E+E Elektronik EE772 Product Manual ( EE772 )

EE772

FLOW SENSOR for

COMPRESSED AIR and GASES

BA_EE772 // v2.2 // Modification rights reserved // 193628

User Manual

Hardware and Software

E+E Elektronik® Ges.m.b.H. does not accept warranty and liability
claims neither upon this publication nor in case of improper treatment
of the described products.

The document may contain technical inaccuracies and typographical
errors. The content will be revised on a regular basis. These changes
will be implemented in later versions. The described products can be
improved and changed at any time without prior notice.

© Copyright E+E Elektronik

®

Ges.m.b.H.

All rights reserved.

USA
FCC notice:

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa­tion. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the installation manual, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Caution:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this device.

CANADIAN
ICES-003 notification:

This Device B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.

2

Table of contents - HARDWARE

1. GENERAL

1.1. Safety Instructions .................................................................................................. 4

1.1.1. Intended Use ................................................................................................... 4

1.1.2. Installation, Start-up and Control

1.2. Environmental Aspects .............................................................................................. 5

............................................................................................................. 4

................................................................................. 5

2. PRODUCT DESCRIPTION ....................................................................................... 6

3. INSTALLATION ...................................................................................................... 7

3.1. Mounting Dimensions ............................................................................................... 7

3.2. Determining Installation Site ........................................................................................ 8

3.3. Installation Position ................................................................................................. 8

3.4. Required Length of Straight Pipe ................................................................................... 9

3.5. Assembly of the Measurement Section ............................................................................. 10

3.5.1. Assembly without Flow Sensor, but with Screw Cap instead (Blind Cap) ............................................. 10

3.6. Installation of the Flow Sensing Probe.............................................................................. 10

3.6.1. Flow Direction .................................................................................................. 10

3.6.2. Installation of the Sensing Probe into the Gauge Mounting Block

3.6.3. Installation of the Sensing Probe into the Gauge Mounting Block with Hot Tap Valve

................................................... 11

................................. 12

4. ELECTRICAL CONNECTIONS .................................................................................13

4.1. Connection Diagram ................................................................................................ 13

4.1.1. Relay and Pulse Output, Internal Switching ....................................................................... 13

4.1.2. Connection with Optional Plug for Power Supply and Outputs (Order Code E4)

4.2. Bus Output (Optional) ............................................................................................... 14

4.2.1. M-Bus (Meter-Bus) .............................................................................................. 14

4.2.2. Modbus RTU

4.2.3. Data Transmission

4.2.4. Addressing

................................................................................................... 15

.............................................................................................. 15

..................................................................................................... 15

...................................... 13

5. CONTROL COMPONENTS ...................................................................................... 16

5.1. Jumper J1 and J2 ................................................................................................... 16

5.2. Digital Interface USB (For Configuration) ........................................................................... 16

5.3. Display / Indicator with Keypad (Optional) .......................................................................... 16

5.3.1. Indication of the Analogue and Pulse Output ...................................................................... 17

5.3.2. Indication of the Switch Output

5.3.3. Indication of the MIN / MAX Values

5.3.4. Reset of the Consumption Counter or the MIN / MAX Value

5.3.5. Maximum Consumption Counter

................................................................................... 17

............................................................................... 17

........................................................ 18

................................................................................. 18

6. ERROR MESSAGES .............................................................................................. 18

7. MAINTENANCE ..................................................................................................... 19

7.1. Removal of the Sensing Probe of the Gauge Mounting Block ..................................................... 19

7.2. Removal of the Sensing Probe of the Gauge Mounting Block with Hot Tap Valve ................................. 19

7.3. Cleaning of the Sensing Element ................................................................................... 19

8. REPLACEMENT PARTS / ACCESSORIES .................................................................19

8.1. Order Code Replacement Sensor .................................................................................. 19

9. TECHNICAL DATA .................................................................................................20

9.1. Factory Setting of Outputs .......................................................................................... 21

Table of contents - SOFTWARE

1. General ................................................................................................................ 22

2. Installation ........................................................................................................... 23

2.1. Configuration of the USB Interface (VirtualCOM) ................................................................... 23

3. User Interface ....................................................................................................... 24

4. Menu Toolbar ........................................................................................................ 25

4.1. File .................................................................................................................. 25

4.2. Transmitter .......................................................................................................... 25

4.3. Extras ............................................................................................................... 25

5. Input Screen ......................................................................................................... 25

5.1. Output 1, Output 2 .................................................................................................. 25

5.1.1. Output Mode ................................................................................................... 25

5.1.2. Measurand

5.1.3. Units

5.1.4. Output Mode – Analogue

5.1.5. Output Mode – Switch (Relay)

5.1.6. Output Mode – Pulse

5.2. Minimum Flow Shutdown ........................................................................................... 27

5.3. Display .............................................................................................................. 28

5.4. Adjustment .......................................................................................................... 28

5.4.1. 1-point Adjustment .............................................................................................. 28

5.4.2. 2-point Adjustment

5.4.3. Reset to Factory Settings

5.5. Measuring Values Overview ........................................................................................30

5.5.1. Reset of the MIN / MAX Values .................................................................................. 30

5.5.2. Reset of the Consumption Counter (Totalizer)

5.6. Setting up Process Parameters ..................................................................................... 30

5.6.1. Change of the Process Gas...................................................................................... 30

5.6.2. Change of the Standard Conditions

5.6.3. Pressure Compensation

5.7. External Pressure Sensor for Pressure Compensation ............................................................. 31

5.8. Bus Configuration ................................................................................................... 31

..................................................................................................... 25

........................................................................................................... 25

........................................................................................ 26

................................................................................... 26

............................................................................................ 27

.............................................................................................. 29

........................................................................................ 30

..................................................................... 30

.............................................................................. 31

......................................................................................... 31

3

1. GENERAL

This manual is a part of the scope of supply and serves to ensure optimal operation and functioning of the
equipment.
For this reason, the manual must be read before start-up.
Therefore, it is necessary that this manual is read and understood by those responsible for the handling,
installation, and maintenance of the equipment.

This manual may not be used for competitive purposes or passed on to third parties without the written
consent of E+E Elektronik Ges.m.b.H.
It is permitted to make copies for personal use.
All information, technical data and illustrations contained in these instructions are based on information
available at the time of publication.

Please find this document and further product information on our website at
www.epluse.com/EE772.

Explanation of Symbols

This symbol indicates safety instructions.

The safety instructions have to be carried out unconditionally. If disregarded loss, injury, or damage may be
inflicted to people and property. In any case E+E Elektronik® Ges.m.bH. cannot be hold responsible.

This symbol indicates attention.

The note should be observed to achieve an optimal functioning of the equipment.

1.1. Safety Instructions

1.1.1. Intended Use

The flow sensor is intended to be used for the measurement of air and other non-corrosive gases in pipelines
only. Consult the factory first before the measurement of wet or filthy gases.

The design of the flow sensor allows for the EE772 to be installed in a pressurized system up to PN40 – is
40 bar (580 psi).

Prior to the start of the installation, the system has to be depressurized. Before the installation or
removal of the sensing probe or the screw cap, the gauge mounting block should be closed.

