2700SX-HR
GALAXY PRO
PROFESSIONAL
17 GALLON CARPET EXTRACTOR
OWNER’S/OPERATOR’S MANUAL
2700IX-HR
PROUDLY DESIGNED AND MANUFACTURED BY
WWW.EDIC-USA.COM
Revised 1-26-18
TABLE OF CONTENTS
RECEIVING YOUR EQUIPMENT...................................................................................
WARNINGS AND SAFETY..............................................................................................
ELECTRICAL INFORMATION.......................................................................................
GROUNDING INSTRUCTIONS......................................................................................
MAINTENANCE................................................................................................................
CORD STORAGE AND SAFETY....................................................................................
2700SX-HR MACHINE OVERVIEW..............................................................................
ACCESSORY HEATER OVERVIEW...............................................................................
HOW TO USE AN ACCESSORY HEATER...................................................................
CLEANING CARPET.........................................................................................................
CLEANING UPHOLSTERY..............................................................................................
WIRING...............................................................................................................................
TROUBLESHOOTING.....................................................................................................
UPPER BREAKDOWN 2700SX-HR/ 2700IX-HR........................................................
LOWER BREAKDOWN 2700SX-HR..............................................................................
LOWER BREAKDOWN 2700IX-HR............................................................................
WARRANTY INFO............................................................................................................
NOTES.................................................................................................................................
3
3, 4
4
4
5
5
6
7
8
9
9
10
11
12, 13
14, 15
16, 17
18, 19
20
2
RECEIVING YOUR NEW 2700SX-HR OR
2700IX-HR: When your package is delivered, check
the carton carefully for signs of rough handling. If your
2700SX-HR/2700IX-HR is damaged, notify the carrier
immediately and request an inspection. Be sure to keep
the carton, packing inserts, packing lists and carrier’s
receipt until the inspector has veried your claim.
EDIC’s liability ceases when the carrier picks up the shipment. However, our customer service sta will be happy
to furnish any information needed in connection with
the claim and will attempt to expedite a resolution.
PLEASE READ BEFORE OPERATING YOUR
NEW 2700SX-HR/2700IX-HR:
Read the manual carefully and completely before attempting to operate the unit. is manual has important
information for the use and safe operation of the machine. Keep this manual handy at all times.
is equipment has been engineered and manufactured
to provide excellent performance and service. To ensure
that your equipment will continue to perform as intended:
• Maintain equipment regularly- following the suggested maintenance schedule provided.
• Use only original EDIC parts when servicing.
• Operate equipment with care.
If additional information is needed, please contact:
EDIC
800-338-3342
All information and specications printed in the manual are current at the time of printing; however because
of EDIC’s policy of continual product development, we
reserve the right to make changes at any time without
notice.
FAILURE TO COMPLY WITH THE FOL-
LOWING WARNINGS AND INSTRUCTIONS
WILL VOID THE WARRANTY.
WARNING!
• e machine was designed for use on carpet cleaning
applications as per instructions and recommendations written in this manual. Any deviation from its
proper use or purpose and the consequential damage
that may occur is the sole responsibility of the end
user.
• Disconnect the power cord from the outlet before
servicing. Do not leave machine connected to an electrical outlet when unattended.
• Do not immerse or use this machine in standing water. Such use may cause electric shock.
• When using an extension cord, use only a 3-prong
conductor grounding cord-12 gauge wire or heavier.
• To avoid electric shock, do not expose the unit to rain
or snow. Store it indoors in a heated location only.
• Do not use the machine for dry vacuuming.
• Use defoamer at all times to prevent damage to the
vacuum motor.
• Do not use water in excess of 130°F (54°C) in the
solution tank
• To prevent seal damage and chemical build-up to the
pump system, run clean water through the solution
lines aer each day’s use.
• Use only commercially available carpet cleaning solutions and defoamer intended for use with machines
of this type. Do not use dyes, bleaches, ammonia, or
other additives.
• e use of powdered cleaning solution, if not diluted
properly, may result in damage to the pump. Powdered chemical is not recommended. If powdered
chemicals are used, premix in a separate container
before placing in the solution tank.
• Always read and understand your chemical’s MSDS
(Material Safety Data Sheet) before use.
• is equipment is not designed to handle or use
combustible/volatile substances such as gasoline or
kerosene, in, on, or near the machine. e use of such
materials will cause extreme hazardous condition.
• Do not expose machine to freezing temperatures.
3
• All repairs must be done by an authorized
EDIC repair station.
• Do not use replacement parts other than original
EDIC parts.
• Do not allow your spray stream to remain in one
xed location as surface damage may occur.
• Check that all spray nozzles are securely fastened.
Loose nozzles could be ejected from equipment at
high speeds.
• is is not a toy. Keep away from children.
• Do not pull by the power or use power cord as a handle. Always unplug by grabbing the plug and pulling,
do not unplug by pulling the power cord.
• Inspect cord for damage. Do not use damaged cords.
Connect only to properly grounded outlets.
• Keep hair, ngers, loose clothing, and body parts
away from moving parts and openings.
• Turn o all controls before disconnecting machine
• Use caution with ejected liquid or chemicals. High
pressures and temperatures could be hazardous to
nearby people or surroundings.
• Do not run the heater dry. always make sure you have
water
• Do not expose heater to freezing temperatures.
• Prevent burns by wearing gloves or using a barrier to
remove hot quick disconnects.
• Never leave heater or equipment unattended when
connected or powered on.
• e accessory heater was designed for use on
2700SX-HR/2700IX-HR extractors for carpet, oor
and upholstery extraction applications. Any deviation
from its proper use or purpose and the consequential
damage that may occur is the sole responsibility of
the end user.
