Internet Camera
User Manual
Version: Beta
Up-date: 2004/08/10
2
Contents
1. Introduction.......................................................................................................................3
2. Package Content..............................................................................................................3
3. System Requirement........................................................................................................3
4. Hardware Installation........................................................................................................4
4.1. LED and focus ring...........................................................................................4
4.2. Camera Ports....................................................................................................4
5. Using the Install Wizard....................................................................................................5
6. Using the camera viewer..................................................................................................9
6.1. Panel Introduction.............................................................................................9
6.1.1. Camera buttons ........................................................................................9
6.1.2. Camera Status..........................................................................................9
6.1.3. Change resolution.....................................................................................9
6.1.4. View 4 cameras simultaneously..............................................................10
6.1.5. Setting button..........................................................................................10
6.1.6. Playback .................................................................................................13
6.1.7. Control button .........................................................................................13
7. Using the Admin application...........................................................................................14
8. WEB Control...................................................................................................................16
9. Frequently Asked Questions...........................................................................................19
10. Technical Specifications..........................................................................................20
3
1. Introduction
Thank you for choosing the Internet Camera. This Camera sends live video through the Internet to a
web browser or camera viewer anywhere in the world! This compact, self-contained unit lets you keep
an eye on your home, your kids, and your workplace—whatever’s important to you.
How does the Camera do all of this? Unlike standard “web cams” that require an attached PC, the
Internet Camera can connect directly to a network. The Motion JPEG video compression produces a
high quality, high-frame rate, 320 x 240 video stream.
The included Viewer & Recorder utility lets you record the video stream to your local hard drive, “live” or
on a predetermined schedule.
Use the instructions in this Guide to help you integrate the Camera into your network. These
instructions should be all you need to get the most out of the Internet Camera.
2. Package Content
One Internet Camera
One Installation CD-ROM
One power adapter
One Camera Stand
One Category 5 Ethernet Cable
If any of the above items are missing, please contact your reseller.
3. System Requirement
Local Area Network: 10Base-T Ethernet or 100BaseTX Fast Ethernet
Recommended: PC, Mac or Notebook to access the Internet Camera
Web/Admin application/Camera viewer Configuration
• Windows XP, Me, 2000, 98SE
• CPU: Pentium III, 450MHz or above
• Memory Size: 128MB (256MB recommended)
• VGA card resolution: 800 x 600 or above
4
4. Hardware Installation
4.1. LED and focus ring
The Camera head and its focus ring allow you to modify the aim and focus of the Camera.
To adjust the Camera’s focus, rotate the dark focus ring.
LED
Monitoring: When someone is viewing the camera, the LED will light.
Ready: When the camera is power on and ready for access, the LED will light.
4.2. Camera Ports
The Camera features two ports and a Reset button.
Power: The Power port is where you will connect the power adapter.
LAN: The LAN port is where you will connect the Ethernet network cable.
Reset: The Reset button is what you will press if you need to reset the Camera. Insert a paper clip into
the hole. Then press the button and hold it in for five seconds.
Install the camera
1. Connect the Ethernet network cable to your router or switch.
2. Plug the power adapter into an electrical outlet.
Focus ring
LED
Green: Monitoring
Orange: Ready
5
Reset Button:
5. Using the Install Wizard
Follow the simple steps below to run the Install Wizard to guide you quickly through the Installation
process.
1. Power on your PC and insert the CD-ROM
2. The setup page should load automatically. If
it does not, please select your CD-ROM drive
manually to open the setup page.
1. Select “Install software and Configure
the Camera” to initiate the installation.
4. Follow the step to configure the first Internet Camera that you have.
6
4. Click Next to continue the installation.
5. If you wish to install the software program in
an alternate location, click change, otherwise
click next to move on to the next step.
6. Click Install to start the installation
Loading...