Mounting, electrical installation, putting in operation and maintenance should only be done by qualified
personnel.

The use of the flow sensor EE772 in any other way than described in this manual bears a safety risk for
people and the entire measurement installation and is therefore not allowed.

The manufacturer cannot be hold responsible for damages as a result of incorrect handling, installation, and
maintenance of the equipment.

To avoid health risks or damage to the equipment, the installation should not be operated on with tools, which
are not specifically mentioned or described in this manual.

Excessive mechanical stress and inappropriate handling must be avoided.

A short interruption of the flow using the measurement ball valve cannot be avoided when exchanging the
sensing probe.

The flow sensor can only be utilized in accordance with the conditions defined in the technical data. Otherwise,
inaccuracies of the measurement will occur and equipment failures cannot be ruled out.

For the safety of the user and for the functionality of the equipment the recommended steps by the
manufacturer to put into operation, to test and to maintain should be taken and completed.

4

1.1.2. Installation, Start-up and Control

The flow sensor is designed and built in accordance with the latest state in technology, tested adequately and
has been shipped from the factory in good order and condition.

As the user, you are responsible to comply with all applicable safety regulations amongst others:

• Instruction for the installation

• Local standards and codes

The manufacturer has taken all measures to assure safe operation. The user has to make sure that the
equipment is positioned and installed in such a way that safe operation is not impaired.
The equipment is tested in the factory and shipped in good order and condition.
This manual contains information and notes of caution, which have to be adhered to by the user to assure a
safe operation.

• Mounting, electrical installation, putting into operation and maintenance should only be done by

qualified personnel. The plant operator should authorize qualified personnel to operate on the
installation.

• It is necessary that this manual is read and understood by these professionals and that they follow

the instructions as detailed in this manual.

• Check all connections of the entire installation thoroughly, before putting the system into operation.

• Disconnect the device from power supply before opening or closing to avoid damages.

• Do not put a damaged product into operation and make sure that that does not happen

inadvertently.

• A malfunction of the equipment should only be handled and fixed by authorized and qualified

personnel

• If it is not possible to repair the malfunction, put the equipment out of operation and make sure that

it cannot be put back into operation again.

• Repairs not described in this manual may only be carried out by the manufacturer or by the

respective service organization.

Disclaimer of Liability

The manufacturer or their delegated representative is only liable in case of intend or gross negligence. The
accountability is limited to the value of the order issued at the time to the manufacturer.
The manufacturer is not liable for damages, originated from disregarding the safety instructions or violating
the instructions of the manual or operating conditions.
Consequential damages are excluded from the any liability.

1.2. Environmental Aspects

The products from E+E Elektronik® are developed and designed in due consideration to the importance of the
protection of the environment. Therefore, disposal of the product also should not lead to pollution of the
environment.
The single-variety components must be separated before the sensor is disposed of. The electronic
components must be collected and as electronic scrap properly be disposed of.

5

2. PRODUCT DESCRIPTION

The flow sensor of the series EE772, based on the measurement principle of thermal mass flow, is suited for
the measurement of flow of air and gases in pipelines. Measurement of for instance the consumption of com­pressed air, nitrogen, CO2 or other non-corrosive and non-flammable gases.

The EE772 measures the volume flow at standard conditions according to DIN 1343 (P0=1023.25 mbar;
t0=273.15 K or 0 °C (32 °F). In addition to the standard volume flow, the measurand mass flow, norm flow and
temperature are available.
The EE772 has an integrated consumption counter. The consumption quantity is indicated in the display and
is not lost after a power failure. Two signal outputs are available. Depending on the application, the outputs
can be configured as analogue (current or voltage), switch output or as pulse output for the measurement of
the consumption.

Signal conditioning with optional display

1

The enclosure with the signal conditioning is mounted either
on the measurement probe (type T19 or T20 compact) or is
remote with a plugable sensor cable up to 10 meter (33 feet) –
(type T3 with remote probe).

Sensing probe with measurement electronics

2

The interchangeable sensing probe contains the sensor
element and the measurement electronics, in which the data of
the factory calibration is stored. The sensing probe is easy and
quickly interchangeable in the eld, independent of the
electronics for the signal conditioning. After the exchange, the

conguration of the outputs is unchanged.

1

2

3

Sensor cable (only by model C with remote sensing probe)

3

The sensor cable allows for the remote installation, up to 10
meter (33 feet), of the sensing probe from the housing with the
signal conditioning.

Gauge mounting block

4

The gauge mounting block allows for the easy and reliable
installation within the pipeline. During installation in the pipeline,
observe the required inlet and outlet paths (see page 9).
The nominal size of the gauge mounting block must match the
nominal size of the pipe. The gauge mounting block is suitable
for pressures up to 40 bar (580 PSI) and available for pipe
diameters DN40 (1 1/2") to DN80 (3").

The gauge mounting block with hot tap valve allows for the

4a

installment and removal of the sensing probe under pressure
without interrupting the process flow.

Screw cap

5

The screw cap, with female thread, is screwed in place if the
flow meter is not installed and the pipeline has to be used.

5

4a

4

6

3. INSTALLATION

3.1. Mounting Dimensions

EE772-T19 / EE772-T20

Compact

115 (4.53) 145 (5.71)

cable gland
M16x1.5

dimensions in mm (inch)

60 (2.36)

56 (2.2)

EE772-T3

Remote probe

Drilling Plan:

cable gland
M16x1.5

129 (5.08)

The bottom part of the housing is
mounted with 4 screws (not in the
scope of supply).
Max. screw diameter: 4.5 mm
e.g. 4.2 x 38 mm DIN 7938H Screws

60 (2.36)

40 (1.57)

(0.17 inch).

HA071xxx

Gauge mounting block

(6.38)

152 (5.98)

female thread

H

108.5 (4.27) 108.5 (4.27)L

pipe diameter Thread L H

DN40 (1 1/2") R

DN50 (2") Rp or NPT 2" 131 (5.16) 108.5 (4.27)

DN65 (2 1/2") Rp or NPT 2 1/2" 131 (5.16) 108.5 (4.27)

DN80 (3") Rp or NPT 3" 131 (5.16) 118.5 (4.67)

dimensions in mm (inch)
female thread:

Whitworth-Thread acc. EN 10226 (old DIN 2999) or NPT

or NPT 1 1/2" 110 (4.33) 108.5 (4.27)

p

162

opening for additional
sensors G1/2“

HA072xxx

Gauge mounting block with hot tap valve

200 (7.87)

H

L

210 (8.27)

7

3.2. Determining Installation Site

•

The installation site should be easy accessible and free of vibrations and shocks.

• Observe at least 260 mm (10.24 inch) clearance above the housing with the signal conditioning, in

order to be able to remove the sensing probe if necessary.

• The ambient temperature should not exceed the value as stated in the specifications (see page

20) – consider heating by radiation.

• Air purity on the installation site according to ISO 8573-1:2010: at least class 3.4.4

• The fluid should not condense at the installation site. Condensation on the tip of the sensing probe

must be avoided.

• In compressed air systems, the installation must be downstream of the dryer. If there is no dryer, at

least steam trap and suitable filter must be present.

