User Manual
HEAD BANG
83131/83132/83133
Instructions:
① Power key/ telephone answering key
② Touch to increase the volume/ to pick previous song
③ Touch to reduce the volume/ to pick next song
④ Mic hole
⑤ USB charging port
⑥ AUX IN port
Features:
1. Bluetooth Version: 2.1+ EDR
2. Support Bluetooth phone calls, Bluetooth Music and re-dial last number
3. Finger Touch control design
4. Support PC voice communication( With special Mic Cable)
5. Support Computer, MP3, CD …AUX in
6. Built-in lithium battery, with Micro USB charging port
7. Smart Electricity-saving (after 3 minutes no connection or 55 seconds no
paring, it will turn off automatically to save the electricity.)
Specifications:
1. Wireless transmission distance: CLASS II
2. Battery capacity: 300MAH
3. Frequency range: 20-20KHZ
4. Sensitivity: 95DB
5. Speaker impedance: 32 ohm
6. Speaker Size: 32MM
7. Charging time: 2H
8. Voice Communication working time: 8-10H
9. Bluetooth Music Playing time: 8-10H
(Based on two-thirds of the maxium volume)
Operations:
1. Bluetooth Functions
Bluetooth pairing:
1. For first time paring, press and hold key for seconds to pairing mode,
the light will indicate in BLUE and RED light flash in turn. When the pairing
is successful, your device will show the connected Bluetooth icon (pairing
name) “ED_Head Bang.”
2. After successful pairing, press key to play music sourcing from your
device. Press again to pause. When
there is phone call coming, press
key to answer the call directly, Press
and hold key for 3 seconds to
change to mobile phone private
answering. Press and hold on 3
seconds again back to Bluetooth
answering.
3. Double click key to call the Number which you made last phone call.
Bluetooth Music:
1. Click key for once to play the music
sourcing from your mobiles. Click again to
pause.
2. Finger touch area is divided into two parts
by “.”.Quick click the volume to increase or
reduce area to realize songs pick the next
or previous.
3.
Press and hold the volume control area,
you can easily to increase or reduce the
volume continuously. When it reaches the maximum or minimum, the
device will indicate with a tick voice.
Click non-continuously to increase or reduce the volume by steps.
Bluetooth phone calls:
1. When there is a phone call incoming, press key to answer the call
directly, press and hold on key for 3 seconds to change to your mobile
phone private answering, press and hold on once again to back to
Bluetooth answering.
2. Double-click key to call the Number which you made last phone call.
LINE IN function:
When you want to listen to the music
sourcing from other audio devices, connect
the Headphone with them, with the AUX in
Cable inside the AUX in port as the picture
shows.
On this model, the Bluetooth will turn off
automatically, turn it on is not allowed.
Charging function:
1. Connect the Charging cable with a adapter or (Computer’s USB port), while
the other end insert into the USB charging port as pictures shows. This
device will indicate in RED light keeping bright on the right when charging.
When it is full, the RED light will turn off automatically.
Accessories:
AUX IN cable (length: 1.2M)
Charging Cable (length: 0.65M)
Measurement:
