EDCO BB14E User Manual

Operator’s Instruction Manual

BB14G

E-BB14E&BB14G-I-0714

E-SPTS-I-0809

EQUIPMENT DEVELOPMENT CO., INC.

Masonry Saws

BB14E

Shown with Optional Pro Cart

GASOLINE AND ELECTRIC 14” MASONRY SAWS

EQUIPMENT DEVELOPMENT CO., INC.

Shown with Optional Stand

100 Thomas Johnson Drive, Frederick, MD 21702-4600 USA

Phone: [phone] • 301-663-1600

Fax: [phone] • 301-663-1607

edcoinc.com • [e-mail]

E-BB14E&BB14G-I-0714

EQUIPMENT DEVELOPMENT CO., INC.

READ AND UNDERSTAND THE OPERATORS INSTRUCTION MANUAL THOROUGHLY

BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.

Death or serious injury could occur if this machine is used improperly.

SAFETY
MESSAGES

• Safety Instructions are proceeded by a graphic alert symbol
of DANGER, WARNING, or CAUTION.

GASOLINE/PROPANE POWERED EQUIPMENT

• Gasoline is extremely fl ammable and poisonous.
It should only be dispensed in well ventilated areas,
and with a cool engine.

• Small gasoline engines produce high concentra

tions of carbon monoxide (CO) example: a 5 HP 4
cycle engine operation in an enclosed 100,000 cu. ft. area
with only one change of air per hour is capable of providing
deadly concenrations of CO in less than fi fteen minutes.
Five
changes of air in the same area will produce noxious fumes
in less than 30 minutes. Gasoline or propane powered quip­ ment should not be used in enclosed or partially enclosed
areas. Symptoms of CO poisoning include, headache,
nausea, weakness, dizziness, visual problems and loss of
conscious ness. If symptoms occur get into fresh air and
seek medical attention immediately.

• Check all electrical cables - be sure connections are tight and

cable is continuous and in good condition. Be sure cable is

correctly rated for both the operating current and voltage of

this equipment.

• Improper connection of the equipment-grounding conductor can

result in a risk of electric shock. Check with qualifi ed electri-
cian or service person if there is any doubt as to whether the
outlet is properly grounded. Adhere to all local codes and

ordinances.

• NOTE: In the event of a malfunction or breakdown, grounding

provides a path of least resistance for the electric current to

dissipate. The motor is equipped with a grounded plug and

must be connected to an outlet that is properly installed and

properly grounded. DO NOT modify the plug provided on the

motor. If the plug does not fi t the outlet have a qualifi ed elec-

trician install the proper receptacle.

• Switch motor OFF before disconnecting power.

ELECTRICAL POWERED EQUIPMENT

Extreme care must be taken when operating electric
models with water present: Ensure power cord is prop­erly grounded, is attached to a Ground-Fault-Interrupter
(GFI) outlet, and is undamaged.

SAFETY MESSAGES

Indicates an imminent hazard which, if not
avoided, will result in death or serious injury.

Indicates an imminent hazard which, if not avoid­ed, can result in death or serious injury.

Indicates hazards which, if not avoided, could
result in serious injury and or damage to the
equipment.

• Engine exhaust from this product contains
chemicals known to the State of California to
cause cancer, birth defects or other reproductive
harm.

• Do not disconnect power by pulling cord. To disconnect, grasp
the plug, not the cord.

• Unplug power cord at the machine when not in use and before
servicing.

GENERAL INSTRUCTIONS

• Equipment should only be operated by trained personnel in

good physical condition and mental health (not fatigued). The
operator and maintenance personnel must be physically able
to handle the bulk weight and power of this equipment.

• This is a one person tool. Maintain a safe operating distance
to other personnel. It is the operators’ responsibility to keep
other people (workers, pedestrians, bystanders, etc.) away
during operation. Block off the work area in all directions with
roping, safety netting, etc. for a safe distance. Failure to do so
may result in others being injured by fl ying debris or exposing
them to harmful dust and noise.

• This equipment is intended for commercial use only.

• For the operator’s safety and the safety of others, always keep

all guards in place during operation.

• Never let equipment run unattended.

• Personal Protection Equipment and proper safety attire must
be worn when operating this machinery. The operator must
wear approved safety equipment appropriate for the job such
as hard hat and safety shoes when conditions require. Hear­ing protection MUST be used (operational noise levels of this
equipment may exceed 85dBA). Eye protection MUST be worn
at all times.

Keep body parts and loose clothing away from moving
parts. Failure to do so could result in dismemberment
or death.

• Do not modify the machine.

• Stop motor/engine when adjusting or servicing this equipment.

Maintain a safe operating distance from fl ammable
materials. Sparks from the cutting-action of this machine
can ignite fl ammable materials or vapors.

DUST WARNING

Some dust created by power sanding, sawing,
grinding, drilling, and other construction activi­ties contains chemicals known to cause cancer,
birth defects, or other reproductive harm. Some
examples of these chemicals are:

• Lead from lead-based paints, and

• Crystalline silica from bricks and concrete and other

masonry products.
Your risk of exposure to these chemicals varies depending

on how often you do this type of work. To reduce your risk:
work in a well ventilated area, use a dust control system, such
as an industrial-style vacuum, and wear approved personal
safety equipment, such as a dust/particle respirator designed
to fi lter out microscopic particles.

Page 2

800-638-3326 • edcoinc.com • [e-mail]

E-BB14E&BB14G-I-0714

EQUIPMENT DEVELOPMENT CO., INC.

