Installation Instructions for 102 Series Triliptical
Cheshire, CT 06410 203-699-3300 (Ph)
203-699-3365 (Cust. Serv. Fax)
203-699-3078 (Tech. Serv. Fax)
DescriptionDescription
Description
DescriptionDescription
The Edwards Triliptical DeviceNet Stackable Beacon Lighting System is a unique audible-visual signaling device that can
contain up to 5 light modules and a multiple tone module in a single "stack."
All components of the Lighting System are UL listed subassemblies and cUL Listed. The enclosures are Type 3R, Type 4X
and IP65 Rated. The unit has been tested by ODVA's authorized independent test lab and found to comply with ODVA
conformance test software.
The optically designed lenses are available in five colors. Each lens module contains a removable cover to allow for
easy relamping. The lens module cover features a molded-in gasket for weather tight reliability.
The Lighting System's base is supplied with a terminal block and may be used with an optional horn assembly. See
Tables 1 and 2 for specification information.
NOTE: The DeviceNet Electronic Data Sheet is available on the Edwards Signaling website at:
http://www.edwards-signals.com/index.cfm?Level=147&PG=3&PID=19. Scroll down to "Installation
Instructions" and click on "102 DeviceNet Electronic Data Sheet"
Device Profile
Revision 1.00
Firmware Revision 1.02
The DeviceNet interface is in the Triliptical DeviceNet Base, 102TBS-DN. The base interfaces between the network and all
installed stacklight modules.
DeviceNet Stackable Beacon Lighting System
®
The Triliptical DeviceNet Stackable Beacon is a slave device. It is a general purpose status indicator designed to
indicate the status of a machine or process.
The Triliptical DeviceNet Stackable Beacon has LED, halogen, incandescent or strobe light sources which display the
status of the machine or the process. The power required to drive the lamps is supplied separately from the bus
power for the 120V AC (N5) version. DC power for the 24V DC (G1) version may be taken locally or from the
DeviceNet Network. A standard open style 2 pin connector is used to connect 24V DC @ 1.75A (max) or 120V AC at
0.6A (max) to drive the 5 light sources.
The unisolated physical layer contains DeviceNet required mis-wiring protection circuitry. A standard open style
(unsealed) 5 pin connector is used to connect the Stackable Beacon to the DeviceNet bus. The current draw from the
bus is 0.12A for both the AC and DC versions.
The Triliptical DeviceNet Stackable Beacon contains a preprogrammed microcontroller which implements the Group
2 pre-defined Master/Slave Connection Set. This allows for one Explicit Messaging Connection and one Poll Connection. The objects (classes) supported are described in the next section. The Stackable Beacon resets automatically when
DeviceNet power is applied.
1.0 Object Model
1.1 Object Present in the 102TBS-DN:
OBJECT Optional/Required # of Instances
Identity (1) Required 1
Message Router (2) Required 1
Devicenet (3) Required 1
Assembly (4) Required 1
Connection (5) Required 1
1.2 Object that Effect Behavior:
OBJECT Effect on Behavior
Identity (1) Supports the reset service
Message Router (2) No effect
Devicenet (3) Configures port attributes
Assembly (4) I/O assembly for lamps
Connection (5) Establishes the number of connections
CHESHIRE, CT 203-699-3000 CUST. SERV. FAX 203-699-3365 TECH. SERV. FAX 203-699-3078
P/N 3100125 ISSUE 3 © 2003
PAGE 1
1.3 Object Interfaces:
OBJECT Effect on Behavior
Identity (1) Message router
Message Router (2) Explicit message connection instance
Devicenet (3) Message router
Assembly (4) I/O connection or message router
Connection (5) Message router
1.4 Identification of I/O Assembly Interfaces:
Instance Number Type Name
1 Input/Output Lamps ON/OFF, Lamp diagnostics, and sounder control
1.5 Format of I/O Assembly data Attribute:
Input to the DeviceNet bus as a response to the poll command from master node.
Data Byte 0 value indicates the lamp is OK or it is either burned out or missing.
Data Byte 1 value indicates the lamp was on or off when last poll command was received.
Data Byte 2 value indicates the current sounder module control value.
