IC-7000
Night Vision
Night Vision
Pan/Tilt IP Surveillance Camera
Pan/Tilt IP Surveillance Camera
Introduction
IC-7000 is an easy-to-use IP Camera for remote monitoring. Simply type the
IP address of the IC-7000 in the browser (Microsoft IE) address bar, and you
can watch remote streaming video with voice. The IC-7000 features motorized
pan and tilt features with maximum angles of +180°~ -35° (vertical) and ±175°
(horizontal). Users can conveniently control the camera remotely
through the Web interface.
Night Vision
With built-in IR (Infra Red) LED’s, the IC-7000 supports Night Vision. Users
are still able to view and record video clips in complete darkness. The IC-7000
can be applied to your warehouse, office and home for night time surveillance.
TV-OUT, SD Card
The built-in TV-out decoding/coding feature can display the monitored image
on a TV screen (NTSC or PAL TV). The camera also features an SD slot to
save snapshots of triggered events (motion detected) directly on the SD
memory card. It is a good backup when the Internet is disconnected and an
e-mail snapshot can not be sent.
TV-OUT , SD Card Slot
European Headquarters
Edimax Technology Europe B.V.
TEL: +31-499-377344
FAX: +31-499-372647
[email protected]
United Kingdom Office
Edimax Technology (UK) Ltd.
TEL: +44-845-1238307
FAX: +44-845-1238306
[email protected]
Germany Office
Edimax Technology Europe BV
TEL : +49-215488-2831
FAX : +49-215488-2834
e-mail : [email protected]
U.S.A. Office
Edimax Computer Company
TEL: +1-408-496-1105
FAX: +1-408-980-1530
[email protected]
Headquarters
Edimax Technology Co., LTD.
TEL: +886-2-7739-6888
FAX: +886-2-7739-6887
[email protected]
Poland Office
Edimax Technology Poland SP. Z o.o.
TEL: +48-22-6079-480
FAX: +48-22-6079-481
[email protected]
Romania Office
Edimax Technology Romania
TEL: +40-31-4250126
FAX: +40-31-4250125
[email protected]
Russia Office
Edimax Technology Russia
TEL: +7-495-921-0239
FAX: +7-495-921-0239
[email protected]
Latin America Office
Edimax Latin America Inc.
TEL: +1-786-845-8099
FAX: +1-786-331-8490
[email protected]
China Office
Beijing Edimax Science &
Technology Co., Ltd.
TEL: +86-10-8266-5815
FAX: +86-10-8266-5795
[email protected]
Page 2
www.edimax.com
EDIMAX TECHNOLOGY CO., LTD.
Key Features:
• Views real time video/audio via IE browser with max 640x480 screen
• Records the audio/video stream, "live" or on a predetermined schedule
• Supports video recording with different frame rates：1, 3, 5, 10 fps
• Supports Pan/Tilt with viewing angle +180°~-35° (vertical) and ±175°
(horizontal)
• Image Compression Format : M-JPEG
• Supports motion detection and snapshots the triggered event
• Motion-triggered image capture, image can be sent to FTP, E-Mail, SD
Card and PC
• Supports 4X digital zoom
• Supports Night Vision with built-in IR (Infra red) LED
• Supports virtual IP and port switch in IP DSALM
• Built-in TV Out connector to view video through TV set
•. Firmware Upgradeable
1 X RJ-45 UTP PortInternet interface
1 x TV OUT Output interface
SD Card SlotStorage interface
ResetButton
IC-7000 Model NO.
High touch 10φ-40db±3 Microphone
TCP/IP, SMTP, FTP, PPPoE, DHCP Protocol
0 ~ 45 ℃Operating Temperature
220gWeight
1 x LED for Status + 6 x IR LEDLED Indicators
95 x 94 x 121mmDimension
CE, FCCCertifications
DC5V , 2A Power
Specification：