GROUNDING INSTRUCTIONS FOR
115VOLT:
is piece of equipment must be grounded. Should an
electrical malfunction occur, grounding provides a path
of least resistance for electrical current- reducing the risk
of electric shock. is piece of equipment is furnished
with a cord that has a grounding conductor and grounding plug. e grounded plug must only be plugged
into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
WARNING:
Connecting the equipment to an improperly grounded
outlet can result in an increased risk of electric shock. A
qualified electrician should be consulted if you are unsure
that the outlet is properly grounded. Do not modify the
plug provided with the equipment. If it will not fit the
outlet, have a proper outlet installed by a qualified electrician.
is appliance is designed for use on a 120-volt circuit.
e grounding plug provided looks like the plug illustrated in Figure 1. Replace the power cord if the grounding
pin is damaged or broken.
Extension cords connected to this machine should be
12 gauge, three-wire cords with three-prong plugs and
outlets. DO NOT use extension cords more than 25 feet
(7.6 m) long.
ELECTRICAL - 115 Volt
Model: 2700SX-HR/2700IX-HR
is machine is designed to operate on a standard 15
amp, 120 volt, 60 Hz, AC circuit. Voltages below 105 volt
AC or above 125 volts AC could cause serious damage to
the motor.
4
Figure 1
MAINTENANCE:
is 2700SX-HR/2700IX-HR has been engineered and
built to require minimum maintenance. But like any
machine, it does require basic care to keep it in optimum
working condition. Careful attention to these maintenance instructions will give you maximum operating
performance and life expectancy of the machine.
Wee kl y :
• Check and clean solution lter
• Check for obstructions in vacuum pathways
• Quarterly:
• Check pump, plumbing and ttings for leaks
• Check power cords and hoses for tears
CAUTION: Disconnect the power cord from the outlet
before doing any clean up or maintenance on the machine
1. Keep the machine clean. Do not allow dust to accumulate on external surfaces or near any moving parts.
2. Aer every job, wipe down the surface of the machine
with a clean damp cloth.
3. Inspect cord for damage. Do not use machine with a
damaged cord.
PERIODIC MAINTENANCE
• Use only chemicals safe for extractors
• Adhere to the appropriate mix ratios for all chemicals
• For optimal performance, it is suggested that the
operator ush the system aer every job or at the end
of the day.
• Pump seals and valves may need to be replaced at the
1000 hour mark if a loss in pressure is noted
Daily:
CORD STORAGE:
While not in use, storage can be accomplished by winding cord around handle assy. Cord should be
completely unwound during operation.
CORD SAFETY
• Do not leave appliance when plugged in. Unplug
from outlet when not in use and before servicing
• Do not use with damaged cord or plug. If appliance is
not working as it should, has been dropped, damaged,
le outdoors, or dropped into water, return to service
center for inspection and repair.
• Do not pull or carry by cord, use cord as handle, close
a door on cord, or pull cord around sharp edges or
corners. Do not run this 2700SX-HR/2700IX-HR
over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling cord. To unplug, grasp the
plug, not the cord.
• Do not handle plug or appliance with wet hands.
• is equipment should be stored indoors and not
exposed to rain.
1. Always keep the machine clean inside and out.
2. Pour 2 gallons of clean hot water in the solution
tank. Turn the pump on and ush the entire system
through the wand nozzles for about a minute to prevent alkaline build-up.
3. Remove dirt and lint build-up inside the lter screen
in the recovery tank. Lint should be cleaned o so
that air ow is not impeded.
4. Check the solution tank strainer in the solution tank.
If lint has accumulated in the screen, remove and
rinse it in clear running water.
5
2700SX-HR/ 2700IX-HR
OVERVIEW
1. Handle- Used to maneuver and position the 2700SXHR/2700IX-HR. Contains switch box (for switchbox,
see #12).
2. Recovery tank and lid- Tank collects recovered waste
water. Lid allows access to recovery tank and creates a
seal to ensure suction.
3. Solution tank and lid- Tank used to store clean water
or solution for your job. Lid allows access to the
solution tank and prevents external contamination of
solution tank.
4. Non-marking front 4” locking casters and rear 10”
wheels.
5. Recovery/vacuum hose inlet barb- connect your
recovery vacuum hose to this barb.
1
3
2
6. Male twist lock pigtail- Connects to 50 power cord.
One circuit per cord.
7. Solution line Q.D.- Pressurized connection for solution line.
8. Cool air intake for vacuum.
9. Recovery tank dump valve
10. Heater mounting brackets.
11. Switch box- Two switches marked “VACUUM” and
one switch marked “PUMP”.
11
5
10
6
7
4
9
8
6
ACCESSORY HEATER KIT 605HR/705HR
OVERVIEW
(PURCHASED SEPARATELY)
1. INLET QUICK DISCONNECT AND HOSE- Connects to machine’s outlet.
2. POWER SWITCH.
3. LAMP- Indicates when heat element is on and working.
4. TWIST LOCK PIG-TAIL- is connects to the
female twistlock plug on the rear of the 2700SXHR/2700IX-HR.
5. OUTLET QUICK DISCONNECT- Connects to
working solution line.
2
3
6. HANDLE- Used to hold and transport the heater
7. MOUNTING FEET- Used to engage the mounting
brackets on an 2700SX-HR/2700IX-HR extractor
and secure the heater.
8. RESET ACCESS POINT- Allows access to the breaker switch in the event the unit has been run dry.
4
5
7
6
1
8
6
7
HOW TO USE AN ACCESSORY HEATER:
1. Fill the solution tank of your 2700SX-HR/2700IXHR extractor with sucient water or solution for the
task at hand. Do not use water over 130 degrees F.
2. Mount the Heater by lining up the two mounting
legs (See #7 on page 8) to the two mounting brackets on the rear of the machine (#11 on pages 6&7).
3. Connect your heater’s inlet hose (#1 on page 8) to the
machine’s outlet quick disconnect (#7 on pages 6&7).
4. Connect your 25 solution hose
to the heater’s Q.D. (#5 on page 8)
5. Connect your 50FT power cord to the twist
lock pigtail on the heater (#4 on page 8). Plug
the 50 power cord(s) to the twist lock pigtail
on the back of the machine (#6 on pages 6&7)
6. Connect the power cord(s) to the machine and an
approved 15 amp outlet. If your machine is a 2700IXHR, each of the two cords must be on a separate 15
am circuit.
