Edifier EDF50 User Manual

9HU

Bluetooth Stereo Headphones

W293BT



ᲗFeatures

Გ

Designed like an oxygen tank, the W293BT is machined into shell form by a precision based metal powder process geared for optimum performance

Გ

Supported by strong low-frequency output, this earphones is highly recommended for dynamic audio performance

Გ

CSR chip with Bluetooth V4.1 supports AAC and Qualcomm® aptX™ audio decoding

Გ

Dual batteries support up to 8 hours of continuous play

Გ

I IPX4 rating ensures water resistance at all times

Გ

Connects up to 10m in distance

Გ

Tilted in- ear design match multi-size earrings, silicone ear tips for comfortable wear

Გ

Wired controller easily enables voice calls, volume adjustment and song changes

Bluetooth version: Bluetooth V4.1

Bluetooth protocol: HFP᱃HSP᱃A2DP᱃AVRCP

Audio decoding: Qualcomm® aptX™ audio decoding Connecting distance: 10m Working time: 8h Charging time: 1.5h Standby time: About 300h Input: DC 5.0V 500mA Frequency response range: 20Hz-20KHz

Sound pressure level󰵪SPL󰵫: 105dB

,PSHGDQFH

Thank you for using the stereo Bluetooth headphone W293bt. Please carefully read this manual before using the product.

ᲗSpecification

ᲗFunction operational

ᲗBox contents:

micro USB charging

cable*1pcs

Headphone*1pcs

Storage bag*1pcs

Ear holder* 3 pairs

Wire clip*1pcs

User manual*1pcs

Warranty card*1pcs

Silicon ear tips*3 pairs

Volume increase/next track

Multi-function key

Volume decrease/previous track

ᲗOperation

Fully Charged

low battery level

᱃Charging

Before the first use or the battery is in low level, please complete charging firstly.

1. Plug the USB charging cable into a PC’s USB port.

2. Connect the charging cable to the headphone’s micro USB charging port.

Red light on = Charging Red light off = fully charge

Charging time: It takes about 1.5 hours to do a fully charge.

Tips:

1. When Blue light quickly flashes thrice and headphone emit prompt per 3 minutes, it shows the battery is in low level, and just can supports 30 minute use.

2. In order to avoid shortening the battery life, please charge the headphone at least per 3 months when the headphone is un-use for a long time.

Warning: The rechargeable batteries of the headphone must be properly disposed for recycling. Never dispose of batteries in fire to avoid explosion.

2᱃ON/OFF

3. Pairing

Indicator

Blue light flashes quickly

Red light flashes quickly

Function

OFF

Operation

Press and hold multi-function button for about 3 seconds

Indicator

Red/blue light flash alternately

Function

Enter into pairing mode

Operation

Press and hold multi-function key for about 5 seconds

Tips

1. Under pairing status, the headphone will return to standby dormant status after 2 minutes without connecting successfully, you can press any key to start the operation under standby status.

2. The headphone will automatically turn off after 15 minute without any operation.

3. When the headphone disconnect due to over the effective distance, it will automatically re-connect if the headphone enter the connecting distance in 5 minutes, and will automatically turn off over 15 minutes.

4. When the headphone is in low battery level, it will automatically enter dormant state, and it will automatically be awaked and re-connect the near and paire mobile phones after starting to charge.

1. Make the headphone enter into pairing mode according to the follow operation

2. Keep your mobile and the headphone within 1 meter distance. The closer, the better.

3. Enable Bluetooth function on your mobile and search for Bluetooth devices.

4. Select “EDIFIER W293BT’” to pair up and connect. When successfully connected, the blue light of the headphone flashes slowly. Tips: When under pairing process, please input “0000” when it needs pairing password. After complete pairing, the headphone will automatically connect the last connected device in the next time use.



Functions

Answer call

Reject call

Connecting with two devices

1. Pair the headphone with the first device.

2. Re-start the headphone and enter pair status. Press and hold the multi-function key for about 5 seconds to enter the pairing settings, and pair with the second device.

3. Select connecting with the headphone from the first device. Now the headphone is connected with the first and second devices.

4. Making call via headphone

1. Basic operations

Headphone status Incoming call

ringing Incoming call

ringing

Calling

Talking

Talking(muted)

Talking (headphone)

Talking (mobile phone)

Device connected and without call

Operation

Press multi-function key

Press and hold multi-function key for about 2 seconds

Press multi-function key

Press + key

Press - key

Press and hold – key for about 2 seconds

Press and hold + key for about 2 seconds

Press and hold multi-function key for about 2 seconds

Double press multi-function key

Cancel Call

End call

Increase volume

Decrease volume

Mute

Transfer call to mobile

Cancel mute

Transfer call

to headphone

Last number redial

Voice dial



2. Three party call operation

3. Connect call from two mobiles

Caution: Use for extended periods at high volume may affect your hearing capacity. Use product responsibly. Tips:

1. When the volume of the headphone is set to its maximum, you will hear prompt.

2. Voice dial function just be useful for the mobile phone that has voice function assistant (such as siri of iPhone), and for the android mobile phone, it needs under un-lock status for use.

3. Press +/- keys at the same time when without conversation to enable the voice assistant function, again press +/- keys at the same time to

disenable the voice assistant function.󰵽

Function

Answer new incoming call and end the current call

Answer new incoming call and put the current call on hold

Switch call

End the current call and switch to the on-hold call

Headphone status

Incoming the second call

Talking

Incoming the second call

Talking

Operation

Press multi

-function key

Double press multi-function key

Double click multi-function key

Press multi

-function key

Function Headphone status Operation

End the first mobile call and answer the second incoming call

Put the first mobile call on hold and answer the second incoming call

Switch call

End the current call and return to the on-hold mobile call

Talking while one call is on hold

Press multi

-function key

Double press multi-function key

Double click multi-function key

Press multi

-function key

Another call comes in when you are on the first call Another call comes in when you are on the first call

Talking while one call is on hold

Operation Press + key Press - key

Press multi-function key Press multi-function key

Function Increase volume Decrease volume Previous track Next track Pause Resume play

Headphone status Play music Play music Play music Play music Play music Pause to play music



5. Play music

ᲗMaintenance and repair

Please read the following suggestions. These suggestions will help you stay in

compliance with the warranty terms and prolong the product life.

Გ Keep the product dry and away from wet places to avoid moisture

getting into internal circuit. Do not use the product during intense exercise

or when you sweat too much.

Გ Do not place the product under directly the sunlight or near heat sources.

High temperature will shorten the electronic components’ life and

damage batteries and cause certain plastic parts deformation.

Გ Do not put the product in very cold places in order to prevent its internal

circuit board from being damaged.

Გ Do not dismantle the product. Non-technician may damage the product.

Გ Do not drop, violently vibrate or strike the product with hard items. It may

cause damage to the circuit.

Გ Do not use strong chemical products or detergent to clean the

headphone.

Გ Do not use any sharp items to scratch the product surface. It may

damage the housing surface.

Press and hold – key for about 2 seconds

Press and hold + key for about 2 seconds

IC Caution

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.

Le present appareil est conforme a ux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation estautorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectrique subi, mêmesi le brouillage est susceptible d'en compromettre le fonctionnement.

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authori ty to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.