Table of Contents

Section Page Number

Operator Controls ................................................................................................................... 4-5

Safety Guidelines. ..................................................................................................................... 6

Operating Instructions .......................................................................................................... 7-11

Maintenance ....................................................................................................................... 12-14

Maintenance Schedule ............................................................................................................ 15

SMI Dust and Silica Warning ................................................................................................... 18

Limited Equipment Warranty ................................................................................................... 19

E-SPTS-I-0809

BB14G

Height

Length

Width

Both models shown with optional stands

HOW TO ORDER REPAIR PARTS

To insure product safety and reliability, always
use genuine EDCO replacement parts when
making repairs to the equipment.

When ordering parts, please specify the MOD­EL and SERIAL NUMBER of the machine as
given on the NAMEPLATE. In addition, give
part number, description and quantity as listed
in the parts list.

Please note: Due to improvements and
changes in the equipment the illustrations
shown may be different from the actual ma­chine.

Toll Free: Voice 1-800-638-3326

Fax [phone]

Figure 1

Model

Height

Width

Length

Weight

BB14E

Width

Length

Height

Specifi cations and dimensions are approximate

and subject to change.

BB14E

31.5”

80cm

25”

63.5cm

42 1/4”

107.8cm

165 lbs

74.8kg

BB14G

37”

94cm

25”

63.5cm

43”

109cm

175 lbs

79.4kg

800-638-3326 • edcoinc.com • [e-mail]

Page 3

E-BB14E&BB14G-I-0714

EQUIPMENT DEVELOPMENT CO., INC.

Operator Controls - Gas Models

BB14 Gas (Figure 2)

A Air Filter
B. Fuel Tank
C. On/Off Switch
D. Water Pump Belt Guard
E. Oil Dip Stick
F. Handle
G. Blade Guard
H. Water Tray Plug
I. Rolling Table
J. Angle Cutting Stop
K. Welded Steel Frame/Water Tray
L. Drive Belt Guard
M. Cutting Head Lock
N. Engine Throttle
O. Recoil Starter
P. Optional Pro Cart

B CDE

A

O

N

L

M

K

P

Figure 2

F

G

H

J

I

Page 4

Do not operate gasoline powered equipment

without adequate ventilation.

Carbon monoxide is an invisible,

odorless gas that can kill.

Figure 3

800-638-3326 • edcoinc.com • [e-mail]

G L

M

E-BB14E&BB14G-I-0714

E-SPTS-I-0809

J

EQUIPMENT DEVELOPMENT CO., INC.

Operator Controls- Electric Models

I

A

K

J

C

B

D

N

E

H

F

BB14 Electric (Figure 4)

A. Operating Handle
B. Motor
C. Reset Button
D. Power Cord
E. Water Pick Up Hose
F. Water Tray Plug
G. Rolling Table
H. Welded Steel Frame/Water Tray
I. Blade Guard
J. Drive Belt Guard
K. Blade Guard Lock
L. Cutting Angle Lock
M. Optional Folding Table
N. Submersible Water Pump

Figure 4

Electric motor must be properly grounded

at all times.

Figure 5

800-638-3326 • edcoinc.com • [e-mail]

Page 5

E-BB14E&BB14G-I-0714

EQUIPMENT DEVELOPMENT CO., INC.

Read and understand this Operator’s Instruction Manual,

and the Engine Manufacturer’s Owner’s Manual

before operating this equipment.

Death of serious injury can result if this machine is used improperly.

Safety Guidelines

Eye and ear protection must be worn at all times while the saw is in use. During normal operation, sound
pressure levels exceed 85dBA. Use only ANSI approved safety glasses to help prevent eye injury. Standard
eyeglasses have only impact resistant lenses; they are NOT safety glasses.

Operator must wear appropriate clothing and footwear. Do not wear loose clothing or jewelry that can
get tangled in moving parts. Footwear should provide sure footing and protection from debris that may be
dropped. Take steps to insure hair will not be caught in moving parts. If necessary, tie it back.

• When loading or unloading the saw, use caution. Make sure rolling table is locked so that the blade will not

be damaged. Do not move the saw while the engine is running.

• Never exceed the maximum operating speed of the blade. Match the blade speed rating with the arbor shaft
speed. (See page 11)

• Never leave the saw running unattended.

• Never operate this saw under the infl uence of drugs, alcohol or when taking medications that impair the senses or
reactions, or when excessively tired or under stress.

• Do not lend or rent this equipment without including the Operator’s Instruction Manual and the Engine Manufac­ turer’s Manual.

• Make sure all safety decals can be clearly read and understood. Replace damaged or missing decals immeditely.

For Electric Models:

• Electric motor must be properly grounded at all times. Check the outlet box to be sure the electrical service is
properly grounded and that adequate power is available. Insuffi cient power will cause motor to overheat and burn
out. Use only grounded extension cords correctly sized for the current draw and voltage drop (amp rating and
length). Never use frayed, damaged, taped or under rated extension cords. Electrical shock could result in death
or serious injury and damage to the equipment.

For Gasoline Models:

• Poisonous exhaust gas. Do not operate gasoline powered equipment without adequate ventilation. Carbon
monoxide is an invisible, odorless gas that can kill. NEVER REFUEL AN ENGINE WHILE IT IS HOT OR AN
ENGINE WHILE IT IS RUNNING. Only refuel in a well-ventilated area and only refuel after the engine has cooled
completely. Thoroughly cleanup any spilled fuel before starting the engine.

Dry cutting creates a large volume of airborne dust. For health reasons, the operator should wear an
applicable respirator. The dust may contain chemicals known to cause serious illnesses, including

Silicosis - a fatal disease of the lungs. Check the chemical properties of the material to be cut and

follow all EPA/OSHA regulations.

Safety warnings and guidelines do not by themselves eliminate danger.

They are not substitutes for proper accident prevention procedures and good judgement.

Page 6