7. Connect your 25 vacuum hose to the extractor’s
vacuum inlet barb (#5 on pages 6&7)
8. Connect your vacuum and solution line to a carpet
wand or upholstery attachment.
9. COMPLETE THIS STEP BEFORE TURNING
HEATER ON: Turn the pump switch to the “ON”
position using the pump switch on the handle of
your 2700SX-HR/2700IX-HR. Pressing the solution
valve trigger of your attachment, spray water for 1015 seconds until you have a steady ow. is ensures
the heater is lled with uid.
10. Turn heater on using the power switch (#2 on page
8) and allow up to 3 minutes for the unit to heat up.
11. e heater is ready for use once the green lamp (#3
on page 8) shuts o. Once you start cleaning, the
green lamp will turn on and o throughout your job
as the thermostats automatically regulate the temperature.
8
CLEANING CARPET:
1. Using a dedicated dry vacuum, pre-vacuum the space
to be cleaned to remove as much dirt as possible. Do
not use the extractor to dry vacuum as it does not
have a dry lter.
2. Pre-spray the carpet
3. See steps 1-11 in section “How to use an accessory
heater”
4. Make sure the drain valve (#10 on page 6) is closed by
pushing the T-handle all the way in.
5. Always use de-foamer- Previously shampooed carpets
usually have a heavy build-up of old shampoo residue
which can cause the vacuum system to ingest foam
and result in damage to the vacuum motor.
6. With the vacuum and pump switches in the “ON”
position, slowly pull the tool towards you with the
solution valve trigger pressed. Make a dry pass forward and backward over the cleaned area to recover
residual dirt and solution.
7. Do not overwet carpet! Make overlapping passes to
prevent streaking.
8. If the carpet is heavily soiled, squeeze solution valve
trigger on the forward pass as well as backwards,
allowing cleaning solution a few seconds longer to
work prior to vacuuming. Another method is to raise
the wand 8” above the carpet and pre-spray lightly
prior to cleaning passes. On extremely soiled carpets,
we recommend using a pre-spray solution.
9. When you are close to running out of solution, turn
o the pump and the heater. Attach the drain elbow
on the drain valve. Place a pail under the downspout
and pull up the drain valve T-handle. Dirty solution
will pour out until the tank is empty. Close the drain
valve. Use a clean bucket when you rell the solution
tank so you do not create contamination.
10. When the job is completed, turn the switches o,
including the heater, and disconnect the vacuum and
solution hoses from the carpet tool and the machine.
Drain the recovery tank through the drain valve as
before.
CLEANING UPHOLSTERY:
Cleaning upholstery with success requires a good knowledge of the type of fabric to be worked on. Look for the
cleaning instruction label sewn on the underside of the
furniture for the recommended method of cleaning the
fabric. If it calls for dry cleaning, do not attempt to clean
with the wet extraction method. Otherwise, damage to
the fabric could occur. Extraction works perfectly on
most synthetic fabrics including synthetic velvets.
Before proceeding, test the fabric for colourfastness.
Apply a small amount of ready-to-use cleaning solution
on the fabric in an inconspicuous spot. Wait for 2 to 3
minutes and rub the area with a white terry cloth towel.
If no color comes o the towel, the fabric should be safe
to clean. If a little color comes o, there is some risk of
colors running when you clean. It may be possible to
stabilise colors by cleaning with an acidic rinse.
1. Using a dedicated dry vacuum, pre-vacuum the space
to be cleaned to remove as much dirt as possible. Do
not use the extractor to dry vacuum as it does not
have a dry lter.
2. See steps 1-11 in section “How to use an accessory
heater”
3. Make sure the drain valve (#10 on page 6) is closed by
pushing the T-handle all the way in.
4. Attach an upholstery tool to the hose set.
5. Always use de-foamer. Previously cleaned upholstery
may have a heavy build-up of old shampoo residue
which can cause the vacuum system to ingest foam
and result in damage to the vacuum motor.
6. With the vacuum and pump switches in the “ON” position, slowly pull the tool backward with the solution
valve trigger pressed. Make a dry pass forward and
backward over the cleaned area to recover residual
dirt and solution.
7. Clean using as little solution as possible. Do not
overwet the upholstery! Make overlapping passes to
prevent streaking.
8. On heavily soiled areas like arm rests, pre-treat with a
recommended pre-spray and /or hold the upholstery
tool a few inches above the fabric and press lever to
spray on the solution before making a pass.
9
FOR THE FOLLOWING GALAXY AND
GALAXY PRO MODELS: SX, SX-HR, IX-HR, JX-HR,
MOTOR HOUSING
HANDLE
WHITE
BLACK
BLACK
WHITE
WIRING DIAGRAM
10
TROUBLESHOOTING
ELECTRICAL SYSTEM
PROBLEM SOLUTION
NO ELECTRICAL POWER 1. Defective power cord.
2. House or building circuit breaker tripped
POWER IS INTERMITTENT TO ONE OR ALL MOTORS
VACUUM SYSTEM
PROBLEM SOLUTION
NO VACUUM SUCTION 1. Drain Valve open.
LOW VACUUM SUCTION 1. Accumulated dirt on intake lter screen.
1. Faulty electrical cable.
2. Defective switches.
3. Loose terminal or discolored terminal connections.
2. Vacuum lid is not sealed against tank.
3. Loose vacuum hose, vacuum connection
2. Worn out vacuum lid gasket.
3. Lint & dirt build-up on wand head.
4. Defective vacuum hose.
5. Loose connection in the vacuum motor.
SOLUTION SYSTEM
PROBLEM SOLUTION
PUMP MOTOR RUNS BUT NO SPRAY THROUGH
SPRAY TIPS
UNEVEN OR WEAK SPRAY FOR SPRAY TIPS 1. Clogged or dirty spray tips.
