8. 21 Register an Account

2) Click to register an account if you do not have one and use the account to log in.

Figure 8. 22 Register an Account

3) In the Device Management interface, click to register the device.

Digital Video Recorder User Manual

Figure 8. 23 Register the Device

4) Input Device Serial No., Device Domain (Device Name) and HTTP Port. And click OK to

add the device.

 Access the Device via Web Browser or Client Software After having successfully registered the device on the HiDDNS server, you can access your device via web browser or Client Software with the Device Domain Name (Device Name).

 OPTION 1: Access the Device via Web Browser Open a web browser, and enter http:// www.hiddns.com/alias in the address bar. Alias refers to the Device Domain Name on the device or the Device Name on the HiDDNS server. Example: http:// www.hiddns.com/nvr1

If you mapped the HTTP port on your router and changed it to port No. except 80, you have to enter http:// www.hiddns.com/alias:HTTP port in the address bar to access the device. You can refer to Chapter 9.2.11 for the mapped HTTP port No.  OPTION 2: Access the devices via iVMS

For iVMS, in the Add Device window, select and then edit the device information.

Nickname: Edit a name for the device as you want. Server Address: www.hiddns.com Device Domain Name: It refers to the Device Domain Name on the device or the Device Name on the HiDDNS server you created. User Name: Enter the user name of the device. Password: Enter the password of the device.

Digital Video Recorder User Manual

Figure 8. 24 Access Device via iVMS

5. Click the Apply button to save the settings. After setting all the required parameters for the DDNS, you can view the connecting status of the device by checking the Status information.

8.8.4 Configuring NTP Server

Purpose: A Network Time Protocol (NTP) Server can be configured on your DVR to ensure the accuracy of system date/time. Steps:

1. Enter the Network Settings interface.

Menu > Configuration > Network

2. Select the NTP tab to enter the NTP Settings interface.

Figure 8. 25 NTP Settings Interface

3. Check the Enable NTP checkbox to enable this feature.

4. Configure the following NTP settings:

• Interval: Time interval between the two synchronizing actions with NTP server. The unit is minute.

• NTP Server: IP address of NTP server.

• NTP Port: Port of NTP server.

5. Click the Apply button to save and exit the interface.

The time synchronization interval can be set from 1 to 10080 minutes, and the default value is 60 minutes. If the DVR is connected to a public network, you should use a NTP server that has a time synchronization function, such as the server at the National Time Center (IP Address: 210.72.145.44). If the DVR is set in a more customized network, NTP software can be used to establish a NTP server used for time synchronization.

Digital Video Recorder User Manual

8.8.5 Configuring NAT

Purpose: Universal Plug and Play (UPnP™) can permit the device seamlessly discover the presence of other network devices on the network and establish functional network services for data sharing, communications, etc. You can use the UPnP™ function to enable the fast connection of the device to the WAN via a router without port mapping. Before you start: If you want to enable the UPnP™ function of the device, you must enable the UPnP™ function of the router to which your device is connected. When the network working mode of the device is set as multi-address, the Default Route of the device should be in the same network segment as that of the LAN IP address of the router. Steps:

1. Enter the Network Settings interface. Menu > Configuration > Network

2. Select the NAT tab to enter the UPnP™ settings interface.

Figure 8. 26 UPnP™ Settings

Interface

3. Check checkbox to enable UPnP™.

4. Select the Mapping Type as Manual or Auto in the drop-down list. OPTION 1: Auto

If you select Auto, the Port Mapping items are read-only, and the external ports are set by the router automatically.

1) Click Apply button to save the settings.

2) You can click Refresh button to get the latest status of the port mapping.

Figure 8. 27 UPnP™ Settings

Finished-Auto

OPTION 2: Manual If you select Manual as the mapping type, you can edit the external port on your demand by clicking to

activate the External Port Settings dialog box. Steps:

Digital Video Recorder User Manual

1) Click to activate the External Port Settings dialog box. Configure the external port No. for server

port, http port and RTSP port respectively.

 You can use the default port No., or change it according to actual requirements.  External Port indicates the port No. for port mapping in the router.  The value of the RTSP port No. should be 554 or between 1024 and 65535, while the value of the

other ports should be between 1 and 65535 and the value must be different from each other. If multiple devices are configured for the UPnP™ settings under the same router, the value of the port No. for each device should be unique.

Figure 8. 28 External Port Settings Dialog

Box

2) Click Apply button to save the settings.

3) You can click Refresh button to get the latest status of the port mapping.