For Units Configured with 5 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
1=PWR LOST CARE CARE 1 = REP 1 = REP 1 = REP 1 = REP 1 = REP
2=PWR OK 0 = OK 0 = OK 0 = OK 0 = OK 0 = OK
1 DON'T DON'T DON'T LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
CARE CARE CARE 1 = ON 1 = ON 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF 0 = OFF 0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 4 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T LMP 4 LMP 3 LMP 2 LMP 1
1=PWR LOST CARE CARE CARE 1 = REP 1 = REP 1 = REP 1 = REP
2=PWR OK 0 = OK 0 = OK 0 = OK 0 = OK
1 DON'T DON'T DON'T DON'T LMP 4 LMP 3 LMP 2 LMP 1
CARE CARE CARE CARE 1 = ON 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF 0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
P/N 3100125 ISSUE 3 PAGE 2
For Units Configured with 3 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T DON'T LMP 3 LMP 2 LMP 1
1=PWR LOST CARE CARE CARE CARE 1 = REP 1 = REP 1 = REP
2=PWR OK 0 = OK 0 = OK 0 = OK
1 DON'T DON'T DON'T DON'T DON'T LMP 3 LMP 2 LMP 1
CARE CARE CARE CARE CARE 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 2 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T DON'T DON'T LMP 2 LMP 1
1=PWR LOST CARE CARE CARE CARE CARE 1 = REP 1 = REP
2=PWR OK 0 = OK 0 = OK
1 DON'T DON'T DON'T DON'T DON'T DON'T LMP 2 LMP 1
CARE CARE CARE CARE CARE CARE 1 = ON 1 = ON
0 = OFF 0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 1 Light Module
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T DON'T DON'T DON'T LMP 1
1=PWR LOST CARE CARE CARE CARE CARE CARE 1 = REP
2=PWR OK 0 = OK
1 DON'T DON'T DON'T DON'T DON'T DON'T DON'T LMP 1
CARE CARE CARE CARE CARE CARE CARE 1 = ON
0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
P/N 3100125 ISSUE 3PAGE 3
Output to the 102TBS-DN with the poll command from master node.
Data Byte 0 value indicates the lamps to be turned ON or OFF.
Data Byte 1 value indicates the ON lamps to be Steady ON or Flashing and the Flashing rate (45, 60 or 80 flashes
per minute) selected. Strobe units should always be set to Steady ON.
Data Byte 2 value indicates the sounder to be turned ON or OFF and the tone to be chosen.
For Units Configured with 5 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 DON'T DON'T DON'T LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
CARE CARE CARE 1 = ON 1 = ON 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF 0 = OFF 0 = OFF
1 0 0 1 LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
45 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY 0 = STDY 0 = STDY
1 0 1 0 LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
60 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY 0 = STDY 0 = STDY
1 1 DON'T DON'T LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
80 CARE CARE 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY 0 = STDY 0 = STDY
1 0 0 0 LMP 5 LMP 4 LMP 3 LMP 2 LMP 1
80 FPM 80 FPM 80 FPM 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
DEFLT DEFLT DEFLT 0 = STDY 0 = STDY 0 = STDY 0 = STDY 0 = STDY
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 4 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 DON'T DON'T DON'T DON'T LMP 4 LMP 3 LMP 2 LMP 1
CARE CARE CARE CARE 1 = ON 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF 0 = OFF
1 0 0 1 DON'T LMP 4 LMP 3 LMP 2 LMP 1
45 CARE 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY 0 = STDY
1 0 1 0 DON'T LMP 4 LMP 3 LMP 2 LMP 1