• Observe the direction of the flow by the installation (see page 10).

• Observe the recommended straight pipe lengths up and downstream, in order to warrant the speci-

fied measurement accuracy.

• The flow sensor should be installed as far as possible from any flow disturbance. Valves or check-

valves should be installed in a respective distance from the flow sensor.

3.3. Installation Position

Make sure that the arrow on the tip of the sensing probe is pointing in the direction of the flow.

Model

Vertical Mounting Compact Remote

+ ++

Horizontal Mounting, sensor upwards

++ ++

Horizontal Mounting, sensor downwards

- -

Horizontal Mounting, sensor across

++ ... recommended installation position

+ ..... not recommended if there is vibration on the pipeline

- ...... not recommended

8

+ ++

3.4. Required Length of Straight Pipe

The flow sensor should be installed as far as possible from disturbances of the flow. The causes for distur­bance of the flow are for instance, reducers, elbows, T-pieces, valves, gate valves, etc. The specified meas­urement accuracy can be achieved only when the following straight inlet and outlet pipe lengths are installed:

• The wall thickness of the inlet and outlet pipe should be 2.6 mm

• The stated values are as a minimum. If possible, allow for greater distances.

• Valves or gate valves should be installed downstream of the flow sensor.

• With lighter gases the inlet straight pipe should be longer.

nominal pipe size (DN)

ow direction

straight inlet pipe

Type

Extension 15 x DN 5 x DN

Reduction 15 x DN 5 x DN

90° - elbow 20 x DN 5 x DN

straight outlet pipe

(DN = Nominal Pipe Size)

Straight inlet pipe Straight outlet pipe

Two 90° - elbows,
in one level

Two 90° - elbows,
in two levels, T-piece

Valve, gate valve 50 x DN 5 x DN

9

25 x DN 5 x DN

30 x DN 5 x DN

3.5. Assembly of the Measurement Section

In order to install or remove the gauge mounting block, the pipeline system should
be depressurized.

All connections to be made with appropriated sealing material on the threads.

•

• The sealing material should not change the area of the inner cross section of the pipe. It must be

warranted that the connections after installation are free of leaks.

• All fittings must be tested on seal tightness.

• Make sure during the assembly of the measurement section that the arrows on the pipe section

and the gauge mounting blocks are pointing in the same direction as the flow.

• The recess for the alignment pin must be at the side of the outlet.

Use sealing
material!

recess for
alignment pin

Flow Direction

3.5.1. Assembly without Flow Sensor, but with Screw Cap instead (Blind Cap)

In order to use the measurement section without the flow sensor, the blind screw

cap (in the scope of supply) must be screwed tight onto the opening of the gauge
mounting block. If not needed the screw cap can be screwed and stored on the
side of the gauge mounting block.

3.6. Installation of the Flow Sensing Probe

3.6.1. Flow Direction

The flow direction is indicated with an arrow on the tip of the probe. Due to the alignment pin is the installation
of the sensing probe in the gauge mounting block only possible in the direction of the flow. After a removal,
the sensing probe will be re-installed in the measurement section in exactly the same position as done at the
factory. Hence, the highest reproducibility is guaranteed.

Flow Direction

10

3.6.2. Installation of the Sensing Probe into the Gauge Mounting Block

Make sure that the pipe line is depressurized!Make sure that the pipe line is depressurized!

•

Remove transport protection cap of the head of the sensing probe.

• Mount the sensing probe in the gauge mounting block in such a way that the alignment pin fits in

the recess on the gauge mounting block.

• Screw the retainer nut by hand so far that a certain resistance is noticeable.

• Check the correct installation position of the flow sensor. The alignment pin must fit in the recess

on the gauge mounting block.

• Tighten the red coloured retainer nut by hand. Tightening by hand should be sufficient. However, if

the seal is not leak tight carefully tighten the nut with an appropriate tool a bit further

• The mechanical installation of the flow sensor is therewith completed.

11

3.6.3. Installation of the Sensing Probe into the Gauge Mounting Block with Hot Tap Valve

The gauge mounting block with hot tap valve allows for the instalment and removal of the sensing probe under
pressure, without interrupting the process flow.

Operate the gauge mounting block with hot tap valve only with the hand, without tools!

Functionallity:

Position OPEN - MEASURE: The sensor head is immersed into the pipe.
Position CLOSE - SERVICE: The gauge mounting block with hot tap valve pressure tight closed. You can

remove the sensor probe.

OPEN-MEASURE CLOSE-SERVICE

• Turn the gauge mounting block with hot tap valve in position CLOSE - SERVICE and mount the

sensing probe in the gauge mounting block with hot tap valve in such a way that the alignment pin
fits in the recess on the sealing cone.

• Screw the retainer nut by hand so far that a certain resistance is noticeable.

• Check the correct installation position of the flow sensor. The alignment pin must fit in the recess

on the sealing cone.

• Tighten the retainer nut by hand. Tightening by hand should be sufficient. However, if the seal is

not leak tight carefully tighten the nut with an appropriate tool a bit further.

• Turn the gauge mounting block with hot tap valve in position OPEN - MEASURE.

• The mechanical installation of the flow sensor is therewith completed.

12

4. ELECTRICAL CONNECTIONS

Important note:

The manufacturer cannot be held responsible for personal injuries or damage to property as a result of
incorrect handling, installation, wiring, power supply and maintenance of the device.

Before electrical connections are made turn off the power supply first. If not observed the electronics can be
damaged as a result.
Only a qualified electrotechnical engineer may install the device.

• Unscrew the four screws and remove the cover of the housing.

• The screw terminals are located in the bottom part of the housing.

• For the electrical connection of the flow sensor a six-wire cable is needed (e.g. 6 x 1 mm

measuring probe

2

(AWG 17))

Modbus data A (=D+) / M-Bus

Modbus data B (=D-) / M-Bus

+

p

4...20mA

I

or

or

18...30V AC/DC

-

≅

V

mA

mA_Input

OUT 1-2

OUT 1-1

OUT 2-1

OUT 2-2

+15V

Vcc

GND

optional bus output
Modbus RTU or M-Bus

optional
pressure sensor

signal output 1
analogue- or switching output

signal output 2
switching- or pulse output

supply

4.1. Connection Diagram

•

Screw terminal OUT 1-1 for the analogue output is internally connected with GND.

• The housing should be grounded to achieve optimal electromagnetic compliance.

4.1.1. Relay and Pulse Output, Internal Switching

OUT x-1

OUT x-2

The relay switch and pulse outputs are both potential free.

4.1.2. Connection with Optional Plug for Power Supply and Outputs (Order Code E4)

Pin Assignment

1 OUT 2-2

2 OUT 1-2

3 OUT 1-1

4 GND

Connection plug for the
power supply and ana­logue outputs (rear view of

the terminals)

5 OUT 2-1

6 n.c.

7 Vcc

8 n.c.

13

4.2. Bus Output (Optional)

4.2.1. M-Bus (Meter-Bus)

The M-Bus (Meter Bus) is a field bus for recording consumption data. Transmission is carried out serially on
a reverse polarity protected two-wire line. The flow sensor as M-Bus slave requires a separate supply voltage.
No specific topology (line or star) is prescribed for the cabling. Normal telephone cable of type J-Y(St)Y
Nx2x0.8mm can be used. A maximum of 250 meters is permitted per segment (primary addressed).