Figure 8. 29 UPnP™ Settings Finished-Manual

8.8.6 Configuring More Settings

Steps:

1. Enter the Network Settings interface.

Menu > Configuration > Network

2. Select the More Settings tab to enter the More Settings interface.

Figure 8. 30 More Settings Interface

3. Configure the remote alarm host, server port, HTTP port, multicast, RTSP port.  Alarm Host IP/Port: With a remote alarm host configured, the device will send the alarm event or

Digital Video Recorder User Manual

exception message to the host when an alarm is triggered. The remote alarm host must have the CMS (Client Management System) software installed. The Alarm Host IP refers to the IP address of the remote PC on which the CMS (Client Management System) software (e.g., iVMS) is installed, and the Alarm Host Port must be the same as the alarm monitoring port configured in the software (default port is 7200).

 Multicast IP: The multicast can be configured to realize live view for more than the maximum number

of cameras through network. A multicast address spans the Class-D IP range of 224.0.0.0 to

239.255.255.255. It is recommended to use the IP address ranging from 239.252.0.0 to

239.255.255.255. When adding a device to the CMS (Client Management System) software, the multicast address must be the same as the device’s multicast IP.

 RTSP Port: The RTSP (Real Time Streaming Protocol) is a network control protocol designed for use

in entertainment and communications systems to control streaming media servers. Enter the RTSP port in the text field of RTSP Port. The default RTSP port is 554, and you can change it according to different requirements.

 Server Port and HTTP Port: Enter the Server Port and HTTP Port in the text fields. The default

Server Port is 8000 and the HTTP Port is 80, and you can change them according to different requirements.

The Server Port should be set to the range of 2000-65535 and it is used for remote client software access. The HTTP port is used for remote IE access.

Figure 8. 31 Configure More

Settings

4. Click the Apply button to save and exit the interface.

8.8.7 Configuring HTTPS Port

Purpose: HTTPS provides authentication of the web site and associated web server that one is communicating with, which protects against Man-in-the-middle attacks. Perform the following steps to set the port number of https. Example: If you set the port number as 443 and the IP address is 192.0.0.64, you may access the device by inputting https://192.0.0.64:443 via the web browser.

The HTTPS port can be only configured through the web browser. Steps:

1. Open web browser, input the IP address of device, and the web server will select the language automatically

according to the system language and maximize the web browser.

Digital Video Recorder User Manual

2. Input the correct user name and password, and click Login button to log in the device.

3. Enter the HTTPS settings interface.

Configuration > Remote Configuration > Network Settings > HTTPS

4. Create the self-signed certificate or authorized certificate.

Figure 8. 32 HTTPS Settings

OPTION 1: Create the self-signed certificate

1) Click the Create button to create the following dialog box.

Figure 8. 33 Create Self-signed Certificate

2) Enter the country, host name/IP, validity and other information.

3) Click OK to save the settings. OPTION 2: Create the authorized certificate

1) Click the Create button to create the certificate request.

2) Download the certificate request and submit it to the trusted certificate authority for signature.

3) After receiving the signed valid certificate, import the certificate to the device.

5. There will be the certificate information after you successfully create and install the certificate.

Figure 8. 34 Installed Certificate

Property

6. Check the checkbox to enable the HTTPS function.

7. Click the Save button to save the settings.

Digital Video Recorder User Manual

8.8.8 Configuring Email

Purpose: The system can be configured to send an Email notification to all designated users if an event is detected, e.g. an alarm or motion event is detected, etc. Before configuring the Email settings, the DVR must be connected to a local area network (LAN) that maintains an SMTP mail server. The network must also be connected to either an intranet or the Internet depending on the location of the e-mail accounts to which you want to send notification. Additional, the Preferred DNS server must be configured. Before you start: Make sure you have configured the IPv4 Address, IPv4 Subnet Mask, IPv4 Gateway and the Preferred DNS Server in the Network Settings menu. Please refer to Chapter 8.7 Configuring General Settings for detailed information. Steps:

1. Enter the Network Settings interface.

Menu > Configuration > Network

2. Select the Email tab to enter the Email Settings interface.

Figure 8. 35 Email Settings Interface

3. Configure the following Email settings: Enable Server Authentication (optional): Check the checkbox to enable the server authentication feature. User Name: The user account of sender’s Email for SMTP server authentication. Password: The password of sender’s Email for SMTP server authentication. SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com). SMTP Port No.: The SMTP port. The default TCP/IP port used for SMTP is 25. Enable SSL (optional): Click the checkbox to enable SSL if required by the SMTP server. Sender: The name of sender. Sender’s Address: The Email address of sender. Select Receivers: Select the receiver. Up to 3 receivers can be configured. Receiver: The name of the receiver of the Email. Receiver’s Address: The Email address of the receiver. Enable Attached Pictures: Check the checkbox of Enable Attached Picture if you want to send email

with attached alarm images. The interval is the time between two captures of the alarm images.

