Edimax Technology AR-6024 User Manual

ADSL Broadband Router

AR-6024

User’s Manual

Table of Contents

Specification................................................................................................................2

Package Contents.......................................................................................................5

Hardware Connecting.................................................................................................. 6

LED Indicators............................................................................................................. 7

General Setting...........................................................................................................8

One Page Setup--------------------------------------------------------------------------------- 12 Status ---------------------------------------------------------------------------------------------- 14

Router.........................................................................................................14

ADSL ..........................................................................................................16

PPP............................................................................................................. 17

Advanced Setting......................................................................................................22

ADMINISTRATION ----------------------------------------------------------------------------- 23

WAN............................................................................................................ 23

LAN............................................................................................................. 29

DNS ............................................................................................................ 31

NAT.............................................................................................................32

Port Forwarding .......................................................................................... 34

ADSL Configuration.................................................................................... 35

RIP Configuration........................................................................................ 36

Firewall ....................................................................................................... 37

Service Filtering..........................................................................................41

Diagnostic Test............................................................................................ 49

Router Table................................................................................................ 51

MAC Filtering..............................................................................................52

Security-------------------------------------------------------------------------------------------- 53

Admin Password.........................................................................................53

User Password............................................................................................ 54

Misc Configuration......................................................................................55

System Log................................................................................................. 57

Code Update...............................................................................................58

Status ---------------------------------------------------------------------------------------------- 59

Router.........................................................................................................59

ADSL ..........................................................................................................61

WAN Status.................................................................................................62

ATM Status..................................................................................................63

TCP connections......................................................................................... 64

Learned MAC Table.................................................................................... 65

PPP Status.................................................................................................. 66

Save Settings/Reboot................................................................................. 67

Appendix...................................................................................................................68

Specification

4-Port Ethernet ADSL Router

Features

 ADSL Compliance

ANSI T1.413 i2 ITU G.992.1 (G.dmt) Annex A, B ITU G.992.2 (G.lite) Maximum downstream rate of 8Mbps Maximum upstream rate of 1Mbps Dying Gasp (optional)

 ATM Protocols and Encapsulations

PPP over ATM (RFC 2364) PPP over Ethernet (RFC 2516) Bridged/Routed Ethernet over ATM (RFC 1483) Classical IP over ATM (RFC 1577) ATM Forum UNI 3.1/4.0 PVC 10 PVCs (simultaneous and encapsulation independent) VPI/VCI range 0-255, 0-65536 Encapsulation hunting of up to 8 pre-defined VPI/VCI & encapsulation sets ATM AAL5 (Adaption Layer type 5) UBR & CBR OAM F4/F5

 Bridging Functionality

IEEE 802.1D (self learning transparent bridge) 256 MAC Addresses support PPP Half Bridge - No 3rd party PPPoE client software required

 Routing Functionality

Static IP routing (configurable route table) RIPv2 (backward compatible with RIPv1)

DHCP server/client/relay agent PPP auto reconnect and configurable timeouts PPP auto reconnect on WAN access PPP Auto, PAP, and CHAP 128 character support for PPPx username/passwords DNS proxy NAT, NAPT & Dynamic NAPT ALG support (FTP, SMTP/POP3, ICMP, NNTP, RTSP, IRC, CuSeeMe, Telnet, Messenger, EPIC games, id games, Sierra studios games) Wild Card DMZ Virtual server (Port mapping) VPN pass through (IPSec - ESP Tunnel mode, L2TP, PPTP) Bridge filtering ICMP IGMP MAC Address Spoofing Auto VPI/VCI PPPoE/PPPoA detection Multiple PPP sessions per PVC

 Management

HTTP client and server Password protection (2 levels) Configurable Web pages FTP server and client (for network upgrade) Local firmware upgrade via Web configuration pages Remote firmware upgrade via FTP client Restore to Factory defaults via Web or hardware reset 7 layer diagnostics with links to help pages System logging Inner pair / Outer pair / Auto-detection of RJ-11

 Ethernet Features

IEEE 802.3/802.3u auto-negotiation compliant Auto sense 10/100 Full or Half duplex mode Half duplex - back pressure flow control Full duplex - IEEE 802.3x flow control Crossover Detection and Auto Correction

 Hardware

LAN: 4-Port 10/100Base-T (RJ-45) ADSL: One Port (RJ-11) Power: 9VAC 800mA LED indicators: Power, Ready (Status), ADSL, LAN＊4 Reset button

 Certification: FCC Part 15/Part 68, CE, LVD

Application Diagram

Internet

Package Contents

 ADSL Router  CD-ROM containing Manual  Ethernet Cable (CAT5 UTP Straight-Through)  ADSL Cable (Standard telephone cable)  USB Cable (Optional)  Power Adapter  Quick Installation Guide hardcopy

Hardware Connecting

4 Port Ethernet ADSL Route

Splitter (optional and changes depending on country specification)

RJ-45 Ethernet port connect Ethernet cable here

RJ-11 ADSL port connect

ADSL cable here

Factory Reset

Power Adapter (9VAC/800mA)

Power cord connect here

LED Indicators

Label Meaning Status Indicates PWR Power On Power is on

Off Power is off RDY WAN Link Flashing Link being attempted by router. On Link established Off No link LAN 1/ LAN 2/ LAN 3/ LAN 4 On

Off

LAN Link Flashing

4 Port Ethernet ADSL Router

Flashes when data is being sent or received on the LAN connection.