Read-out of the current measurement/consumption data

The following measurement/consumption values are transmitted during a standard query:

• Standard volumetric flow (32 Bit Real)

• Temperature (32 Bit Real)

• Mass flow (32 Bit Real)

• Consumption meter status (32 Bit Real)

• Flow velocity (32 Bit Real)

• Standard volumetric flow (32 Bit Integer)

• Temperature (32 Bit Integer)

• Mass flow (32 Bit Integer)

• Consumption meter status (64 Bit Integer)

• Flow velocity (32 Bit Integer)

The table below shows the package structure of the measurement/consumption data sent by the EE77x
sensor:

Header

68 Start of telegram

4F 4F L-eld (length)

68 Second starting signal

08 C-eld (RSP_UD)

XX A-eld (Adresse)

Start User data

72 CI-eld (variable data structure)

XX XX XX XX Identication number

A5 16 Producer (0x16A5 … EUE)

01 Version

09 Medium (9 … compressed air)

XX Access number (continuous)

00 Status

00 00 Signature

Data record 1: Volumenstrom

05 DIF (32 Bit Real)

3E VIF (Volume owmesse in m³/h)

XX XX XX XX Act. measuring value

Data record 2: Temperature

05 DIF (32 Bit Real)

5B VIF (Temperature in °C)

XX XX XX XX Act. measuring value

Data record 3: Mass ow

05 DIF (32 Bit Real)

53 VIF (Mass ow in kg/h)

XX XX XX XX Act. measuring value

Data record 4: Consumption meter reading

05 DIF (32 Bit Real)

16 VIF (Volume in m³)

XX XX XX XX Act. measuring value

Data record 5: Flow rate

05 DIF (32 Bit Real)

7F VIF (manufacturer specic in m/s)

XX XX XX XX Act. measuring value

Data record 6: Pressure

05 DIF (32 Bit Real)

6B VIF (Pressure in bar)

XX XX XX XX Act. measuring value

Data record 7: Volume ow

04 DIF (32 Bit Integer)

-3

-2

m³)

-3

-3

m³/h)

-2

kg/h)

bar)

°C)

3B VIF (Volume ow in 10

XX XX XX XX Act. measuring value

Data record 8: Temperatur

04 DIF (32 Bit Integer)

59 VIF (Temperature in 10

XX XX XX XX Act. measuring value

Datenrecord 9: Mass ow

04 DIF (32 Bit Integer)

51 VIF (Mass ow in 10

XX XX XX XX Act. measuring value

Datenrecord 10: Consumption meter reading

07 DIF (64 Bit Integer)

13 VIF (Volume in 10

XX XX XX XX
XX XX XX XX

Datenrecord 11: Flow rate

04 DIF (32 Bit Integer)

7F VIF (manufacturer specic in 10

XX XX XX XX Act. measuring value

Data record 12: Pressure

04 DIF (32 Bit Real)

68 VIF (Pressure in 10

XX XX XX XX Act. measuring value

End of user data

XX Check sum

16 End of telegram

Akt. consumption data

-2

m/s)

14

Secondary addressing

1 2 3 4 5 6 7 8

1 - ON
0 - OFF

1 2 3 4 5 6 7 8

1 - ON
0 - OFF

1 2 3 4 5 6 7 8

1 - ON
0 - OFF

In addition to primary addressing, the EE77x sensor provides the option of secondary addressing. The fields
of identification number, manufacturer, version and medium are used together as the secondary address. The
exact sequence of the secondary addressing is described in detail in the M-Bus Standard: https://m-bus.com/
assets/downloads/MBDOC48.PDF

4.2.2. Modbus RTU

The measured values are stored as a 32 bit float value. Depending on the measurement unit selected, the
measurements are saved in SI or US/GB units. The measurement unit can be changed using the configuration
software.
For resetting the MIN/MAX-Values write 0 to the corresponding write register.
For Modbus protocol setting please see Application Note AN0103 (www.epluse.com/EE772).

Modbus Map:

Register Protocol-

Address

Read Registers (Function Code 0x03 / 0x04) / 32 bit float value

30026 19 Standardized Flow m/s SFPM
30028 1B Standardized Volumetric Flow m
30030 1D Temperature °C °F
30032 1F Massflow kg/h kg/h
30034 21 Consumption reading m
30036 23 Pressure bar psi
30261 104 MIN-Value Standardized Flow m/s SFPM
30263 106 MAX-Value Standardized Flow m/s SFPM
30265 108 MIN-Value Standardized Volumetric Flow m
30267 10A MAX-Value Standardized Volumetric Flow m
30269 10C MIN-Value Temperature °C °F
30271 10E MAX-Value Temperature °C °F
30273 110 MIN-Value Massflow kg/h kg/h
30275 112 MAX-Value Massflow kg/h kg/h
30277 114 MIN-Value Pressure bar psi
30279 116 MAX-Value Pressure bar psi

Write Registers (Function Code 0x06) / 16 bit integer value

60261 104 Reset MIN/MAX-Value Standardized Flow
60262 105 Reset MIN/MAX-Value Standardized Volumetric Flow
60263 106 Reset MIN/MAX-Value Temperature
60264 107 Reset MIN/MAX-Value Massflow
60265 108 Reset MIN/MAX-Value Pressure

Measuring Value SI-Unit US/GB-Unit

3

/h SCFPM

3

3

/h SCFPM

3

/h SCFPM

3

ft

4.2.3. Data Transmission

Factory Setting
M-Bus

Baud Rate 2400 9600 600...9600 9600...57600

Data Bits 8 8 8 8
Parity Even Even None, Odd, Even None, Odd, Even
Stop Bits 1 1 1 or 2 1 or 2
Slave-Address 1 1 0...254 1...247

Factory Setting
Modbus

Adjustable Values

M-Bus Modbus RTU

4.2.4. Addressing

The flow sensors are factory-set to address 1. The slave address can be set via switches on the PCB.

Factory Setting:

1 - ON
0 - OFF

1 2 3 4 5 6 7 8

Slave-Address = 1

Slave-Address = 255

1 - ON
0 - OFF

1 2 3 4 5 6 7 8

The address set using
the configuration
software is used.

Dip-Switch for address setting

15

5. CONTROL COMPONENTS

V

0

: 323.8 m3/h

Maximal

5.1. Jumper J1 and J2

If the signal output is altered from relay to analogue output or vice versa, Jumper Output 1 has to be relocated.

If the analogue output is altered from a current to a voltage output or vice versa, Jumper Out-1 has to be
relocated.

signal output 1 =
switching output

signal output 1 =
analogue output

Jumper Output 1

Jumper Out-1

analogue output = current signal (e.g. 4-20mA)

analogue output = voltage signal (e.g 0-10V)

Modbus RTU only

Line Termination = OFF

Line Termination = ON
150 Ohm parallel to
bus output A and B

Jumper Line Termination

5.2. Digital Interface USB (For Configuration)

The USB connector is behind the blind screw cap, at the side of the housing.