60 CARE 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY 0 = STDY
1 1 DON'T DON'T DON'T LMP 4 LMP 3 LMP 2 LMP 1
80 CARE CARE CARE 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY 0 = STDY
1 0 0 0 DON'T LMP 4 LMP 3 LMP 2 LMP 1
80 FPM 80 FPM 80 FPM CARE 1 = FLSH 1 = FLSH 1 = FLSH 1 = FLSH
DEFLT DEFLT DEFLT 0 = STDY 0 = STDY 0 = STDY 0 = STDY
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
P/N 3100125 ISSUE 3 PAGE 4
For Units Configured with 3 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 DON'T DON'T DON'T DON'T DON'T LMP 3 LMP 2 LMP 1
CARE CARE CARE CARE CARE 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF
1 0 0 1 DON'T DON'T LMP 3 LMP 2 LMP 1
45 CARE CARE 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY
1 0 1 0 DON'T DON'T LMP 3 LMP 2 LMP 1
60 CARE CARE 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY
1 1 DON'T DON'T DON'T DON'T LMP 3 LMP 2 LMP 1
80 CARE CARE CARE CARE 1 = FLSH 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY 0 = STDY
1 0 0 0 DON'T DON'T LMP 3 LMP 2 LMP 1
80 FPM 80 FPM 80 FPM CARE CARE 1 = FLSH 1 = FLSH 1 = FLSH
DEFLT DEFLT DEFLT 0 = STDY 0 = STDY 0 = STDY
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 2 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 DON'T DON'T DON'T DON'T DON'T DON'T LMP 2 LMP 1
CARE CARE CARE CARE CARE CARE 1 = ON 1 = ON
0 = OFF 0 = OFF
1 0 0 1 DON'T DON'T DON'T LMP 2 LMP 1
45 CARE CARE CARE 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY
1 0 1 0 DON'T DON'T DON'T LMP 2 LMP 1
60 CARE CARE CARE 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY
1 1 DON'T DON'T DON'T DON'T DON'T LMP 2 LMP 1
80 CARE CARE CARE CARE CARE 1 = FLSH 1 = FLSH
FPM 0 = STDY 0 = STDY
1 0 0 0 DON'T DON'T DON'T LMP 2 LMP 1
80 FPM 80 FPM 80 FPM CARE CARE CARE 1 = FLSH 1 = FLSH
DEFLT DEFLT DEFLT 0 = STDY 0 = STDY
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
P/N 3100125 ISSUE 3PAGE 5
For Units Configured with 1 Light Module
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 DON'T DON'T DON'T DON'T DON'T DON'T DON'T LMP 1
CARE CARE CARE CARE CARE CARE CARE 1 = ON
0 = OFF
1 0 0 1 DON'T DON'T DON'T DON'T LMP 1
45 CARE CARE CARE CARE 1 = FLSH
FPM 0 = STDY
1 0 1 0 DON'T DON'T DON'T DON'T LMP 1
60 CARE CARE CARE CARE 1 = FLSH
FPM 0 = STDY
1 1 DON'T DON'T DON'T DON'T DON'T DON'T LMP 1
80 CARE CARE CARE CARE CARE CARE 1 = FLSH
FPM 0 = STDY
1 0 0 0 DON'T DON'T DON'T DON'T LMP 1
80 FPM 80 FPM 80 FPM CARE CARE CARE CARE 1 = FLSH
DEFLT DEFLT DEFLT 0 = STDY
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
2.0 Standard Objects.
2.1 Identity Object (Class ID = 1).
There is a single instance of the identity object for the Triliptical DeviceNet Stackable Beacon. No class attributes
are supported. All of the instance attributes are contained in rom and are gettable but not settable. The table
below shows the values.
ATTRIBUTE ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get Vendor Code Uint 0x201 (513)
2 Get Product Type Uint 0x0000
3 Get Product Code Uint 0x0001
4 Get Revision Word 01.01
5 Get Status UDINT 0x0000
6 Get Serial # Uint UNIQUE SERIAL #
7 Get Product Name STRUCT 102
Identity Object Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
Reset 0x05 0, 1
2.2 Message Router Object (Class ID = 2).
There is no externally visible interface to the Message Router Object.
2.3 DeviceNet Object (Class ID = 3).
There is a single instance of the DeviceNet Object for the Triliptical DeviceNet Stackable Beacon.
