Edge10 C190 User Manual

Advanced Display Systems

LCD Display

CHANNEL

Menu:

1.Introduction

Product Description .....................Page.1

Package Contents.........................Page.1

Product Features.......................... Page.1

Cleaning......................................Page.2

Precautions..................................Page.2

2.Control Function

OSD Button .................................Page.4

OSD Control................................Page.6

HOT Control................................Page.7

3.Inputs Diagram

Inputs..........................................Page.8

4.Display Angle....................................Page.10

5.Product Specification.........................Page.12

6.Display Modes...................................Page.13

7.Service Information............................Page.14

Introduction

Product Description

Congratulations on your purchasing this new generation of monitor.
Your LCD monitor incorporates high quality display into a small light
weighted module. It has power-saving capabilities and emits no X-ray
radiation. You will certainly benefit from this monitor in lots of way to
name some of them, comfort safety and environmental protection.

This LCD monitor incorporates 19" color active matrix thin-film­transistor (TFT) liquid crystal display to provide superior display per­formance. A maximum resolution of SXGA 1280X1024 is ideal for
designs that enhance this LCD monitor’s performance are Plug & play
compatibility, audio system and OSD (On Screen Display) controls.

Package Contents

Included with your LCD monitor are following items:

19" TFT LCD monitor
15pin D-sub signal cable
AC power cable

,

User s m anual
Sound Card Cable
Warranty Card

Product Features

High contrast color TFT LCD display support resolution up to SXGA

1280X1024

Compatible with IBM VGA, VESA, and Macintosh standards.

Embedded audio system provides sound performance.

AV-IN and S-video use.

AUDIO, and PC line in sound application.

1

Cleaning

Gently wipe the screen with a clean camel hair lens brush, or a soft, clean,
lint-free cloth.
This removes dust and other particles that can scratch the screen,
Do not apply pressure to the screen surface when wiping it clean.
Do not pour or spray any liquid directly onto the screen or case of the
LCD monitor.
Chemical cleaners have been reported to damage the screen or the LCD
monitor.

Read all these instructions and save them for later use.
Follow all warning and instructions on the product.

Product
Do not block the vent holes in the case.
Do not insert sharp objects or spill liquid into the LCD monitor through

cabinet slots.
It may cause accidental fire, electric shock or failure.
Disconnect the power plug from the AC outlet if you
for an indefinite period of time.
Do not attempt to service this product yourself, as opening or removing
covers may expose you to dangerous voltage points or other risks.
Do not touch the screen directly with your fingers. You may damage

the screen, and the oil from your skin is difficult to remove.
Do not apply pressure to screen. The LCD is very delicate.

Power
Use the type of power indicated on the marking label.

Plugs

,

Do not remove any of the prongs of the monitor s three-pronged power

plug.
Disconnect the power plug from the AC outlet under following
conditions:
If you for an indefinite period time.
When the power cord or plug is damaged or frayed.
If the product does not operate normally when the operating instructions
are followed.

Precautions

2

are not using it

are not using it

If the product has been dropped or the cabinet has been damaged.
If the product exhibits a distinct change in performance, indicating a
need for service.

Power and extension cords
Do not allow anything to rest on the power cord.
Do not locate this product where persons will walk on the cord.
Use the proper power cord with correct attachment plug type. If the
power source is 120V AC, use a power cord that has UL and C-UL
approvals. If the power source is a 240V AC supply, use the tandem
(T blade) type attachment plug with ground conductor power cord that

,

meets the respective European country s safety regulations, such as
VDE for Germany.
.

Do not overload wall outlets or power cords. Ensure that the total of all
units plugged into the wall outlet does not exceed 10 amperes.
Ensure that the total ampere ratings on all units plugged into the

,

extension cord is not above the cord s rating.
If the power supply cord, which came with your monitor, is to be
connected to the PC instead of the wall outlet, this equipment is to be
used with UL/TUV approved computers with receptacle rated
100~240V AC,50/60Hz,1.0A(minimum).
Environment
Place the monitor on a flat and level surface.
Place the monitor in a well-ventilated place.
Keep the monitor away from:
Overly hot, cold or humid places, places directly under sunlight, dusty
surroundings, equipment that generate strong magnetic fields.

3

Control Function

Control Button Front View

1. PowerLED: This power LED indicates different status
when this unit operates in different modes.

2. Power switch: pressing this button turns the display
system power on or off.

3. Increase: This button is used to increase the value of
the selected OSD control option or the volume when in
audio mode.

4

CHANNEL