• remove the blind screw cap with a screwdriver

• plug in the USB connector

Install the configuration software, which is in the scope of supply. The configuration software is

available for downloading as well from our website at www.epluse.com

blind screw cap

USB-cable

5.3. Display / Indicator with Keypad (Optional)

An optional two-line display is available for the flow sensor EE772. The display is an integral part of the cover
of the housing and has two soft-keys for the control of the indicator.

line 1

pushbutton - UP

V

: 1.3 m3/h

0

T : 27.97 °C

pushbutton - DOWN

line 2

16

Depending on the configuration of the outputs either the measured values, the status of the relay or the consumption

V

0

: 323.8 m3/h

Maximal

T : 27.97 °C

V

0

: 1.3 m3/h

V

0

: 45.0 m3/h

Rel : 1

V

0

: 323.8 m3/h

Maximal

V

0

: 323.8 m3/h

Maximal

V

0

: 323.8 m3/h

Maximal

is indicated.

measurand

measuring value
unit

V

: 1.3 m3/h

0

T : 27.97 °C

Measurand SI Unit US Unit

v

0 Standardized Flow m/s SFPM

T Temperature °C °F

V

0 Standardized Volumetric

m3/h; m3/min; l/min SCFM; SLPM

Flow

m Massflow kg/h; kg/min; kg/s kg/h; kg/min; kg/s

Q Consumption m

3

3

ft

p Pressure bar psi

5.3.1. Indication of the Analogue and Pulse Output

Line 1 indicates always the configured measurand at output 1. In line 2 the desired measurement value can be
indicated using the UP and DOWN keys.

5.3.2. Indication of the Switch Output

Line 1 indicates the status of the switch output. In line 2 the desired measurement value can be indicated using the
UP and DOWN keys.

The display shows an inverse image if the relay output is active (relay has switched).

Rel : 1

V0: 1.5 m3/h

Rel : 1

V

: 45.0 m3/h

0

Switch output inactive (relay has not switched) Switch output active (relay has switched)

5.3.3. Indication of the MIN / MAX Values

Keep the DOWN key pressed for > 3 sec to indicate the MIN value.
Keep the UP key pressed for > 3 sec to indicate the MAX value.

V

: 1.3 m3/h

0

T : 27.97 °C

MAX value press pushbutton UP >3s

MIN value press pushbutton DOWN >3s

17

After that the several different measurement values can be indicated using the UP or DOWN keys.
Keep the DOWN or UP key pressed for > 3 sec to exit the MIN / MAX mode.

Maximal

: 323.8 m3/h

V

0

5.3.4. Reset of the Consumption Counter or the MIN / MAX Value

Keep both the UP and DOWN key pressed for > 3 sec to enter the menu for resetting the consumption coun­ter or the MIN / MAX value.
Select the desired menu item by pressing the UP or DOWN key briefly.

Maximal

: 323.8 m3/h

V

0

Press pushbutton UP and DOWN at the same time for >3s

To confirm the selected choice of the menu keep the DOWN or UP key pressed for > 3 sec.
Select menu item “NO” or “EXIT” to cancel without resetting.

> Clear Consumption
Clear Min/Max
Exit

5.3.5. Maximum Consumption Counter

The maximum consumption counter readout on the display is 999,999,999.0 m

3

or 99,999,999.0 ft3. Then it
shows “LCD maximum”. The internal memory continues counting. The maximum counter reading is 3.4 * 1038
m3. It is possible to read-out the counter reading with the configuration software.

6. ERROR MESSAGES

In case the flow sensor is equipped with the optional display, the following error message can be indicated.

ERROR 01: sensing probe is not detected

Cause: the sensing probe is not connect or is defect
Effect: the display indicates “0” for all measurand. The analogue output defaults to the lowest

configured value.
Action: check the head of the sensing probe for visual damage.
check the sensor cable from the sensing probe to the electronics of the signal conditioning.

ERROR 02: the EEprom is defect

Cause: the EEPROM for the storing of the consumption counter and MIN /MAX value is defect.
Effect: the consumption counter and MIN / MAX values are no longer available. All measure-

ment values though are still indicated. The analogue, relay and pulse output are still

functional.
Action: return the flow sensor to the manufacturer.

18

7. MAINTENANCE

7.1. Removal of the Sensing Probe of the Gauge Mounting Block

Gauge mounting block without hot tap valve

Make sure that the pipe line is depressurized!

•

Loose the retainer nut and pull the sensor probe from the gauge mounting block.

• Operation without the flow sensor installed page 10.

7.2. Removal of the Sensing Probe of the Gauge Mounting Block with Hot Tap Valve

The sensor can be removed under pressure without flow interruption.

• Turn the gauge mounting block with hot tap valve with the hand without tools (anti-clockwise rotation) in

the position SERVICE - CLOSE.

• Only if the gauge mounting block with hot tap valve is fully in the position SERVICE - CLOSE the sensor

is hermetically sealed against the pressurized line.

• Loose the retainer nut slowly. Let the air exhaust slowly and make sure that is was only the relief pres-

sure and the gauge mounting block with hot tap valve is hermetically sealed.

• Loose the retainer nut and pull the sensor probe from the gauge mounting block with hot tap valve.

• Operation without the flow sensor installed page 10.

The sensor head is sensitive. Use the protection cap for transport and storage!

7.3. Cleaning of the Sensing Element

Do not use an abrasive cleaning agent, an organic solvent containing halogen or acetone.

• Clean the head of the sensor probe by carefully swirling in warm water of isopropyl alcohol. It is

recommended to use isopropyl alcohol if the pollution is crease or oil.

The sensor should not be touch by fingers or solid objects like screwdrivers or brushes!

• Leave the sensor to dry in ambient air.

8. REPLACEMENT PARTS / ACCESSORIES

8.1. Order Code Replacement Sensor

Replacement Sensor PE772-

Compact ri-le

Type

Measuring range High - 0...200 m/s

Measurement valve for
pipe diameter

Mounting

Electrical connection

Compact le-ri
Remote probe T3

DN40 N40 N40
DN50 N50 N50
DN65 N65 N65
DN80 N80 N80
Gauge mounting block TG2 TG2
Gauge mounting block with hot tap valve TG3 TG3
Cable gland and screw terminals no code
1 plug for power supply and outputs E4

flow direction right to left

flow direction left to right

(656.2 ft/s) HV33 HV33

T19
T20

19

Order Example Order Example

PE772-T19HV33N65TG2E4

Model: Compact ri-le
Working range: High
Measurement valve for pipe diameter: DN65
Mounting: Gauge mounting block
Electrical connection: 1 plug for power supply and outputs

PE772-T3HV33N65TG2

Model: Remote probe
Working range: High
Measurement valve for pipe diameter: DN65
Mounting: Gauge mounting block
Electrical connection: Cable gland and screw terminals

9. TECHNICAL DATA

Measurands

Flow Volumetric flow at standard conditions acc. to DIN 1343

p

Measuring range HV33 (high)

DN50 (2"): 3.50...1400 m3/h 2.06...823.6 SCFM
DN65 (2 1/2"): 5.97...1400 m3/h 3.51...823.6 SCFM
DN80 (3"): 9.04...1400 m3/h 5.32...823.6 SCFM