ERRATIC PRESSURE 1. Pump check valves defective or dirty
1. Clogged spray tips.
2. Clogged solution intake lter screen.
3. Clogged female quick disconnect coupler.
4. Quick disconnects not fully connected
5. Dirty or damaged pump head valves.
6. Defective pump check valve.
7. Crack in pump housing.
8. Lost Prime.
2. Accumulated dirt on solution intake lter screen.
3. Accumulation of debris inside pump and plumbing.
4. Worn pump bearing (excessive noise).
5. Punctured pump diaphragm.
6. Defective rectier or motor.
7. Worn nozzles.
8. Priming valve is open. Close Pressure relief/priming
valve
2. Lost prime.
11
43
6
7
8
9
10
11
1
2
12 13 14 15 16 17 18 19
20
21
22
23
24
25
26
27
28
2930
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
2700SX-HR/ 2700IX-HR
Upper
1/26/2018
5B
5D
5A
5
5C
A
B
C
D
53
ITEM
NO.
1
F11787-1 Solution Tank, Galaxy Pro
2
F11788-1 Recovery Tank, Galaxy Pro
3
F11791-1 Lid, Sol Tank, Galaxy Pro
4
E11836 Gasket, Recovery Tank
5
12904A Stand Pipe Assembly
K11965 Elbow, 180 Deg. Float Ball
K00672 Pvc Pipe, 1.5 X 12 in, Sch 40 Wht
10989-2A Float Ball Screen
K00741 Adapter
6
F11785-1 Lid, Recovery Tank
7
C11167 Bolt, 1-4 X 20
8
K02714 Plug, .500
9
B11769 Extension Cord, 12-3 SJTW
10
C11177 Velcro Strap
11
H02548-2 Label, Important, Cord
12
B00185-30 Wires, 73 in
13
B00185-40 Wires, 73 in
14
B010314 Wire Harness
15
F11786-1 Handle
16
B00177 Terminal Lug, Female, QD, .25 X .032, 16-14 AWG, Fully Insulated
17
B00185-40 Wire,14 GA Black, UL1015, 5 in
18
C00295-1 #10 X .75in Pan, Black SMS, Phillips
19
C00293 #8 X .5in Pan, Black SMS, Phillips
20
D11168 Cover, Switchplate, Galaxy
21
B02211-1 Switch, Rocker, Green Light
22
D010284 Switchplate
23
E010453 Gasket, Switch Bracket
24
B00177-1 Terminal Lug, Female, QD, .25 X .032
25
B00185-30 Wire,14 GA White, UL1015, 5 in
26
C02315 Lockwasher, #10 Int. Str, SS
27
C00264 Nut, 10-32
28
C00288-1 .25-20 X 2.25 Flat Head
29
C00288 .25-20 X 1.5 Flat Head
30
K00666 90 Elbow, SCH D 40, 1.5 in
31
K00665-1 Hose Adapter, 1.5in, Black
32
C00313 Hex Bolt, .25 X 20 X .75
33
C02312 Lockwasher, .25 in., Internal Star
34
C00314-1 Hex Bolt, 1-4 X 20 X 1in
35
C00233 Washer, Flat, .25 in
36
D010283 Plate, Heater Mounting
37
F11804 Heater Mount
38
C00261 Nut, .25-20, Hex
39
K00710 Elbow, Drain Valve, Black
40
K00711 Drain Valve, Black
41
E11128 Gasket, Drain Valve
42
C12110 Hex Bolt, .375-16 X 1.75
43
C11540 Washer, .375 ID X .875 OD
44
K11185 Elbow, 90, 1.5 in, MT-MS, PVC
45
K00672-1 Pvc Pipe, 1.5 X 2.25 in, Sch 40 Wht
46
A00060 3-8 Barb X 1-4MP, Brass
47
A00052 .25 X .375 M-F 90 deg Brass
48
C11244 Washer, .56 X 1.5 X .05
49
A00124 Hex Nut, .25 NPT Brass
50
D00373 Inlet Filter, .25 NPT
51
C11144 Screw, .25-20 X 2, SS
12
2700SX-HR/ 2700IX-HR
53
C00238 Washer, .275 in, Neosteel
2
Upper
ITEM
NO.
1
F11787-1 Solution Tank, Galaxy Pro
F11788-1 Recovery Tank, Galaxy Pro
2
3
F11791-1 Lid, Sol Tank, Galaxy Pro
E11836 Gasket, Recovery Tank
4
5
12904A Stand Pipe Assembly
A
K11965 Elbow, 180 Deg. Float Ball
B
K00672 Pvc Pipe, 1.5 X 12 in, Sch 40 Wht
10989-2A Float Ball Screen
C
K00741 Adapter
D
6
F11785-1 Lid, Recovery Tank
C11167 Bolt, 1-4 X 20
7
8
K02714 Plug, .500
9
B11769 Extension Cord, 12-3 SJTW
10
C11177 Velcro Strap
11
H02548-2 Label, Important, Cord
12
B00185-30 Wires, 73 in
13
B00185-40 Wires, 73 in
14
B010314 Wire Harness
15
F11786-1 Handle
16
B00177 Terminal Lug, Female, QD, .25 X .032, 16-14 AWG, Fully Insulated
17
B00185-40 Wire,14 GA Black, UL1015, 5 in
18
C00295-1 #10 X .75in Pan, Black SMS, Phillips
19
C00293 #8 X .5in Pan, Black SMS, Phillips
20
D11168 Cover, Switchplate, Galaxy
21
B02211-1 Switch, Rocker, Green Light
22
D010284 Switchplate
23
E010453 Gasket, Switch Bracket
24
B00177-1 Terminal Lug, Female, QD, .25 X .032
25
B00185-30 Wire,14 GA White, UL1015, 5 in
26
C02315 Lockwasher, #10 Int. Str, SS
27
C00264 Nut, 10-32
28
C00288-1 .25-20 X 2.25 Flat Head
29
C00288 .25-20 X 1.5 Flat Head
30
K00666 90 Elbow, SCH D 40, 1.5 in
31
K00665-1 Hose Adapter, 1.5in, Black
32
C00313 Hex Bolt, .25 X 20 X .75
33
C02312 Lockwasher, .25 in., Internal Star
34
C00314-1 Hex Bolt, 1-4 X 20 X 1in
35
C00233 Washer, Flat, .25 in
36
D010283 Plate, Heater Mounting
37
F11804 Heater Mount
38
C00261 Nut, .25-20, Hex
39
K00710 Elbow, Drain Valve, Black
40
K00711 Drain Valve, Black
41
E11128 Gasket, Drain Valve
42
C12110 Hex Bolt, .375-16 X 1.75
43
C11540 Washer, .375 ID X .875 OD
44
K11185 Elbow, 90, 1.5 in, MT-MS, PVC
45
K00672-1 Pvc Pipe, 1.5 X 2.25 in, Sch 40 Wht
46
A00060 3-8 Barb X 1-4MP, Brass
47
A00052 .25 X .375 M-F 90 deg Brass
48
C11244 Washer, .56 X 1.5 X .05
49
A00124 Hex Nut, .25 NPT Brass
50
D00373 Inlet Filter, .25 NPT
51
C11144 Screw, .25-20 X 2, SS
52
S11179 Non-Skid Tape, 1 in. Roll
PART NUMBER
3-25-08
DESCRIPTION
QTY.
