DATASHEET
DATASHEET
RJ45 Patch cable S/FTP, Cat.6A, TM21, UC900, white
RJ45 Patch cable S/FTP, Cat.6A, TM21, UC900, white
Description
The Cat.6A RJ45 patch cable manufactured in Europe guarantees very good characteristics for 10 Gigabit Ethernet
applications. The patch cable is composed of the Cat.7 raw cable UC900 SS27 from Draka and TM21 connectors
from Hirose.
Cross section 4 x 2 x AWG27/7
Mounted anti-kink grommet
General data
Category 6A (TIA)
Type of connector connection 1 RJ45 8(8)
Type of connector connection 2 RJ45 8(8)
Connector type TM21 red
Contacts Gold plated
Pin assignment 1:1
Allocation acc. TIA/EIA 568B
Type Shielded
Anti-kink sleeve put-on
Colour anti-kink sleeve white
Locking lever True
Mechanical characteristics
Mating cycles ≥750
Bending radius >25 mm
Conductive shield 360° shield contact
This datasheet was created automatically on 05-02-2020 . Technical changes reserved.
This datasheet was created automatically on 05-02-2020 . Technical changes reserved.
EFB-Elektronik GmbH
EFB-Elektronik GmbH
Striegauer Straße 1
Striegauer Straße 1
33719 Bielefeld
33719 Bielefeld
fon: +49 521 40 41 8-0
fon: +49 521 40 41 8-0
fax: +49 521 40 41 8-50
fax: +49 521 40 41 8-50
info@efb-elektronik.de
info@efb-elektronik.de
www.efb-elektronik.de
www.efb-elektronik.de
Page 1/3
Page 1/3
DATASHEET
RJ45 Patch cable S/FTP, Cat.6A, TM21, UC900, white
Cable construction
Raw cable Cat.7
Cable structure S/FTP
Total screening ca. 45 %
Cable construction 4x2
AWG-size/strands per core 27/7
Conductor Material Copper
Cable sheath
Jacket material LSZH
Colour outer sheath white
Outer diameter of the cable 5.9 mm
Euro class Eca
Flame-retardant acc. IEC60332-1
Halogen-free acc. IEC60754-2
Low smoke acc. IEC61034
Environmental conditions
Temperature Range (Operation) -20 – 60 °C
Temperature Range (Installation) 0 – 50 °C
Electrical characteristics
NVP value 79 %
Impedance 100 ±25 Ω
Conductor resistance DC 170 Ω/km
Loop resistance < 340 Ω/km
Resistance unbalance < 3 %
Insulation resistance > 2000 MΩ
Test voltage 1000 (V DC, 1min) core/core und core/screen
Transmission characteristics
Bandwidth 500MHz
Standards, approvals, certifications
Connector IEC 60603-7-51
Harmonised Standard EN 50575
Available variants
This datasheet was created automatically on 05-02-2020 . Technical changes reserved.
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
fon: +49 521 40 41 8-0
fax: +49 521 40 41 8-50
info@efb-elektronik.de
www.efb-elektronik.de
Page 2/3