Indicates a link to your LAN or Network card is active. Indicates no link to LAN

General Setting

You can use the RJ 45 cable or the USB cable connect to the ADSL Router. Please see the connecting procedures as below:

Move your cursor as following sequence Start \ Settings \ Control

Panel and click Control Panel. Then double-click on the Network Connections

In the LAN or High-Speed Internet window, right-click on icon corresponding to your network interface card (NIC) and select Properties.(This icon may be labeled Local Area Connection).

In the General Tab of the Local Area Connection Properties menu.

Highlight Internet Protocol (TCP/IP) under “This connection uses the following items.” by click on it once. Click on the Properties button.

Select Obtain an IP address automatically: by clicking once in the

circle. Click OK button to confirm and save your changes, and the close the Control Panel.

Release IP & Renew IP, then Check Default Gateway: 10.0.0.2

Launch your PC web browser and enter the URL: 10.0.0.2

In the User name/Password prompt, please type in admin/epicrouter

as default.

Now you can start browsing the web through the ADSL device.

One Page Setup

When working with wide area connections, the first thing you must do is to have the handle of the connection. Once you have the handle for a Connection you must define the PVC and protocol settings for it.

LAN IP Address & Subnet Mask: The default is 10.0.0.2and 255.255.255.0 you can

change it to another private IP address, such as 211.22.10.191 and 255.0.0.0. For most configurations it is recommended to leave it as default.

Service Name: Enter the name of your ISP. This information is for identification

purposes only.

Username: Enter the username provided by your ISP.

Password: Enter the password provided by your ISP. Disconnect Timeout: Disconnect Timeout means the router will disconnect after

being idle for a preset amount of time.

WAN Type: Select type from the list.

VC Settings

VPI: If instructed to change this, type in the VPI value for the initial connection (using

PVC 0). Default = 8.

VCI: If instructed to change this, type in the VCI value for the initial connection (using

PVC 0). Default = 35.

Static IP Address: Enter the IP address provided by your ISP. such as

192.168.241.101.

Subnet Mask: Set your Subnet Mask such as 255.255.255.0

BRIDGE

Mode: Select Enable or Disable from the list. Note: Click the Submit button to save the settings in temporary memory. If you make

changes the configurations.

Status

Router

The Home page shows the Firmware Version and WAN and LAN interface status.

Firmware Version: This field displays the Firmware Version number.

WAN: These fields display the IP Address, Subnet Mask, MAC Address for WAN

interface.

LAN: These fields display the IP Address, Subnet Mask, MAC Address for LAN

interface.

Number of Ethernet devices connected to the DHCP server: This field displays the

number of DHCP clients connected to the ADSL Router. It also shows the IP address and MAC address of the attached DHCP clients.

ADSL

The ADSL Status page shows the ADSL physical layer status.

Showtime Firmware Version: This field displays the ADSL data pump firmware

version number.

Line State: This field displays the ADSL connection process and status. Modulation: This field displays the ADSL modulation status for G.dmt or T1.413. Annex Mode: This field displays the ADSL Annex modes for Annex A or Annex B. Startup Attempts: This field displays the ADSL connection attempts after loss of

showtime.

Max Tx Power: This field displays the transmit output power level of the CPE. Co Vendor: This field displays the Central Office DSLAM vendor name. If available. Elaspsed Time: This field displays the time of the modem has been in operation.

PPP

The PPP Status page shows the status of PPP for each PPP interface. See PPP.

These fields display the following information on each PPP interface:

 Connection Name (user defined)  Interface (PVC)  Mode (PPPoE or PPPoA)  Status (Connected or Not Connected)  Packets Sent  Packets Received  Bytes Sent  Byte Received

Connect and Disconnect: Each PPP session can be individually controlled, simply

enter the desired connection number into the “Connection #” field and select either connect or disconnect from the drop down menu and click on the “Execute” button.

WAN Configuration: The WAN configuration page allows the user to set the

configuration WAN/ADSL ports.

Per VC Settings

Virtual Circuit: Selection Enable or Disable. VPI: If instructed to change this, type in the VPI value for the initial connection (using

PVC 0). Default = 0.