1
1
1
1
1
1
1
1
1
1
6
4
1
1
1
1
1
1
1
2
1
2
2
1
3
1
1
4
1
2
1
4
4
1
1
2
2
4
6
1
1
2
1
1
1
2
2
1
1
1
1
1
1
1
2
1
13
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
1
C00297 SCREW, #8 X .25 IN, PAN
34 A00061 3-8 BARB X 1-4 FP, BRASS
2 J11863 HOSE, 3 IN
35
H02564-2 LABEL, CAUTION, MOTOR
3 J00639 SCREW CLAMP, 1.63-2.43 IN
36
C11165 SCREW, #8 X 1 IN PAN,
BLACK
4
J00618 VACUUM HOSE, 2 IN GRAY,
WIRE, 22 IN LG
37
F11790 HEATER, TUNNEL COVER,
5 F11178-BLK INTERCOOLER, BLACK
1
38
B11779 STUB, 12-3 SJTW YELLOW
1
6
C00273 LOCKNUT, 1-4 X 20,
NYLON, SS
39
C00293 #8 X .5 IN PAN, BLACK
7 C00233 WASHER, FLAT, .25 IN
26
40
B00192 MOUNT, NYLON TIE
1
8 E00449 GROMMET
6
41
B11606 STRAIN RELIEF, PIGTAIL
1
9
C00284 SCREW, 10-32 X .375
GROUND
42
1
10 B11150 GROUND WIRE
2
43
H03545 COVER, SERIAL # LABEL
1
11
G00537 VACUUM MOTOR, 82 IN,
44
12 J00657 HOSE CLAMP, 2IN SLDPRT
1
45
C02305 CAP NUT, 5 IN PUSH ON
2
13
J00618 VACUUM HOSE, 2 IN,
GRAY, WIRE, 4 IN LG
46
C00240 WASHER, SHOULDER,
14 C00254 LOCK WASHER, 1-4 IN SPLIT
1
47
2
15 C00261 NUT, 25-20 HEX
10
48
1
16
1
49
1
17
C11189 SCREW, 1-4 X 20 X 4.5 IN
50
18
C11516 SCREW, 1-4 X 20 X 4.5 IN,
51
19
C02312 LOCKWASHER, .25 IN,
52
J00613B SOLUTION HOSE, .375 IN,
20
G11314-3 PRESSURE REGULATOR,
53
J11508 SCREW CLAMP #6, 7-16 TO
21 A00060 3-8 BARB X 1-4MP, BRASS
54
A00054 ELBOW, .90, .375 MP X
22 A00052 .25 X .375 M-F 90º BRASS
3
55
B00191 NYLON TIE, 11 IN, BLACK
4
23 A00616 TEE, .25 FP, BRASS
1
56
B00190 NYLON TIE, 4 IN
13
24 A00111 NIPPLE, .25 IN
2
57
G13761 PUMP, 100PSI , 115 V
1
25
A00121 FITTING, .25 MP X .25 FP,
BR ASS
58
1
26 C11244 WASHER, .5 ID X 1.5 OD
2
59
J00613B SOLUTION HOSE, .375 X 26
27 A00104 QD, 1-4 M X 1-4 FP, BRASS
1
60
J11154 SOLUTION HOSE, .375 X 10
28 A00097 CAP, INLINE FILTER
61
A11243 TEE, .375B X .375B X .375B,
29
A00094 CHECKVALVE, NO
62
J11154 SOLUTION HOSE, .375 X 10
30 A00094 CHECK VALVE BODY
63
J00618 VACUUM HOSE, 2 IN.
