Edimax Technology ES-3316P User Manual

ES-3305P / ES-3308P / ES-3316P

Quick Installation Guide

09-2012 / v1.0

1

COPYRIGHT

Copyright  Edimax Technology Co., Ltd. all rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission from Edimax Technology Co.,
Ltd.

Edimax Technology Co., Ltd. makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability, or fitness for any particular purpose.
Edimax Technology Co., Ltd. reserves the right to revise this publication and to
make changes from time to time in the contents hereof without the obligation to
notify any person of such revision or changes.

The product you have purchased and the setup screen may appear slightly
different from those shown in this QIG. The specification is subject to change
without notice. Please visit our web site www.edimax.com for the update. All
brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.

Edimax Technology Co., Ltd.

Add: No. 3, Wu‐Chuan 3rd Rd., Wu‐Ku Industrial Park, New Taipei City, Taiwan
Tel: +886‐2‐77396888

Email: [e-mail]

2

PRODUCT INTRODUCTION

PWR LED

LNK/ACT LEDs 1 - 5

LNK/ACT LEDs 1 - 8

PWR LED

PWR LED

LNK/ACT LEDs 1 - 16

Model:

ES-3305P: 5 Port Fast Ethernet Desktop Switch
ES-3308P: 8 Port Fast Ethernet Desktop Switch
ES-3316P: 16 Port Fast Ethernet Desktop Switch

Package Contents

Before you start using this switch, please check if there is anything missing in the
package, and contact your dealer to claim the missing item(s):

 Fast Ethernet Desktop switch
 User manual
 Power Adapter

Front Panel

ES-3305P

ES-3308P

ES-3316P

3