VCI: If instructed to change this, type in the VCI value for the initial connection (using

PVC 0). Default = 0

MAC Spoofing: MAC Spoofing is developed to solve the scenario when the ISP only

recognizes one MAC address. Copy the ISP-recognized MAC address here.

ATM

Service Category: UBR and CBR are supported from the ATM.

Bandwidth: Bandwidth setting takes effect only when the CBR is selected. The

maximum available bandwidth is from the upstream data rate of ADSL status page.

ENCAPSULATION: Selection follow as Table-1 Configuration BRIDGE: Enabling bridge mode will place the unit into Transparent bridge mode (like

a Ethernet ADSL modem) to use this mode you should also set your WAN type to a Bridging option (e.g RFC1482 Bridge using LLC).

IGMP: IGMP relay/proxy specification and environment:

Support IGMP proxy/relay function for ADSL modem, based on the following requirement and case:

On CO side, there must be at least one IGMP querier (router) present. IGMP querier will send IGMP query packet. The ADSL modem is responsible to relay these IGMP query to Ethernet.

End-user multicast application device send IGMP report while receiving IGMP query or being activated by user, the ADSL modem should be responsible to proxy (that is, change source IP to ADSL modem’s WAN IP) the IGMP report to ADSL WAN side, include all PVCs. The same case is for IGMP leave packet.

Not necessary to relay multicast routing between two ADSL PVCs or two interfaces in LAN side.

Special purpose multicast packet (such as RIP 2 packet) should run without interference.

Table-1 Configuration

WAN Configuration IP address N/A Automatically

Subnet Mask N/A Automatically

WAN Type 1483 Bridged

Bridge Enabled Disabled Disabled Disabled PPP Service N/A Provided by ISP N/A N/A

Bridge Mode Router Mode

(PPPoA/PPPoE)

assigned by ISP

PPPoA IP LLC, 1483 Bridged IP VC-Mux

LLC/VC-Mux,

PPPoE

LLC/VC-Mux

Router Mode (Dynamic IP) Automatically assigned by ISP Automatically assigned by ISP 1483 Bridged/Routed IP LLC, 1483 Bridged/Routed VC-Mux, Classical IP over ATM

Router Mode (Static IP) Provided by ISP

Provided by ISP

1483 Bridged/Routed IP LLC, 1483 Bridged/Routed VC-Mux, Classical IP over ATM

PPP User name PPP Password DHCP Client enable

N/A Provided by ISP N/A N/A

Unchecked Unchecked Checked Unchecked

Table-2

Rx Entity Packet Class TTL Action Notes

ADSL IGMP query 1 Relay to Ethernet IGMP report 1 Ignore IGMP leave 1 Ignore General Multicast IP - Relay it to Ethernet. Ethernet IGMP query 1 Ignore IGMP report 1 Relay to all ADSL PVC IGMP leave 1 Relay to all ADSL PVC General Multicast IP - Ignore

PPP: The current release supports multiple PPP sessions per PVC. The PPP

configuration in the WAN configuration page is for the first PPP session for each PVC. The predefined PPP Account Name (Account ID) is “Simple PPP Account 0” for PVC0 and predefined PPP Connection Name is “Simple PPP Session 0” for PVC0. For the other PVC X, the predefined account name and connection name will be Simple PPP Account X and Simple PPP Session X. X is the PVC number from 1 to 7. It can support up to total of 16 PPP sessions, and each PVC can support up to 8 PPP sessions, the multiple PPP sessions may be configured with any combination over 8 PVCs.

Service Name: The service name of PPP is required by some ISPs. If the ISP does

not provide the Service Name, please leave it blank.

Username: Your user name provided by your ISP. Password: Your password provided bye your ISP. Disconnect Timeout: The Disconnect Timeout allows the user to set the specific

period of time to disconnect from the ISP. The default is 0, which means never disconnect from the ISP.

MRU: Maximum Receive Unit indicates the peer of PPP connection the maximum size

of the PPP information field this device can be received. The default value is 1492 and is used in the beginning of the PPP negotiation. In the normal negotiation, the peer will accept this MRU and will not send packet with information field larger than this value.

MTU: Maximum Transmission Unit indicates the network stack of any packet is larger

than this value will be fragmented before the transmission. During the PPP negotiation, the peer of the PPP connection will indicates its MRU and will be accepted. The actual MTU of the PPP connection will be set to the smaller one of MTU and the peer’s MRU. The default is value 1492.

MSS: Maximum Segment Size is the largest size of data that TCP will send in a single

IP packet. When a connection is established between a LAN client and a host in the WAN side, the LAN client and the WAN host will indicate their MSS during the TCP connection handshake. The default value is 1432.

Automatic Reconnect: When it is checked, it will maintain the PPP connection all the

time. If the ISP shut down the PPP connection, it will automatically reconnect PPP session.

DHCP: Use Table-1 to configure a valid setting for each PVC. Host Name: Required by some ISPs. If the ISP does not provided the Host name,
