DATASHEET
DATASHEET
RJ45 Patch cable S/FTP, Cat.6A, LSZH, Cat.7 Raw cable,
RJ45 Patch cable S/FTP, Cat.6A, LSZH, Cat.7 Raw cable,
green
green
Description
The shielded Cat.6A RJ45 patch cable with ensures excellent performance for 10 Gigabit Ethernet applications. The
moulded grommet captivates with its slim design and thus simplifies the insertion process in cramped conditions.
Cross section 4 x 2 x AWG26 / 7
Moulded grommet, slim design
Length imprint on the boot
General data
Category 6A (TIA)
Type of connector connection 1 RJ45 8(8)
Type of connector connection 2 RJ45 8(8)
Connector type RJ45 Standard yellow
Contacts Gold plated
Pin assignment 1:1
Allocation acc. TIA/EIA 568B
Type Shielded
Length imprint yes
Anti-kink sleeve moulded
Colour anti-kink sleeve green
Locking lever yes
Mechanical characteristics
Mating cycles ≥750
Bending radius >32,5 mm
Conductive shield Selected shield contact
This datasheet was created automatically on 05-02-2020 . Technical changes reserved.
This datasheet was created automatically on 05-02-2020 . Technical changes reserved.
EFB-Elektronik GmbH
EFB-Elektronik GmbH
Striegauer Straße 1
Striegauer Straße 1
33719 Bielefeld
33719 Bielefeld
fon: +49 521 40 41 8-0
fon: +49 521 40 41 8-0
fax: +49 521 40 41 8-50
fax: +49 521 40 41 8-50
info@efb-elektronik.de
info@efb-elektronik.de
www.efb-elektronik.de
www.efb-elektronik.de
Page 1/3
Page 1/3
DATASHEET
RJ45 Patch cable S/FTP, Cat.6A, LSZH, Cat.7 Raw cable,
green
Cable construction
Raw cable Cat.7
Cable structure S/FTP
Cable construction 4x2
AWG-size/strands per core 26/7
Conductor Material Copper
Cable sheath
Silicone-free yes
Jacket material LSZH
Colour outer sheath green
Cat.7 raw cable S/FTP 4x2xAWG26/7 PIMF 600MHz
Printing
Outer diameter of the cable 6.5 mm
Flame-retardant acc. IEC60332-1
Halogen-free acc. IEC60754-2
Low smoke acc. IEC61034
ISO/IEC 11801 & EN50173-1 TIA/EIA 568B-2.1 Halogen
Free ***10GIGABIT***
Environmental conditions
Temperature range -20 – 60 °C
Electrical characteristics
Impedance 100 ±5 Ω
Conductor resistance DC 146 Ω/km
Loop resistance 292 Ω/km
Resistance unbalance 5 %
Insulation resistance 10 MΩ
Contact resistance 30 mΩ
Test voltage 1000 (V DC, 1min) core/core und core/screen
Transmission characteristics
Bandwidth 500MHz
Standards, approvals, certifications
Connector IEC 60603-7-51
Available variants
This datasheet was created automatically on 05-02-2020 . Technical changes reserved.
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
fon: +49 521 40 41 8-0
fax: +49 521 40 41 8-50
info@efb-elektronik.de
www.efb-elektronik.de
Page 2/3