Standardized flow in ≤DN50 (2"): 0.5...200 m/s 100...39370 SFPM

air, CO2, nitrogen, argon DN65 (2 1/2"): 0.5...117 m/s 100...23031 SFPM
DN80 (3"): 0.5...77 m/s 100...15157 SFPM

Standardized volumetric flow in air DN40 (1 1/2"): 2.26...904 m3/h 1.33...531.8 SCFM

Accuracy in air at 7 bar (abs) (101.5 psi) and 23°C (73°F)1) ± (1.5 % of measuring value + 0.5 % of full scale)
Temperature dependency ± (0.1 % of measuring value/°C)

Pressure dependency
Response time t

2)

0.5 % of measuring value / bar

< 1 s

90

Sample rate 0.1 s

Temperature

Measuring range
Accuracy at 20°C (68°F) ± 0.7 °C (1.26 °F)

Outputs

Signal range and measurands are freely configurable
Analogue output Voltage 0 - 10 V 0 < I
Current (3-wire) 0 - 20 mA and 4 - 20 mA R
Switch output Potential-free, max. 44 V DC, 500 mA switching capacity
Pulse output Totalizer, pulse length: 0.02...2 s
Digital interface (optional)
RS485 (EE772 = 1 unit load)
Protocol Modbus RTU
Default settings Baud rate 9 600
M-Bus
Default settings Baud rate 2 400

Input

Dynamic pressure compensation 4 - 20 mA (2-wire; 15 V) input for external pressure sensor

= 1 013.25 mbar (14.7 psi); T0 = 0 °C (32 °F)

0

-20...80 °C (-4...176 °F)

< 1 mA

L

L < 500 Ohm

3)

, parity even, stop bits 1, slave ID 1

4)

, parity even, stop bits 1, slave ID 1

20

General

Supply voltage 18 - 30 V AC/DC
Current consumption, max. 200 mA (with display)
Temperature range Ambient, storage -20...60 °C
Medium -20...80 °C (-4...176 °F)
Nominal pressure 40 bar (580 psi)
Humidity 0...100 %RH, non-condensing
Electrical connection Cable gland M16 and screw terminals max. 1.5 mm
optional with connector M12x1, 8 pole
Electromagnetic compatibility EN 61326-1 EN 61326-2-3
Industrial Environment
Material Enclosure Metal (AlSi
Probe Stainless steel
Sensor head Stainless steel / glass
Gauge mounting block Aluminium
Enclosure protection rating IP65 / NEMA 4

1) The accuracy statement includes the uncertainty of the factory calibration with an enhancement factor k=2 (2-times standard deviation). The accuracy was
calculated in accordance with EA-4/02 and with regard to GUM (Guide to the Expression of Uncertainty in Measurement).
The accuracy specifications apply when using inlet and outlet sections of suitable length, see User Manual.

2) The flow meter is calibrated at 7 bar (abs) (101.5 psi). At other working pressure the error can be compensated by setting the actual pressure
with the configuration software.

3) Supported baud rates: 9 600, 19 200, 38 400 and 57 600; find more details about communication setting in the User Manual and the Modbus
Application Note at https://www.epluse.com/EE772.

4) Supported baud rates: 600, 1 200, 2 400, 4 800 and 9 600; find more details about communication setting in the User Manual.

9.1. Factory Setting of Outputs

SI-Unit

Analogue output

[0...10 V / 0(4)...20 mA] from to unit

low (L1) high (H1)
Standardized DN40: 0 450 900 m

volumetric flow DN50: 0 700 1400 m3/h
DN65 0 1400 m3/h
DN80 0 1400 m3/h
Mass flow DN40: 0 570 1140 kg/h
DN50: 0 890 1780 kg/h
DN65: 0 1780 kg/h
DN80: 0 1780 kg/h
Standardized flow
DN65 0 117,25 m/s
DN80 0 77,41 m/s
Temperature all Ø -20 80 80 °C

DN40/50 0 100 200 m/s

(-4...140 °F)

Cu)

3

2

(AWG 16),

3

/h

Switching output [switching point/hysteresis]
Standardized DN40: 360/36 720/72 m

volumetric flow DN50: 560/56 1120/112 m3/h
DN65 1120/112 m3/h
DN80 1120/112 m
Mass flow DN40: 460/46 920/92 kg/h
DN50: 700/70 1400/140 kg/h
DN65: 1400/140 kg/h
DN80: 1400/140 kg/h
Standardized flow
DN65 80/8 m/s
DN80 60/6 m/s
Temperature all Ø 30/3 70/7 °C

Pulse output pulse value = 1m

DN40/50 80/8 180/18 m/s

3

pulse duration = 0.1 s

3

3

/h

/h

21

US-Unit

Analogue output [0...10 V / 0(4)...20 mA] from to unit
low (L1) high (H1)
Standardized DN40: 0 260 520 SCFM

volumetric flow DN50: 0 410 820 SCFM
DN65: 0 820 SCFM
DN80: 0 820 SCFM
Mass flow DN40: 0 570 1140 kg/h
DN50: 0 890 1780 kg/h
DN65: 0 1780 kg/h
DN80: 0 1780 kg/h
Standardized flow
DN65 0 23081 SFPM
DN80 0 15238 SFPM
Temperature all Ø -4 176 176 °F

Switching output [switching point/hysteresis]
Standardized DN40: 210/21 420/42 SCFM

volumetric flow DN50: 330/33 660/66 SCFM
DN65: 660/66 SCFM
DN80: 660/66 SCFM
Mass flow DN40: 460/46 920/92 kg/h
DN50: 700/70 1400/140 kg/h
DN65: 1400/140 kg/h
DN80: 1400/140 kg/h
Standardized flow
DN65 15000/1500 SFPM
DN80 10000/1000 SFPM
Temperature all Ø 90/9 150/15 °F

DN40/50 0 19685 39370 SFPM

DN40/50 15000/1500 30000/3000 SFPM

Pulse output pulse value = 1CF pulse duration = 0.1 s

CONFIGURATION SOFTWARE

LIMITED LIABILITY

E+E Elektronik shall not be held liable for any damages or consequential damages (for example, but not
restricted to, loss of earnings, interruption of business, loss of information and data or any other financial
losses) resulting from the installation, use or impossibility of use of an E+E Elektronik software product and
any associated support services or non-performance of support services.

1. General

The configuration software can be downloaded free of charge at www.epluse.com/EE772
The configuration software, allows for a user-friendly adaptation of the flow meter to the application. In addi­tion, the measurement values for flow and temperature can be calibrated / adjusted.

The system requirements for the installation and execution of the software are:

• Windows XP with SP3, Windows Vista or Windows 7

• .NET framework 3.5 with SP1

• USB 2.0 interface

During setup there will be no installation of .NET Framework 3.5 SP1 – if the required version is not already
installed on the computer the following error message will appear at the start of the configuration software.

.NET Framework 3.5 SP1 can be installed using Windows Update.

22

2. Installation

In order to set up a smooth installation of the configuration software of the EE772, admin authorization for the
personal computer is required.

