X100
Multimedia Speaker
User's Manual
Edifier Enterprises Canada Inc.
Made in China
1
Overview
Welcome !
Very thanks for choosing Edifier multimedia speaker,it can
provide good sound for multimedia computer and home theater.
Before operating the system, please read this manual thoroughly
and retain it for future reference.
Overview
1 Sub Woofer 2 Volume Control
3 Bass Adjusting Switch
5 Speaker Out Splint 6 Power Switch
7 Satellite Speakers (left and right) 8 User's Manual
Audio connecting cord
9
4 Line In Port
2
Operating
Operating
CONNECTING
1
Connect the satellite speakers to the output RCA on the
back panel of the Sub-woofer. Please note to match the color,
red to red and white to white.
Connect the subwoofer to the Audio device.
2
Using Audio connecting cord , connect the Line-input port
of the subwoofer to Line-out of the Audio Device (Such as the
computer, Discman, etc).
3 Playing the audio device
Plug the AC power plug into the wall outlet and turn on the
power switch, Now your speaker system is ready for Use.
Adjusting the volume control and Bass adjusting switch, then
you can enjoy the music.
SPECIFICATIONS
Total Power Output : RMS 2.5W x 2 + 5W(THD=10%)
Input Impedance: 10K Ohm
Input Sensitive: 450 mV
Bass Unit: 4" Aluminum coil, 4 Ohm
Tweeter Unit: " Paper coil, 4 Ohm
Dimension(Subwoofer): 191(W) x 183(H) x 222(D)mm
Dimension(Satellite): 83(W) x 108(H) x 80(D)mm
Gross Weight: About 3.1 Kg
2 3/4
Notice
Edifier assumes no responsibility for any errors that may appear
in this manual. Information contained herein is subject to change
without notice.
Copyright 2005
All Rights Reserved.
Manual Edition 1.2, Jun. 2005
Printed in CHINA
WARNING
To reduce the risk of electric shock ,Do not expose this apparatus
to rain or moisture.
Notice
Edifier and Edifier logo are owned by Edifier Enterprises Canada Inc.
and may be registered. And other brand names and trademarks are
the property of their owners.