DeviceNet Object Class Attributes:
ATTRIBUTE ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get Revision Uint 0x0002
P/N 3100125 ISSUE 3 PAGE 6
DeviceNet Object Class Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
DeviceNet Object Instance Attributes:
ATTRIBUTE ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get Macid Uint Dipswitch
2 Get Baud rate USINT Dipswitch
3 Get BOI BOOL 0x01 Auto-Reset 0x00 Hold
4 Get/Set Bus off counter USINT 0x00 (Set) Value (Get)
5 Get Allocation info STRUCT Allocate Serv
DeviceNet Object Instance Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
Set Attribute Single 0x10 Attribute ID
Allocate 0x4B Allocation Choice Master MACID
Release 0x4C Release Choice
2.4 Assembly Object (Class ID = 4)
There is a single instance of the Assembly Object for the Triliptical DeviceNet Stackable Beacon. No class
attributes or services are supported for the Assembly Class.
Assembly Object Instance Attributes:
ATTR ACCESS DATA
ID RULES NAME TYPE VALUE
3 Get/Set Data Struct See Sect 1.5
Assembly Object Instance Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
Set Attribute Single 0x10 Attribute ID
P/N 3100125 ISSUE 3PAGE 7
2.5 Connection Object (Class ID = 5).
There are two instances of the Connection object in the 102TBS-DN. Instance #1 is assigned to the Explicit
Messaging Connection. Instance #2 is assigned to the Polled I/O Connection. The following table shows the
attributes and the pre-defined values where applicable. No class attributes are supported.
Connection Object - Explicit Message Connection (Instance #1)
ATTR ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get State USINT 0x03
2 Get Instance type USINT 0x00
3 Get Xport class trigger USINT 0x83
4 Get Produced CONN. ID UINT 0x5FB for MACID 63
5 Get Consumed CONN. ID UINT 0x5FC for MACID 63
6 Get Initial COMM. Characteristics UINT 0x21
7 Get Produced CONN. size UINT 0x0007
8 Get Consumed CONN. size UINT 0x0007
9 Get/Set Expected packet rate UINT Application dependent
10 N/A N/A N/A Not used
11 N/A N/A N/A Not used
12 Get/Set Watchdog timeout action USINT 0x01 Default
13 Get Produced path length UINT 0x0000
14 Get Produced path ARRAY OF USINT <NULL>
15 Get Consumed path length UINT 0x0000
16 Get Consumed path ARRAY of USINT <NULL>
Connection Object - Poll I/O Message Connection (Instance #2)
ATTR ACCESS DATA
ID RULES NAME TYPE VALUE
1 Get State USINT State Dependent
2 Get Instance type USINT 0x01
3 Get Xport class trigger USINT 0x82
4 Get Produced CONN. ID UINT 0x3FF for MACID 63
5 Get Consumed CONN. ID UINT 0x5FD for MACID 63
6 Get Initial COMM. Characteristics UINT 0x01
7 Get/Set Produced CONN. size UINT 0x03
8 Get/Set Consumed CONN. size UINT 0x03
9 Get/Set Expected packet rate UINT Application dependent
10 N/A N/A N/A Not used
11 N/A N/A N/A Not used
12 Get/Set Watchdog timeout action USINT (0x00 Default) 0, 1, 2
13 Get Produced path length UINT 0x0006
14 Get Produced path ARRAY OF USINT 20.04.24.01.30.03
15 Get Consumed path length UINT 0x0006
16 Get Consumed path ARRAY of USINT 20.04.24.01.30.03
Connection Object Services:
SERVICE SERVICE CODE PARAMETERS
Get Attribute Single 0x0E Attribute ID
Set Attribute Single 0x10 Attribute ID
P/N 3100125 ISSUE 3 PAGE 8
InstallationInstallation
Installation
InstallationInstallation
WARNING
To prevent electrical shock, do not connect power
until instructed to do so.
Safety Message to Installers, Users, and Maintenance Personnel
The Triliptical DeviceNet Status Indicator must be installed in accordance with the latest edition of the National
Electrical Code and/or other applicable local regulations, by a trained and qualified electrician. The selection of the
mounting location, its controls and the routing of the wiring is to be accomplished under the direction of the
facilities engineer.
WARNING
To prevent electrical shock, do not connect to the
system when power is on.
NOTE: For NEMA Type 4X applications, it is recommended that the unit be conduit mounted vertically facing up.
1. Mount the Triliptical DeviceNet Stackable Beacon Base (102TBS-DN) by installing on 3/4" (19 mm) conduit (not
supplied). Pull field wiring (if required) and DeviceNet wiring through the conduit entrance hole.
