EDIMAX GS-1005BE User guide [ml]

GS-1005BE
Schnellinstallationsanleitung
08-2020 / v1.0
Inhalt
I. Produktinformationen ............................................... 1
I-1. Verpackungsinhalt ...................................................................................... 2
I-2. Hardwareübersicht ..................................................................................... 2
I-3. LED-Status .................................................................................................. 3
II.Hardwareinstallation ................................................ 3
1
I. Produktinformationen
Der Edimax GS-1005BE mit fünf 2,5-Gigabit-Ethernet-Ports ist einfach einzurichten und erfordert keine Konfiguration oder Software. Außerdem, wenn Ihr Netzwerk über eine Mischung aus älteren und modernen Datenverarbeitungsfunktionen verfügt, ermöglicht jeder Port außerdem 100 Mbps Standard-Ethernet-, 1000 Mbps Fast Ethernet- oder 2,5G Gigabit Ethernet-Verbindungen. Dieser Switch sorgt für eine schnelle und zuverlässige Datenübertragung, die sich ideal für die Netzwerkkonnektivität in Privathaushalten, kleinen Büros, kleinen und mittleren Unternehmen und Unternehmensumgebungen eignet.
Alle unterstützenden Dokumente finden Sie über den folgenden Link oder den QR-Code:
https://www.edimax.com/download
(Geben Sie nach Ihrem Besuch der offiziellen Edimax-Website die
Modellnummer „GS-1005BE“ in das Suchfeld ein, um nach diesem Produkt zu
suchen.)
1
I-1. Verpackungsinhalt
Nr.
Beschreibung
1
LED (PWR, Link/ACT)
2
5 LAN-Ports
3
Netzbuchse
GS-1005BE
Netzadapter
(12V)
Schnellinstallations-
anleitung
1
1
2
3
Bevor Sie dieses Produkt benutzen, überprüfen Sie bitte, ob irgendetwas in der Verpackung fehlt, und wenden Sie sich an Ihren Händler, um fehlende Teile zu melden.
I-2. Hardwareübersicht
2
I-3. LED-Status
Funktion
Farbe
Status
Beschreibung
LINK/ACT
Grün/Gelb
An
Port ist verbunden
Aus
Port getrennt oder Verbindung
fehlgeschlagen
Blinkend
Senden oder Empfangen von
Daten.
PWR
Grün
An
Stromversorgung an
Aus
Strom aus
Hinweis: LNK/ACT,
- Grün = Verbindung mit 2,5G
- Gelb = Verbindung mit 100/1000M
II. Hardwareinstallation
Dieser Abschnitt führt Sie durch die Schritte zur Einrichtung des GS-1005BE.
1. Stecken Sie den Netzadapter in eine Wandsteckdose.
HINWEIS: Stellen Sie sicher, dass die „PWR”-LED Grün leuchtet.
2. Schließen Sie ein Ethernet-Kabel vom LAN-Port an den Router an.
HINWEIS: Stellen Sie sicher, dass die „LAN”-LED Grün oder Gelb leuchtet.
3. Schließen Sie ein Ethernet-Kabel vom LAN-Port an alle Geräte an,
die über einen Ethernet-Port verfügen.
3