31
C02322 HEX BOLT, 1-4 X 20 X 1.75
IN
64
32 D01037 HEATER MOUNTING PLATE
65
33
C11440 SPACER, HEATER
MOUNTING PLATE
66
2 3 4 6 7 8
9
11
12
13
15
16
272625242220 21
22
28
34
3738
55
39
40
454647
46
4849
50
7
51
52
54
56
57 58 59
62
54
6
17
7
63
64
65
66
32
33
42
41
7
15
31
60
61
23
53
2700SX-HR Base
1-26-18
36
1
14
19
18
29
43
44
55
6
35
30
5
10
14
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
1
C00297 SCREW, #8 X .25 IN, PAN
HE AD
34 A00061 3-8 BARB X 1-4 FP, BRASS
1
2 J11863 HOSE, 3 IN
1
35
H02564-2 LABEL, CAUTION, MOTOR
HOUSING
3 J00639 SCREW CLAMP, 1.63-2.43 IN
3
36
C11165 SCREW, #8 X 1 IN PAN,
BLACK
4
J00618 VACUUM HOSE, 2 IN GRAY,
WIRE, 22 IN LG
37
F11790 HEATER, TUNNEL COVER,
5 F11178-BLK INTERCOOLER, BLACK
1
38
B11779 STUB, 12-3 SJTW YELLOW
1
6
C00273 LOCKNUT, 1-4 X 20,
NYLON, SS
39
C00293 #8 X .5 IN PAN, BLACK
7 C00233 WASHER, FLAT, .25 IN
26
40
B00192 MOUNT, NYLON TIE
1
8 E00449 GROMMET
6
41
B11606 STRAIN RELIEF, PIGTAIL
1
9
C00284 SCREW, 10-32 X .375
GROUND
42
1
10 B11150 GROUND WIRE
2
43
H03545 COVER, SERIAL # LABEL
1
11
G00537 VACUUM MOTOR, 82 IN,
44
12 J00657 HOSE CLAMP, 2IN SLDPRT
1
45
C02305 CAP NUT, 5 IN PUSH ON
2
13
J00618 VACUUM HOSE, 2 IN,
GRAY, WIRE, 4 IN LG
46
C00240 WASHER, SHOULDER,
14 C00254 LOCK WASHER, 1-4 IN SPLIT
1
47
2
15 C00261 NUT, 25-20 HEX
10
48
1
16
1
49
1
17
C11189 SCREW, 1-4 X 20 X 4.5 IN
HEX
50
18
C11516 SCREW, 1-4 X 20 X 4.5 IN,
51
19
C02312 LOCKWASHER, .25 IN,
52
J00613B SOLUTION HOSE, .375 IN,
20
G11314-3 PRESSURE REGULATOR,
53
J11508 SCREW CLAMP #6, 7-16 TO
21 A00060 3-8 BARB X 1-4MP, BRASS
54
A00054 ELBOW, .90, .375 MP X
22 A00052 .25 X .375 M-F 90º BRASS
3
55
B00191 NYLON TIE, 11 IN, BLACK
4
23 A00616 TEE, .25 FP, BRASS
1
56
B00190 NYLON TIE, 4 IN
13
24 A00111 NIPPLE, .25 IN
2
57
G13761 PUMP, 100PSI , 115 V
1
25
A00121 FITTING, .25 MP X .25 FP,
BR ASS
58
1
26 C11244 WASHER, .5 ID X 1.5 OD
2
59
J00613B SOLUTION HOSE, .375 X 26
27 A00104 QD, 1-4 M X 1-4 FP, BRASS
1
60
J11154 SOLUTION HOSE, .375 X 10
28 A00097 CAP, INLINE FILTER
61
A11243 TEE, .375B X .375B X .375B,
29
A00094 CHECKVALVE, NO
62
J11154 SOLUTION HOSE, .375 X 10
30 A00094 CHECK VALVE BODY
63
J00618 VACUUM HOSE, 2 IN.
31
C02322 HEX BOLT, 1-4 X 20 X 1.75
64
32 D01037 HEATER MOUNTING PLATE
65
33
C11440 SPACER, HEATER
66
2700SX-HR Base 1-26-18
1
1
4
115V
D11134 VAC PLATE
FLAT HEAD, PHILIPS
INTERNAL STAR
16
1
2
2
1
5
1
1
BLUE GRANITE
SMS, PHILIPS
K10510 PLUG, 1.25 IN, BLACK
H00565-5 LABEL, SERIAL NUMBER
NYLON
G11767 WHEEL, 10 IN
D1AXLE
F11789BASE
C00314-1 HEX BOLT, 1-4 X 20 X 1 IN
G03518-L LOCKING CASTER, 4 IN
BLACK
1
2
1
4
8
2
1
BR ASS
STRAINER
IN
1
1
1
1
1
1
4
1
15
7-8 IN
.375B, NYLON
' PUMP PLATE
IN, BLACK
IN, WIRE REINFORCED
NYLON
IN, WIRE REINFORCED
GRAY, WIRE, 7 IN LG
E11169 GASKET, VAC MOTOR
B00179-2 CLOSED END CNTR, 16-3
8
2
1
1
1
1
2
2
1
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
1
C00297 SCREW, #8 X .25 IN, PAN
HE AD
34 A00061 3-8 BARB X 1-4 FP, BRASS
1
2 J11863 HOSE, 3 IN
1
35
H02564-2 LABEL, CAUTION, MOTOR
HOUSING
3 J00639 SCREW CLAMP, 1.63-2.43 IN
3
36
C11165 SCREW, #8 X 1 IN PAN,
BLACK
4
J00618 VACUUM HOSE, 2 IN GRAY,
WIRE, 22 IN LG
37
F11790 HEATER, TUNNEL COVER,
5 F11178-BLK INTERCOOLER, BLACK
1
38
B11779 STUB, 12-3 SJTW YELLOW
1
6
C00273 LOCKNUT, 1-4 X 20,
NYLON, SS
39
C00293 #8 X .5 IN PAN, BLACK
7 C00233 WASHER, FLAT, .25 IN
26
40
B00192 MOUNT, NYLON TIE
1
8 E00449 GROMMET
6
41
B11606 STRAIN RELIEF, PIGTAIL
1
9
C00284 SCREW, 10-32 X .375
GROUND
42
1
10 B11150 GROUND WIRE
2
43
H03545 COVER, SERIAL # LABEL
1
11
G11394 VACUUM MOTOR, 82 IN,
44
12 J00657 HOSE CLAMP, 2IN SLDPRT
1
45
C02305 CAP NUT, 5 IN PUSH ON
2
13
J00618 VACUUM HOSE, 2 IN,
GRAY, WIRE, 4 IN LG
46
C00240 WASHER, SHOULDER,
14 C00254 LOCK WASHER, 1-4 IN SPLIT
1
47
2
15 C00261 NUT, 25-20 HEX
10
48
1
16
1
49
1
17
C11189 SCREW, 1-4 X 20 X 4.5 IN
HEX
50
8
18
C11516 SCREW, 1-4 X 20 X 4.5 IN,
FLAT HEAD, PHILIPS
51
2
19
C02312 LOCKWASHER, .25 IN,
52
J00613B SOLUTION HOSE, .375 IN,
20
G11314-3 PRESSURE REGULATOR,
53
J11508 SCREW CLAMP #6, 7-16 TO
21 A00060 3-8 BARB X 1-4MP, BRASS
54
A00054 ELBOW, .90, .375 MP X
22 A00052 .25 X .375 M-F 90º BRASS
3
55
B00191 NYLON TIE, 11 IN, BLACK
4
23 A00616 TEE, .25 FP, BRASS
1
56
B00190 NYLON TIE, 4 IN
13
24 A00111 NIPPLE, .25 IN
2
57
G13639 PUMP, 220PSI , 115 V
1
25
A00121 FITTING, .25 MP X .25 FP,
BR ASS
58
1
26 C11244 WASHER, .5 ID X 1.5 OD
2
59
J00613B SOLUTION HOSE, .375 X 26
27 A00104 QD, 1-4 M X 1-4 FP, BRASS
1
60
J11154 SOLUTION HOSE, .375 X 10
28 A00097 CAP, INLINE FILTER
61
A11243 TEE, .375B X .375B X .375B,
29
A00094 CHECKVALVE, NO
62
J11154 SOLUTION HOSE, .375 X 10
30 A00094 CHECK VALVE BODY
63
J00618 VACUUM HOSE, 2 IN.