2. Assemble the stackable beacon lighting system (Figure 1).
a. Pull the captive key in the lens module into the "out" position.
b. Place the first lens module on top of the base.
c. Push in the captive key to secure the lens module.
d. Insert the appropriate light source into board grooves at bottom of lens module, ensuring that the four
prongs on the PC board are aligned with the plug located in the back of the lens assembly.
WARNING
Ensure the magnifier ring on the lens cover and the
magnifier ring on the lens module are aligned
(Figure 1).
NOTE: When using LED light sources, ensure that the color of the LED light source and the lens assembly match.
e. Place the lens assembly cover on the front of the lens module and secure using two captive screws.
f. Repeat steps a through e for any remaining modules (up to 5).
g. Once the last module has been assembled, place the cap on top and secure the cap with the captive screw.
Network & Field ConnectionsNetwork & Field Connections
Network & Field Connections
Network & Field ConnectionsNetwork & Field Connections
CAUTION
Observe precautions for handling electrostatic
sensitive devices while handling printed circuit
boards.
P/N 3100125 ISSUE 3PAGE 9
WARNING
To avoid electrical shock hazards, do not connect
wires when power is applied.
1. Make DeviceNet connections to the 5 position female terminal block plug as indicated in the below table. The 5
DeviceNet bus terminals are silkscreened near the terminals on the printed circuit board. Make connections as
follows:
Pin 5 V + Red Wire
Pin 4 CAN_H White Wire
Pin 3 Drain Bare Wire
Pin 2 CAN_L Blue Wire
Pin 1 V - Black Wire
2. A two (2) position screw terminal is provided to connect either separate 24V DC or 120V AC (depending on version
-G1 (24V DC) or -N5 (120V AC) light source operating power to the Triliptical DeviceNet Stackable Beacon. The
terminals for the 24V DC unit are labeled as "+" and "-". Polarity is not important for the 120V AC unit. Make
connections as follows:
Pin 1 (+) + 24V DC Red Wire
Pin 2 (-) - 24V DC Black Wire
or
Pin 1 120V AC Black Wire
Pin 2 120V AC White Wire
3. For the 24V DC unit only, if it is desired to power the light sources from DeviceNet power, jumper (V+) and (V-) on
the 5 position DeviceNet terminal block to (+) and (-) respectively on the 2 position screw terminal.
Set DIPSWITCH S1 for the BAUD RATE and MAC ID required as follows:
Note the legend on the dipswitch for the sense of 0 and 1 (0 = OFF and 1 = ON)
SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
BAUD RATE - 125 Kbps 0 0
BAUD RATE - 250 Kbps 0 1
BAUD RATE - 500 Kbps 1 0
BAUD RATE - 125 Kbps 1 1
MAC ID 0 000000
MAC ID 1 000001
MAC ID 2 000010
MAC ID 3 000011
MAC ID 4 000100
MAC ID 5 000101
MAC ID 6 000110
MAC ID 7 000111
MAC ID 8 001000
MAC ID 9 001001
MAC ID 10 (0x0A) 001010
MAC ID 11 (0x0B) 001011
MAC ID 12 (0x0C) 001100
MAC ID 13 (0x0D) 001101
MAC ID 14 (0x0E) 001110
MAC ID 15 (0x0F) 001111
MAC ID 16 (0x10) 010000
P/N 3100125 ISSUE 3 PAGE 10
SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
MAC ID 17 (0x11) 010001
MAC ID 18 (0x12) 010010
MAC ID 19 (0x13) 010011
MAC ID 20 (0x14) 010100
MAC ID 21 (0x15) 010101
MAC ID 22 (0x16) 010110
MAC ID 23 (0x17) 010111
MAC ID 24 (0x18) 011000
MAC ID 25 (0x19) 011001
MAC ID 26 (0x1A) 011010
MAC ID 27 (0x1B) 011011
MAC ID 28 (0x1C) 011100