• During installation of the software the EE772 should NOT be connected with the USB cable to the

computer.

• Wit Setup.exe the InstallShield-Wizard for the EE772 configurator will be started.

• Follow the instructions on the screen to install the software.

At first, the configuration software will be installed and then the installation of the USB driver activated – except

if the user has defined that USB setup is disabled.
The USB driver will be automatically installed the moment the first connection is made with the EE772.
The appearing dialog boxes can be dealt with the settings “No. do not download driver from the internet” and
“Install the hardware automatically”.

If the EE772 configuration software and the USB driver are installed correctly, and the EE772 is connected
via the USB interface with the personal computer, a connection “Silicon Labs CP210x USB to UART Bridge”
should have been created in the device manager.

See: Start => Settings => Control Panel => System => Hardware =>
Device Manager

2.1. Configuration of the USB Interface (VirtualCOM)

After the startup of the software, the correct VirtualCOM interface for the
USB driver must be configured
The number for the used USB interface can be found under:
Start => Settings => Control Panel => System => Hardware =>
Device Manager

The setting is done under menu “Extras” and menu item “Optional extras…..”

23

Select the COM-port number as shown in the device manager.

These settings are done only once and at the first start of the configuration software. The settings are stored
for future use.

3. User Interface

4

1

2

3

1

3

2

Basic information:
After retrieving the data from the transmitter, the basic information of the device is shown here.

Status message:
Here are the messages shown about the status and other information.

Input screen:
Input screen for the configuration or adjustment of the flow meter.

4

Menu tool bar:
Selection of menu items.

24

4. Menu Toolbar

4.1. File

Delete status message deletes the status messages.

Exit closes the configuration software.

4.2. Transmitter

Please note: The term “Transmitter” is used synonymously with “Sensor” in this user manual.

Read reads the actual configuration of the transmitter.

Send uploads the ‘new’ configuration to the transmitter.

The following settings are uploaded to the transmitter

• Units

• Output 1

• Output 2

• Display mode

• Pressure transmitter

Prior to uploading the ‘new’ configuration to the transmitter, a dialog box will show a summary of the
changes. Click on the button ‘OK’ and the configuration will be uploaded to the transmitter; click
‘Cancel’ to cancel the operation.

4.3. Extras

Configurations of the VirtualCOM interface (see page 23).

5. Input Screen

5.1. Output 1, Output 2

In this screen the actual settings of the transmitter for the output 1 and 2, resp. relay 1 and 2 are shown. The
user can alter and upload these settings to the transmitter, together with other changes of the configuration.

5.1.1. Output Mode

Here the mode of signal output can be determined.
Output 1: analogue or switch (relay) output
Output 2: switch (relay) or pulse output

NOTE:
In case the mode of output 1 is changed, the Jumper J1 on the board of the signal conditioning electronics
has to be relocated as well (see page 25)

5.1.2. Measurand

Here is determined which measurand will be represented at the particular output.

5.1.3. Units

Choice of the engineering units of the selected measurand in either SI- (m/s; °C; m3/h) or US-units
(SFPM; °F; SCFM).

NOTE:
The setting “Units” on the tabs for Output 1 and Output 2 are in sync with each other. If the units are changed
on one of the output tabs, automatically the units on the other output tab are changed accordingly.

25

5.1.4. Output Mode – Analogue

Within the limits of measurement range and the scaling of the output, the analogue output can be freely
configured and scaled. Either a standard output signal (0 - 5 V, 0 - 10 V, 0 - 20 mA, 4 - 20 mA) can be selected
or a user defined range for the current / voltage output (e.g. 1 - 9 V).

NOTE:
In case the analogue output is changed (from current to voltage or vice versa), the Jumper J2 on the board
of the signal conditioning electronics has to be relocated as well (see page 25).

5.1.5. Output Mode – Switch (Relay)

In the field for the “Switch-mode”, one can select “Hysteresis” or “Window”.

The field for “Type” is to determine the switch action of the relay, NO = Normally Open (activate to close), NC
= Normally Close (activate to open).

Under “Measuring range” in the field “From” the low value of the measuring range can be entered and in the

field “To” the high value.
The hysteresis of the set point is entered as a percentage of the
measuring range.
[measuring range] = high measuring value – low measuring value

e.g. hysteresis
set point = 500 m3/h and reset point is 450 m3/h

Hysteresis = 50 m3/h = 0.5 % of measuring range

Hysteresis

3

m

/h

When the measurement value reaches set point 1, the relay will be
activated. The value at the reset point is the value at set point 1 minus
the hysteresis.

set point 1

NO (activate to close)

NC (activate to open)

Hysteresis

1

0

1

0

t

e.g. set point 1 = 100 m3/h and the hysteresis 5 m3/h.
the relay switches at 100 m3/h. The reset point is at 96 m3/h.
Hysteresis = 5 m3/h = 5% of the measuring range

26

Window

3

m

/h

The relay is activated as long as the measuring value is between
the values of set point 1 and set point 2.
The hysteresis of each set point is fixed at 0.2% of the measuring

set point 1

set point 2

range.

e.g.: set point 1 = 100 m

3

/h; set point 2 = 80 m3/h;

hysteresis of each set point is 1 m3/h (0.2% of 500 m3/h)

t

NO (activate to close)

NC (activate to open)

1

0

1

0

  

3

80 m






/h = set point 2
100 m3/h = set point 1
99 m3/h = set point 1 - hysteresis
79 m3/h = set point 2 - hysteresis

5.1.6. Output Mode – Pulse

If output 2 is configured for pulse, the measurand can be consumption only. Under “Pulse”, the duration of the
pulse and the pulse value (Significance level of pulse) can be freely configured.

Volume Flow [m3/h] Number of Pulses

3

/Pulse]

=

HourPulse Value [m

The duration of the pulse can be set between 0.02 and 2 seconds.

e.g. Duration of pulse = 100ms; one pulse for each m3 consumed

The pulse – interval – ratio must be at least 1 : 2, meaning that the duration of the pulse interval must be at
least twice the duration of the pulse itself.

OUT 2

≥ 2 s

1/3 min. 2/3

t

Calculation of the minimum “pulse value” or the maximum “pulse duration”.

IMPW_MIN = NORMV_MAX [m3/h] * IMPL [s] / 1200
IMPL_MAX = IMPW [m3] * 1200 / NORMV_MAX [m3/h]

IMPW pulse value [m

IMPL pulse length (duration) [s]
IMPW_MIN minimum pulse value [m3]
IMPL_MAX maximum pulse length (duration)
NORMV_MAX expected maximum volume flow (m3/h)

3

]

5.2. Minimum Flow Shutdown

The minimum flow shutdown is switched on and off using the “active” checkbox.

If the output signal is ≤ than the set “Shutdown value”, the flow meter issues 0 on the analogue output.

27

5.3. Display

If an optional display is installed, at the tab Display the following items can be entered:
Drop-down input field “Display-Mode”

• Single spaced

• Double spaced (default)

Checkbox “Backlight”

• Checked = ON

• Unchecked = OFF

In the input field
“Description (free text), a
user specific name (max.
16 characters) for the
transmitter can be

entered.
e.g.: HALL 1
With the button “send” only the description will be uploaded to the transmitter.

5.4. Adjustment

The user can perform an adjustment for the measurands normflow and temperature in air.
The configuration software distinguishes between a 1-point and a 2-point adjustment automatically, depending
on how many reference points for adjustments are entered.

The values entered for the customer’s adjustment are stored in the electronics of the sensing probe and are
therefore not lost if the electronics of the signal conditioning are replaced (see page 6)

If the checkbox “Performing customer-adjustment” is checked, the adjustment mode will be activated and the
actual measuring value in the set interval automatically retrieved from the flow meter (transmitter).

NOTE: At first change to “Calibration gas” in the tab “Process parameters”.
While the customer-adjustment is active all other pages, functions and commands are deactivated.

In the field “Adjustment” the measurand to be adjusted is selected.
In the field “Measuring value” the actual measurement value of the transmitter is indicated.
The update-interval can be set.

In the field “Reference value” the measurement value of the standard is entered.
After clicking the button “send” a control dialog box appears in which the values can be corrected if needed.
Then the reference value will be uploaded to the flow meter (transmitter) and is the adjustment procedure
complete.
The reference point of the customer-adjustment must be within the determined measuring range.

The customer-adjustment results in a slight rotation of the characteristic line, in such a way that the measure­ment deviation at the upper and lower adjustment points equals zero.
The configuration software determines, depending on its position, if it is an upper or lower adjustment point.

5.4.1. 1-point Adjustment

lower adjustment point upper adjustment point

possibility 1 0 - 50% of measuring range 100% of measuring range

possibility 2 0% of measuring range >50 - 100% of m.r.

28

m.r. ... measuring range

10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

upper adjustment point at 80% of measuring range

lower adjustment point automatically at 0% of m.r.

lower adjustment point at 20% of measuring range

upper adjustment point automatically at 100% of m.r.

100%

90%

80%

70%

60%

50%

40%

output signal

30%

20%

10%

characteristic line before adjustment

characteristic line after adjustment

measuring range

selected adjustment point

100%

90%

80%

70%

60%

50%

40%

output signal

30%

20%

10%

characteristic line before adjustment

characteristic line after adjustment

selected adjustment point

10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

measuring range

5.4.2. 2-point Adjustment

With a 2-point adjustment procedure the lower adjustment point must be between 0 and 40% of the measur­ing range, and the upper adjustment point between 60 and 100% of the measuring range. If the adjustment
point is between 40 and 60% of the measuring range, automatically a 1-point adjustment procedure will be
executed instead.

lower adjustment point upper adjustment point

possibility 1 0 - <40% of m.r. 60 - 100% of m.r.

possibility 2 40 - <50% of m.r. 100% of m.r.

possibility 3 0% of m.r. 50 - <60% of m.r.

lower adjustment point at 10% of measuring range
upper adjustment point at 90% of measuring range

100%

90%

80%

70%

60%

50%

40%

output signal

30%

20%

10%

characteristic line before adjustment

characteristic line atfer adjustment

10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

measuring range

29

5.4.3. Reset to Factory Settings

Customer-adjustment can be reset to the factory settings by checking the appropriate checkbox and subse­quently clicking the “reset” button.

5.5. Measuring Values Overview

The tab measuring values provides an overview of the retrieved actual measurement values of the flow
meter (transmitter). Clicking on “Fetch values” will retrieve the actual measurement and MIN / MAX values for
flow, volume flow, temperature, mass flow and pressure (only if a pressure transmitter is connected) from the
transmitter – additional the reading of the consumption meter is retrieved as well.
Checking the “Polling” checkbox will retrieve the measuring data from the transmitter at the selected interval.

5.5.1. Reset of the MIN / MAX Values

The MIN/ MAX values of each measurand, as stored in the flow meter (transmitter), can be reset by checking
the appropriate checkbox and subsequently clicking the “Clear MIN / MAX” button.

5.5.2. Reset of the Consumption Counter (Totalizer)

The reading of the consumption meter can be reset by clicking the “Reset meter” button.

5.6. Setting up Process Parameters

In the tab Process Parameters you can change the Process gas (medium) and set the pressure compensa­tion

5.6.1. Change of the Process Gas

NOTE: This function is only active if the flow meter for a medium different from air has been ordered (see
order code Medium in the data sheet)

Calibration-Gas: Is the gas (medium) in which the flow meter was calibrated in the factory. Unless otherwise
specified, the flow meter is calibrated at the factory always in air.

Process-Gas: Is the gas (medium) in the measured process. The adjustable process gases are set at the
factory and can be selected from a list.

30

The flow meter is factory set to the ordered gas (medium).
If the setting for the process-gas modified or changed between calibration- and process gas, the changed
setting has to be sent to the transmitter. Use “send data to the transmitter and read ...” button.
The “active gas” to which the flow meter is set, you can see in the field basic information.

5.6.2. Change of the Standard Conditions

The flow meter is factory-set to standard conditions conforming to DIN 1343.

Factory setting: P

The corrected volume flow measured value is calculated in line with the standard conditions set.

5.6.3. Pressure Compensation

To achieve the highest measuring accuracy, the actual pressure can be entered in the field “pressure”.
The “Send” button is used only to send the process pressure to the transmitter.

= 1013.25 mbar, t0 = 0°C (273.15 K)

0

5.7. External Pressure Sensor for Pressure Compensation

In order to achieve the highest accuracy, the input from an external pressure transmitter will be very useful if
the pressure fluctuates strongly (e.g. 3 to 10 bar (45 to 150 psi)). An absolute pressure transmitter with a
2-wire loop powered 4 - 20 mA output should be used.
On the tab “Pressure transmitter” the measuring range can be entered.

5.8. Bus Configuration

If the flow meter is equipped with an optional bus module, the data transfer rate and the network address can
be set on the “Bus configuration” tab.
The network address set is only used when the dip switches on the flow meter PCB are set to 255 (see page 14).

31

HEADQUARTERS

E+E Elektronik Ges.m.b.H.

Langwiesen 7
4209 Engerwitzdorf
Austria
Tel.: [phone]
E-mail: [e-mail]
Web: www.epluse.com

SUBSIDIARIES

E+E Elektronik China

18F, Kaidi Financial Building,
No.1088 XiangYin Road
200433 Shanghai
Tel.: [phone]
E-mail: [e-mail]

E+E Elektronik France

Le Norly III, 136 chemin du Moulin
69130 Ecully
Tel.: [phone]
E-mail: [e-mail]

E+E Elektronik Germany

Schöne Aussicht 8 C
61348 Bad Homburg
Tel.: [phone]
E-mail: [e-mail]

E+E Elektronik Italy

Via Alghero 17/19
20128 Milano (MI)
Tel.: [phone]
E-mail: [e-mail]

E+E Elektronik Korea

Suite 2001, Heungdeok IT
Valley Towerdong, 13,
Heungdeok 1-ro, Giheung-gu
16954 Yongin-si, Gyeonggi-do
Tel.: [phone]
E-mail: [e-mail]

E+E Elektronik USA

333 East State Parkway
Schaumburg, IL 60173
Tel.: [phone]
E-mail: [e-mail]
