Supports GDI printers
Combo Print Server
Shares Your GDI/Host-based Printers
This Combo Print Server can let you share the GDI printer to all PCs
through your network. GDI printers, built-in Windows Graphical Device
Interface (GDI), are sometimes called host-based printers because they
rely on the host computer (Win2000/XP/Vista) to rasterize pages to an
image format, not PostScript or PCL language. Therefore, almost none of
Print Servers in the market can support GDI printers. PS-1216U
implements a special technology which allows it to communicate with the
GDI printer as if it is connected directly to your computer. With the feature,
the GDI printer becomes a shared device easily.
Compatible with Multiple Popular Operating Systems
The Print Server supports GDI printer in the most popular operating
systems: Windows 2000 SP4 above, XP SP1 above and Vista.
Easy Installation and Configuration (with Web-Based Configuration)
PS-1216 easy-to-use Windows installation wizard allows quick installation
and setup. The print server can also be conveniently configured from any
network client with a web-browser.
Fault-Tolerant Firmware Upgrades
Users don’t have to worry about error s oc curring in the midst of an upgrade,
thus preventing the print server from operating. The print server's faultÂtolerant upgrade function resumes the upgrade should problems occur
during the initial upgrade.
PS-1216U
U.K.
Edimax Technology (UK) Ltd.
TEL: +44-845-1238307
FAX: +44-845-1238306
[email protected]
Poland
Edimax Technology Poland
SP. z o.o.
TEL: +48-22-6079-480
FAX: +48-22-6079-481
[email protected]
U.S.A.
Edimax Computer Company
TEL: +1-408-496-1105
FAX: +1-408-980-1530
[email protected]
Latin America
TEL: +1-786-845-8099
FAX: +1-786-331-8490
[email protected]
China
TEL: +86-10-6213-9288
FAX: +86-10-6213-9231
[email protected]
Russia
Edimax Technology Russia
Tel./Fax: +7-495-101-0239
[email protected]
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL: +886-2-7739-6888
FAX: +886-2-7739-6887
[email protected]
Europe
Edimax Technology Europe B.V.
TEL: +31-499-377344
FAX: +31-499-372647
[email protected]
Page 2
www.edimax.com
EDIMAX TECHNOLOGY CO., LTD.
Features
Complies with IEEE 802.3, IEEE 802.3u Wired Ethernet standards.
Provides one USB 2.0 port to connect to GDI printer.
Shares GDI printer to all PCs through Ethernet Network.
Supports TCP/IP network protocols.
Supports DHCP Server and Client protocols.
Supports Web-based management and Windows Configuration Utility.
Supports GDI printer in Windows 2000 SP4 above and Windows XP
SP1 above.
Supports Fault-Tolerant F/W upgrade
Specification
Model NO. PS-1216U
Flash 512KB NOR Flash
RAM 2MB SDRAM
USB Port USB 2.0 Type A x 1
LAN Port
10/100M UTP Port x 1
(Auto-MDI/MDI-X)
Power 7.5VDC, 0.5A Power Adapter
Dimension 20(H) x 58(W) x 75(D) mm
Temperature 0~55oC
Humidity 10~90% (Non-Condensing)
Certification FCC, CE, C-Tick