MAC ID 29 (0x1D) 011101
MAC ID 30 (0x1E) 011110
MAC ID 31 (0x1F) 011111
MAC ID 32 (0x20) 100000
MAC ID 33 (0x21) 100001
MAC ID 34 (0x22) 100010
MAC ID 35 (0x23) 100011
MAC ID 36 (0x24) 100100
MAC ID 37 (0x25) 100101
MAC ID 38 (0x26) 100110
MAC ID 39 (0x27) 100111
MAC ID 40 (0x28) 101000
MAC ID 41 (0x29) 101001
MAC ID 42 (0x2A) 101010
MAC ID 43 (0x2B) 101011
MAC ID 44 (0x2C) 101100
MAC ID 45 (0x2D) 101101
MAC ID 46 (0x2E) 101110
MAC ID 47 (0x2F) 101111
MAC ID 48 (0x30) 110000
MAC ID 49 (0x31) 110001
MAC ID 50 (0x32) 110010
MAC ID 51 (0x33) 110011
MAC ID 52 (0x34) 110100
MAC ID 53 (0x35) 110101
MAC ID 54 (0x36) 110110
MAC ID 55 (0x37) 110111
MAC ID 56 (0x38) 111000
MAC ID 57 (0x39) 111001
MAC ID 58 (0x3A) 111010
MAC ID 59 (0x3B) 111011
MAC ID 60 (0x3C) 111100
MAC ID 61 (0x3D) 111101
MAC ID 62 (0x3E) 111110
MAC ID 63 (0x3F) 111111
P/N 3100125 ISSUE 3PAGE 11
4. If using the optional Cat No. 102SIGMT-DN multi-tone module, connect the five position female connector on the
tone module to the upper set of male pins in the Triliptical DeviceNet Stackable Beacon Base. Set the selected tone
in accordance with the table below. Set the third Byte (Data Byte 2) in accordance with the table below in order to
access the required tone. "X" is the "Don't Care" State.
Switch Settings*
Tone Bit3 Bit2 Bit1 Bit0
Tone Off 0 X X X
Stutter Beep 1 0 0 0
Continuous 1 0 0 1
3 Pulse Horn 1 0 1 0
Rapid Siren 1 0 1 1
Hi/Lo 1 1 0 0
Fast Whoop 1 1 0 1
Yeow 1 1 1 0
Beep 1 1 1 1
*1 is ON. 0 is OFF.
5. Install the 102TBS-* front cover or the optional 102SIGMT-DN-G1 multi-tone module by tightening the two captive
front screws.
6. Test the Triliptical DeviceNet Stackable Beacon to ensure that it operates as intended.
To test the device for functionality the unit must be connected to a DeviceNet network via the five (5) pin
connector. Turn on the network power supply and local power (if so configured) for the lamps. All lamps will
flash instantaneously (some lamps may not be visible) as the unit checks for proper lamp operation. The value of
the data byte in the master poll will be displayed on the lamps until it is changed by subsequent poll command.
The pre-defined poll connection has consume size of three (3) bytes, and a produce size of three (3) bytes. When
all the connections are released the lamps will display the last poll command data before release of the connection.
7. The following is an Output Data Byte example
Byte 2
XXXX 1 001
Set
Tone
On
Set
Tone
Value 1
8. The following is an Input Data Byte example:
Byte 2
XXXX 1001
Sounder is
ON with
Tone
Value 1
Byte 1
000 00001
Set
Flash
Rate =
8OFPM
Set
Lamp 1
to
Flashing
Byte 1
XXX 00011
Lamp 2
was ON
before last poll
command
Byte 0
XXX 11111
Byte 0
0XX 00001
Local
Power
is OK
Lamp 1 is
burned out
or missing
Set
Five
Lamps
ON
P/N 3100125 ISSUE 3 PAGE 12
MaintenanceMaintenance
Maintenance
MaintenanceMaintenance
WARNING
To prevent electrical shock, disconnect network
and local power to the unit. Wait 5 minutes for
stored energy in strobe modules to dissipate before
working on unit.
Light Source Replacement
1. Loosen captive screws and remove cover of affected lens module.
2. Remove the light source assembly from the lens module.
3. Install new light source assembly ensuring that the four prongs on the PC board are aligned with the plug
located in the back of the lens module.
