©2003 Edelbrock Corporation Rev. 4/03
EDELBROCK ADJUSTABLE PANHARD ROD
for 1982-2002 Camaro & Firebird
Catalog #5222
INSTALLATION INSTRUCTIONS
Please study these instructions carefully before installing your new Panhard Rod. If you have any questions or problems,
please contact our Technical Hotline at: 1-800-416-8628, 7:00 am to 5:00 pm, Monday through Friday, Pacific
Standard Time or e-mail us at edelbrock@edelbrock.com. Please fill out and mail your warranty card.
Application: Designed for 1982-2002 Camaro and Firebird to re-center the rear axle after changing the ride height.
Suggested Tools for Installation:
❑ Jack and proper load rated jackstands
❑ 18mm and 21mm combination wrenches
❑ 18mm and 21mm 1/2” drive sockets and ratchets
❑ Large screw driver
1. Raise vehicle and support with jackstands on a stable surface.
Note: Vehicle must be supported with vehicle’s normal weight on rear axle.
2. Remove bolts at each end of the stock panhard rod and remove stock panhard rod. Inspect hardware, and
replace, if needed.
3. Clean hardware and panhard rod mounting brackets.
4. Install the Edelbrock panhard rod using the stock hardware. Use one drop of blue locktite on clean bolt threads
and torque to 50 ft.lbs.
Note: Your new adjustable panhard rod is to be installed with the adjuster sleeve on the driver’s side of the
vehicle.
5. Edelbrock panhard rod are greased during assembly, but it is a good idea to grease the bushings after installation
and during normal service.
6. Your new adjustable panhard rod comes adjusted to stock length. To adjust, simply loosen the two jam nuts and
turn the adjuster sleeve until the rear-end is centered. To check, measure from the tire sidewall to the fender lip.
Both sides should be the same.
Kit Contents
Qty
. Part # Description
1 25-4064 Panhard Rod Assembly
INSTALLATION INSTRUCTIONS
Edelbrock Corporation
2700 California Street
Torrance, CA 90503
Toll-Free Tech Line: 1-800-416-8628
Office: 310-781-2222
Tech E-Mail: edelbrock@edelbrock.com
®
