10/100/1000BaseT to 1000BaseSX/LX
Media Converter Series
User’s Manual
FCC Warning
This device has been tested and found to comply with limits for a Class B digital device, pursuant to Part 2 and 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates and radiates radio frequency energy and, if not installed and used in accordance with the user’s manual, it may cause interference in which case users will be required to correct interference at their own expenses.
CE Warning
This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.
Introduction
This Gigabit Ethernet Media Converter Series is designed to bridge a 10/100/1000BaseT(X) signal to
a 1000BaseSX/LX signal. It’s used to extend the
distance connection between two Gigabit Ethernet twisted-pair devices via fiber cables transparently without any performance degradation.
This Media Converter Series is based on the switching hub design. It supports Auto-Negotiation and Flow Control function on the twisted-pair port. Besides, it can provide different types of fiber connectors, such as SC, LC and SFP for multi-mode or single-mode cables.
Package Contents
Before you start to install this converter, please verify your package that contains the following items:
One Media Converter One Power Adapter One User’s Manual
3
Key Features
Compliant with IEEE 802.3 10BaseT, IEEE
802.3u,100BaseTX, IEEE 802.3ab 1000BaseT and IEEE 802.3z 1000BaseSX/LX Standards
1x 10/100/1000BaseT(X) Ethernet TP Port and
1x 1000BaseSX/LX Gigabit Ethernet Fiber Port or 1x Gigabit SFP Open Slot Fiber port
One SFP open slot can support either
Multi-Mode or Single- Mode SFP Module
TP Port can support Half/Full-Duplex
Auto-MDI/MDI-X and Auto-Negotiation
Adjustable DIP Switch for LLF/LFP function
(Link Fault Pass-through)
Multiple Optical Fiber Connectors
Connector Type: SC, ST , LC or SFP
Distance: MM (220/550M) , SM (10km, 20km…) Options for 19” Converter Chassis for up to
16-slot with redundant power supply for additional expansion use
Installation
I. DC Input & External Power Adapter
The External Power Adapter specification:
AC Input range from 90VAC to 260VAC AC frequency range from 47Hz to 63Hz, TUV,
CE, UL Safety
Power Adapter DC Output is +5VDC 1.4A The device DC Input is +5VDC 1.4A.
II. TP port (RJ-45)
The device TP port support Auto-MDIX,
Auto-Negotiation and Flow Control functions. The cable length up to 100 meters is for Cat5, Cat5e or Cat6 shielded/unshielded twisted-pair cable.
III. The Fiber Port
There’re different types of fiber connectors, such as SC, LC and SFP for multi-mode or single-mode fiber cables.
IV. DIP Switch Setting: (LLF/LFP Function)
V. Link Loss Forwarding (LLF) / Link Fault Pass-through (LFP) Function
When LLF/LFP function is enabled, no matter the device of TP port or fiber port is loose, linking status on TP or fiber port will inform their connected device. If the TP port is unplugged, the converter stops transmitting over the fiber port, causing the remote fiber node link to fail. The LED will show link failure on both the TP and fiber ports. If the fiber link fails, the converter causes the remote TP node link to fail. The LED also shows the link failure on both the TP and fiber ports. The figures below show normal status when the link succeeds and the error status on TP cable (A / D) or fiber cable (B/C) fails to
connect.
Note :
Warning :
When the setting of the DIP switch is
changed, the power has to be turned off and the new setting will be effective after turned on again.
LED
Status
Description
Power
On
Power on
LINK/ACT On
Fiber Link
Flashing
Data active
10/100M/ACT On
Link on 10/100M
Flashing
Data active
1000M/ACT On
Link on 1000M
Flashing
Data active
LEDs LED Indicators of Fast Ethernet Media Converter
Connections Multi-Mode Fiber (MMF)
Single-Mode Fiber (SMF)
Standards
IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX IEEE 802.3ab 1000BaseT IEEE 802.3z 1000BaseSX/LX IEEE 802.3x Flow Control
Features
Number of Port: 1 10/100/1000BaseT with
RJ-45 Connector 1 Gigabit Fiber port with SC,
ST, LC or SFP Open Slot
Data Transfer Rate
2000Mbps/Full-Duplex
Transmission Media
TP: 1000BaseT Cat. 5, 5E, 6 UTP/STP, up to 100 m
1000BaseSX: (220/550M)
50/125μm Multi Mode Fiber
optic cable, up to 220 m
62.5/125μm Multi Mode Fiber
optic cable, up to 550 m
1000BaseLX: (10km, 20km..)
9/125μm Single Mode Fiber
optic cable
Technical Specifications
Led Indicators
(TX):10/100M/ACT,1000M/ACT (FX): Link/ACT Per Unit: Power
Power Requirement
DC 5V
Power Consumption
5 Watts (Max)
Dimensions
102 × 75 × 23 mm (L x W x H)
Weight
210 g
Operating Temperature
0 to 45
Storage Temperature
-20 to 90
Humidity
10 to 90% RH (non-condensing)
Certifications
FCC, CE