WARNING
Ensure the magnifier ring on the lens cover and the
magnifier ring on the lens module are aligned
(Figure 1).
4. Replace lens cover and secure using two captive screws.
Cleaning
The lens surfaces should be periodically dusted and cleaned with a dry soft clean cloth to maintain optimum light
visibility. If necessary, the outside of the lens may be cleaned with water and a mild detergent on a well rung out soft
clean cloth.
P/N 3100125 ISSUE 3PAGE 13
15"
(381mm)
1/2"
(13mm)
3 5/8"
(92mm)
3 5/8"
(92mm)
Cap (supplied with base)
Magnifier
Ring
Board
Groove
Light Source
Assembly
Captive Key
Signal Base
(Cat. No. 10STBS shown)
Lens Module
Cover
(2) Captive
Screws
3"
(76mm)
Figure 1. Assembling the Stackable Status Indicator
P/N 3100125 ISSUE 3 PAGE 14
Table 1. Triliptical DeviceNet Status Indicator Specifications
Electrical Manufacturers Replacement Lamp Life (hours)
Catalog No. Ratings Lamp Ratings Lamp Calculated#Projected
##
Base Units
102TBS-DN-G1 24V DC, 1.75A
102TBS-DN-N5 120V AC, 0.60A
+
+
N/A N/A N/A N/A
Optional Horn Assembly
102SIGMT-DN-G1 24V DC, 0.05A N/A N/A N/A N/A
Lens Modules
102LM-* N/A N/A N/A N/A N/A
Light Sources
102LS-SINH-G1 24V DC, 0.32A 9 Watts 50LMP-9WH 12,000 --
or Ind. Trade 303*** 3,000 -102LS-SINH-N5 120V AC, 0.11A 12 Watts 50LMP-12WH 20,000 - 102LS-SIN-G1 24V DC, 0.32A 10 Watts 50LMP-10W or 10,000 - -
Ind. Trade 303 3,000 - 102LS-SIN-N5 120V AC, 0.08A 10 Watts 50LMP-10W 2,500 -102LS-ST-G1 24V DC, 0.30A 3 Joule Strobe -- 3,000
102LS-ST-N5 120V AC, 0.12A 3 Joule Strobe - - 3,000
###
###
--
--
102LS-SLEDA-G1** 24V DC, 0.062A -- N/A 100,000 -102LS-SLEDB-G1**
102LS-SLEDG-G1**
102LS-SLEDR-G1**
102LS-SLEDW-G1**
102LS-SLEDA-N5** 120V AC, 0.022A -- N/A 100,000 -102LS-SLEDB-N5**
102LS-SLEDG-N5**
102LS-SLEDR-N5**
102LS-SLEDW-N5**
+
Currents shown are for a stackable indicator with 5 light modules.
*Signifies lens module color (A - amber, B - blue, C - clear, G - green, R - red)
**Signifies lens and LED module color (A - amber, B - blue, G - green, R - red) NOTE: LED light sources must be used with
the corresponding color lens module (e.g., a blue LED light source, 102LS-SLEDB-G1, must be used with a blue lens,
102LM-B).
***A non-halogen lamp, as listed, may be used in place of the halogen lamp.
#
At nominal operating voltage.
##
Projected lamp life based on manufacturer's calculated lamp life @ 65 fpm and 50% duty cycle.
###
Strobe tube life @ operating power to 75% efficiency.
Table 2. Pertinent DeviceNet Specifications
Operating DeviceNet Bus Current 0.12A
Current Draw supplied by separate power supply (per Light Module) DC: 0.062 to 0.320A
AC: 0.022 to 0.120A
In-Rush Current supplied by separate power supply (per Light Module) DC: 1.2A
AC: 0.5A
Flash Rate (selectable via second data byte of POLL command) 45, 60 or 80 fpm
Operating Temperature 32F to 158F (0C to 70C)
P/N 3100125 ISSUE 3PAGE 15
Contacting Edwards:
Phone: (203) 699-3000
E-Mail: techsupport@edwards-signals.com
customerservice@edwards-signals.com
Website: http://www.edwards-signals.com
P/N 3100125 ISSUE 3 PAGE 16
Loading...
