INSTALLATION INSTRUCTIONS
Valve Spring Seat Kit
For Edelbrock SB Chevy, SB Ford,
SB Chrysler, Pontiac and Olds Performer,
Performer RPM, and E-tec Cylinder Heads
Catalog #5769
• Please study these instructions carefully before installing your valve spring seat kit. If you have any
questions or problems, please call our Technical Hotline at: 1-800-416-8628, 7:00 am – 5:00 pm,
Pacific Standard Time, Monday through Friday or e-mail us at edelbrock@edelbrock.com.
Kit Contents
16 – Spring Seat/Cup
• DESCRIPTION: The 5769 valve spring seat/cup kit is a replacement parts kit intended for Edelbrock
Small Block Chevy Performer, Performer RPM, and E-tec cylinder heads; Small Block Ford
Performer and Performer RPM cylinder heads; SB Chrysler Performer RPM cylinder heads; Pontiac
Performer RPM; and Olds Performer RPM cylinder heads. The 5779 kit is designed for use with the
#5767 valve springs that are standard in complete cylinder heads Part #s 60179, 60229, 60259,
602519, 60269, 60279, 60289, 60299, 60329, 60359, 60379, 60399, 60519, 60579, 60599, 60719,
607119, 60739, 607319, 60759, 60779, 60859, 60879, 60899, 608919, 60909, 60979, 60989, and
60999. The spring seat/cup has a register for the O.D. of the valve spring that has a 1.470” dia. and
the cup O.D. is 1.62”. The spring seat register I.D. is .565” and the thickness is .060”.
INSTALLATION NOTES
1) If this spring cup kit is used on cylinder heads manufactured prior to the introduction of
spring cups, machining to enlarge the diameter of the spring pockets will be required to
install these valve spring seat cups. A minimum valve spring counterbore diameter of
1.65” will be required.
2) The valve spring cups require the removal of the valve stem seals to be installed. We
recommend replacing the old valve seals with new valve seals. New valve seals should be
installed with engine oil applied to valve stem sealing area of the seal.
3) Valve spring installed height should be checked before the final installation of the valve spring
cups. If the installed height of the valve spring needs to be decreased a valve spring shim may
be installed between the spring cup and the cylinder head.
• PLEASE complete and mail your warranty card. Be sure to write the model number of this product
in the “Part #_______” space.
THANK YOU.
Edelbrock Corporation • 2700 California Street • Torrance • California 90503
©
2002 Edelbrock Corporation Rev. 2/02
Brochure No. 63-0069