31
C02322 HEX BOLT, 1-4 X 20 X 1.75
IN
64
32 D01037 HEATER MOUNTING PLATE
65
33
C11440 SPACER, HEATER
MOUNTING PLATE
66
66
2 3 4 6 7 8
1
5
9
10
11
56
65
64
63
62
6
54
6
57 58 59
12
13
14
15
16
7
23
272625242220 21
19
28
29
61
60
17
18
22
30
35
34
32
33
31
7
15
55
54
41
42
53
52
51
50
7
4849
2700IX-HR Base
16
55
39
40
43
44
46
1-26-18
36
3738
454647
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
1
C00297 SCREW, #8 X .25 IN, PAN
HE AD
34 A00061 3-8 BARB X 1-4 FP, BRASS
1
2 J11863 HOSE, 3 IN
1
35
H02564-2 LABEL, CAUTION, MOTOR
HOUSING
3 J00639 SCREW CLAMP, 1.63-2.43 IN
3
36
C11165 SCREW, #8 X 1 IN PAN,
BLACK
4
J00618 VACUUM HOSE, 2 IN GRAY,
WIRE, 22 IN LG
37
F11790 HEATER, TUNNEL COVER,
5 F11178-BLK INTERCOOLER, BLACK
1
38
B11779 STUB, 12-3 SJTW YELLOW
1
6
C00273 LOCKNUT, 1-4 X 20,
NYLON, SS
39
C00293 #8 X .5 IN PAN, BLACK
7 C00233 WASHER, FLAT, .25 IN
26
40
B00192 MOUNT, NYLON TIE
1
8 E00449 GROMMET
6
41
B11606 STRAIN RELIEF, PIGTAIL
1
9
C00284 SCREW, 10-32 X .375
GROUND
42
1
10 B11150 GROUND WIRE
2
43
H03545 COVER, SERIAL # LABEL
1
11
G11394 VACUUM MOTOR, 82 IN,
44
12 J00657 HOSE CLAMP, 2IN SLDPRT
1
45
C02305 CAP NUT, 5 IN PUSH ON
2
13
J00618 VACUUM HOSE, 2 IN,
GRAY, WIRE, 4 IN LG
46
C00240 WASHER, SHOULDER,
14 C00254 LOCK WASHER, 1-4 IN SPLIT
1
47
2
15 C00261 NUT, 25-20 HEX
10
48
1
16
1
49
1
17
C11189 SCREW, 1-4 X 20 X 4.5 IN
HEX
50
18
C11516 SCREW, 1-4 X 20 X 4.5 IN,
51
19
C02312 LOCKWASHER, .25 IN,
52
J00613B SOLUTION HOSE, .375 IN,
20
G11314-3 PRESSURE REGULATOR,
53
J11508 SCREW CLAMP #6, 7-16 TO
21 A00060 3-8 BARB X 1-4MP, BRASS
54
A00054 ELBOW, .90, .375 MP X
22 A00052 .25 X .375 M-F 90º BRASS
3
55
B00191 NYLON TIE, 11 IN, BLACK
4
23 A00616 TEE, .25 FP, BRASS
1
56
B00190 NYLON TIE, 4 IN
13
24 A00111 NIPPLE, .25 IN
2
57
G13639 PUMP, 220PSI , 115 V
1
25
A00121 FITTING, .25 MP X .25 FP,
BR ASS
58
1
26 C11244 WASHER, .5 ID X 1.5 OD
2
59
J00613B SOLUTION HOSE, .375 X 26
27 A00104 QD, 1-4 M X 1-4 FP, BRASS
1
60
J11154 SOLUTION HOSE, .375 X 10
28 A00097 CAP, INLINE FILTER
61
A11243 TEE, .375B X .375B X .375B,
29
A00094 CHECKVALVE, NO
62
J11154 SOLUTION HOSE, .375 X 10
30 A00094 CHECK VALVE BODY
63
J00618 VACUUM HOSE, 2 IN.
31
C02322 HEX BOLT, 1-4 X 20 X 1.75
64
32 D01037 HEATER MOUNTING PLATE
65
2700IX-HR Base 1-26-18
1
1
4
115V
D11134 VAC PLATE
FLAT HEAD, PHILIPS
INTERNAL STAR
16
1
2
2
1
5
1
1
BLUE GRANITE
SMS, PHILIPS
K10510 PLUG, 1.25 IN, BLACK
H00565-5 LABEL, SERIAL NUMBER
NYLON
G11767 WHEEL, 10 IN
D AXLE
F11789 BASE
C00314-1 HEX BOLT, 1-4 X 20 X 1 IN
G03518-L LOCKING CASTER, 4 IN
BLACK
1
2
1
4
8
2
1
BR ASS
STRAINER
IN
1
1
1
1
1
1
4
1
17
7-8 IN
.375B, NYLON
' PUMP PLATE
IN, BLACK
IN, WIRE REINFORCED
NYLON
IN, WIRE REINFORCED
GRAY, WIRE, 7 IN LG
E11169 GASKET, VAC MOTOR
B00179-2 CLOSED END CNTR, 16-3
8
2
1
1
1
1
2
2
1
Quality Above All
The following Limited 5-year Warranty is given by EDIC with respect to the following specific
EDIC products:
Polaris
Saturn High Speed
Aviator
Supernova
Saturn Low Speed
Galaxy Pro
Aqua Dri
2 Years Parts & Labor
TORO HD Orbital
TORO Orbital
FloodBuster
Extractors
1725-TES has a 4-year
1725-TPT has a 2-year
Warranty Registration:
To register your product warranty, visit our website at:
www.edic-usa.com/warranty-registration/
EDIC STANDARD LIMITED WARRANTY PLAN FOR MACHINES MANUFACTURED AFTER 2/14/2017
Galaxy 5
Endeavor
Heat N Run
The following Warranty is given by EDIC with respect to the following specific EDIC products:
Dynamo Vacuums
Pilot Autoscrubber
Galaxy Automotive
LIFETIME on rotationally molded polyethylene tanks, stainless steel heater tank and Saturn stainless steel
brush covers.