Digital Video Recorder User Manual

Interval: The interval refers to the time between two actions of sending attached pictures. E-mail Test: Sends a test message to verify that the SMTP server can be reached.

4. Click the Apply button to save the Email settings.

5. You can click the Test button to test whether your Email settings work. The corresponding Attention

message box pops up.

Figure 8. 36 Email Testing Attention

8.9 Checking Network Traffic

Purpose: You can check the network traffic to obtain real-time information of DVR such as linking status, MTU, sending/receiving rate, etc. Steps:

1. Enter the Network Traffic interface. Menu > Maintenance > Net Detect

Figure 8. 37 Network Traffic Interface

2. You can view the sending rate and receiving rate information on the interface. The traffic data is refreshed every 1 second.

Digital Video Recorder User Manual

8.10 Configuring Network Detection

Purpose: You can obtain network connecting status of DVR through the network detection function, including network delay, packet loss, etc.

8.10.1

Testing Network Delay and Packet Loss

Steps:

1. Enter the Network Traffic interface. Menu > Maintenance > Net Detect

2. Click the Network Detection tab to enter the Network Detection menu.

Figure 8. 38 Network Detection Interface

3. Select a NIC to test network delay and packet loss.

4. Enter the destination address in the text field of Destination Address.

5. Click the Test button to start testing network delay and packet loss.

8.10.2

Exporting Network Packet

Purpose: By connecting the DVR to network, the captured network data packet can be exported to USB-flash disk, SATA and other local backup devices. Steps:

1. Enter the Network Traffic interface. Menu > Maintenance > Net Detect

2. Click the Network Detection tab to enter the Network Detection interface.

3. Select the backup device from the dropdown list of Device Name.

Click the Refresh button if the connected local backup device cannot be displayed. When it fails to detect the backup device, please check whether it is compatible with the DVR. You can format the backup device if the format is incorrect.

Digital Video Recorder User Manual

Figure 8. 39 Export Network Packet

4. Click the Export button to start exporting.

5. After the exporting is complete, click OK to finish the packet export.

Up to 1M data can be exported each time.

8.10.3

Checking Network Status

Purpose: You can also check the network status and quick set the network parameters in this interface. Steps:

Click Status on the right bottom of the page.

Figure 8. 40 Checking Network Status

If the network is normal the following message box pops out.

Figure 8. 41 Network Status Checking Result

If the message box pops out with other information instead of this one, you can click Network button to show the quick setting interface of the network parameters.

Digital Video Recorder User Manual

Figure 8. 42 Network Parameters Configuration

8.10.4

Checking Network Statistics

Purpose: You can check the network statistics to obtain the real-time information of the device. Steps:

1. Enter the Network Statistics interface. Menu > Maintenance> Net Detect

2. Click the Network Stat. tab to enter the Network Statistics menu.

Figure 8. 43 Network Stat. Interface

3. View the bandwidth of Remote Live View, bandwidth of Remote Playback, and bandwidth of Net Total Idle.

4. Click Refresh button to get the latest bandwidth statistics.

Digital Video Recorder User Manual

Chapter 9 HDD Management

9.1 Initializing HDDs

Purpose: A newly installed hard disk drive (HDD) must be initialized before it can be used with your DVR. Steps:

1. Enter the HDD Information interface. Menu > HDD>General.

Figure 9. 1 HDD Information Interface

2. Select HDD to be initialized.

3. Click the Init button.

Figure 9. 2 Confirm Initialization

4. Select the OK button to start initialization.

Figure 9. 3 Start Initialization

5. After the HDD has been initialized, the status of the HDD will change from Uninitialized to Normal.

Digital Video Recorder User Manual

Figure 9. 4 HDD Status Changes to Normal

Initializing the HDD will erase all data on it.

The HDDs which are free of working for a long time can be enabled to sleep, thus to decrease the power consumption of the device and extend the life of the HDDs. Click Menu > HDD > Advanced.

Figure 9. 5 Enable HDD Sleeping

Check the checkbox of Enable HDD Sleeping (by default), and the HDDs which are free of working for a long time will be set to sleep. Uncheck the checkbox of Enable HDD Sleeping, and the HDDs will be set to work for all time.