5 YEARS on service labor, and all other parts not covered by the Lifetime terms.
2 YEARS on service labor, and all other parts not covered by the Lifetime terms.
Fivestar
Galaxy
Bravo
parts warranty and a
2-year labor warranty
Saturn Dual Speed
Saturn HD Low Speed
Atlas
parts warranty and a
1-year labor warranty
CR2 Restroom Cleaner
EDIC REPLACEMENT PARTS LIMITED WARRANTY PLAN
All parts sold as replacement parts for out-of-warranty EDIC products have the following Limited Warranty,
with no warranty on labor: 30 DAYS
Your product is warranted to be free of defects in material and workmanship for the period set forth above,
after the date of delivery to the retail purchaser, when operated in normal service and used in accordance
with the operating and maintenance instructions in the Owner’s Manual. This warranty is limited to and
provides at no cost to the retail purchaser repair or replacement of parts determined to be defective, at EDIC’s
option, and labor, if provided for above, to replace or repair the parts (“service labor”) according to EDIC’s
Standard Rates, during the warranty period set forth above. This warranty excludes transportation charges
unless authorized in writing by EDIC. No warranty returns for refund or credit will be permitted. In the event of
a defect, these are your exclusive remedies. Warranty claims must be made in writing to EDIC prior to
returning the product and no products will be accepted for repair or replacement without prior authorization
by EDIC. Use of parts not approved by EDIC in EDIC products will void this warranty. Warranty repair or
replacement shall not extend the original warranty period of the product, and replacement parts used for in-
1753 Blake Ave., Los Angeles, CA 90031 | 800.338.3342 | www.edic-usa.com
18
Quality Above All
warranty repairs will only be warranted for the remainder of the original warranty and not from their
installation date. Any parts or product replaced under this Limited Warranty will become the property of EDIC.
EXCEPTIONS AND EXCLUSIONS FROM THE WARRANTY. This Limited Warranty only covers product issues
caused by defects in material or workmanship during normal service. It does not cover product issues from
any other cause, including but not limited to (a) transportation damages; (b) alteration by unauthorized
persons; (c) unauthorized use, unreasonable use, misuse, or abuse (including the use of incompatible or
corrosive chemicals or overloading of capacity); (d) failure caused by lack of proper maintenance and cleaning;
(e) normal wear on items such as cords, belts, hoses, switches, bumpers, gaskets, seals, carbon brushes,
squeegees, harnesses, valves, cams, extraction brushes, bearings, handle grips, filters and finishes; (f) acts of
God; or (g) modification of or any part of the product. This Limited Warranty does not cover EDIC products
sold AS IS and WITH ALL FAULTS. This Limited Warranty is valid only in the United States and Canada.
We suggest that you complete and return the enclosed product registration card promptly to facilitate
verification of the date of the original purchase. However, return of the product registration card does not
eliminate the need for the retail purchaser to maintain the original proof of the purchase in order to obtain
the warranty benefits. In the event that you do not have proof of purchase date, the purchase date for
purposes of this warranty will be the date of manufacture.
For specific information on how to obtain warranty services for your product, please write to:
EDIC/Warranty Department
1753 Blake Ave.
Los Angeles, CA 90031
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE OF THIS STATEMENT.
THERE IS NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY USE ON THESE GOODS.
NO IMPLIED WARRANTY, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, APPLIES TO THE PRODUCT AFTER THE APPLICABLE PERIOD OF THE EXPRESS LIMITED
WARRANTY STATED ABOVE, AND NO OTHER EXPRESS WARRANTY, EXCEPT AS MENTIONED ABOVE, GIVEN
BY ANY PERSON OR ENTITY WITH RESPECT TO THE PRODUCT SHALL BIND EDIC. EDIC SHALL NOT BE LIABLE
FOR ANY FORM OF ACTION FOR ANY DAMAGES, WHETHER DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL,
OR INDIRECT, TO PROPERTY OR PERSON, INCLUDING BUT NOT LIMITED TO, DAMAGE OR LOSS OF INCOME,
LOSS OF PRODUCTION, OR LOSS OF PROFITS DUE TO MALFUNCTIONING OF ANY PRODUCT, REGARDLESS OF
THE LEGAL THEORY ON WHICH THE CLAIM IS BASED. IN NO EVENT SHALL RECOVERY OF ANY KIND AGAINST
EDIC BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY EDIC, AND CAUSING
THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, YOU ASSUME ALL THE RISK AND LIABILITY
FOR LOSS, DAMAGE OR INJURY TO YOU AND YOUR PROPERTY AND TO OTHERS AND THEIR PROPERTY
ARISING OUT OF USE OR MISUSE OF, OR INABILITY TO USE, THE PRODUCT NOT CAUSED DIRECTLY BY
NEGLIGENCE OF EDIC. THIS LIMITED WARRANTY STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or allow
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This Limited Warranty gives you specific legal rights and you may have other rights which vary from state to
state (or province).
0900.002/9989
1753 Blake Ave., Los Angeles, CA 90031 | 800.338.3342 | www.edic-usa.com
19
NOTES
_________________
20
Loading...