9.2 Managing Network HDD

Purpose: You can add the allocated NAS or disk of IP SAN to DVR, and use it as network HDD. Steps:

1. Enter the HDD Information interface.

Menu > HDD>General

Figure 9. 6 HDD Information Interface

2. Click the Add button to enter the Add NetHDD interface, as shown in Figure 9. 7.

Digital Video Recorder User Manual

Figure 9. 7 HDD Information Interface

3. Add the allocated NetHDD.

4. Select the type to NAS or IP SAN.

5. Configure the NAS or IP SAN settings.

• Add NAS disk:

1) Enter the NetHDD IP address in the text field.

2) Click Search to search the available NAS disks.

3) Select the NAS disk from the list shown below. Or you can just manually enter the directory in the text field of NetHDD Directory.

4) Click OK to add the configured NAS disk.

Up to 8 NAS disks can be added.

Figure 9. 8 Add NAS

Disk

• Add IP SAN:

1) Enter the NetHDD IP address in the text field.

2) Click the Search button to the available IP SAN disks.

3) Select the IP SAN disk from the list shown below.

4) Click the OK button to add the selected IP SAN disk.

Digital Video Recorder User Manual

Up to 8 IP SAN disks can be added.

Figure 9. 9 Add IP SAN Disk

5) After having successfully added the NAS or IP SAN disk, return to the HDD Information menu. The added NetHDD will be displayed in the list.

If the added NetHDD is uninitialized, please select it and click the Init button for initialization.

Figure 9. 10 Initialize Added NetHDD

9.3 Managing HDD Group

9.3.1 Setting HDD Groups

Purpose: Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a particular HDD group through HDD settings. Steps:

1. Enter the Storage Mode interface. Menu > HDD > Advanced

2. Set the Mode to Group, as shown in Figure 9. 11.

Digital Video Recorder User Manual

Figure 9. 11 Storage Mode Interface

3. Click the Apply button and the following Attention box will pop up.

Figure 9. 12 Attention for Reboot

4. Click the Yes button to reboot the device to activate the changes.

5. After reboot of device, enter the HDD Information interface.

Menu > HDD > General

6. Select HDD from the list and click the icon to enter the Local HDD Settings interface, as shown in Figure 9. 13.

Figure 9. 13 Local HDD Settings Interface

7. Select the Group number for the current HDD.

The default group No. for each HDD is 1.

8. Click the OK button to confirm the settings.

Figure 9. 14 Confirm HDD Group Settings

Digital Video Recorder User Manual

9. In the pop-up Attention box, click the Yes button to finish the settings.

9.3.2 Setting HDD Property

Purpose: The HDD property can be set to redundancy, read-only or read/write (R/W). Before setting the HDD property, please set the storage mode to Group (refer to step1-4 of Chapter 9.3.1 Setting HDD Groups). A HDD can be set to read-only to prevent important recorded files from being overwritten when the HDD becomes full in overwrite recording mode. When the HDD property is set to redundancy, the video can be recorded both onto the redundancy HDD and the R/W HDD simultaneously so as to ensure high security and reliability of video data. Steps:

1. Enter the HDD Information interface. Menu > HDD > General

2. Select HDD from the list and click the icon to enter the Local HDD Settings interface, as shown in Figure 9. 15.

Figure 9. 15 Set HDD Property

3. Set the HDD property to R/W, Read-only or Redundancy.

4. Click the OK button to save the settings and exit the interface.

5. In the HDD Information menu, the HDD property will be displayed in the list.

At least 2 hard disks must be added on your DVR when you want to set a HDD to Redundancy, and there is one HDD with R/W property.

Digital Video Recorder User Manual

100

9.4 Configuring Quota Mode

Purpose

Each camera can be configured with allocated quota for the storage of recorded files.

Steps

1. Enter the Storage Mode interface. Menu > HDD > Advanced

2. Set the Mode to Quota, as shown in Figure 9. 16.

The DVR must be rebooted to enable the changes to take effect.

Figure 9. 16 Storage Mode Settings Interface

3. Select a camera for which you want to configure quota.

4. Enter the storage capacity in the text field of Max. Record Capacity (GB).

5. You can copy the quota settings of the current camera to other cameras if required. Click the Copy button to

enter the Copy Camera interface, as shown in Figure 9. 17.

Figure 9. 17 Copy Settings to Other Camera(s)

6. Select the camera (s) to be configured with the same quota settings. You can also click the checkbox of Analog to select all cameras.

7. Click the OK button to finish the Copy settings and back to the Storage Mode interface.

EFB SP-8HDSET User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
